Samsung AS09HPB User manual

THE FEATURE OF PRODUCTAIR CONDITIONER
■Energy Saving Function
■High Impressive & Elegant Design
■Excellent Dust Collection Filter
: The metallic dust filter is used.
■Multi Functional Cleaning System
: The anti allergy filter and activated deodorizing
filter are adopted.
■Human Touch Remote control
SERVICE
Manual
For more information, Please access to our service web site (http://itself.sec.samsung.co.kr)
Basic : INDOOR UNIT OUTDOOR UNIT
Basic : AS09HPB
Basic : AS12HPB
Model : AS09BPA
Model
: AS12BPA
Model : AS09BPA/XSA
Model : AS12BPA/XSA
Model Code : AS09BPAN AS09BPAX
Model Code :
AS12BPAN AS12BPAX
Model Code : AS09BPAN/XSA AS09BPAX/XSA
Model Code
: AS12BPAN/XSA AS12BPAX/XSA
SPLIT-TYPE AIR CONDITIONER
AS09BPAN, AS12BPAN
AS09BPAN/XSA, AS12BPAN/XSA
AS09BPAX, AS12BPAX
AS09BPAX/XSA, AS12BPAX/XSA
24437A(1)_co 1/16/05 9:56 PM Page 1

Contents
11. Precautions ........................................................................................................................................... 1-1
1-1 Installing the air conditioner .......................................................................................................... 1-1
1-2 Power supply and circuit breaker ............................................................................................... 1-1
1-3 During operation ................................................................................................................................1-1
1-4 Disposing of the unit ........................................................................................................................ 1-2
1-5 Others .................................................................................................................................................... 1-2
12. Product Specifications.............................................................................................................. 2-1
2-1 The Feature of Product .................................................................................................................. 2-1
2-2 Name of Each Part ........................................................................................................................... 2-2
2-3 Product Specifications .................................................................................................................... 2-4
2-4 The Comparative Specifications of Product .......................................................................... 2-5
2-5 Accessory and Option Specifications ....................................................................................... 2-7
13. Alignment and Adjustments................................................................................................. 3-1
3-1 Indoor Display Error and Check Method ................................................................................ 3-1
3-2 Outdoor LED Error Display and Check Method .................................................................. 3-2
3-3Setting Option Setup Method
......................................................................................................
3-3
14. Disassembly and Reassembly........................................................................................... 4-1
4-1 Indoor Unit ........................................................................................................................................... 4-1
4-2 Outdoor Unit ........................................................................................................................................ 4-5
15. Exploded Views and Parts List......................................................................................... 5-1
5-1 Indoor Unit ........................................................................................................................................... 5-1
5-2 Outdoor Unit ......................................................................................................................................... 5-5
5-3 Ass'y Control In ................................................................................................................................... 5-7
5-4 Ass'y Control Out................................................................................................................................5-9
16. Electrical Parts List....................................................................................................................... 6-1
17. Wiring Diagram.................................................................................................................................. 7-1
7-1 Indoor Unit ........................................................................................................................................... 7-1
7-2 Outdoor Unit ......................................................................................................................................... 7-2
18. Schematic Diagram....................................................................................................................... 8-1
8-1 Indoor Unit ........................................................................................................................................... 8-1
8-2 Outdoor Unit ......................................................................................................................................... 8-2
24437A(1)_1 1/16/05 9:57 PM Page 1

Contents
19. Circuit Descriptions ..................................................................................................................... 9-1
9-1 PCB Circuit Descriptions................................................................................................................. 9-1
9-2 Refrigerating Cycle Diagram ......................................................................................................... 9-3
10. PCB Diagram .......................................................................................................................................10-1
10-1 Indoor PCB ........................................................................................................................................ 10-1
10-2 Outdoor PCB ..................................................................................................................................... 10-2
11. Operating Instruction and Installation........................................................................ 11-1
11-1 Main Function .................................................................................................................................... 11-1
11-2 Wireless Remote Control-Buttons and Display................................................................... 11-4
12. Troubleshooting ............................................................................................................................... 12-1
12-1 Items to be checked first .............................................................................................................. 12-1
12-2 Fault Diagnosis by Symptom...................................................................................................... 12-2
12-3 PCB Inspection Method ................................................................................................................12-20
12-4 Main Part Inspection Method......................................................................................................12-22
13. Block Diagram....................................................................................................................................13-1
13-1 Indoor Unit .......................................................................................................................................... 13-1
13-2 Outdoor Unit....................................................................................................................................... 13-3
14. Reference Sheet...............................................................................................................................14-1
14-1 Index for Model Name ................................................................................................................... 14-1
14-2 Refrigerant Pressure Distribution.............................................................................................. 14-2
14-3 Pressure & Capacity mark........................................................................................................... 14-2
14-4 Q & A for Non-trouble..................................................................................................................... 14-3
14-5 Cleaning/Filter Change.................................................................................................................. 14-6
14-6 Installation........................................................................................................................................... 14-8
14-7 Installation Diagram of Indoor Unit and Outdoor Unit...................................................... 14-9
24437A(1)_1 1/16/05 9:57 PM Page 2

