Samsung MH FJEA series User manual

02_ features
For easy future reference write the model and serial number
down. You will find your model number on the right side of
the air conditioner.
Model #
Serial #
features of your new
air conditioner
• Slim & Smart Design
Extremely slim and compact design will allow this air conditioner to fit in any kind of interior
space.
•
function generates hydrogen(H) and oxygen(O2) to attack undesirable air contaminants
such as bacteria, pollen, and odor. It makes you breathe better as if you were staying around
waterfalls, ocean surf, rivers and mountains.
• 2Way air outlet
There are two separate air outlets for cooling and heating. Having warmer air coming out
from the bottom part of the air outlet will spread the warm air evenly throughout the room.
Stay cooler and warmer in every corner of your room.
• Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can
also be an efficient heating method in the winter with the advanced “Heat Pump” system.
This technology is up to 300% more efficient than electrical heating, so you can further
reduce its running cost. Now, meet year-round needs with one air conditioner.

safety information _03
ENGLISH
safety information
To prevent electric shock, disconnect the power before servicing, cleaning, and
installing the air conditioner.
SAFETY INFORMATION
Before using your new air conditioner, please read this manual thoroughly to
ensure that you know how to safely and efficiently operate the extensive features
and functions of your new appliance.
Because the following operating instructions cover various models, the
characteristics of your air conditioner may differ slightly from those described in
this manual. If you have any questions, call your nearest contact center or find
help and information online at www.samsung.com.
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe
personalinjuryordeath.
CAUTION
Hazards or unsafe practices that may result in minor
personalinjuryorpropertydamage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or
personal injury when using your air conditioner, follow
these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Cut-off the power supply.
Make sure the machine is grounded to prevent electric
shock.
Call the contact center for help.
Note.
Thesewarningsignsareheretopreventinjurytoyouandothers.
Pleasefollowthemcarefully.
Afterreadingthissection,keepitinasafeplaceforfuture
reference.

04_ safety information
safety information
SEVERE WARNING SIGNS
Do not place the air conditioner near hazardous
substances or equipment that releases free flames to
avoid fire, explosions or injuries.
•Potential risk of fire hazard or explosion.
Do not install the outdoor unit at an unstable place or
elevated surface where there is potential risk of falling.
•If the outdoor unit falls, it may cause personal injury or loss of
property.
Failure or damage may occur if any changes or
modification that is not stated in the installation manual
was performed. In this case, user will be responsible for
the repair expenses.
Install the air conditioner away from direct exposure to
sunlight, heating apparatus, and humid places.
•Hang curtains on windows to boost cooling efficiency and to
avoid the risk of electric shock.
Use the power line with the power specifications of the
product or higher and use the power line for this appliance
only. In addition, do not use an extension line.
•Extending the power line may result in electric shock or fire.
Install an exclusive circuit breaker and short-circuit breaker
for the air conditioner.
•Potential risk of electric shock or fire.
Do not insert anything such as fingers or branches into the
air conditioner vents while the air conditioner is running.
•Keep the children away from the air conditioner to prevent
them from putting their finger on the air conditioner. Potential
risk of personal injury.
If any foreign substance such as water has entered the
appliance, cut-off the power supply and contact the
nearest service center.
•Failing to do so may result in electric shock or fire.
Turn off the air conditioner using the provided remote
control or control accessory (if provided). Do not cut-off
the power supply to turn off the unit (unless there is an
immediate danger).
Do not run the air conditioner for an extended period of
time in a room with the door closed or with babies, elderly
or disabled people.
•Open the door or windows to ventilate your room at least
once an hour to prevent oxygen shortage.
The air conditioner is composed of moving parts. Keep
children away from the unit to avoid physical injury.
Make sure that children take precautions against access to
the air conditioner and they do not play with the unit.
Do not clean the interior of air conditioner on your own.
WARNING
•Youmaydamagethepartswhichcancauseelectricshockorfire.

