Samsung MWR-WG00KN User manual

Air conditioner
User manual
Wired remote controller MWR-WG00KN
•Thank you for purchasing this Samsung Product.
•Before operating this unit, please read this user manual carefully and retain it for future
reference.
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 1 2019-05-16 오후 2:29:12

2
English
Contents
Safety Information 3
Safety Information 3
Power Smart Features 5
Remote Controller Operation 5
Operation modes • Controlling temperature • Controlling fan speed • Controlling air flow direction
Cooling Operation 7
Cool mode • Wind-Free function
Dehumidifying Operation 8
Dry mode
Air Purifying Operation 8
Purify function
Heating Operation 9
Heat mode
Quick Smart Features 9
Auto mode • Fan mode • Quiet function • Sleep function • Long Wind function
Ventilation (ERV) Operation 11
Ventilation (ERV) Operation 11
Operation modes • Controlling fan speed • E-Saver function • Clean up function
Energy-Saving Operation 13
Energy-Saving Operation 13
Schedule • Energy
Setting Options 15
Setting Options 15
How to set the Options • Current Time Setting (Example)
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 2 2019-05-16 오후 2:29:13

3
English
Safety Information
Safety Information
This content is intended to protect the user’s safety and prevent property damage. Please read it carefully
for correct use of the product.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
Follow directions. Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the appliance. Do NOT disassemble.
FOR INSTALLATION
WARNING
The installation of this appliance must be performed by a qualified technician or service company.
• Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury.
You must connect the product with rated powerupon installation.
• Failing to do so may result in problems with the product, electric shock, or fire.
Do not install this appliance near a heater, inflammable material. Do not install this appliance in a
humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not
install this appliance in a location where gas may leak.
• Failing to do so may result in electric shock or fire.
CAUTION
Install the product on a hard and even place that can support its weight.
•If the place cannot support its weight, the product may fall down and it may cause product damage.
FOR POWER SUPPLY
WARNING
Do not bend or pull the power cord excessively. Do not twist or tie up the power cord.
• Failing to do so may result in electric shock or fire.
Safety Information
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 3 2019-05-16 오후 2:29:13

4
Safety Information
English
Safety Information
FOR OPERATION
WARNING
If the appliance generates a strange noise, a burning smell or smoke, unplug the product immediately
and contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
To reinstall the airconditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage, electric shock, or fire.
• A delivery service for the product is not provided. If you reinstall the product in another location,
additional construction expenses and an installation fee will be charged.
If the malfunction diagnosis indicator appears or malfunctions, then stop operation immediately.
•If you detect any burning smells from the product or it malfunctions, then immediately turn off the air
conditioner/Ventilator(ERV) and power, and then contact the service centre. Continuing to use the device in
this state can cause electrical shock, fire, or damage to the product.
•If the E836 indicator appears, then it means that it is time to contact the service centre for periodic
inspection. Neglecting these periodic inspections can result in malfunctions (only applicable to GHP model).
Do not attempt to repair, disassemble, or modify the product yourself.
• Failing to do so may result in electric shock, fire, product malfunction, or injury.
CAUTION
Do not allowwaterto enterthe product.
• Failing to do so may result in fire or explosion.
Do not operate the product with wet hands.
• Failing to do so may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the product.
•As well as being harmful to humans, it may also result in electric shock, fire, or product malfunction.
Do not give a strong impact to the product and do not disassemble the product.
Do not use this product for other purposes.
•This product is designed to be used only for a system air conditioner.
Do not press the buttons with any sharp objects.
• Failing to do so may result in electric shock or part damage.
FOR CLEANING
WARNING
Do not clean the product by spraying water directly onto it. Do not use benzene, thinner, alcohol or
acetone to clean the product.
• Failing to do so may result in discoloration, deformation, damage, electric shock, or fire.
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 4 2019-05-16 오후 2:29:14

