Samsung Anycall SGH-Z508 User manual

* Depending on the software installed or your service provider, some of the descriptions in this manual may
not match from your phone.
* Depending on your country, your phone and accessories may appear different from the illustrations
in this manual.
World Wide Web
http://www.samsungmobile.com Printed in Korea
Code No.:GH68-08585A
English. 11/2005. Rev 1.0

SGH-Z508
User’s Guide

Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Use road safety at all times
Do not use a hand-held phone while driving.
Park the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference.
Using them in an aircraft is both illegal and
dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be
using equipment that could be sensitive to
external radio frequency energy. Follow any
regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.

1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 78.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent
information regarding safety or phone
features.
 Indicates that you can get more
information on the referenced page.
→ Indicates that you need to press the
Navigation keys to scroll to the
specified option and then select it.
[ ] Indicates a key on the phone. For
example, []
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, < Msg . >
•3G
Your phone is capable of operating
in a 3G environment, allowing
much greater data transfer speed,
video streaming, and video
conferencing.
Special features of your phone
• Camera and Camcorder
Use the camera module on your
phone to take a photo or record a
video.
•MediaPlayer
Play media files on your phone.
•IrDA
Send and receive Phonebook and
Organiser data and media files via
an infrared port.

3
Special features of your phone
•Bluetooth
Send photos, images, videos, and
other personal data, and connect to
other devices using free, wireless
Bluetooth technology.
•WAPbrowser
Access the wireless web and access
various services and current
information.
• Get Personal with Photo Caller
ID
See who’s calling you with their
very own photo displays.
• Name card
Create name cards with your
number and profile whenever
introducing yourself to others use
this convenient electronic name
card.
• Multimedia Message Service (MMS)
Deliver MMS messages with a combination of
text, images, and audio.
•E-mail
Deliver e-mails with images, video, and audio
attachments.
•Java
Enjoy Java ™ -based embedded
games and download new games.
• Organiser
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.

4
Contents
Special features of your phone 2
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone .............................. 7
Power on or off................................................. 8
Keys and display............................................... 9
Display........................................................... 10
Access menu functions...................................... 11
Customise your phone ...................................... 12
Make/Answer calls............................................ 14
Step outside the phone 14
Begin with your camera, games, WAP, and other special
features
Use camera..................................................... 14
Play media files ............................................... 15
Play games ..................................................... 16
Browse the web............................................... 16
Use Contacts................................................... 17
Send messages ............................................... 18
View messages................................................ 20
Use Bluetooth wireless...................................... 20
Use a memory card.......................................... 21
Enter text 23
Pinyin, Stroke, ABC, T9, Number, and Symbol mode
Call functions 26
Advanced calling features
Menu functions 30
All menu options listed
Solve problems 77
Help and personal needs
Health and safety information 78

5
1 Call log  p. 30
1 Missed calls
2 Dialled calls
3 Received calls
4 Current contacts
5 Delete all
6 Data calls
7 Calls cost
*
8 Calls time
 p. 30
 p. 31
 p. 31
 p. 31
 p. 31
 p. 31
 p. 31
 p. 32
2 Contacts  p. 32
1 Search contact
2 New contact
3 Groups
4 Speed dial
5 My name card
6 Copy all
7 Own number
8 Service number *
9 Settings
0 Memory status
 p. 32
 p. 33
 p. 34
 p. 34
 p. 35
 p. 35
 p. 35
 p. 35
 p. 35
 p. 35
3 Applications  p. 36
1 Media player
2 Voice memo
3 World clock
4 Calculator
5 Converter
6 SAT *
 p. 36
 p. 37
 p. 38
 p. 39
 p. 39
 p. 40
4 Internet  p. 40
1 Go to homepage
2 Enter URL
3 Favourites
4 History
5 Browser settings
6 Network settings
 p. 40
 p. 41
 p. 41
 p. 41
 p. 41
 p. 42
5 Messages  p. 42
1 Create new
2 Inbox
3 Drafts
4 Outbox
5 Sent box
6 Email inbox
7 Templates
8 Broadcast
9 Delete all
0 Settings
* Memory status
 p. 42
 p. 44
 p. 46
 p. 46
 p. 47
 p. 47
 p. 48
 p. 48
 p. 49
 p. 49
 p. 52
6 File manager  p. 52
Images
Videos
Music
Sounds
Games & More
Other files
Memory card
**
 p. 53
 p. 54
 p. 56
 p. 57
 p. 57
 p. 58
 p. 58
7 Organiser  p. 58
1 Alarm
2 Calendar
3 Week view
4 Today’s events
5 Schedule
6 Anniversary
7 Task
8 Memo
9 Holiday
0 Missed event alarm
* Memory status
 p. 58
 p. 59
 p. 61
 p. 61
 p. 61
 p. 61
 p. 61
 p. 61
 p. 61
 p. 61
 p. 62
8 Camera  p. 62
9 Settings  p. 66
1 Profiles
2 Time & date
3 Phone
4 Display
5 Call
6 Connectivity
7 Application settings
8 Security
9 Memory status
0 Reset settings
 p. 66
 p. 67
 p. 67
 p. 68
 p. 69
 p. 71
 p. 74
 p. 75
 p. 76
 p. 76
* Shows only if supported by your SIM card.
** Shows only if a memory card is in-
serted into the phone.
Overview of menu functions
To access Menu mode, press in Idle mode.

