Samsung PC4NUNMAN User manual

Air conditioner
Installation manual
PC4NUDMAN / PC4NUNMAN / PC4NBDMAN / PC4NBNMAN
•Thank you for purchasing this Samsung air conditioner.
•Before operating this unit, please read this manual carefully and retain it for future
reference.
360_AC_Panel_ENG_EN.indb 1 2016-03-15 오후 3:20:22

2English
Installation
360 cassette panels
Type A: Square panel Type B: Circular panel
Accessories
Item M4 screw Installation manual
Quantity 4 1
Shape
CAUTION
• After installing the product, be sure to explain to the
user how to use the air conditioner.
NOTE
• Tightening torque for the M4 screw: 1.2 to 1.8 N•m
(140 to 180 kgf•cm)
Installing the grille inlet for the
ceiling type and open type
1 Hook the two hook wires of the grille inlet onto the
two wire hooks on the indoor unit body.
CAUTION
• When servicing the product or replacing parts such as
motors and gears, be sure to remove the front grille
first. Failing to do so may cause the hook wires to
unhook and the front grille to drop on the floor.
• Be sure to check the letters for the wire hooks printed
on the indoor unit body and hook the hook wires
onto the specified positions.
2 Rotate the grille inlet clockwise until it is assembled
firmly in place.
NOTE
• When the grille inlet is installed correctly, the indoor
unit display is placed perpendicular to the Samsung
logo printed on the grille inlet.
English
360_AC_Panel_ENG_EN.indb 2 2016-03-15 오후 3:20:23

3English
English
Installing the panel front for the
ceiling type
1 Remove the four cover panels from the panel front.
NOTE
• To remove the cover panels, use the two tongues at
the ends of each cover panel.
2 Push the four corners of the panel front toward the
indoor unit body one at a time until you hear “click”
so that they are assembled in place.
NOTE
• After assembling the panel front in place, you can
slightly adjust its position left and right. If required,
adjust the position of the panel front so that it aligns
with the ceiling opening.
3 Push the centres of the four sides of the panel front
toward the indoor unit body one at a time until you
hear “click” so that they are hooked in place.
4 Insert halfway the four screws into the four holes on
the panel front. Then fasten the screws tightly until
there is no gap between the ceiling and the panel
front.
5 Place each cover panel on a corner of the panel front.
Then push the cover panel upward until it is firmly
assembled to the panel front.
6 Check whether the panel front is firmly fixed to the
indoor unit body.
NOTE
• Make sure that the screws are fastened tightly until
there is no gap between the ceiling and the panel.
• If the panel is installed incorrectly, air may leak out.
360_AC_Panel_ENG_EN.indb 3 2016-03-15 오후 3:20:28

4English
Installing the circular panel on the
indoor unit
1 Insert the decoration panel the indoor unit body.
Then rotate the decoration panel clockwise until it is
assembled firmly.
• Ceiling type
• Open type
NOTE
• Make sure that the panel is assembled firmly: rotate
the decoration panel until you feel that it is clamped
by the internal structure.
2 Check whether the decoration panel firmly fixed to
the indoor unit body.
NOTE
• Make sure that the decoration panel is installed
correctly so that there is no gap between the ceiling
and the panel.
• If the panel is installed incorrectly, air may leak out.
CAUTION
• Make sure to only apply paints and
varnishes for resins (ABS, HIPS) or paint
thinners.
If you apply lacquers for general use on
the panel, it may lead to discoloration or
erosion on the surface of the panel.
Installation
360_AC_Panel_ENG_EN.indb 4 2016-03-15 오후 3:20:29

