Samsung AM KNTD Series User manual

Airconditioner
Usermanual
AM∗∗∗KNTD∗∗ / AM∗∗∗KNQD∗∗
ꞏThank you for purchasing this Samsung air conditioner.
ꞏBefore operating this unit, please read this user manual carefully and retain it forfuture reference.
DB68-06428A-00
IB_EN_DB68-06428A.indd 1 9/19/2016 2:12:55 PM

2English
Contents
Safety Information 4
Safety Information 4
At a Glance 12
Indoor Unit Overview 12
Display
Remote Control Overview 13
Replacing batteries
Storing the remote control
Basic Operation 15
Operation Modes 15
Auto
Cool
Dry
Fan
Heat
Turning the air conditioner on
Selecting the operation mode
Adjusting the temperature
Selecting the fan speed
Selecting air flow direction
Advanced Operation 19
Setting the On or Off timer 19
Using the good’sleep Function 21
Using the Turbo Function 23
Controlling Indoor Units 24
IB_EN_DB68-06428A.indd 2 9/19/2016 2:12:56 PM

3
English
Cleaning and Maintenance 25
Cleaning the Air Conditioner 25
Cleaning the exterior
Disassembling the air filter
Cleaning the air filter
Reassembling the air filter
Maintaining the Air Conditioner 27
Appendix 29
Troubleshooting 29
Operation Ranges 31
Technical specification 32
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household waste at the end of theirworking life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please separate these items from othertypes of
waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact eitherthe retailer where they purchased this product, or their local government office, for
details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and
its electronic accessories should not be mixed with other commercial wastes for disposal.
IB_EN_DB68-06428A.indd 3 9/19/2016 2:12:56 PM

4English
Safety Information
Safety Information
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance.
Because the following operating instructions covervarious models,
the characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact centre or find help and information online at www.samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Follow directions. Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut off the power supply. Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the powerspecifications of the product or
higherand use the power line forthis appliance only. In addition, do
not use an extension line.
• Extending the power line may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or
fire.
• If the voltage/frequency/rated current condition is different, it may
cause fire.
Safety Information
IB_EN_DB68-06428A.indd 4 9/19/2016 2:12:56 PM

5
English
Safety Information
The installation of this appliance must be performed by a qualified
technician orservice company.
• Failing to do so may result in electric shock, fire, explosion, problems
with the product, or injury and may also void warranty on the installed
product.
Install an Isolation Switch next to the AirConditioner(but not on the
panels of the Air Conditioner) and circuit breaker dedicated to the air
conditioner.
• Failing to do so may result in electric shock orfire.
Fix the outdoorunit firmly so that the electric part of the outdoor
unit is not exposed.
• Failing to do so may result in electric shock, fire, explosion, or
problems with the product.
Do not install this appliance neara heater, orinflammable material. Do
not install this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water(rain drops). Do not install this
appliance in a location where gas may leak.
• This may result in electric shock orfire.
Neverinstall the outdoorunit in a location such as on a high external
wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or property
damage.
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic waterpipe, ortelephone line.
• Failure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
• Make sure to use a socket-outlet with ground.
Safety Information
IB_EN_DB68-06428A.indd 5 9/19/2016 2:12:56 PM

6English
Safety Information
CAUTION
Please coverthe airconditionerwith PE BAG afterinstallation, and
remove it when you start to run airconditioner.
Install yourappliance on a level and hard floorthat can support its
weight.
• Failing to do so may result in abnormal vibrations, noise, or problems
with the product.
Install the drain hose properly so that waterdrains correctly.
• Failing to do so may result in water overflowing and property damage.
Avoid adding drain to waste pipes as odours may arise in the future.
When installing the outdoorunit, make sure to connect the drain
hose so that draining is performed correctly.
• The water generated during the heating operation in the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury,
death or property damage.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service
centre.
Do not pull orexcessively bend the powerline. Do not twist ortie the
powerline. Do not hook the powerline overa metal object, place
a heavy object on the powerline, insert the powerline between
objects, orpush the powerline into the space behind the appliance.
• This may result in electric shock orfire.
Safety Information
IB_EN_DB68-06428A.indd 6 9/19/2016 2:12:57 PM

