Samsung AW09P1 Series User manual

AW09P1 Series
AW12P1 Series
AW18P1 Series
AW24P1 Series
Window-type Room Air Conditioner (Cooling)
DB98-33321A-1
USER'S MANUAL
EFP
HS
IL
G
NES
IA
ÇN
A
R
FS
Ê
U
G
U
T
R
O
P
DB98-00000.indd 15 2010-12-21 17:59:02
C
M
Y
CM
MY
CY
CMY
K
DB98-33321A-E.pdf 2010-12-29 15:27:44DB98-33321A-E.pdf 2010-12-29 15:27:44

E-2
Safety Precautions
The following safety precautions must be taken when using your air conditioner.
WARNING
Risk of electric shock. • Can cause injury or death. • Disconnect all
remote electric power supplies before servicing, installing or cleaning.
• This must be done by the manufacturer or its service agent or a similar
qualified person in order to avoid a hazard.
Register your product at www.samsung.com/register
DURING OPERATION

Users of this product are cautioned not to attempt repair of this product at their
own discretion. Instead, they are requested to directly contact a designated
service center or the outlet at which the product was purchased.

Never spill any kind of liquid into the unit. Should this happen, unplug or main
switch off the unit and contact an authorized service center.

Do not insert anything between the air outlet blades because the inner fan may
be damaged and could cause injury. Keep children away from the unit.

Do not place any obstacles in front of the unit.

Do not spray liquid of any kind into the indoor unit. Should this happen, switch off
the breaker used for your air conditioner and contact your installation specialist.

Make sure that the unit is correctly ventilated at all times:
Do not place clothing or other materials over it.

If the wireless remote control will not be used for a long time, remove the
batteries. (If applicable)

When using a wireless remote control, the distance should not be more than 7
meters from the air conditioner. (If applicable)

The air conditioner must be plugged into its own specific power source, which
must be installed in compliance with national wiring,earthing and safety
regulations.

If the power cord is damaged in any way, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a hazard.

This device must be installed according to the national electrical rules.

The appliance must be installation that the plug should be easily accessible
after installation.

If the fuse on PC board is broken please change it with the type of T 3.15A 250V.

The breaker of the air conditioner should be all-pole switch; and the distance
between its two contacts should be no less than 3.5mm. Such means for
disconnection must be incorporation in the fixed wiring.
DISPOSING OF THE UNIT

Before throwing out the device, it is necessary to pull back the battery cells and
get rid of them safely for recycling reasons.

When you need to dispose of the unit, consult your dealer. If pipes are removed
incorrectly, refrigerant may blow out and come into contact with your skin,causing
injury. Releasing refrigerant into the atmosphere also damages the environments.

Please recycle or dispose of the packaging material for this product in an
environmentally responsible manner.
O THERS

Never store or ship the air conditioner upside down or sideways to avoid damage
to the compressor.

The appliance is not intended for use by young children or infirm persons without
supervision: Young children should be supervised to ensure that they do not play
with the appliance.
DB98-27658A.indd 2 2010-12-9 10:14:20

E-3
ENGLISH
 PREPARING YOUR AIR CONDITIONER
nSafety Precautions ........................................................................................ 2
nAir Conditioning Unit-Main Parts and Control Panel..................................... 4
 OPERATION YOUR AIR CONDITIONER
nCooling Your Room....................................................................................... 5
nAiring Your Room.......................................................................................... 6
nSwitching the Air Conditioner Off .................................................................. 6
nAdjusting the Air Flow Direction Horizontally ................................................ 7
nAdjusting the Air Flow Direction Vertically .................................................... 7
 RECOMMENDATIONS FOR USE
nTemperature and Humidity Ranges .............................................................. 7
nCleaning Your Air Conditioner....................................................................... 8
nSolving Common Problems........................................................................... 9
 METHOD OF INSTALLATION...................................................................... 10
Contents
CAUTION
“The high inrush current of the starting compressor motor can have adverse effects to
the operation of other equipment under unfavorable mains conditions. This equipment
does not comply with the relevant technical standards for the limitation of voltage
fluctuations and flicker.”
Before connection this equipment to the power supply system, please report to your
suply authority and obtain the consent.
Do not connect other electric appliances to the same supply lines.
The maximum permissible system impedance at the power junction box is 0.24 ohms.
Usually, the maximum permissible mains impedance will not be exceeded when the
branch to the power outlet is fed from a junction box with a rated current of 32A.
AW18
 
PRESS PUSH IMPORTANT NOTE
The illustrations in the step-by-step procedures use four different symbols:

E-4
Air Conditioning Unit - Main Parts and Control Panel
Air inlet (Inside)
The air filter is
located in side
Air Outlet
Inner air flow blades
(right/left orientation)
Outer air flow blades
(up/down orientation)
Air inlet (Outside)
Ventilation lever
The design and shape are subject to
change according to the model.
Coolest
Power plug
The type of the power plug
may differ according to the
type of local power supply.
Power Cable
Coolest
Operating mode
selection dial
Temperature
control dial
Air flow blade
swing switch

E-5
ENGLISH
Cooling Your Room
You must select the Cool mode if you wish to lower the temperature
in your room.You can also set the fan speed.
1Select the operating mode and fan speed.
To cool your room with a... Set the operating mode
selection dial to...
High fan speed HI COOL
Between HIGH and LOW MED COOL
Low fan speed LOW COOL
Result:  The air conditioner starts up in the Cool mode.
 The fan starts up at the speed selected.
 You can change modes at any time.
2 To adjust the temperature, turn the temperature control dial
to the desired position.
Possible temperatures: Between 18 °C and 29 °C inclusive.
Result:  The air conditioner starts cooling if the room temperature is
higher than the selected temperature.
3 To control the direction of the air flow, refer to page 7.
