Samsung AM***FNFDEH series User manual

Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
Floor Standing Unit
AMFNFDEH
AMFBFDEH
ITFRESEN PT NLELDE HU PL
DB68-03677A-06
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 3 2016-04-06 오후 2:25:11

02
features of your new
air conditioner
• Cool Summer Offer
On those hot sweltering summer days and long restless nights, there is no better escape
from the heat than the cool comforts of home. Your new air conditioner brings an end to
exhausting hot summer days and lets you rest. This summer, beat the heat with your own
air conditioner.
• Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can
also be an efficient heating method in the winter with the advanced “Heat pump” system.
This technology is up to 300% more efficient than electrical heating, so you can further
reduce its running cost. Now, meet year-round needs with one air conditioner.
• Flexible installation
Duct type air conditioner is designed to be slimmer and offers different solutions for any
shape room allowing for specific air flow requirements. Also, the air intake can be set up on
either the bottom or rear of the unit, so there is more flexibility in installation.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 2 2016-04-06 오후 2:25:11

03
ENGLISH
safety information
To prevent electric shock, disconnect the power before servicing, cleaning,
and installing the air conditioner.
SAFETY INFORMATION
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact center or find help and information online at www.samsung.com.
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in
severepersonalinjuryordeath.
CAUTION
Hazards or unsafe practices that may result in
minorpersonalinjuryorpropertydamage.
CAUTION
To reduce the risk of fire, explosion, electric shock,
or personal injury when using your air conditioner,
follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric
shock.
Call the contact center for help.
Note.
Thesewarningsignsareheretopreventinjurytoyouand
others.
Pleasefollowthemcarefully.
Afterreadingthissection,keepitinasafeplaceforfuture
reference.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 3 2016-04-06 오후 2:25:11

04
safety information
SEVERE WARNING SIGNS
Do not place the air conditioner near hazardous substances
or equipment that releases free flames to avoid fire,
explosions or injuries.
•Potential risk of fire hazard or explosion.
Do not install the outdoor unit at an unstable place or
elevated surface where there is potential risk of falling.
•If the outdoor unit falls, it may cause personal injury or loss of
property.
Failure or damage may occur if any changes or
modification that is not stated in the installation manual
was performed. In this case, user will be responsible for the
repair expenses.
Install the air conditioner away from direct exposure to
sunlight, heating apparatus, and humid places.
•Hang curtains on windows to boost cooling efficiency and to
avoid the risk of electric shock.
Do not cut the power plug and connect to a different power
cable.
Do not yank the power cable and touch the power plug
with hands.
•Potential risk of fire or electric shock.
Never use a damaged or dusted power plug, power cable,
or loosened power receptacle.
•Potential risk of fire or electric shock.
Install an exclusive circuit breaker and short-circuit breaker
for the air conditioner.
•Potential risk of electric shock or fire.
Do not insert anything such as fingers or branches into the
air conditioner vents while the air conditioner is running.
•Keep the children away from the air conditioner to prevent
them from putting their finger on the air conditioner. Potential
risk of personal injury.
Ensure no water gets into the air conditioner.
•Potential risk or electric shock.
•If the water gets into the air conditioner, stop and unplug the
power source immediately.
Turn off the air conditioner using the provided remote
control or control accessory (if provided). Do not unplug to
turn off the unit (unless there is an immediate danger).
WARNING
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 4 2016-04-06 오후 2:25:12

05
ENGLISH
Do not run the air conditioner for an extended period of
time in a room with the door closed or with babies, elderly
or disabled people.
•Open the door or windows to ventilate your room at least
once an hour to prevent oxygen shortage.
The air conditioner is composed of moving parts. Keep
children away from the unit to avoid physical injury.
Make sure that children take precautions against access to
the air conditioner and they do not play with the unit.
Do not clean the interior of air conditioner on your own.
•You may damage the parts which can cause electric shock or
fire.
•Consult contact center for cleaning the interior of the air
conditioner.
Do not connect the air conditioner with heating apparatus
or attempt to disassemble, remodel or repair it yourself.
•Potential risk of malfunction, electric shock or fire. If repairs
are needed, consult the contact center.
Consult the place of purchase or contact center to install,
reinstall or disassemble the air conditioner.
•Improper installation carries a risk of unit malfunction, water
leakage, electric shock or fire.
•If installing in specialty areas, such as a factory complex or
saline coastal area, consult the place of purchase or contact
center for specific installation details.
•The units must be installed according to distances declared,
in order to permit accessibility from each side, either to
guarantee correct operation of maintenance or repairing
products. The unit’s parts must be reachable and removable
completely under safety condition (for people or things).
Consult a dealer regarding the appropriate measures to
prevent the allowable concentration from being exceeded.
•If the refrigerant leaks, and cause the concentration limit to
be exceeded, hazards due to lack of oxygen in the room may
result.
If the indoor unit gets wet, turn the power off immediately
and call your nearest contact center.
•Potential risk of fire or electric shock.
Always make sure that the power supply is compliant with
current safety standards. Always install the air conditioner
in compliance with current local safety standards.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 5 2016-04-06 오후 2:25:12

