Samsung MIM-B16N User manual

PIM(Pulse Input Module)
MIM-B16N
Air Conditioner
installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 1 2016-10-19 오후 3:19:22

Contents
Before installation
Safety Precautions ..........................................................................................................3
Accessories .................................................................................................................4
Viewing the Parts ...........................................................................................................5
PIM System Architecture ....................................................................................................8
Installing the product
Installing the PIM ...........................................................................................................9
Setting the PIM ...........................................................................................................15
PIM Menu Description.....................................................................................................16
English-2
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 2 2016-10-19 오후 3:19:22

Safety Precautions
This installation manual describes how to install the PIM. For installation of other optional accessories, refer to the appropriate
installation manual.
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage.
WARNING
 Read carefully this installation manual before installation and check if the PIM is installed correctly after installation.
 Do not attempt to install or repair this PIM by yourself.
 This PIM contains no user-serviceable parts.
Always consult authorized service personnel for repairs.
 When moving, consult authorized service personnel for disconnection and installation of the PIM.
 Ensure that the wall is strong enough to support the weight of the PIM.
 Must install the PIM with rated power supply.
 The PIM must be installed according to the national electrical rules by an installation specialist.
 If you wish to uninstall the PIM, consult an authorized installation center.
CAUTION
 Do not use inammable gases near the PIM.
 Do not install the PIM in a location where it will come into contact with combustible gases, machine oil, sulphide gas, etc.
 Avoid locations where acid/alkali solution or special spray is used.
 Choose a location that is dry and sunny, but not exposed to direct sunlight. Suitable temperature is between 0°C(32°F)
and 39°C(102.2°F).
 Do not spill water into the PIM.
 Do not apply tensile strength to the cable to avoid cable damage.
 Do not press the buttons with a sharp object.
 Do not connect the power cable to the control terminal.
 If the PIM is installed in a hospital or other special places, it should not aect other electronic devices.
English-3
BEFORE INSTALLATION01
Before installation
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 3 2016-10-19 오후 3:19:22

Accessories
Make sure you have each item. Supplied items may vary depending on your country or service provider.
The type and quantity may dier depending on the specications.
Item PIM Adapter Power cable M4x16 Screw Installation
manual Cable tie
Quantity 1 1 1 6 1 1
Shape
• The PIM must be installed by a trained installer.
• Ensure the main power is turned o before installing the PIM.
• Be sure to use adapter and power cable we provide.
• The power cable and the communication cable must be installed according to the national electrical wiring
regulations. (Use 2C x 0.75mm2communication cable.)
CAUTION
English-4
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 4 2016-10-19 오후 3:19:22

Viewing the Parts
Main Parts
PIM Exterior
LCD Display
Shows current time and consumption
by channel.
Various menus will be displayed
depending on button input.
LCD Operation button
There are 4 buttons [Menu, (Down), (Up), Set]
and you can access, move and check the menu.
LED Indicator
Checks the status using 14 LEDs such as Power,
COM1 TX/RX, Signal, COM2 TX/RX and Check.
PIM Bottom cover
Unfasten 2 screws on the bottom and
separate the bottom cover from PIM. Then
check cable connection part.
Explanation of LED Indicator
Item Name Status
Power Power indicator Turns blue when the power is supplied.
COM1 TX/RX Data transmission/reception with DMS
indicator
Blinks in orange during the normal transmission/
reception.
Signal (1)~(8) Input pulse indicator Blinks in orange when a normal pulse is input from
the meter.
COM2 TX/RX Reserved Reserved
Check Error indicator Blinks in orange when the error occurs. (It will be o
when the error is cleared.)
English-5
BEFORE INSTALLATION01
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 5 2016-10-19 오후 3:19:22

Viewing the Parts
PIM Cable Connection Part
Cable groove
Power terminal
Reset button
Pulse input terminal
(Channel 1~4)
RS485 communication terminal
(COM1, COM2)
Pulse input terminal
(Channel 5~8)
Name Description
Pulse input terminal
(CH1~CH8)
Terminal that the pulse from Meter is inputted
(Channel1~Channel8)
Dry contact must be connected.
Power terminal Terminal to connect PIM adapter
Reset button Button used to reset PIM
RS485 Communication terminal COM1: Connection terminal for RS485 communication with DMS
COM2 : Not in use (It will be used for MODBUS in the future)
Cable groove Groove for arranging cables
English-6
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 6 2016-10-19 오후 3:19:23

PIM Interior
LED Display board
40-pin cable
20-pin cable
Main board
Sub board
Product Dimensions
240
255
64.8 (Unit : mm)
English-7
BEFORE INSTALLATION01
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 7 2016-10-19 오후 3:19:24

PIM System Architecture
DMS
PIM
Meter
Meter
(max. 8 units)
ROOM 0 ROOM 1 ROOM 2
Outdoor Unit
Pulse input
 Maximum 8 PIM units can be connected to DMS.
 Maximum 8 meter(Power/Gas/Water) can be connected to PIM.
English-8
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 8 2016-10-19 오후 3:19:24

Installing the PIM
Installing the PIM on the Wall
1. Separate the installation plate on the rear side of PIM.
2. Fix the installation plate on the wall using 4 screws.
3. Hang the PIM on the groove which is on the top of the installation plate.
Installation
plate
4. Open the bottom cover and x the installation plate and PIM using 2 screws.
- Depending on the installation environment, open the top cover and x PIM
using assistant holes. (Screws for assistant hole are not provided.)
Assistant hole
5. If you install PIM inside of the wall or wiring from the rear side is needed, use
wiring groove on the bottom of PIM.
Wiring groove
• To prevent breakdown and damage of PIM and for safe usage, it is recommended to install PIM on the wall.
CAUTION
English-9
INSTALLING THE PRODUCT02
Installing the product
MIM-B16N_PIM_IM_DB68-04502A-03_EN.indd 9 2016-10-19 오후 3:19:25

Installing the PIM
Connecting a Meter, PIM and DMS
Connecting a Meter and PIM
1. Unfasten the 2 screws on the bottom of the PIM front cover. Hold the bottom
2sides of the PIM and push downwards to slide open the cover.
2. Connect the adapter to the power terminal.
- Arrange the adapter as shown in the gure.
Adapter
3. Connect PIM and a Meter as many as you want. In this step, use communication
cable and 8 terminal blocks which are attached to the pulse input terminal of
PIM.
- For the communication cable connection instruction of a Meter or additional
setting instruction, refer to the installation manual of a Meter.
- Connect the communication cable considering the polarity. [Left:(+), Right:(-)]
Connect
communication
cable
Meter
(+) (-)
• Maximum 8 meter(Power/Gas/Water) can be connected to 1 PIM.
• Use 2Cx0.75mm2communication cable.
CAUTION
English-10