safety information _05
ENGLISH
Do not connect the air conditioner with heating apparatus
or attempt to disassemble, remodel or repair it yourself.
•Potential risk of malfunction, electric shock or fire. If repairs
are needed, consult the contact center.
Consult the place of purchase or contact center to install,
reinstall or disassemble the air conditioner.
•Improper installation carries a risk of unit malfunction, water
leakage, electric shock or fire.
•If installing in specialty areas, such as a factory complex or
saline coastal area, consult the place of purchase or contact
center for specific installation details.
•The units must be installed according to distances declared,
in order to permit
accessibility from each side, either to guarantee correct
operation of maintenance or repairing products. The unit’s
parts must be reachable and removable completely under
safety condition (for people or things).
Consult a dealer regarding the appropriate measures to
prevent the allowable concentration from being exceeded.
•If the refrigerant leaks, and cause the concentration limit to
be exceeded, hazards due to lack of oxygen in the room may
result.
If the indoor unit gets wet, turn the power off immediately
and call your nearest contact center.
•Potential risk of fire or electric shock.
Always make sure that the power supply is compliant with
current safety standards. Always install the air conditioner
in compliance with current local safety standards.
Verify that the voltage and frequency of the power supply
comply with the specifications and that the installed power
is sufficient to ensure the operation of any other domestic
appliance connected to the same electric lines.
Use a rated circuit breaker only.
•Never use steel wires or copper wires as a circuit breaker. It
may cause fire or unit malfunctions.
Do not put undue stress or place heavy object on the
power cable.
Do not bend the power cable excessively.
•Potential risk of fire or electric shock.
To protect the product from water and possible shock, you
should keep the power cable and the connection cord of
the indoor and outdoor units in the protection tube.
When opening or closing the front panel, use a stable stool
and watch your steps carefully.
Disconnect the air conditioner from power supply before it
is repaired or disassembled.
Clean the air conditioner after the inner fan stops
operating.
•Potential risk of injury or electric shock.
•Consult contact center for cleaning the interior of the air
conditioner.

06_ safety information
safety information
SEVERE WARNING SIGNS (CONT’D)
Use a receptacle that has a ground terminal. The
receptacle must be used exclusively for the air conditioner.
•Improper electrical grounding may cause electric shock or fire.
Be sure to ground the unit. Do not connect the ground
wire to gas or water pipes, lighting rods, or telephone
grounding lines.
•If the unit is not properly grounded, electric shock may result.
If the appliance generates a strange noise, a burning
smell or smoke, cut-off the power supply immediately and
contact the nearest service center.
•Potential risk of fire or electric shock.
CAUTION SIGNS
Do not block or place items in front of the air conditioner.
Do not step, hang onto, or place heavy items on the air
conditioner.
•Potential risk of personal injury.
If failure or damage occurs on the conditions of improper
use not followed by the installation manual, there will be an
extra labor charge for installing and construction.
•Potential risk of malfunction, electric shock or fire if repairs
or installations are attempted by a non-qualified service
technician.
Do not spray flammable gases such as insecticide near the
air conditioner.
•Potential risk of electric shock, fire or unit malfunction.
Do not open the front grille during operation.
•Potential risk of electric shock or unit malfunction.
Cool air should not flow directly towards people, pets, and
plants.
•It is harmful to your health, pets, and plants.
Do not drink drain water coming out of the air conditioner.
•Potential risk of health hazard.
Do not allow children to climb on the air conditioner.
Do not use the air conditioner as a cooling precision
instrument for food, pets, plants, cosmetics or machinery.
Do not pull or give excessive shock to the air conditioner.
•Potential risk of fire, or unit malfunction and there are risk of
personal injury because unit may fall down.
Do not spray water directly on the air conditioner or use
benzene, thinner or alcohol to clean the surface of the unit.
•Potential risk of electric shock or fire.
•Potential risk of damage to the air conditioner.
Do not place any objects, especially containers with liquid.
WARNING
CAUTION