7
English
Safety Information
CAUTION
When not using the airconditionerfora long period of time orduring
a thunder/lightning storm, cut the powerat the circuit breaker.
• Failing to do so may result in electric shock orfire.
FOR USING
WARNING
If the appliance is flooded, please contact yournearest service
centre.
• Failing to do so may result in electric shock orfire.
If the appliance generates a strange noise, a burning smell or
smoke, cut off the powersupply immediately and contact the
nearest service centre.
• Failing to do so may result in electric shock orfire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the powerline. Do not
touch the appliance or powerline.
• Do not use a ventilating fan.
• A spark may result in an explosion orfire.
To reinstall the airconditioner, please contact yournearest service
centre.
• Failing to do so may result in problems with the product, water
leakage, electric shock, or fire.
• Delivery service forthe product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
• Especially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to
salt in the air, please contact your nearest service centre.
IB_EN_DB68-06428A.indd 7 9/19/2016 2:12:57 PM

8English
Safety Information
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the airconditioneroff with the circuit breakerwhile it is
operating.
• Turning the air conditioner off and then on again with the circuit
breaker may cause a spark and result in electric shock or fire.
Afterunpacking the air conditioner, keep all packaging materials
well out of the reach of children, as packaging materials can be
dangerous to children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the front panel with yourhands or fingers during the
heating operation.
• This may result in electric shock or burns.
Do not insert yourfingers or foreign substances into the airinlet/
outlet of the air conditioner.
• Take special care that children do not injure themselves by inserting
their fingers into the product.
Do not strike or pull the airconditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoorunit that allows children to
climb onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditionerforlong periods of time in badly
ventilated locations ornear infirm people.
• Since this may be dangerous due to a lack of oxygen, open a window
at least once an hour.
Safety Information
IB_EN_DB68-06428A.indd 8 9/19/2016 2:12:57 PM

9
English
Safety Information
If any foreign substance such as waterhas entered the appliance, cut
the powerby unplugging the powerplug and turning the circuit breaker
off and then contact yournearest service centre.
• Failing to do so may result in electric shock orfire.
Do not attempt to repair, disassemble, ormodify the appliance
yourself.
• Do not use any fuse (such as copper, steel wire, etc.) otherthan the
standard fuse.
• Failing to do so may result in electric shock, fire, problems with the
product, or injury.
CAUTION
Do not place objects ordevices underthe indoor unit.
• Water dripping from the indoor unit may result in fire or property
damage.
Check that the installation frame of the outdoor unit is not broken at
least once a year.
• Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and
current is measured according to ISO standard for energy efficiency.
Do not stand on top of the appliance orplace objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the product, or
injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
IB_EN_DB68-06428A.indd 9 9/19/2016 2:12:57 PM

10 English
Safety Information
Do not spray volatile material such as insecticide onto the surface of
the appliance.
• As well as being harmful to humans, it may also result in electric
shock, fire or problems with the product.
Do not drink the waterfrom the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote control and do not
disassemble the remote control.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not use this air conditionerto preserve precision equipment,
food, animals, plants or cosmetics, orforany other unusual
purposes.
• This may result in property damage.
Avoid directly exposing humans, animals orplants to the airflow
from the air conditionerfor long periods of time.
• This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, orlack of
experience and knowledge, without supervision orinstruction
concerning use of the appliance by a person responsible fortheir
safety. Children should be supervised to ensure that they do not play
with the appliance.
Safety Information
IB_EN_DB68-06428A.indd 10 9/19/2016 2:12:58 PM

11
English
Safety Information
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not
use benzene, thinner, alcohol oracetone to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock
or fire.
Before cleaning orperforming maintenance, cut off the power
supply and wait until the fan stops.
• Failing to do so may result in electric shock orfire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the
outdoorunit since it has sharp edges.
• This should be done by a qualified technician. Please contact your
installer or service centre.
Do not clean the inside of the airconditioner byyourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the filter, refer to the descriptions in the ‘Cleaning at a
Glance’ section.
• Failing to do so may result in damage, electric shock or fire.
IB_EN_DB68-06428A.indd 11 9/19/2016 2:12:58 PM

12 English
At a Glance
06
03
04
01
02
07
05
01 Air intake
02 Air filter(under the panel)
03 Air flow blade (up and down)
04 Air flow blade (left and right)
05 Room temperature sensor
06 Display
07 Power button / Remote control receiver
Display
01
02
03
04
05
01 Operation indicator
02 Timer indicator
03 Turbo indicator
04 Power button
05 Remote controller receiver
The actual product may differ slightly from the image depicted below.
Indoor Unit Overview
At a Glance
IB_EN_DB68-06428A.indd 12 9/19/2016 2:12:58 PM