SERViS iSTASYONLARI GÖSTERiR LiSTE
İTHALATÇI/İMALATÇI-ÜRETİCİ FİRMANIN
1
ÜNVANI SAMSUNG ELECTRONICS ISTANBUL PAZ.VE TİC.LİMİTED
ŞİRKETİ LTD. ŞTİ.
2
MERKEZ ADRESİ FLAT OFİS İSTANBUL İŞ MERKEZİ OTAKÇILAR CAD.NO:78K:3
NO:B3 EYUP
3
TELEFON [phone]
4
FAKS 0212 4378528
6
TİCARET SİCİL NO 629388
8
VERGİ NO 7420397337
1
Servis Adi AHMET DOĞRUDAĞ-DOĞUŞ ELEKTRONİK
Yetkili Ad Soyad
Vergi Dairesi TOPÇU MEYDANI
Vergi No 66274209310
Telefon No 904142153076
HYB No 63-HYB-14
Adres HAMİDİYE MAH.263.SOK.RÜMEYSA APT ALTI NO:27/A
Şehir ŞANLIURFA
2Servis Adi AK GÜVEN SOĞUTMA-ALİ YILDIZ
Yetkili Ad Soyad
Vergi Dairesi İSTİKLAL VERGİ DAİRESİ
Vergi No 9600318189
Telefon No 03243286260
HYB No 33-HYB-400
Adres BAHÇELİEVLER MH. HÜSEYİN OKAN MERZECİ BLV. NO:476/A .
Şehir MERSİN
3Servis Adi ATEŞ ELEKTRONİK - ÖZCAN ATEŞ
Yetkili Ad Soyad
Vergi Dairesi ARDA
Vergi No 34609345408
Telefon No 02842352837
HYB No 59-HYB-770
Adres FATİH MAH. İBRAHİM AY CAD. PEMBE KÖŞK APT. NO:1 /
EDİRNE
Şehir EDİRNE
4Servis Adi AYTEK ÇINAR-ŞAFAK KOÇ-ÜMİT TELLAL ORTAKLIĞI/BİRLİK
TEKNİK ORTALIĞI
Yetkili Ad Soyad
Vergi Dairesi GÖNEN
Vergi No 2510299103
Telefon No 02667627811
HYB No 10-HYB-867
Adres MALKOÇ MAHALLESİ MÜFTİ ŞEVKET CADDESİ NO:60/D /
GÖNEN
Şehir BALIKESİR
5Servis Adi BAŞARAN TEKNİK SERVİS-MEHMET BAŞARAN
Yetkili Ad Soyad
Vergi Dairesi SERİK
Vergi No 14257579684
Telefon No 0242.7220548
HYB No 07-HYB-531
Adres KÖKEZ MAHALLESİ BURMAHANCI CADDESİ No:104/C
Şehir ANTALYA
6Servis Adi BAYRAK ELEKTRONİK TAMİR BAKIM HİZMETLERİ SAN.TİC.LTD.ŞTİ.
Yetkili Ad Soyad
Vergi Dairesi GAZİLER
Vergi No 1550544868
Telefon No 903624316480
HYB No 55-HYB-292
Adres 19 MAYIS MAH.AĞABALİ CAD. NO:38 İLKADIM/ SAMSUN
Şehir SAMSUN
7Servis Adi BERK SERVİS HASAN BAYRAKTAR
Yetkili Ad Soyad
Vergi Dairesi İLYASBEY
Vergi No 10743028780
Telefon No 902626414565
HYB No 34-HYB-2952
Adres - KIZILAY CD.1201/2 SK. - NO:1/C
Şehir KOCAELİ
8Servis Adi EKREM MANDAL-GÜVEN TEKNİK
Yetkili Ad Soyad
Vergi Dairesi BEYDAĞI V.D.
Vergi No 6120003243
Telefon No 904223242145
HYB No 44-HYB-45
Adres UÇBAĞLAR MAH.YUNUS EMRE CAD.NO:25
Şehir MALATYA
9Servis Adi EMİR ELEKTRONİK-SECATTİN AYLANÇ
Yetkili Ad Soyad
Vergi Dairesi ERZURUM
Vergi No 12596155408
Telefon No 0442 237 37 01
HYB No 25-HYB-223
Adres GEZ MAH. ÇAYKARA CAD. NO:44/14
Şehir ERZURUM
10 Servis Adi EM-TA TEKNİK-EMRAH KORUYUCU
Yetkili Ad Soyad
Vergi Dairesi OSMANİYE
Vergi No 5800184379
Telefon No 903288125766
HYB No 01-HYB-3166
Adres 7 OCAK MAH. D. AHMET ALKAN CAD. NO:132/C . / MERKEZ
Şehir OSMANİYE
11 Servis Adi ENVER TURKUT - TURKUT TEKNİK
Yetkili Ad Soyad
Vergi Dairesi DÜDEN
Vergi No 20410577534
Telefon No 0242.3442333
HYB No 07-HYB-253
Adres GÜVENLİK MAHALLESİ 267. SOKAK No:16 A/A MURATPAŞA /
ANTALYA
Şehir ANTALYA
12 Servis Adi FATİH TÜRK - HAZAR SOĞUTMA
Yetkili Ad Soyad
Vergi Dairesi SİVRİCE
Vergi No 39784205288
Telefon No 904242186621
HYB No 23-HYB-226
Adres RÜSTEM PAŞA MH. HACI HAYRİ CD. NO:100/E
Şehir ELAZIĞ
13 Servis Adi GARANTİ SERVİS DAYANIKLI TÜKETİM MALLARI PAZARLAMA
SERVİS HİZMETLERİ SANAYİ VE TİCARET LTD. ŞTİ.
Yetkili Ad Soyad
Vergi Dairesi GAZİOSMANPAŞA
Vergi No 3890693692
Telefon No 0212 6250625
HYB No 34-HYB-4664
Adres ALİBEYKÖY GÜZELTEPE MAHALLESİ AVCI SOKAK NO.8/B EYÜP
Şehir İSTANBUL
14 Servis Adi GENERAL SOĞUTMA-HALİL ABBASOĞLU
Yetkili Ad Soyad
Vergi Dairesi KİLİS
Vergi No 0010358834
Telefon No 905442754211
HYB No 27-HYB-4201
Adres
ALTINÜZÜM MAHALLESİ NEMİKA CADDESİ No:73 A/Z1 / KİLİS
MERKEZ
Şehir KİLİS
15 Servis Adi GÖKSEL SARFAKLAR
Yetkili Ad Soyad
Vergi Dairesi KARESİ
Vergi No 34540021010
Telefon No 02662447072
HYB No 10-HYB-528
Adres HACI İLBEY MAH. ANAFARTALAR CAD. NO:80/A
POSTAKODU:10100 ALTIEYLÜL/BALIKESİR
Şehir BALIKESİR
[SETK] Card Information_6801-002234-01_B5.indd 1 2017-11-09 오후 1:00:48

