Samsung SH09BPD User manual

INDOOR UNIT
SH09BPD
SH12BPD
OUTDOOR UNIT
SH09BPDX
SH12BPDX
SERVICE Manual
CONTENTSAIR CONDITIONER
1. Product Specifications
2. Operating Instructions
3. Disassembly and Reassembly
4. Refrigerating Cycle Diagram
5. Set Up the Model Option
6. Troubleshooting
7. Exploded Views and Parts List
8. PCB Diagram
9. Wiring Diagram
ROOM AIR CONDITIONER
DB98_00000A(1)_co 1/29/04 4:58 PM Page 3

1Samsung Electronics
1. Product Specifications
1-1 Table
Model
Item SH12BPD
SH12BPDX
Power Source ø-V-Hz
Capacity W
BTU/h
Energy Efficiency Ratio BTU/wh
Air Flow m3/min
Moisture Removal \/h
Noise Level Indoor dBA
Noise Level Outdoor
Capacity W
BTU/h
Energy Efficiency Ratio BTU/wh
Air Flow m3/min
Noise Level Indoor dBA
Noise Level Outdoor
Available Voltage Range V
Running Amperes A
Power Input W
Power Factor %
Running Amperes A
Power Input W
Power Factor %
Starting Current A
Fuse Capacity A x V
Power Cord A x V
Cable-Connector mm3 x G
Type -
Model Name -
Safety Devices -
Model Name -
Running Capacitor µF x VAC
Model Name -
Running Capacitor µF x VAC
Refrigerant Tube EEV
Refrigerant to Charge (R410A) g
Dimension Indoor unit : W x H x D mm
Outdoor unit : W x H x D mm
Weigth Indoor unit kg
Outdoor unit kg
1-220/240-50
2,800(1,500~3,400)
9,500(5,100~11,600)
11.8(10.0~13.8)
7.0
1.5
34
53
3,200(1,500~4,500)
10,900(5,100~15,300)
13.6(10.2~14.6)
8.2
39
53
187~264
3.6(2.0~4.9)
800(370~1,150)
96.6(84.5~97.6)
4.0(1.8~6.5)
800(350~1,500)
95.6(81.8~98.6)
10↓
3.15 x 250 / 20 x 250
15 x 250
1.5 x 4
Single Rotary
G4C090LU2ER
204CT
YDK-204F8C-1
1.2µF / 450V
AMASS-020WTVB
1.7µF / 450V
UKV-18D11
900
890 x 285 x 179
762 x 532 x 280
8.5
39.5
1-220/240-50
3,500(1,500~4,000)
11,900(5,100~13,600)
10.9(10.2~13.8)
9.0
1.6
39
53
4,000(1,500~5,000)
13,600(5,100~17,000)
11.6(10.0~14.6)
9.3
42
53
187~264
4.8(2.0~5.9)
1,090(370~1,330)
98.0(82.3~98.7)
5.5(1.8~7.2)
1,170(350~1,700)
97.8(81.8~98.4)
10↓
3.15 x 250 / 20 x 250
15 x 250
1.5 x 4
Single Rotary
G4C090LU2ER
204CT
YDK-204F8C-1
1.2µF / 450V
AMASS-020WTVB
1.7µF / 450V
UKV-18D11
950
890 x 285 x 179
762 x 532 x 280
8.5
39.5
Com-
pressor
Fan
Motor
Electrical
Rating
Cooling
Indoor
Outdoor
Cooling
Heating
Heating
Perfor-
mance
Remark : Text condition Indoor room Outdoor room
Cooling test DB27˚C / WB19˚C DB35˚C / WB24˚C
Heating test DB20˚C / WB15˚C DB 7˚C / WB 6˚C
SH09BPD
SH09BPDX
DB98_00000A(1)_1 1/29/04 4:22 PM Page 1

Samsung Electronics2
1-2 Pressure Graph
■SH09BPD
7
6.5
6
5.5
5
4.5
4
32.4
30.6
28.8
27.0
24.0
21.5
Outdoor inlet air DB temp.( C)
Low Pressure (kg/cm2G)
Indoor Inlet air DB temp.( C)
20 25 30 35 40 45
■SH12BPD
6.5
6
5.5
5
4.5
4
3.5
32.4
30.6
28.8
27.0
24.0
21.5
Outdoor inlet air DB temp.( C)
Low Pressure (kg/cm2G)
Indoor Inlet air DB temp.( C)
20 25 30 35 40 45
DB98_00000A(1)_1 1/29/04 4:22 PM Page 2

3Samsung Electronics
2. Operating Instructions
2-1 The Feature of Key in remote control
Fan speed adjustment button.
Each time you press this button, FAN SPEED is changed in the following order.
Temperature adjustment button(DOWN).
To decrease the temperature by the pressing the temperature button.
FUNCTION OF KEY
On/Off button.
Press the button to stop or run the air conditioner.
NAMED OF KEYNo
1
2
3
4
5
6
7
8
Swing button.
It adjusts the airflow to upward and downward.
Temperature adjustment button(UP).
To increase the temperature by the pressing the temperature button.
(On/Off)
(UP)
(DOWN)
Low Medium High
Automatic(rotated : )
Anion button.
Press the button to generate ion from the air conditioner.
Turbo button.
The air conditioner cools or heats the room as quickly as possible.
After 30 minutes, the air conditioner is reset automatically to the previous mode.
Mode selection button.
Each time you press this button
Mode is changed in the following order : Auto Mode : Fan Only
: Cool Mode : Heat Mode
: Dry Mode
Sleep button.
The sleep timer can be used when you are cooling or heating your room to switch the
air conditioner off automatically after a period of 6 hours.
DB98_00000A(1)_1 1/29/04 4:22 PM Page 3

Operating Instructions
Samsung Electronics4
Digital On/Off button.
If you want to turn off the display during operation press the button.
Off Timer button.
The Off Timer enables you to switch off the air conditioner automatically after
a given period of time that is from 30 minutes to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
FUNCTION OF KEYNAMED OF KEYNo
9
10
11
12
On Timer button.
The On Timer enables you to switch on the air conditioner automatically after
a given period of time that is from 30 minutes to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
Timer Set/Cancel button.
After setting On Timer or Off Timer, press the button to set it completely.
And press the button again to cancel On Timer or Off Timer set.