06
safety information
SEVERE WARNING SIGNS (CONT’D)
Verify that the voltage and frequency of the power supply
comply with the specifications and that the installed power
is sufficient to ensure the operation of any other domestic
appliance connected to the same electric lines.
Use a rated circuit breaker only.
•Never use steel wires or copper wires as a circuit breaker. It
may cause fire or unit malfunctions.
Do not put undue stress or place heavy object on the
power cable.
Do not bend the power cable excessively.
•Potential risk of fire or electric shock.
To protect the product from water and possible shock, you
should keep the power cable and the connection cord of
the indoor and outdoor units in the protection tube.
When opening or closing the front panel, use a stable stool
and watch your steps carefully.
Disconnect the air conditioner from power supply before it
is repaired or disassembled.
Clean the air conditioner after the inner fan stops operating.
•Potential risk of injury or electric shock.
Use a receptacle that has a ground terminal. The receptacle
must be used exclusively for the air conditioner.
•Improper electrical grounding may cause electric shock or
fire.
Be sure to ground the unit. Do not connect the ground wire
to gas or water pipes, lighting rods, or telephone grounding
lines.
•If the unit is not properly grounded, electric shock may result.
If you smell burning plastic, hear strange sounds, or see
smoke coming from the unit, unplug the air conditioner
immediately and call a contact center.
•Potential risk of fire or electric shock.
WARNING
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 6 2016-04-06 오후 2:25:12

07
ENGLISH
CAUTION SIGNS
Do not block or place items in front of the air conditioner.
Do not step, hang onto, or place heavy items on the air
conditioner.
•Potential risk of personal injury.
If failure or damage occurs on the conditions of improper
use not followed by the installation manual, there will be an
extra labor charge for installing and construction.
•Potential risk of malfunction, electric shock or fire if repairs
or installations are attempted by a non-qualified service
technician.
Do not spray flammable gases such as insecticide near the
air conditioner.
•Potential risk of electric shock, fire or unit malfunction.
Do not open the front grille during operation.
•Potential risk of electric shock or unit malfunction.
Cool air should not flow directly towards people, pets, and
plants.
•It is harmful to your health, pets, and plants.
Do not drink drain water coming out of the air conditioner.
•Potential risk of health hazard.
Do not allow children to climb on the air conditioner.
Do not use the air conditioner as a cooling precision
instrument for food, pets, plants, cosmetics or machinery.
Do not pull or give excessive shock to the air conditioner.
•Potential risk of fire, or unit malfunction and there are risk of
personal injury because unit may fall down.
Do not spray water directly on the air conditioner or use
benzene, thinner or alcohol to clean the surface of the unit.
•Potential risk of electric shock or fire.
•Potential risk of damage to the air conditioner.
Do not place any objects, especially containers with liquid.
Do not touch the pipe connected to the air conditioner.
CAUTION
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 7 2016-04-06 오후 2:25:12

08
safety information
CAUTION SIGNS (CONT’D)
Install the indoor unit away from lighting apparatus using
the ballast.
•If you use the wireless remote control, reception error may
occur due to the ballast of the lighting apparatus.
Install the outdoor unit where operating noise and vibration
will not disturb your neighbor and in a well-ventilated area
with no obstacle.
•Potential risk of malfunction.
•Operating noise may disturb your neighbor.
Make sure that there are no obstacles or covers that block
the air conditioner.
Allow sufficient space for air circulation.
•Insufficient ventilation may result in poor performance.
If the power cable is damaged, the manufacturer or a
qualified service technician must replace it.
If a power outage occurs while the air conditioner is
working, turn off the power source immediately.
Max current is measured according to IEC standard for
safety and current is measured according to ISO standard
for energy efficiency.
Check for damage on delivery. If damaged, do not
install the air conditioner and call the place of purchase
immediately.
Keep indoor temperatures stable and not extremely cold,
especially where there are children, elderly or disabled
people.
The packaging material and used batteries of the remote
controller (optional) must be disposed of in accordance
with the national standards.
The refrigerant used in the air conditioner must be treated
as chemical waste. Dispose the refrigerant following
national standards.
Have a qualified service technician install the air
conditioner and perform a trial operation.
Firmly connect the drain hose to the air conditioner for
proper water drainage.
CAUTION
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 8 2016-04-06 오후 2:25:12