5
English
Power Smart Features
You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan
speed, and air flow direction.
Use the and buttons to select the desired menu, press the button, use the , buttons to select
the desired item, and then press the button.
Remote Controller Operation
Power Smart Features
Operation modes
You can change the current mode to Auto, Cool, Dry, Fan, and Heat.
Controlling temperature
You can control the temperature in each mode as follows:
Mode Temperature control
Auto/Cool/Dry Adjust by 1 °C between 18 °C and 30 °C.
Fan You cannot control the temperature.
Heat Adjust by 1 °C between 16 °C and 30 °C.
NOTE
• The set temperature range available on the remote controller may change depending on the set
temperature range that indoor unit supports.
Controlling fan speed
You can select the following fan speeds in each mode:
Mode Available fan speeds
Auto/Dry Auto
Cool/Heat Auto, Turbo, High, Medium, Low
Fan Turbo, High, Medium, Low
NOTE
•Turbo appears active only on the indoor unit that supports the Turbo fan speed.
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 5 2019-05-16 오후 2:29:14

6
Remote Controller Operation
English
Power Smart Features
Controlling air flow direction
You can control air flow direction.
General models Fix, Swing, Swing, Swing, Individual
360 cassette model Spot, Mid, Wide, Swing 360, Individual
• For 360-cassette indoor unit
Mode Wired remote controller display Indoor unit indicator
Spot Spot
Mid Mid
Wide Wide
Swing Swing 360
• If 360-cassette indoor units and other indoor units are installed together, the air flow direction does not
change on the indoor units other than 360-cassette when Spot, Mid, or Wide is started as the air flow
direction.
•You can select individual air flow direction for each blade, when the individual indication appears active
on the indoor unit that supports this mode.
NOTE
• The displayed flow direction icon may differ depending on the indoor model.
• The current air flow direction persists even if you change the current mode, or turn off and then turn on
the remote controller.
•Blades that can be selected for Individual may differ depending on the product model.
• When Blade lock is set, the locked blade appears inactive.
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 6 2019-05-16 오후 2:29:15

7
English
Power Smart Features
Cool mode
Use the Cool mode to stay cool in hot weather.
NOTE
• It is recommended to set the desired temperature between 24 ℃ and 26 ℃.
• To cool your room quickly, select a low temperature and a high fan speed.
• To save energy, select a high temperature and a low fan speed.
• As the indoor temperature approaches the set temperature, the compressor will operate at a low speed
to save energy.
Wind-Free function
Use the Wind-Free function to enjoy mild cool breeze exuding from fine holes on the Wind-Free panel with
the air flow blade closed, instead of getting cool wind directly. The automated control of the temperature
and fan speed according to the indoor temperatures keeps your room cool and pleasant.
NOTE
•If the Wind-Free function is cancelled, the air conditioner returns to the previous fan speed.
• You can adjust the set temperature during the Wind-Free function, and recommended set temperatures are
24 to 26 °C. However, you cannot change the set temperature in the Fan mode.
•You can use the Wind-Free function when the Cool, Dry, or Fan mode is running.
• If the room temperature increases because of rise of external temperature, heat from cooking, or other
reason, operate normal cooling first to lower the temperature, before operating Wind-Free to keep the
desired temperature.
•If you select the Wind-Free function in the Fan mode, the compressor stops working so that cool air does
not come out. However, mild breeze comes out and starts to clean the air in the room.
•During the Wind-Free operation, the cold air may be intermittently weakened depending on the
temperature and humidity in the room. But the wind-free air currents are maintained and the weakened
cold air is immediately recovered, consequently keeping the room comfortable. (During the Wind-Free
operation, the air flow blades may open to control the indoor air condition smoothly, depending on
the installation settings. In this case, as soon as the indoor temperature and humidity change, the air
flow blades are closed and the Wind-Free operation restarts. For more information on the installation
settings, see “Setting the indoor unit addresses and the installation options” in the installation manual
of the indoor unit.)
Change of the airflow blade by temperature and humidity
Indoor
temperature
and humidity
Low High
Breeze is blown via the
micro holes on the air flow
blades
Breeze is blown via the micro
holes on the air flow blades
Breeze comes from the air
flow blade depending on the
setting
Air flow blade Closed Closed (default) Opened (according to setting)
• When the Wind-Free function runs while sleeping, you may feel cold air if the air conditioner is installed
over the bed. In this case, set the desired temperature higher than the normal setting temperature.
The smart and powerful cooling functions of the Samsung air conditioner keep an enclosed space
cool and comfortable.
Cooling Operation
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 7 2019-05-16 오후 2:29:15