16 Servis Adi Hakan GÜZEL - ÖZKA ELEKTRONİK
Yetkili Ad Soyad
Vergi Dairesi BİSMİL
Vergi No 4530610193
Telefon No 04124152111
HYB No 21-HYB-3322
Adres ALTIOK MAHALLESİ, İSMAİL BEŞİKÇİ CADDESİ, JİYAN 3
APARTMANI ALTI 87/B / BİSMİL
Şehir DİYARBAKIR
17 Servis Adi İKLİM SOĞUTMA-NİLÜFER ALIÇ
Yetkili Ad Soyad
Vergi Dairesi MUT
Vergi No 52639093434
Telefon No 03247745503
HYB No 33-HYB-923
Adres PINARBAŞI MAHALLESİ ATATÜRK BULVARI No:61/C / MUT
Şehir MERSİN
18 Servis Adi MAVİAY MÜHENDİSLİK MAKİNE İNŞAAT ELEKTRONİK SANAYİ
VE TİCARET LİMİTED ŞİRKETİ
Yetkili Ad Soyad
Vergi Dairesi pamukkale
Vergi No 6130692275
Telefon No 02582620009
HYB No 20-HYB-1221
Adres Merkezefendi Mahallesi 29 Ekim Bulvarı No:37/A Maviay İş
Merkezi Merkezefendi/Denizli / DENİZLİ
Şehir DENİZLİ
19 Servis Adi MEHMET ALKAYA HİZMET ELEKTRONİK TEKNİK SEVİSİ
KAYAPINAR ŞUBESİ
Yetkili Ad Soyad
Vergi Dairesi GÖKALP
Vergi No 0540127437
Telefon No 04122575172
HYB No 21-HYB-3383
Adres
MEDYA MAHALLESİ 153.SOKAK SEÇKİN SİTESİ ALTI 5/A /41 / KAYAPINAR
Şehir DİYARBAKIR
20 Servis Adi NAİLE KABASAKAL
Yetkili Ad Soyad
Vergi Dairesi nazilli
Vergi No 22279368582
Telefon No 02563136266
HYB No 09-HYB-588
Adres ALTINTAŞ MAHALLESİ FEVZİ ÇAKMAK CADDESİ NO:22/A
NAZİLLİ/AYDIN / NAZİLLİ
Şehir AYDIN
21 Servis Adi NECMİ GÜRALP ÖZCAN GÜRALP MÜHENDİSLİK
Yetkili Ad Soyad
Vergi Dairesi ZİYAPAŞA
Vergi No 6710098948
Telefon No 903224540680
HYB No 01-HYB-2994
Adres GAZİPAŞA MH. BORSA CAD. BORSA APT.NO:32/F
Şehir ADANA
22 Servis Adi PINAR ELEKTRONİK
Yetkili Ad Soyad
Vergi Dairesi İSTİKLAL
Vergi No 8210021023
Telefon No 0 324 336 8298
HYB No 33-HYB-21
Adres MAHMUDİYE MAH.108 SOK.NO:32/B
Şehir MERSİN
23 Servis Adi SALİHLİ TEKNİK-TİMUR ACAR Esnaf
Yetkili Ad Soyad
Vergi Dairesi ADİL ORAL
Vergi No 25850289290
Telefon No 05542154699
HYB No 45-HYB-725
Adres CUMHURİYET MH. ESKİ MANİSA YOLU NO: 87 TURGUTLU/
Şehir MANİSA
24 Servis Adi SAMTİT ELEKTRİK ELEKTRONİK BİLİŞİM DAYANIKLI TÜKETİM
MALLARI SANAYİ VE TİCARET LTD. ŞTİ.
Yetkili Ad Soyad
Vergi Dairesi SELÇUK
Vergi No 7420421584
Telefon No 03322388484
HYB No 42-HYB-1352
Adres MUSALLA BAĞLARI MAH. TELGRAFÇI HAMDİBEY CAD. NO:10
/ SELÇUKLU