09
ENGLISH
Check for damages on the outdoor unit installation pad at
least once a year.
•Potential risk of personal injury or property loss.
When using a wireless remote control, the distance should
not be more than 7 meters from the air conditioner.
If the remote control is not used for a long period of time,
remove the batteries to prevent leakage of electrolyte.
When cleaning the outdoor unit, touch the heat exchanger
radiator fins with extreme care.
•Wearing thick gloves can protect your hands.
Make sure that the condensed water dripping from the
drain hose runs out properly and safely.
The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety: Young children should be supervised to ensure that
they do not play with the appliance.
ForuseinEurope: This appliance can be used by
children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
Inspect the condition, electric connections, pipes and
external case of the air conditioner regularly by a qualified
service technician.
Do not open doors and windows in the room being cooled
during operation unless necessary.
Do not block the air conditioner vents. If objects block the
air flow, it may cause unit malfunction or poor performance.
Make sure there are no obstacles under the indoor unit.
•Potential risk of fire or loss of property.
The air conditioner should be used only for the applications
for which it has been designed: the indoor unit is not
suitable to be installed in areas used for laundry.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 9 2016-04-06 오후 2:25:12

10
safety information
CAUTION SIGNS (CONT’D)
Our units must be installed in compliance with the spaces
indicated in the installation manual to ensure either
accessibility from both sides or ability to perform routine
maintenance and repairs. The units’ components must be
accessible and that can be disassembled in conditions of
complete safety either for people or things.
For this reason, where it is not observed as indicated into
the Installation Manual, the cost necessary to reach and
repair the unit (in safety, as required by current regulations
in force) with slings, trucks, scaffolding or any other means
of elevation won’t be considered in-warranty and charged
to end user.
Ensure the off-on and protection switches are properly
installed.
Do not use the air conditioner if damaged. If problems
occur, immediately stop operation and disconnect the plug
from the power supply.
If the air conditioner will not be used for an extended
period of time (for example, over several months), unplug
the power from the wall.
Call the place of purchase or a contact center if repairs are
needed.
•Potential risk of fire or electric shock if disassembly or repairs
are attempted by a
non-qualified service technician.
CAUTION
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 10 2016-04-06 오후 2:25:12

11
ENGLISH
contents
VIEWING YOUR AIR CONDITIONER
12
12 Floor standing unit
USING YOUR AIR CONDITIONER
13
13 Tips on using your air conditioner
CLEANING AND MAINTAINING
THE AIR CONDITIONER
14
14 Cleaning the filter
14 Air filter
16 Maintaining your air conditioner
16 Periodical checks
17 Internal protections via the unit
control system
APPENDIX
18
18 Troubleshooting
19 Operation ranges
20 Model specification (Weight and dimension)
INSTALLING YOUR AIR CONDITIONER
21
21 Installation part
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for disposal.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 11 2016-04-06 오후 2:25:12

12
viewing your air conditioner
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air
conditioner and stay cool or warm with optimal efficiency.
Please read the user manual to get started and to make the best use of the air conditioner.
FLOOR STANDING UNIT
Your air conditioner may look slightly different from the illustration shown above depending
on your model.
Filter
Air Outlet
Air Intake
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 12 2016-04-06 오후 2:25:12