13
English
At a Glance
Remote Control Overview
01
05
06
07
08
09
16
17
18
20
21
02
03
04
11
12
13
19
14
15
10
01 Set temperature indicator
02 Timer option indicator
03 Operation mode indicator
04 Options indicator
05 Low battery indicator
06 Transmit indicator
07 Fan speed indicator
08 Vertcal air swing indicator
09 Horizontal air swing indicator
NOTE
• This function is not available in this model.
10 Settings indicator
11 Power button
12 Temperature button
13 Options button
14 Timer button
15 Direction button/Selection button
16 Vertical air swing button
17 Mode button
18 Fan speed button
19 Horizontal air swing button
NOTE
• This function is not available in this model.
20 Settings button
21 SET button
NOTE
• The air conditioner may not be operated by the
remote control if the controller is placed close
to strong light such as a fluorescent lamp or
neon sign. In this case, use the remote control
right in front of the remote control receiver of
the indoor unit.
• If other electrical products are operated by the
remote control, call your nearest service center.
• To silence the beep sound, press the Settings
→ <, > or Settings → (Beep) blinking → SET
button. When you press the Settings → <, >
or Settings → (Beep) blinking → SET button
again, the beep sound will be active again.
At a Glance
IB_EN_DB68-06428A.indd 13 9/19/2016 2:12:59 PM

14 English
At a Glance
Replacing batteries
When the icon appears in the remote control
display, replace the batteries with new ones. Two
1.5V AAA type batteries are required.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with
other household waste at the end of theirworking life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly
disposed of, these substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle
them through your local, free battery return system.
Storing the remote control
If the remote control will not be used for an
extended period of time, store it in the remote
control holder with the batteries removed.
CAUTION
• Make sure that water does not come into the
remote control.
two 1.5V AAA type batteries
Remote Control Overview
IB_EN_DB68-06428A.indd 14 9/19/2016 2:12:59 PM

15
English
Basic Operation
Auto
In Auto mode, the air conditioner will automatically adjust
the temperature and fan speed to maintain your fresh
environment.
• When the indoor temperature is too high, the powerful cool
breeze is generated and when the indoor room becomes cool
enough, the soft breeze is generated.
Cool
The Cool mode is frequently used and you can freely control
the temperature, fan speed, and air flow direction in Cool
mode.
• When you select the Heat mode while the Cool mode is on,
the Cool mode is cancelled.
Dry
The air conditioner in Dry mode acts like a dehumidifier by
removing moisture from the indoor air. The Dry mode will
provide you with fresh air even on a rainy day.
Fan
The Fan mode provides you with a breeze just like a fan to
make fresh environment for you.
Basic Operation
Operation Modes
IB_EN_DB68-06428A.indd 15 9/19/2016 2:12:59 PM

16 English
Basic Operation
Heat
In Heat mode, you can warm your room even in fall and
winter.
• The fan may not commence immediately to avoid generating
a cold breeze.
• In Heat mode, defrost operation may be performed to remove
the frost formed on the outdoor unit. (When the frost is
removed by the defrost operation in Heat mode, steam is
generated from the outdoor unit.)
• If you stop operating the air conditioner after heating
operation, the fan will operate for some time to cool the
indoor unit.
• When you select the Cool mode while the Heat mode is on,
the Heat mode is cancelled.
NOTE
• When the outdoor temperature is relatively low and the humidity
is relatively high in Heat mode, the outdoor unit's heating
capacity may decrease due to the frost formed on the outdoor
heat exchanger. The defrost operation removes the frost formed
on the heat exchanger of the outdoor unit for 5 to 12 minutes.
During the defrost operation, the indoor unit does not generate
breeze in order to prevent cold breeze blowing out.
– The interval between defrost operations can decrease
depending on the amount of the frost formed on the outdoor
unit.
– The interval between defrost operations can also decrease
depending on the humidity level in the air.
Operation Modes
IB_EN_DB68-06428A.indd 16 9/19/2016 2:12:59 PM