8
Dehumidifying Operation
English
Power Smart Features
Dry mode
Use the Dry mode in rainy or humid weather.
NOTE
•You cannot change fan speed in the Dry mode.
• The greater the difference between room temperature and set temperature, the longer the needed time
to dehumidify the air is.
The dehumidifying function of the Samsung air conditioner keeps an enclosed space dry and comfortable.
Dehumidifying Operation
Purify function
Use the Purify function to remove harmful materials in the air to provide you a clean and healthy
environment.
This function is available in the Auto, Cool, Dry, Fan, and Heat modes.
NOTE
• During the Air Purifying operation, dust is collected on the active filter panel.
• When the Purify function is additionally selected in the Fan mode, you cannot change the set
temperature.
• When the Purify function is additionally selected while a specific mode is running, there is little
difference in electricity consumption and operating noise.
Air purity level indications
• The indications are displayed only on the models that support the air purity level display function.
• The air purity levels for PM10, PM2.5, and PM1.0 appear as follows:
Purity level PM10 PM2.5/PM1.0
Colour Concentration (μ/m³) Colour Concentration (μ/m³)
Very Poor Red 151 or more Red 76 or more
Poor Yellow 81-150 Yellow 36-75
Normal Green 31-80 Green 16-35
Good Blue 30 or less Blue 15 or less
• When you set Air Quality to ON, the screen saver displays the current air purity level details.
‒ You can set the screen saver launch time in Option > User mode.
• Air purity level can only be displayed on indoor units supporting this function.
The air purification function of the Samsung air conditioner keeps the air in an enclosed space purified.
Air Purifying Operation
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 8 2019-05-16 오후 2:29:16

9
English
Power Smart Features
Heat mode
Use the Heat mode to stay warm.
NOTE
• While the air conditioner warms up, the fan may not operate for a while at the beginning to prevent cold
wind.
• If the outdoor temperature is low and the humidity is high while the Heat mode is running, the heating
performance of the air conditioner may decrease due to frost or ice that forms on the outdoor heat
exchanger. When this condition happens, the air conditioner runs the Defrost function for about 5 to 12
minutes to remove the frost and ice, both water and steam are released from the outdoor unit.
• While the Defrost function is running, the indoor unit provides no breeze to prevent cold wind.
•The operation time of the Defrost function varies depending on the amount of the frost and ice and the
humidity.
• While the Defrost function is running, none of other functions will work, even if you select them on the
remote controller.
The heating functions of the Samsung air conditioner keep an enclosed space warm and comfortable.
Heating Operation
Auto mode
Use the Auto mode when you want the air conditioner to automatically control the mode (Heat or Cool). The
air conditioner will provide the most comfortable atmosphere that it can.
NOTE
•You cannot change the fan speed.
• While the Cool mode is running, the air conditioner produces a strong cold air if there is a large
difference between the set temperature and the current temperature. When the temperature difference
becomes small, the air conditioner automatically changes the air flow direction and keeps the room at a
comfortable temperature.
Fan mode
Use the Fan mode to run the air conditioner like a common fan. The air conditioner provides a natural breeze.
NOTE
• If the air conditioner will not be used for an extended period of time, dry the air conditioner by running it
in the Fan mode between 3 and 4 hours.
There is a variety of useful functionality provided by the Samsung air conditioner.
Quick Smart Features
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 9 2019-05-16 오후 2:29:16

10
English
Power Smart Features
Quiet function
Quiet function decreases the operation sound in the Auto, Cool, Dry, or Heat mode.
NOTE
• You can control the set temperature, fan speed, and air flow direction.
• When you select Quiet in Wind-Free or Long Wind function, the previous function is cancelled.
Sleep function
Sleep function automatically turns off the air conditioner after 6 hours without stopping the operation in the
middle of the night.
NOTE
•You can select this function only in the Cool and Heat modes.
• You can control the set temperature, fan speed, and air flow direction.
• When you select Sleep in Wind-Free or Long Wind function, the previous function is cancelled.
Long Wind function
Use the Long Wind function to quickly deliver a long reaching air flow.
NOTE
•You can select this function only in the Cool, Dry, and Fan modes.
• You cannot control the fan speed and air flow direction.
• When you select Long Wind in the Wind-Free, Quiet, or Sleep function, the previous function is cancelled.
Quick Smart Features
SOL 신규 유선리모컨 LCD 유럽향 IB_EN_DB68-08384A-00_Book_.indd 10 2019-05-16 오후 2:29:16