1-1Samsung Electronics
1. Precautions
1-1 Installing the air conditioner
● Users should not install the air conditioner by themselves.
Ask the dealer or authorized company to install the air conditioner except the window-type air conditioner in U.S.A and Canada.
● If you don’t install the air conditioner properly, it may cause a fire, a water leakage or an electric shock.
● You must install the air conditioner according to the national wiring regulations and safety regulations.
● Install the indoor unit higher than 2.5m from the floor to avoid the injury caused by the operation of the fan.
(except the window-type air conditioner)
● The manufacturer is not responsible for any accidents or injury caused by an incorrect installation.
● When installing the built-in type air conditioner, keep all electric cables such as the power cable and the connection cord in pipes,
ducts, or cable channels to protect them from the danger of impact or any other incidents.
1-2 Power supply and circuit breaker
● If the power cord of the air conditioner is damaged, it must be replaced by the manufacturer or a qualified person in order to
avoid a hazard.
● The air conditioner must be plugged into an independent circuit if applicable or connect the power cable to the auxiliary circuit
breaker.
An all pole disconnection from the power supply must be incorporated in the fixed wiring with a contact opening of >3mm.
● Do not extend an electric cord to the air conditioner.
● The air conditioner must be plugged in after you complete the installation.
1-3 During operation
● Do not repair the air conditioner at your discretion.
It is recommended to contact a service center directly.
● Never spill any kind of liquid on the air conditioner.
If this happens, turn off the air conditioner and contact an authorized service center.
● Do not insert anything between the airflow blades to prevent damage of the inner fan and consequent injury.
Keep children away from the air conditioner.
● Do not place any obstacles in front of the air conditioner.
● Do not spray any kind of liquid into the indoor unit. If this happens, turn off the air conditioner and contact a service center.
● Make sure that the air conditioner is well ventilated at all times:
Do not place a cloth or other materials over it.
● Remove the batteries if you don’t use the remote control for a long time. (If applicable)
● Use the remote control within 7 meters from the indoor unit. (If applicable)
24437A(1)_1 1/16/05 9:57 PM Page 1-1

Samsung Electronics1-2
1-5 Others
● Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
● Young children or infirm persons should be always supervised when they use the air conditioner.
● Max current is measured according to IEC standard for safety.
● Current is measured according to ISO standard for energy efficiency.
1-4 Disposing of the unit
● Before throwing out the air conditioner, remove the batteries from the remote control.
● When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant may blow out and
cause air pollution. When it contacts with your skin, it can cause skin injury.
● The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
24437A(1)_1 1/16/05 9:57 PM Page 1-2

2-1Samsung Electronics
2. Product Specifications
2-1 The Feature of Product
■Energy saving function
Makes a room cool with and energy saving and arises the efficiency of air conditioner.
■High impressive & elegant design
With a Smart and fashionable style, the high impressive interior design allow this product to set place in anywhere.
■Excellent dust collection filter
With a metallic dust filter that upgrades the dust collection function than a common plastic filter, you can enjoy the best
cleanliness.
■Multi functional cleaning system
With an anti-allergy filter and activated deodorizing filter, it removes an allergy antigen as well as a tobacco odor.
■Human touch remote control
The use of air conditioner is easier and more convenient by the human touch remote control of new design.
24437A(1)_1 1/16/05 9:57 PM Page 2-1

Samsung Electronics2-2
2-2 Name of Each Part
The design and shape can be changed according to the model.
Air filter
(under the grille)
Air flow blades
(outlet)
Power(On/Off) button
Set temperature &
room temperature
Operation indicator
(Auto-Cool, Cool, Dry, Fan : Blue
Auto-Heat, Heat : Orange)
Auto cleaning indicator
(Blue)
Energy saving indicator
(Blue)
Anions indicator
(Blue)
Turbo function indicator
(Blue)
Timer indicator
(Orange)
Fan speed indicator
(Blue)
Remote control sensor
Room Temperature sensor
Air Inlet
Note : • In the Auto mode, 2 fan indicators increase and decrease continuously and turn round.
• In the modes except the Auto mode, the fan speed indicator increases and decreases
continuously and turn round each time you press the button. If you set the Turbo
function, the fan speed indicator turns round with the maximum setting and speed.
• If you want to turn on/off the Display during operation, press the button on
the remote control.
• The room temperature sensor senses air temperature around the
sensor, and shows the temperature on the display.
2-2-1 Indoor Unit
24437A(1)_1 1/16/05 9:57 PM Page 2-2