safety information _07
ENGLISH
Do not touch the pipe connected to the air conditioner.
Install the indoor unit away from lighting apparatus using
the ballast.
•If you use the wireless remote control, reception error may
occur due to the ballast of the lighting apparatus.
Install the outdoor unit where operating noise and vibration
will not disturb your neighbor and in a well-ventilated area
with no obstacle.
•Potential risk of malfunction.
•Operating noise may disturb your neighbor.
Make sure that there are no obstacles or covers that block
the air conditioner.
Allow sufficient space for air circulation.
•Insufficient ventilation may result in poor performance.
If the power cable is damaged, the manufacturer or a
qualified service technician must replace it.
If a power outage occurs while the air conditioner is
working, turn off the power source immediately.
Max current is measured according to IEC standard for
safety and current is measured according to ISO standard
for energy efficiency.
Check for damage on delivery. If damaged, do not
install the air conditioner and call the place of purchase
immediately.
Keep indoor temperatures stable and not extremely cold,
especially where there are children, elderly or disabled
people.
The packaging material and used batteries of the remote
controller (optional) must be disposed of in accordance
with the national standards.
The refrigerant used in the air conditioner must be treated
as chemical waste. Dispose the refrigerant following
national standards.
Have a qualified service technician install the air
conditioner and perform a trial operation.
Firmly connect the drain hose to the air conditioner for
proper water drainage.
Check for damages on the outdoor unit installation pad at
least once a year.
•Potential risk of personal injury or property loss.
When using a wireless remote control, the distance should
not be more than 7 meters from the air conditioner.
If the remote control is not used for a long period of time,
remove the batteries to prevent leakage of electrolyte.
When cleaning the outdoor unit, touch the heat exchanger
radiator fins with extreme care.
•Wearing thick gloves can protect your hands.
Make sure that the condensed water dripping from the
drain hose runs out properly and safely.

08_ safety information
safety information
The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety: Young children should be supervised to
ensure that they do not play with the appliance.
CAUTION SIGNS (CONT’D)
Inspect the condition, electric connections, pipes and
external case of the air conditioner regularly by a qualified
service technician.
Do not open doors and windows in the room being cooled
during operation unless necessary.
Do not block the air conditioner vents. If objects block
the air flow, it may cause unit malfunction or poor
performance.
Make sure there are no obstacles under the indoor unit.
•Potential risk of fire or loss of property.
The air conditioner should be used only for the
applications for which it has been designed: the indoor
unit is not suitable to be installed in areas used for laundry.
Our units must be installed in compliance with the spaces
indicated in the installation manual to ensure either
accessibility from both sides or ability to perform routine
maintenance and repairs. The units’ components must be
accessible and that can be disassembled in conditions of
complete safety either for people or things.
For this reason, where it is not observed as indicated into
the Installation Manual, the cost necessary to reach and
repair the unit (in safety, as required by current regulations
in force) with slings, trucks, scaffolding or any other means
of elevation won’t be considered in-warranty and charged
to end user.
Ensure the off-on and protection switches are properly
installed.
Do not use the air conditioner if damaged. If problems
occur, immediately stop operation and cut-off the power
supply.
When not using the air conditioner for a long period of time
or during a thunder/lightning storm, cut the power at the
circuit breaker.
Call the place of purchase or a contact center if repairs are
needed.
•Potential risk of fire or electric shock if disassembly or repairs
are attempted by a non-qualified service technician.
CAUTION

contents _09
ENGLISH
contents
VIEWING YOUR AIR CONDITIONER
BEFORE USE
10
10 Checking the indoor unit
10 Main parts
10 Mode indicator and control button
11 Removing the front panel
11 Viewing the power button and parts under
the panel
11 Checking the outdoor unit
12 Checking the remote control
13 Remote control display
13 Using the remote control
13 Installing the batteries
OPERATING BASIC FUNCTION
14
14 Turning the air conditioner on and off
14 Selecting operation mode
14 Auto
15 Cool
16 Dry
17 Fan
18 Heat
19 Adjusting the air flow direction
19 Vertical air flow
19 Horizontal air flow
OPERATING ADVANCED FUNCTION
20
20 Setting the Timer
20 On Timer
21 Off Timer
22 Combining ON and Off timer
23 Using the function
CLEANING AND MAINTAINING THE AIR
CONDITIONER
24
24 Cleaning the exterior
24 Cleaning the filter
24 Air filter
25 Anti-allergy filter
26 Replacing the filter
26 Deodorizing filter
26 Maintaining your air conditioner
APPENDIX
27
27 Troubleshooting
28 Operation ranges
This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), and the Electromagnetic
Compatibility Directive (2004/108/EC) of the European Union.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be
disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they
can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories
should not be mixed with other commercial wastes for disposal.