Şehir KONYA
25 Servis Adi SİMGE ELEKTRONİK-YAŞAR ALAR
Yetkili Ad Soyad
Vergi Dairesi YILDIRIM BEYAZIT
Vergi No 55804106610
Telefon No 0312 3251876
HYB No 06-HYB-84
Adres ETLİK MAH. YENİ ETLİK CAD. NO:205/ A
Şehir ANKARA
26 Servis Adi SİSTEM GURUP ELEKTRONİK TİCARET VE TAAHHÜT LTD. ŞTİ.
Yetkili Ad Soyad
Vergi Dairesi MALTEPE
Vergi No 7710312272
Telefon No 903122120143
HYB No 06-HYB-2185
Adres
ETİ MAH.GAZİ MUSTAFA KEMAL BULVARI NO.104/A ÇANKAYAANKARA
Şehir ANKARA
27 Servis Adi STAR ELEKTRONİK SERVİS HİZMETLERİ-MEHMET YILMAZ
Yetkili Ad Soyad
Vergi Dairesi KARADENİZ
Vergi No 13664938404
Telefon No 904623216224
HYB No 61-HYB-1084
Adres İNÖNÜ MAH. YAVUZ SELİM BULVARI YAVUZ SELİM APARTMANI
NO.164/A / ORTAHİSAR
Şehir TRABZON
28 Servis Adi UFUK NEBİ TEMEL
Yetkili Ad Soyad
Vergi Dairesi ERGANİ
Vergi No 17482883854
Telefon No 04126112043
HYB No 21-HYB-3333
Adres ADNAN MENDERES MAHALLESİ YENİ HAL CADDESİ, SOKAK
1/1 / ERGANİ
Şehir DİYARBAKIR
29 Servis Adi ÜN SOĞUTMA-AKİF ÜN
Yetkili Ad Soyad
Vergi Dairesi DÖRTYOL
Vergi No 31831635246
Telefon No 0326 712 38 09
HYB No 31-HYB-28
Adres YEŞİL MAH. ATATÜRK CD.KERVAN SOK.NO:4
Şehir HATAY
30 Servis Adi WEGA ELEKTRONIK SACIT SEN
Yetkili Ad Soyad
Vergi Dairesi ÇORLU
Vergi No 62722092022
Telefon No 282-653 82 81
HYB No 59-HYB-362
Adres CAMIATIK MAH. ÇALISKAN SOKAK NO. 8/A ÇORLU
Şehir TEKİRDAĞ
31 Servis Adi YUSUF KEMİK - MEGA TEKNİK SERVİS
Yetkili Ad Soyad
Vergi Dairesi GAZİKENT
Vergi No 5440343766
Telefon No 03423381070
HYB No 27-HYB-1012
Adres İNCİLİPINAR MAH. MUAMMER AKSOY BLV. KEPKEP PLAZA İŞ
MRK. ALTI NO: 8 ŞEHİTKAMİL /
Şehir GAZİANTEP
SERViS iSTASYONLARI GÖSTERiR LiSTE
Belirtilen Servis Merkezleri iletişim bilgileri 02.06.2017 tarihinde güncellenmiştir ve bu tarihten sonra değişiklik gösterebilir. Bilgilere istinaden,
bölgenizdeki servis merkezlerimize ulaşamadığınız durumlarda 444 77 11 numaralı Çağrı Merkezimizden size en yakın Servis Merkezimizi öğrenebilirsiniz.
[SETK] Card Information_6801-002234-01_B5.indd 2 2017-11-09 오후 1:00:48

Memo
English
360_AC_Panel_ENG_EN.indb 5 2016-03-15 오후 3:20:29

This product is RoHS compliant.
360_AC_Panel_ENG_EN.indb 6 2016-03-15 오후 3:20:29