Product Specifications
2-3Samsung Electronics
2-2-2 Outdoor Unit
Air Inlet(Rear)
Air Outlet
Connection Valve
(inside)
24437A(1)_1 1/16/05 9:57 PM Page 2-3

Samsung Electronics2-4
2-3 Product Specifications
Perfor-
mance
Power
Size
Model
Item
Type
Cooling kW
Heating kW
Dehumidifying |/h
Air Volume Cooling m3/min
Heating (H/M/L)
Noise Cooling dB
Heating (H/L)
Energy Efficiency Ratio Cooling W/W
Heating
Power ph-V-Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Power Factor Cooling %
Heating
Length m
Power Cord Number of Core Wire
Capacity A
Outer Dimension WidthxHeight mm
xDepth inch
Weight(Net) kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose DxL(mm)
Type
Compressor Motor Type
Rated Output
Oil Type
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Freezer Oil Capacity cc
Refrigerant to Change(R410A) g
Protection Device(OLP)
Cooling Test Condition
Maximum Operation Condition
Indoor unit Outdoor unit
Wall-mounted
0.99/2.5/3.5
0.85/3.5/5.0
1.25
7.8/6.1/4.5 31.5/13.0
8.2/6.5/4.9 31.5/13.0
40/25 51
40/25 51
4.13/4.1/3.4
3.86/3.9/3.36
1-220/240-50
240/610/1,030
220/900/1,490
1.5/3.0/5.0
1.35/4.4/6.85
91.0
92.0
2
3
15
950x268x165 790x548x285
37.4x10.6x6.5 31.1x21.6x11.2
940
ø6.35x7.5
ø9.52x7.5
ø18x550
Rotary, G4C090LU2ER
Hermetic
853W
FREOL 68ES-T
Cross-flow Propeller
Resin/Steel Resin/Steel
27 50
2Row 12Step 2Row 24Step
Expansion Valve
320
1,000
None
α
Indoor unit Outdoor unit
Wall-mounted
0.99/3.5/4.2
0.85/4.0/5.5
1.7
8.2/ 6.7/4.5 31.5/13.0
8.6/ 7.1/4.9 31.5/13.0
41/25 53
41/25 53
4.13/3.4/2.9
3.86/3.61/3.07
1-220/240-50
240/1,030/1,450
220/1,105/1,790
1.5/5.0/6.9
1.35/5.3/8.5
92.5
92.5
2
3
15
950x268x165 790x548x285
37.4x10.6x6.5 31.1x21.6x11.2
940
ø6.35x7.5
ø9.52x7.5
ø18x550
Rotary, G4C090LU2ER
Hermetic
853W
FREOL 68ES-T
Cross-flow Propeller
Resin/Steel Resin/Steel
27 50
2Row 12Step 2Row 24Step
Expansion Valve
320
1,000
None
α
AS09BPA AS12BPA
INDOOR UNIT : DB27˚C WB19˚C OUTDOOR UNIT : DB35˚C WB24˚C
INDOOR UNIT : DB32˚C WB23˚C OUTDOOR UNIT : DB43˚C WB26˚C
24437A(1)_1 1/16/05 9:57 PM Page 2-4

2-5Samsung Electronics
2-4 The Comparative Specifications of Product
9.0kg
40.0kg
950x268x165mm
790x548x285mm
40dB↓
51dB↓
Silver Nano Metallic Filter
Anti-Allergy Filter
Deodorizing Filter
Detachable Display
Rotation Blue LED Display
Net Weight
Indoor Unit
Outdoor Unit
Outer Dimension Indoor Unit
(WidthxHeightxDepth) Outdoor Unit
Noise
Indoor Unit
Outdoor Unit
Air Purifying System Filter
Indoor Display
Item
Indoor
Unit
Outdoor
Unit
AS09BPA AS09HPB
9.0kg
33.8kg
950x268x165mm
790x548x285mm
40dB↓
51dB↓
Silver Nano Metallic Filter
Anti-Allergy Filter
Deodorizing Filter
Detachable Display
Rotation Blue LED Display
Design
24437A(1)_1 1/16/05 9:57 PM Page 2-5