10_ viewing
Mode indicator and Control button
1 2 3 4 5 6 7
Each time you press the button, a short beep will sound and the unit is properly operating.
INDICATOR icon will light up when is operating.
FANMODE
INDICATOR This icon will light up when the unit is operating in Fan mode.
TIMERINDICATOR Timer icon will light up when On/Off Timer function is set.
DEICEINDICATOR This icon will light up when the unit starts to de-ice.
POWERBUTTON Turn On/Off the air conditioner. The air conditioner will operate in
Auto mode.
POWERINDICATOR Power icon will light up when the unit is in operation.
REMOTECONTROL
SENSOR Aim the remote control toward this spot on the air conditioner.
1
2
3
4
5
6
7
viewing your air conditioner
before use
Congratulations on the purchase of the air conditioner. We hope you will enjoy the features of your air
conditioner and stay cool or warm with optimal efficiency.
Please read the user manual to get started and to make the best use of the air conditioner.
CHECKING THE INDOOR UNIT
Carefully unpack your air conditioner, and check the unit to make sure it is not damaged.
Main parts
Your air conditioner may slightly look different from illustration shown above depending on
your model.
Air intake
Mode indicator and
Control button
Air outlet
(Cooling/Heating)
Air outlet
(Heating)
Blade pin lever
Blade pin lever

viewing _11
ENGLISH
REMOVING THE FRONT PANEL
Grab the top portion of the front panel and pull the front cover towards yourself. Unhook the safety string
and lift up the front panel.
Viewingthepowerbuttonandpartsunderthepanel
You may locate the Power button among with the mode indicators. When the front panel is
open, you may locate the temperature sensor and the Airflow switch. Temperature sensor is
located on the top left side of the air conditioner just above the anti-allergy/deodorizing filter slot
and the Airflow switch is located on the top right corner of the air conditioner.
You can turn on the air conditioner in Auto mode by pressing the Power button.
When you set the Airflow switch on Auto, it will open the bottom air outlet in Cool, Heat and
Fan modes. However, in Silence mode, the bottom air outlet will be closed. Also, in Cool mode,
the bottom air outlet will be closed within an hour. When you set the Airflow switch on Off, the
bottom air outlet will be closed.
The room temperature sensor measures indoor room temperature.
CHECKING THE OUTDOOR UNIT
Air intake (rear side)
Connection valve (inside)
Air outlet
Auto Off
Auto Off
Auto Off
Airflow switch Operation
Power button
Room temperature sensor
The designs and shape are subject to change according to the model.

12_ viewing
viewing your air conditioner
before use
CHECKING THE REMOTE CONTROL
You can activate the air conditioner by pointing the remote control away from it. When using the remote
control, always point it directly at the air conditioner.
Each time you press the button, a short beep will sound and a transmit indicator appears
on the remote control display.
Remotecontroldisplay
Power
Turn on/off the air conditioner,
Mode
Set one of the 5 operating modes.
(See pages 14~18 for instructions.)
Fan
Adjust how much air flows
through the air conditioner with
the 4 different fan speeds such as
Auto/Low/Medium/High.
OnTimer
Set the On Timer on.
OffTimer
Set the Off Timer off.
Set the mpi mode on/off.
Airswing
Activate/Deactivate air flow blade movement
automatically up and down.
Temp
Increase/Decrease the temperature by 1˚C.
Time
Increase/Decrease the time.
Set
Set the current Timer.
Cancel
Cancel the current Timer.

