Samsung PC1 WC Series User manual

Air conditioner
User manual
PC1*WC**N
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this user manual carefully and retain it for future reference.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX YWYXTW_TX_GGG㝘䟸G[aZ_aX[

2English
Safety Information 3
Safety Information 3
At a Glance 9
Indoor Unit Overview 9
Cleaning and Maintenance 11
Cleaning and Maintaining 11
Cleaning the indoor unit exterior • Cleaning the outdoor unit heat exchanger 11
Removing the air filter and air purification filter 12
Removing the deodorization filter 15
Cleaning the filters 16
Re-attaching the air filter and air purification filter 18
Resetting the filter • Technical specifications 21
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these
items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for
details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH,
WEEE, Batteries, visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGY YWYXTW_TX_GGG㝘䟸G[aZ_aX[

Safety Information
3
English
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models, the
characteristics of your air conditioner may differ slightly from those described in
this manual. If you have any questions, call your nearest contact centre or find
help and information online at www.samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut-off the power supply.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or higher
and use the power line for this appliance only. In addition, do not use an
extension line.
• Extending the power line may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or fire.
• If the voltage/frequency/rated current condition is different, it may cause fire.
Safety Information
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGZ YWYXTW_TX_GGG㝘䟸G[aZ_aX[

Safety Information
Safety Information
4English
The installation of this appliance must be performed by a qualified
technician or service company.
• Failing to do so may result in electric shock, fire, explosion, problems with
the product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material. Do
not install this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water (rain drops). Do not install this
appliance in a location where gas may leak.
• This may result in electric shock or fire.
This appliance must be properly grounded. Do not ground the appliance to
a gas pipe, plastic water pipe, or telephone line.
• Failure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
• Never plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
CAUTION
Install the drain hose properly so that water is drained correctly.
• Failing to do so may result in water overflowing and property damage.
Avoid adding drain to waste pipes as odours may arise in the future.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist or tie the
power line. Do not hook the power line over a metal object, place a heavy
object on the power line, insert the power line between objects, or push
the power line into the space behind the appliance.
• This may result in electric shock or fire.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG[ YWYXTW_TX_GGG㝘䟸G[aZ_aX\

Safety Information
5
English
CAUTION
When not using the air conditioner for a long period of time or during a
thunder/lightning storm, cut the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke,
unplug the power plug immediately and contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line. Do not touch the appliance
or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage,
electric shock, or fire.
• A delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
• Especially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to salt
in the air, please contact your nearest service centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the air conditioneroff with the circuit breakerwhile it is operating.
• Turning the air conditioner off and then on again with the circuit breaker
may cause a spark and result in electric shock or fire.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG\ YWYXTW_TX_GGG㝘䟸G[aZ_aX\

Safety Information
Safety Information
6English
After unpacking the air conditioner, keep all packaging materials well
out of the reach of children, as packaging materials can be dangerous to
children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the front panel with your hands or fingers during the heating
operation.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the outlet when the
air conditioner is operating or the front panel is closing.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not insert your fingers or foreign substances into the air inlet/outlet of
the air conditioner.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not strike or pull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near infirm people.
• Since this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
If any foreign substance such as water has entered the appliance, cut the
power by unplugging the power plug and turning the circuit breaker off
and then contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.)other than the
standard fuse.
• Failing to do so may result in electric shock, fire, problems with the
product, or injury.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG] YWYXTW_TX_GGG㝘䟸G[aZ_aX\

Safety Information
7
English
CAUTION
Do not place objects or devices under the indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Max current is measured according to IEC standard for safety and current
is measured according to ISO standard for energy efficiency.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the
appliance.
• As well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food,
animals, plants or cosmetics, or for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the air flow from the
air conditioner for long periods of time.
• This may result in harm to humans, animals or plants.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG^ YWYXTW_TX_GGG㝘䟸G[aZ_aX\

Safety Information
Safety Information
8English
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use
benzene, thinner, alcohol or acetone to clean the appliance.
• This may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the air conditioner
from the wall socket and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Do not clean the inside of the air conditioner by yourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the internal filter, refer to the descriptions in the ‘Cleaning
and Maintaining’ section.
• Failure to do may result in damage, electric shock or fire.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG_ YWYXTW_TX_GGG㝘䟸G[aZ_aX\