Samsung Electronics2-6
The Comparative Specifications of Product(cont.)
9.0kg
40.0kg
950x268x165mm
790x548x285mm
41dB↓
53dB↓
Silver Nano Metallic Filter
Anti-Allergy Filter
Deodorizing Filter
Detachable Display
Rotation Blue LED Display
Net Weight
Indoor Unit
Outdoor Unit
Outer Dimension Indoor Unit
(WidthxHeightxDepth) Outdoor Unit
Noise
Indoor Unit
Outdoor Unit
Air Purifying System Filter
Indoor Display
Item
Indoor
Unit
Outdoor
Unit
AS12BPA AS12HPB
9.0kg
36.0kg
950x268x165mm
790x548x285mm
43dB↓
53dB↓
Silver Nano Metallic Filter
Anti-Allergy Filter
Deodorizing Filter
Detachable Display
Rotation Blue LED Display
Design
24437A(1)_1 1/16/05 9:57 PM Page 2-6

2-7Samsung Electronics
Item Descriptions Q'TYCode-No. Remark
Installation Plate DB70-00514A 1
Remote Control DB93-03016R 1
Batteries for Remote Control DB47-90024A 2
User's Manual DB98-23940A 1
Installation Manual DB98-23975A 1
3-wire Power Cable DB93-01549C 1
4-wire Assembly Cable - 1
Drain Plug DB67-20011A 1
Rubber Leg DB73-00179A 4
Assembly Pipe, ø6.35mm DB96-10453B 1
Assembly Pipe, ø9.52mm DB96-10453F 1
2-5 Accessory and Option Specifications
2-5-1 Accessories
OWNER'SINSTRUCTIONS
MANUALDEINSTRUCCIONES
ISTRUZIONIPERL'USO
MANUALDEINSTRUÇÕES
MANUELD'UTILISATION
GEBRAUCHSANWEISUNG
Splut-typeRoomAirConditioner
AireacondicionadodomésticosistemaSplit
Condizionatored'ariaperambientiadunitàSeparate
AparelhodearcondicionadotipoSplit
Climatiseurdetypeséparé
Geteilteraumklimaanlage
OWNER'SINSTRUCTIONS
MANUALDEINSTRUCCIONES
ISTRUZIONIPERL'USO
MANUALDEINSTRUÇÕES
MANUELD'UTILISATION
GEBRAUCHSANWEISUNG
Splut-typeRoomAirConditioner
AireacondicionadodomésticosistemaSplit
Condizionatored'ariaperambientiadunitàSeparate
AparelhodearcondicionadotipoSplit
Climatiseurdetypeséparé
Geteilteraumklimaanlage
Indoor
Unit
Outdoor
Unit
Accessory
Box
24437A(1)_1 1/16/05 9:57 PM Page 2-7

Product Specifications
Samsung Electronics2-8
Item Descriptions Q'TYCode-No. Remark
PE T3 Foam Tube Insulation DB72-50165A 1
Vinyl Tape, Width 50mm DB72-00459A 1
Drain Plug DB67-20011A 1
Rubber Leg DB73-00179A 4
Pipe Clamps A DB39-20224A 3
Pipe Clamps B DB39-20224B 3
Cement Nail - 6
M4x16 Tapping Screws 6002-000215 10
Drain Hose, length 2m DB62-00487A 1
Putty 100g DB98-10568A 1
Accessories(cont.)
Accessory
Box
24437A(1)_1 1/16/05 9:57 PM Page 2-8

3-1Samsung Electronics
3. Alignment and Adjustments
3-1 Indoor Display Error and Check Method
1 IPM Over Current(O.C)
2 Compressor Starting Error
3 Compressor Lock Error
4 DC-Link voltage under/over Error
5 Outdoor temperature sensor Error
6 Discharge over temperature
7 Discharge temperature sensor Error
8 Current sensor Error
9 Compressor Vlimit Error
10 Coil temperature sensor Error
11 1min. Time out Communication
12 Fan Error
13 OTP Error
14 Compressor Rotation Error
15 (Low/High) Operation condition secession
16 DC-Link valtage sensor Error
17 I_Trip error / PFC Over current
18 Gas Leak Error
19 AC Line Zero Cross Signal out
20 Capacity Miss-match
21 Room sensor Error Open/Short
22 In-coil sensor Error Open/Short
23 FAN Error
Indoor Fan Motor Abnormal Operation
Holding for 15 sec. at less than 450rpm
24 1min. Time out Communication
25 All Lamps Blink EEPROM Error
26 All Lamps Blink Option Error Option Not Set up, Option Data Error
LED DisplayNo Explanation Explanation
/
24437A(1)_1 1/16/05 9:57 PM Page 3-1