17
English
Basic Operation
Turning the air conditioner on
Press the button to operate the air conditioner.
Selecting the operation mode
Press the button to select an operation mode.
▶▶▶
▶
Adjusting the temperature
Press the button to adjust the temperature.
Mode Temperature control
Auto/Cool/
Dry Adjust by1 °C between 18 °C and 30 °C.
Heat Adjust by1 °C between 16 °C and 30 °C.
Fan Temperature cannot be adjusted.
Selecting the fan speed
Press the button to adjust the fan speed.
Mode Available fan speeds
Auto/Dry (Auto)
Cool/Heat (Auto), (Low), (Med), (High)
Fan (Low), (Med), (High)
Basic Operation
IB_EN_DB68-06428A.indd 17 9/19/2016 2:13:01 PM

18 English
Basic Operation
Selecting air flow direction
Keep the air flow in a constant direction by stopping the
movements of the vertical and horizontal air flow blades.
In operation
▶
NOTE
• If you adjust the vertical air flow blade manually, it may not close
completely when you turn off the air conditioner.
Horizontal air flow (manual)
Keep the horizontal air flow in a constant direction by
changing the directions of the horizontal air flow blades
manually.
NOTE
• Although you press the button, this function does not work.
CAUTION
• To prevent personal injury, make sure that you change the
directions of the horizontal air flow blades after stopping the
movements of the vertical air flow blade.
Remote control display
Basic Operation
IB_EN_DB68-06428A.indd 18 9/19/2016 2:13:02 PM

19
English
Advanced Operation
Setting the On or Off timer
Advanced Operation
You can set the air conditioner to be turned on or off automatically at the desired time.
Setting the On timer
When the air conditioner is turned off:
1. Press the button to select (On).
• The (On) indicator will keep blinking and you can set the time.
2. Press the or button to set the time.
• You can set the time in half hour intervals from 30minutes (0.5
on the display) to 3in hour intervals from 3 to 24 hours.
• The time can be set from minimum 30 minutes to maximum
24hours.
3. Press the button to complete the On timer setting.
• The (On) indicator and the set time of the timerwill be
displayed on the remote control display.
• On timer setting will be cancelled if you don't press the
button within 10seconds after setting the time. Therefore,
check forthe (On) indicator on the remote control display.
Cancel
Press the button
▶ select (On) ▶ press
the or button
▶ set the timer to ▶
press the button
Remote control display
Additional options available in the On timer
Select the mode in the following order: (Auto) ▶ (Cool) ▶ (Dry) ▶ (Fan) and ▶
(Heat).
You can adjust the temperature aftertimer setting is completed.
Temperature adjustment is only available in Auto, Cool, Dry, and Heat modes. In Fan
mode, the temperature cannot be adjusted.
NOTE
• When On timer setting is completed, the setting will be displayed for 3 seconds, and then only the (On)
indicatorwill remain on the remote control display.
• You cannot set the Fan speed when setting the On timer.
IB_EN_DB68-06428A.indd 19 9/19/2016 2:13:03 PM

20 English
Advanced Operation
Setting the Off timer
When the air conditioner is turned on:
1. Press the button to select (Off).
• The (Off) indicator will keep blinking and you can set the time.
2. Press the or button to set the time.
• You can set the time in half hour intervals from 30minutes (0.5
on the display) to 3 hours and in hour intervals from 3 to 24
hours.
• The time can be set from minimum 30 minutes to maximum 24
hours.
3. Press the button to complete the Off timer setting.
• The (Off) indicator and the set time of the timerwill be displayed
on the remote control display.
• Off timer setting will be cancelled if you don't press the
button within 10seconds after setting the time.
Therefore, check for the (Off) indicator on the remote control
display.
Cancel
Press the button
▶ select (Off) ▶ press the
or button ▶ set the timer to ▶ press
the button
NOTE
• Only the latest timer setting will be applied between the Off
timer and good’sleep off timerfunctions.
Remote control display
Combining On timer and Off timer
When the air conditioner is turned off When the air conditioner is turned on
When the set time on On timer is less than that on
Off timer
e.g. On timer: 3hours, Off timer: 5hours
• The air conditioner will be turned on after 3hours
from the moment you have set the timer and the
air conditioner will remain on for 2hours and then
be turned off automatically.
When the set time on On timer is greater than that
on Off timer
e.g. On timer: 3hours, Off timer: 1hour
• The air conditioner will be turned off after 1hour
from the moment you have set the timer and will
be automatically turned on after 2hours from the
moment it was turned off.
NOTE
• The set times for the On timer and the Off timer should be different from each other.
• After the On timer or the Off timer is set, the setting can be cancelled by pressing the button.
Setting the On or Off timer
IB_EN_DB68-06428A.indd 20 9/19/2016 2:13:04 PM