viewing _13
ENGLISH
Remote control display
Installing the batteries
Using the remote control
•Point the remote control towards the remote control sensor of the unit.
•When properly pressing the button on the remote control, you will hear beep sound from the unit.
•The signal may not be received well of electronic lighting style fluorescent lamps,
such as inverter fluorescent lamps are in the same space.
• If other electrical products operate by the remote control, call your nearest contact center.
Operation mode
indicator
Set temperature/
time indicator
Air swing indicator
Low battery indicator
Transmit indicator
On Timer indicator
Off Timer indicator
Fan speed indicator
Auto
Low
Medium
High
indicator
1. Pushtheleverasarrow
indicatesontherearside
oftheremotecontroland
pullup.
2. InserttwoAAAbatteries.

Check and match the “+” and
“-” signs accordingly. Make
sure you have inserted the
batteries in correct position.
3. Closethecoverbyplaceit
backtoitsoriginalposition.
You should hear click sound
when the cover is locked
properly.
Correct disposal of batteries in this product
(Applicable in countries with separate collection systems)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of
with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are
not properly disposed of, these substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and
recycle them through your local, free battery return system.

14_ operating
operating basic function
TURNING THE AIR CONDITIONER ON AND OFF
Press the Power button on the remote control.
You will hear a ringing sound and the air flow blade will move up
and down automatically when air conditioner is properly on. The air
conditioner will operate in the most recent operation mode used or
Auto mode.
When you turn off the air conditioner, air flow blade will stop moving
and remain closed.
Turningon/offyourairconditionerwithouttheremotecontrol.
You can operate your air conditioner by pressing the Power button on the right bottom side of the
air conditioner.
SELECTING OPERATION MODE
Auto
In Auto mode, the air conditioner will automatically set the temperature and fan speed depending
on the room temperature detected by the room temperature sensor.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operation mode.
Press the Mode button on the remote control until
operation mode indicator displays Auto.
The air conditioner will automatically set the fan
speed, and operation mode to Cool or Heat depends
on the room temperature.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the Temperature.
Press the Temp  or  button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between the
range of 16˚C~30˚C.
You can decrease/increase the temperature by 1˚C.
• When the air conditioner is already operating in another mode, press the Mode button
until Auto mode indicator appears on the remote control display.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
Silence
Silence
Silence
Silence
Silence

operating _15
ENGLISH
Cool
In Cool mode, the air conditioner will cool your room. You can adjust the temperature and the fan
speed to feel cooler in hot season.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Cool mode indicator appears on the remote control
display.
The air conditioner operates in Cool mode and
will lower the temperature in your room.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the temperature.
Press the Temp or button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between
the range of 16˚C~30˚C.
You can decrease/increase the temperature by 1˚C.
4. Set the fan speed.
Press the Fanorbutton on the remote control to
set the desired fan speed.
If room temperature reaches desired value, the air
conditioner will shut off cooling for a while and just the
fan runs.
When you press the Fanorbutton, fan speed
will change in order of Auto, Low, Medium and High.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
•If current outside temperatures are much higher than the selected indoor temperature,
it may take time to bring the inner temperature to the desired coolness.
Silence
Silence
Silence
Silence

16_ operating
operating basic function
SELECTING OPERATION MODE
Dry
The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air.
Dry mode makes the air feel refreshing in a humid climate.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Dry mode and Auto fan speed indicator appear on the
remote control display.
In Dry mode temperature will be set automatically and
will appear on the remote control display.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Temperature/Fan speed cannot be adjusted while using this mode.
• Air flow can be adjusted manually. (See page 19 for instructions.)
Silence
Silence

operating _17
ENGLISH
Fan
Fan mode can be selected to ventilate your room. Fan mode will be helpful to refresh the stale air
in your room.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Fan mode indicator appears on the remote control
display.
The air conditioner operates in Fan mode.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the fan speed.
Press the FanSpeed button on the remote control to
set the desired fan speed.
When you press the Fanorbutton, fan speed
will change in order of Low, Medium and High.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
Silence
Silence
Silence
Silence