Samsung Electronics3-2
3-2 Outdoor LED Error Display and Check Method
1 Power off/VDD NG
2 IPM Over Current(O.C)
3 Abnormal Serial communication
4 Compressor Starting error
5 Normal Operation
6 Compressor Lock error
7 DC-Link voltage under/over error
8 Outdoor temperature sensor error(Dual/Single)
9 Discharge over temperature(Dual/Single)
10 Discharge temperature sensor error(Dual/Single)
11 Current sensor error
12 Compressor Limit error
13 Coil temperature sensor error(Dual/Single)
14 1min. Time out Communication
15 Fan error
16 OTP error
17 Compressor rotation error
18 Operation condition secession(Dual only)
19 DC-Link voltage sensor error
20 I_Trip error / PFC Over current
21 GAS Leak error(Dual/Single)
22 AC Line Zero Cross Signal out
23 Power ON reset(1sec)
24 Capacity miss match
25 Test Operation at Cooling Mode
26 Test Operation at Heating Mode
LED Display
Yellow Green Red
No Explanation
: LED ON, : LED OFF, : LED BLINK
24437A(1)_1 1/16/05 9:57 PM Page 3-2

3-3Samsung Electronics
3-3 Setting Option Setup Method
ex) Option No. :
Step 1 : Enter the Option Setup mode.
1st Take out the batteries of remote control.
2nd Press the temperature button simultaneously and
insert the battery again.
3rd Make sure the remocon display shown as .
Step 2 : Enter the Option Setup mode and select your option according to the following procedure.
3 2
1
4
5 6
1
2
The default value is .
Otherwise, push the button to .
Every time you push the button, the display panel reads or
repeatedly.
✳Setting is not required if you must
a value which has a default.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
3
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
4
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
5
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
6
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
24437A(1)_1 1/16/05 9:57 PM Page 3-3

Alignment and Adjustments
Samsung Electronics3-4
7
8
Press button, then the default value is .
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
10
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
9
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
11
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
12
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
9 8
7
10
11 12
✳Setting is not required if you must
a value which has a default.
Step 3 : Upon completion of the selection, check you made right selections.
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Step 4 : Pressing the ON/OFF button ( )
When pressing the operation ON/OFF key with the direction of remote control for unit, the sound ''Ding'' or ''Diriring''
is heard and the OPERATION ICON( ) lamp of the display is flickering at the same time, then the input of option is
completed. (If the diriring sound isn't heard, try again pressing the ON/OFF button.)
Step 5 : Unit operation test-run
First, Remove the battery from the remote control.
Second, Re-insert the battery into the remote control.
Third, Press ON/OFF key with the direction of remote control for set.
•Error Mode
1st If all lamps of indoor unit are flickering, plug out, plug in power plug again and press the ON/OFF key to retry.
2nd If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the correct option code
is set up for its model.
24437A(1)_1 1/16/05 9:57 PM Page 3-4

Alignment and Adjustments
3-5Samsung Electronics
■OPTION ITEMS
REMOCON
MODEL SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
AS09BPAN
AS12BPAN
00A777175247
014677175267
✳ For Australia, exceptionally
REMOCON
MODEL SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
AS09BPAN/XSA
AS12BPAN/XSA
00A577175247
014577175267
24437A(1)_1 1/16/05 9:57 PM Page 3-5

Samsung Electronics4-1
4. Disassembly and Reassembly
4-1 Indoor Unit
Stop operation of the air conditioner and remove the power cord before repairing the unit.
No Parts Procedure Remark
1 Panel Front 1) Stop the air conditioner operation and
shut off the main power.
2) Detach the Front Grille after pushing
out it.
3) Loosen 1 of the right screw and detach
the Ass'y display.
4) Loosen 1 of the right screw and detach
the Terminal Cover.
5) Detach the cover PCB-DVM and thermis-
tor from the Panel Front.
24437A(1)_1 1/16/05 9:57 PM Page 3-6

Disassembly and Reassembly
4-2Samsung Electronics
No Parts Procedure Remark
2
3
Tray Drain
Heat Exchanger
6) Loosen 5 fixing screws of Panel Front.
7) Unlock 2 hooks to fix Panel Front and
Tray Drain.
8) Unlock 2 hooks to fix Panel Front and
Back Body.
1) Detach the connected wire of Stepping
Motor.
2) Pull Tray Drain out from the Back Body.
1) Loosen 1 fixing earth screw of right side.
24437A(1)_1 1/16/05 9:57 PM Page 3-7