9
English
At a Glance
Ɵ˵ʪʒͱͱθЇϩɇʒϩϑʒϑΧɇцɇцͱͱϑ˝˵ϩцʒ˙˙ʪθʪϩ˙θͱϩ˵ʪЇϑϩθɇϩͱϑ˵ͱиɵʪͱиࡥʒʪΧʪʒ˝ͱϩ˵ʪ
ͱʒʪɇʒϩ˵ʪΧɇʪϩцΧʪ࢏Ɵ˵ʪΧЇθ˙ʀɇϩͱΧɇʪϑͱΧϩͱɇцϑϩɇʪʒϩͱΧЇθ˙цɇθɇʪʀͱϑʪʒϑΧɇʀʪ࢏
Indoor Unit Overview
02
03
01
05
06
04
01 Display
Indication Function
On/Off operation indicator
• Heat pump model: On
operation (blue)/Removing
frost (green) indicator
• Cooling only model: On
operation indicator
Timer indicator
Air purifying indicator
Filter cleaning indicator
02 Remote control sensor
03 Air purification level indicator
Pollution
level Colour
PM10
concentration
(急/m³)
Colour
PM2.5 / PM1.0
concentration
(急/m³)
Very poor Red 151 and over Red Above 76
Poor Yellow 81~150 Yellow 36~75
Moderate Green 31~80 Green 16~35
Good Blue 30 and below Blue Below15
• The concentration of PM/UFP may differ
depending on the environmental factors
to which the device is exposed, e.g., a
construction site, road side, fabric sofa,
vacuum cleaner, bedding, or clothes.
• The air purification level may increase in a
location with a fabric carpet, a veterinary
clinic or clothing store exposed to lots of hair,
a highly humid location, or a location where
there is smoke or many insects.
• The air purification level can be affected
by odorous household items, such as air
fresheners, deodorants, or detergents.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGG` YWYXTW_TX_GGG㝘䟸G[aZ_aX]

10 English
Indoor Unit Overview
At a Glance
• The device may continue to display a high air
purification level reading in an environment
where there is inflow of dust or outdoor air
(e.g., proximity to an HVAC/ventilation system
or draughty windows in the building).
• The PM/UFP levels are measured in real time
and may not match the values forecast by the
Ministry of Environment.
• The PM/UFP readings may increase
temporarily if the device is affected by
electromagnetic waves or electrical noise.
• If two devices are installed close to each
other, the devices may display different air
purification level readings depending on the
distance from the source of dust.
CAUTION
• Do not touch the purification filter during
the air purifying operation. This may result in
electric shock.
04 Air flow blade/Air outlet (inside)
05 Wind-Free panel (You can use the Wind-Free
Cooling function when the Cool, Dry, or Fan
mode is running. Refer to the remote control
manual.)
06 Air intake/Air filter (inside)
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGXW YWYXTW_TX_GGG㝘䟸G[aZ_aX]

11
English
Cleaning and Maintenance
Before cleaning the indoor unit, be sure to turn off the auxiliary power switch.
Cleaning and Maintaining
Cleaning the indoor unit exterior
Wipe the surface of the unit with a slightly wet
or dry cloth when needed. Wipe off dirt of odd-
shaped areas by using a soft brush.
CAUTION
• Do not use alkaline detergent, sulphuric
acid, hydrochloric acid, or organic solvents
(such as thinner, kerosene, and acetone) to
clean the surfaces.
• Do not attach any stickers on the surfaces
because this may cause damage.
• When you clean the heat exchanger on the
indoor unit, you need to disassemble the
indoor unit. Therefore, you must contact the
local service center for help.
Cleaning the outdoor unit heat exchanger
Spray water to clean the dust.
CAUTION
• The heat exchanger of the outdoor unit has
sharp edges. Take care when cleaning its
surface.
NOTE
• If it is difficult to clean the heat exchanger
of the outdoor unit, contact the local service
center.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGXX YWYXTW_TX_GGG㝘䟸G[aZ_aX^

12 English
Cleaning and Maintaining
Cleaning and Maintenance
Removing the air filter and air purification filter
PC1MWC**N
PUSH
Press the ťЇϑ˵ signs on the front panel, then
open the grille.
ťθʪϑϑϩ˵ʪ࣑࣒ϑ˝ϑͱϩ˵ʪɇθ˙ϩʪθ࢏
Grab the handle of the air filter and pull it out
from the indoor unit with your hand.
²ɇʒʪϑͱ˙ϩ˵ʪɇθΧЇθ˙ʀɇϩͱ˙ϩʪθ Remove the air purification filter by pulling its
two handles, then remove the safety hook.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGXY YWYXTW_TX_GGG㝘䟸G[aZ_aX`

13
English
Cleaning and Maintenance
PC1NWC**N
PUSH
Press the Push signs on the front panel, then
open the grille.
Press the Push signs on the air filter.
Grab the handle of the air filter and pull it out
from the indoor unit with your hand.
Remove the air purification filter by pulling its
two handles, then remove the safety hook.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGXZ YWYXTW_TX_GGG㝘䟸G[aZ_aYX

14 English
Cleaning and Maintaining
Cleaning and Maintenance
PC1BWC**N
PUSH
Press the Push signs on the front panel, then
open the grille.
Press the Push signs on the air filter.
Grab the handle of the air filter and pull it out
from the indoor unit with your hand.
Remove the air purification filter by pulling its
two handles, then remove the safety hook.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX[ YWYXTW_TX_GGG㝘䟸G[aZ_aYZ