13
ENGLISH
using your air conditioner
TIPS ON USING YOUR AIR CONDITIONER
Here are some tips that you would follow when using your air conditioner.
TOPIC RECOMMENDATION
Cooling • If current outside temperatures are much higher than the selected indoor
temperature, it may take time to bring the inner temperature to the desired
coolness.
• Avoid drastically turning down the temperature.
Energy is wasted and the room does not cool faster.
Heating • Since the air conditioner heats the room by taking heat energy
from outdoor air, the heating capacity may decrease when outdoor
temperatures are extremely low. If you feel the air conditioner insufficiently
heats, using an additional heating appliance in combination with the air
conditioner is recommended.
Frost & De-ice • When the air conditioner runs in Heat mode, due to temperature difference
between the unit and the outside air, frost will form.
If this happens:
- The air conditioner stops heating.
- The air conditioner will operate automatically in De-ice mode for
10 minutes.
- The steam produced on the outdoor unit in De-ice mode is safe.
No intervention is required; after about 10 minutes, the air conditioner
operates again normally.
The unit will not operate when it starts to de-ice.
Fan • Fan may not operate for about 3~5 minutes at the beginning to prevent
any cold blasts while the air conditioner is warming up.
High indoor/outdoor
temperatures
• If both indoor and outdoor temperatures are high and the air conditioner is
running in Heat mode, the outdoor unit’s fan and compressor may stop at
times. This is normal; wait until the air conditioner turns on again.
Power failure • If a power failure occurs during the operation of the air conditioner, the
operating immediately stops and unit will be off. When power returns, the
air conditioner will run automatically.
Protection mechanism • If the air conditioner has just been turned on after operation stops or being
plugged in, cool/warm air does not come out for 3 minutes to protect the
compressor of the outdoor unit.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 13 2016-04-06 오후 2:25:12

14
cleaning and maintaining the
air conditioner
CLEANING THE FILTER
When cleaning the filter, make sure to unplug the power from the unit. No special tools are needed to clean it.
Air filter
Washable air filter captures large particles from the air. The filter is cleaned with a vacuum or
by hand washing.
1. Unscrew the screws (8) on the top of the indoor unit.
2. Remove the front cabinet by unscrewing the screws (8) on the left/right side of
the front cabinet.
3. Remove the Air filter.
Screw
Front cabinet
Screws
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 14 2016-04-06 오후 2:25:12

15
ENGLISH
4. Clean the Air filter with a vacuum cleaner or soft brush.
When the dust is too heavy, rinse the Air filter with warm water mixed with neutral detergent. However,
if you rub the air filter during washing, air filter may get damaged.
5. Dry the Air filter in shaded area and put it back in the indoor unit.
When you dry the Air filter, avoid direct sunlight. Air filter may get deformed when it is exposed to
direct sunlight.
6. Press the Filter Reset button on the remote controller.

•Clean the Air filter every 2 weeks or when the filter indicator( ) lights up on the remote
control receiver. However, cleaning period can vary according to the surrounding
environment and hours of usage, so the period should be shorter in a dusty environment.
• If you have cleaned the air filter even if the filter indicator ( ) has not turned on, you must
press the Filter Reset button after cleaning the filter.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 15 2016-04-06 오후 2:25:13

16
cleaning and maintaining the
air conditioner
MAINTAINING YOUR AIR CONDITIONER
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in
best condition.
1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect
the power plug. There may be internal damage if moisture is left in components.
2. Before using the air conditioner again, dry the inner components of the air conditioner again
by running in Fan mode for 3 to 4 hours. This helps remove odors which may have generated
from dampness.
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type Description Monthly Every4
months
Oncea
year
Indoor unit
Clean the air filter (1)

Clean the condensate drain pan (2)

Thoroughly clean the heat exchanger (2)

Clean the condensate drain pipe (2)

Replace the remote control batteries (1)

Outdoor unit
Clean the heat exchanger on the outside of
the unit (2)

Clean the heat exchanger on the inside of
the unit (2)

Clean the electric components with jets of
air (2)

Verify that all the electric components are
firmly tightened (2)

Clean the fan (2)

Verify that all the fan assembly is firmly
tightened (2)

Clean the condensate drain pan (2)

The checks and maintenance operations described are essential to guarantee the
efficiency of the air conditioner. The frequency of these operations varies according to the
characteristics of the area, the amount of dust, etc.
(1) The described operations should be performed more frequently if the area of installation
is very dusty.
(2) These operations must always be performed by qualified personnel. For more detailed
information, see the Installation Manual.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 16 2016-04-06 오후 2:25:13

17
ENGLISH
Internal protections via the unit control system
This internal protection operates if an internal fault occurs in the air conditioner.
Type Description
Against cold air
The internal fan will be off to against cold air when the heat pump is
heating.
De-ice cycle
The internal fan will be off to against cold air when the heat pump is
heating.
Anti-protection of
internal battery
The compressor will be off to protect internal battery when the air
conditioner operates in Cool mode.
Protect compressor
The air conditioner does not start operating immediately to protect the
compressor of the outdoor unit after it has been started.
If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from
an outdoor unit that may have deposited at low temperatures.
The internal fan is switched off automatically and restarted only after the de-ice cycle is
completed.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 17 2016-04-06 오후 2:25:13