18_ operating
operating basic function
SELECTING OPERATION MODE
Heat
The air conditioner heats as well as cools. Warm your room with this versatile appliance in the
cold of winter.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Modebutton on the remote control until
Heat mode indicator appears on the remote control
display.
The air conditioner operates in Heat mode and warms
your room.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the temperature.
Press the Temp or button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between
the range of 16˚C~30˚C.
You can decrease/increase the temperature by 1˚C.
4. Set the fan speed.
Press the Fanorbutton on the remote control to
set the desired fan speed.
If room temperature reaches desired value, heating will
stop for a while.
•WhenyoupresstheFanorbutton, fan speed
will change in order of Auto, Low, Medium and
High.
•Fan may not operate for about 3~5 minutes at the
beginning to prevent any cold blasts while the air
conditioner is warming up.
• Air flow can be adjusted manually. (See page 19 for instructions.)
• Since the air conditioner heats the room by taking heat energy from outdoor air, the
heating capacity may decrease when outdoor temperatures are extremely low. If you feel
the air conditioner insufficiently heats, using an additional heating appliance in combination
with the air conditioner is recommended.
Silence
Silence
Silence
Silence
Silence
Silence

operating _19
ENGLISH
ADJUSTING THE AIR FLOW DIRECTION
Air flow can be directed to your desired position.
Vertical air flow
Air flow blades move up and down.
1. Press the Airswing button on the remote control.
Air swing indicator will be on and the number of indicator lights move up and down.
Air flow blades move up and down continuously to circulate the air.
To keep the air flow direction in a constant position, press the Airswing button on the
remote control again.
Vertical air flow direction is adjustable when the air conditioner is cooling the room.
Horizontal air flow
Make sure one of the blade pins that stick out of the air flow blades is not broken.
1. Move the blade pins left or right to keep the air flow direction in a constant position you
prefer.
To avoid any injuries, please move the blade pin after stopping Air Swing mode.
While the air conditioner cools the room, operate the appliance
with the air flow blades pointing upwards. If the unit operates
in Cool mode for an extended period of time with the air flow
blades pointing downward, moisture may generate from the
temperature difference and thus carries the risk of electric
shock or unit malfunction.
Cooling/Heating
Heating
Silence
Silence
CAUTION

20_ using advanced functions
using advanced functions
SETTING THE TIMER
This advanced Timer function allows you to turn on/off your air conditioner automatically even when you are
away. Simply set the time and your air conditioner will turn on/off automatically.
On timer
This function allows you to turn on the air conditioner
automatically within the time range of
24 hours. On timer is available while your air
conditioner is on/off.
1. Press the OnTimer button on the remote control.
On timer indicator blinks on the remote control display.
2. Set the time you want the air conditioner to turn on automatically.
Press the Time  or button on the remote control
to change the time setting while On timer indicator
is blinking. You can set the time up to 24 hours,
increasing in 30 minute unit up to first 3 hours and in
hourly unit after first 3 hours.
3. Press the Set/Cancel button on the remote control to
active it on.
The remote control display will show the hour(s) you
have set.
The air conditioner will operate automatically at set time and then On timer indicator
disappears. If On timer is not set within 10 seconds, the air conditioner will end setting.
4. Set the operating mode.
Press the Mode button on the remote control until the
desired mode appears on the remote control display.
The air conditioner will operate in the mode you set.
On timer function is available in Auto/Cool/Dry/Fan/
Heat mode.
• Temperature can also be adjusted. (See step 3 on page 15 for instructions.)
• After the set up while the unit is off, approximately after 10 seconds, all the other
indicators will be gone except the On timer indicator and remaining time.
• Setting time allows you to change by pressing the OnTimer button. Press the Time 
or button to change time setting and then press the Set/Cancel button to active it on.
Silence
Silence
Silence
Silence