15
English
Cleaning and Maintenance
Removing the deodorization filter
WARNING
• Do not wash the deodorization filter with water.
– Water can damage the filter.
• If the filter replacement cycle is exceeded, odors may be emitted. Replace the filter according to
the cycle.
PC1MWC**N Remove the deodorization filter from the air
filter.
PC1NWC**N Remove the deodorization filter from the air
filter.
PC1BWC**N Remove the deodorization filter from the
indoor unit.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX\ YWYXTW_TX_GGG㝘䟸G[aZ_aYZ

16 English
Cleaning and Maintaining
Cleaning and Maintenance
Aʪɇ˝ϩ˵ʪ˙ϩʪθϑ
Cleaning the air filter
Aʪɇϩ˵ʪɇθ˙ϩʪθиϩ˵ɇЭɇʀЇЇʀʪɇʪθͱθϑͱ˙ϩ
ɵθЇϑ˵࢏Ã˙ʒЇϑϩϑϩͱͱ˵ʪɇЭцࡥϩ˵ʪθϑʪϩиϩ˵
θЇ˝иɇϩʪθɇʒʒθцϩɇЭʪϩɇϩʪʒɇθʪɇ࢏
CAUTION
࡛ UͱͱϩϑʀθЇɵϩ˵ʪɇθ˙ϩʪθиϩ˵ɇɵθЇϑ˵ͱθͱϩ˵ʪθ
ʀʪɇ˝Їϩʪϑ࢏Ɵ˵ϑɇцʒɇɇ˝ʪϩ˵ʪ˙ϩʪθ࢏
Leave it for more than 12 hours in shade to
completely dry it.
NOTE
• Clean the air filter once every two weeks
(on an 8-hour daily use basis).
NOTE
࡛ Ɵ˵ʪʀʪɇ˝Χʪθͱʒɇцʒ˙˙ʪθʒʪΧʪʒ˝ͱϩ˵ʪЇϑɇ˝ʪɇʒʪЭθͱʪϩɇʀͱʒϩͱϑࡥϑͱʀʪɇ
ϩ˵ʪɇθ˙ϩʪθʪЭʪθциʪʪ˙ϩ˵ʪʒͱͱθЇϩϑϩ˵ʪʒЇϑϩцɇθʪɇ࢏
࡛ Aʪɇϩ˵ʪʒͱͱθЇϩʪуϩʪθͱθи˵ʪʀʪɇ˝ϩ˵ʪ˙ϩʪθϑ࢏
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX] YWYXTW_TX_GGG㝘䟸G[aZ_aYZ

17
English
Cleaning and Maintenance
Cleaning the air purification filter
Neutral
detergent
Clean the filter as follows: Immerse it for about 30
minutes in lukewarm waterwith neutral detergent
diluted and shake it up/down several times.
CAUTION
• When cleaning the air purification filter,
exercise caution to ensure that your hand is
not cut by the sharp edges of the filter.
NOTE
• Wash the air purification filter without
disassembling it.
• Noise may occur if any large-size dust is
present in the air purification filter.
Leave it for more than 12 hours in shade to
completely dry it.
NOTE
• The cleaning cycle of the air purification filter
is six months (on an 8-hour daily use basis).
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX^ YWYXTW_TX_GGG㝘䟸G[aZ_aYZ

18 English
Cleaning and Maintaining
Cleaning and Maintenance
Re-attaching the air filter and air purification filter
PC1MWC**N
Attach the air purification filter.
When attaching the air purification filter, push
it until a click sound is heard.
Engage the safety hook.
CAUTION
• Noise may occur if the air purification filter is
not attached properly.
Attach the deodorization filter to the air filter.
NOTE
• Attach a new deodorization filter after
removing its package.
Attach the air filter.
When attaching the air filter, use its handles
ɇθʪʒиϩ˵࣑࣒ϩͱʪ˝ɇ˝ʪϩϩͱϩ˵ʪ˵ͱͱϑ࢏
Attach the grille.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX_ YWYXTW_TX_GGG㝘䟸G[aZ_aY]

19
English
Cleaning and Maintenance
PC1NWC**N
Attach the air purification filter.
When attaching the air purification filter, push
it until a click sound is heard.
Engage the safety hook.
CAUTION
• Noise may occur if the air purification filter is
not attached properly.
Attach the deodorization filter to the air filter.
NOTE
• Attach a new deodorization filter after
removing its package.
Attach the air filter.
Attach the grille.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGX` YWYXTW_TX_GGG㝘䟸G[aZ_aY_

20 English
Cleaning and Maintaining
Cleaning and Maintenance
PC1BWC**N
Attach the air purification filter.
When attaching the air purification filter, push
it until a click sound is heard.
Engage the safety hook.
CAUTION
• Noise may occur if the air purification filter is
not attached properly.
Attach the deodorization filter to the indoor unit.
NOTE
• Attach a new deodorization filter after
removing its package.
Attach the air filter.
Attach the grille.
ki]_TW`[W\hTWXpizzG~GmGXGhGGwl|luUGGGYW YWYXTW_TX_GGG㝘䟸G[aZ_aZW