18
appendix
TROUBLESHOOTING
Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary
expenses.
PROBLEM SOLUTION
The air conditioner does not
operate immediately after it
has been restarted.
• Because of the protective mechanism, the appliance does not start operating
immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.
The air conditioner does not
work at all.
• Check that the power plug is properly connected. Insert the power plug into the
wall socket correctly.
• Check if the circuit breaker is switched off.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.
The temperature does not
change.
• Check if you selected Fan mode.
Press the Mode button on the remote control to select another mode.
The cool (warm) air does
not come out of the air
conditioner.
• Check if the set temperature is higher (lower) than the current temperature. Press
the Temperature button on the remote control to change the set temperature.
Press the Temperature button to decrease or increase the temperature.
• Check if the air filter is blocked by dirt. Clean the air filter every two weeks.
• Check if the air conditioner has just been turned on. If so, wait 3 minutes. Cool air
does not come out to protect the compressor of the outdoor unit.
• Check if the air conditioner is installed in a place with a direct exposure to sunlight.
Hang curtains on windows to boost cooling efficiency.
• Check if the cover or any obstacle is not near the outdoor unit.
• Check if the refrigerant pipe is too long.
• Check if the air conditioner is only available in Cool mode.
• Check if the remote control is only available for cooling model.
The fan speed does not
change.
• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto in Auto/Dry mode.
Timer function does not set. • Check if you press the Power button on the remote control after you have set the time.
Odors permeate in the room
during operation.
• Check if the appliance is running in a smoky area or if there is a smell entering from
outside. Operate the air conditioner in Fan mode or open the windows to air out the
room.
The air conditioner makes a
bubbling sound.
• A bubbling sound may be heard when the refrigerant is circulating through the
compressor. Let the air conditioner operate in a selected mode.
• When you press the Power button on the remote control, noise may be heard from
the drain pump inside the air conditioner.
Water is dripping from the
air flow blades.
• Check if the air conditioner has been cooling for an extended period of time with
the air flow blades pointed downwards. Condensation may generate due to the
difference in temperature.
Remote control is not
working.
• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote control sensor.
• Check that there are strong lighting apparatus near the air conditioner. Strong light
which comes from fluorescent bulbs or neon signs may interrupt the electric waves.
The air conditioner does not
turn on or off with the wired
remote control.
• Check if you set the wired remote control for group control.
The wired remote control
does not operate.
• Check if TEST indicator is displayed on the wired remote control. If so, turn off the
unit and switch off the circuit breaker. Call your nearest contact center.
The indicators of the digital
display flashes.
• Press the Power button on the remote control to turn the unit off and switch the
circuit breaker off. Then, switch it on again.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 18 2016-04-06 오후 2:25:13

19
ENGLISH
OPERATION RANGES
The table below indicates the temperature and humidity ranges the air conditioner can be operated within.
Refer to the table for efficient use.
MODE OPERATIONALTEMPERATURE INDOORHUMIDITY IFOUTOFCONDITIONS
INDOOR OUTDOOR
COOLING 18˚C to 32˚C -5˚C to 48˚C 80% or less
Condensation may occur on
the indoor unit with risk to have
either water blow off or drops on
the floor.
HEATING 27˚C or less -20˚C to 24˚C - Internal protection triggers and
the air conditioner will stop.
DRYING 18˚C to 32˚C -5˚C to 48˚C -
Condensation may occur on
the indoor unit with risk to have
either water blow off or drops on
the floor.
The standardized temperature for heating is 7˚C. If the outdoor temperature drops to 0˚C or below,
the heating capacity can be reduced depending on the temperature condition.
If the cooling operation is used at over 32˚C(indoor temperature), it does not cool at its full capacity.
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 19 2016-04-06 오후 2:25:13

20
appendix
MODEL SPECIFICATION (WEIGHT AND DIMENSION)
Type Model Netweight Netdimension(W×D×H)
Indoorunit
AM036FBFDEH/EU 23.0 kg 945×220×600 mm
AM056FBFDEH/EU 28.5 kg 1225×220×600 mm
AM071FBFDEH/EU 28.5 kg 1225×220×600 mm
Indoorunit
(NASA)
AM036FNFDEH/EU 23.0 kg 945×220×600 mm
AM056FNFDEH/EU 28.5 kg 1225×220×600 mm
AM071FNFDEH/EU 28.5 kg 1225×220×600 mm
NASA_Floor Stand_AM@@@FNFDEH@_IB,IM_EN_03677A-05.indd 20 2016-04-06 오후 2:25:13