6
Unpack
Make sure you have each item
You can obtain various accessories
from your local Samsung dealer.
Phone Travel Charger
Battery PC Data Cable
PC Link CD User’s Manual
The items supplied with your
phone and the accessories at
your Samsung dealer may vary,
depending on your country or
service provider.
Your phone
Buttons, features, and locations
Microphone
Headset jack
Navigation keys
Dial key
Exterior
camera
lens
Earpiece
Display
Special
function keys
Volume keys
Interior
camera lens
Infrared port
Camera
key
Memory
card slot
Left soft key
Application
switch key
Video call key
Menu access/
confirm key
Delete key
Alphanumeric keys
Power On/Off/
Menu exit key
External
display
Right soft key

7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you
receive a plug-in SIM (Subscriber Identity Module)
card loaded with your subscription details, such as
your PIN and available optional services. For 3G
services, you can purchase a USIM card.
Install and charge the phone
Remove the battery.
If the phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
1 2
Install the battery. Plug the travel
charger into the
phone.
Plug the charger into a standard AC wall outlet.
The LED on the charger indicates the charging
progress.
• Red: the battery is being charged.
• Green: the battery is completely charged.
• Orange: the battery is not correctly installed
or is operating at a too high or too low
temperature.
When the phone is completely charged (green
charger LED), unplug the charger from the
power outlet.
3 4
5
6

Get started
8
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the charger from the phone.
7
Power on
Do not turn on the
phone when
mobile phone use
is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn
on the phone.
3. If necessary, enter the PIN
and press < Confirm >.
Power off 1. Open the phone.
2. Press and hold [ ].

9
Get started
Keys and display
Key(s) Description
Perform the function indicated on the
bottom line of the display.
In Idle mode, access menu options
directly.  p. 67
In Menu mode, scroll through the
menu options.
In Idle mode, accesses Menu mode.
In Menu mode, select a highlighted
menu option.
Opens the application switch window to
open Call , Messages , and Internet
without exiting the current application.
Makes a video call.
Makes or answers a call.
In Idle mode, retrieves the recent
numbers dialled, missed, or received.
Deletes characters from the display or
an item in an application.
Key(s) Description
Ends a call.
Hold down to switch the phone on and
off.
In Menu mode, cancel input and return
the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, hold [ 1 ] down to access
your voicemail. Hold down [ 0 ] to enter
an international call prefix.
Enter special characters.
Hold [ ] down to activate or
deactivate the Silent profile. Hold down
[ ] to enter a pause.
(on the left)
Adjust the phone volume.
In Idle mode, adjust the keypad tone
volume. With the phone closed, hold
down to activate the external display.
(on the right)
Hold down to turn on the camera.
In Camera mode, switches the camera
lens.

Get started
10
Display
Layout The display has three areas.
Icons Received signal strength
Accessing services in a 2.5G
network; when transferring
data, this icon animates.
Accessing services in a 3G
network; when transferring
data, this icon animates.
Active roaming feature
Voice call in progress
Out of your service area; you
cannot send or receive voice
calls
Text and graphics
displays messages,
instructions, and
information you enter.
Soft key function
indicators
shows the current
functions assigned to
the two soft keys.
Icons
displays various icons.
Select Back
Icons
(continued)
Video call in progress
Out of your service area; you
cannot send or receive video
calls
Bluetooth feature is active;
When transferring data, this
icon blinks red and blue.
 p. 71
Connected with a Bluetooth
headset or hands-free kit
IrDA port is active  p. 73
Memory card inserted
Connected with a computer
via a USB port
Browsing the Internet on a
PC using the phone as a
modem
Connected to a secured web
page

11
Get started
Access menu functions
Icons
(continued)
New message; depending on
the message type, the
following icons may appear.
•:SMS
• : MMS or MMS with
attachments
•:E-mail
•:Voicemail
•:WAPpush
• : Configuration message
Inbox full; depending on the
message type, the following
icons may appear.
•:SMS
• : MMS or MMS with
attachments
•:E-mail
•:Voicemail
•:WAPpush
• : Configuration message
Profile setting  p. 67
•:Normal
• : Meeting
•:Car
•:Silent
• : Outdoor
Battery power level
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current
role.
In each main menu, one of the
most popular sub menu is
assigned to the left soft key.
This allows you to quickly
access the most popular
menus.
Press the left soft
key to confirm the
function displayed
or option
highlighted.
Press the right soft
key to move up
one level.
Select Back

Get started
12
Customise your phone
Select an
option
1. Press the appropriate soft
key or to access Menu
mode.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press < Select >, < OK >, or
to confirm the function
displayed or option
highlighted.
4. To exit, choose either of the
following methods:
• Press < Back > to move
up one level.
• Press [ ] to return to
Idle mode.
Use shortcuts Press the number key
corresponding to the option you
want.
1. In Idle mode, press and
select Settings → Phone →
Language → Screen text .
2. Select a language.
3. Press < Save >.
You can change the call ringer by
changing the properties of the
currently active sound profile.
To change the profile properties:
1. In Idle mode, press and
select Settings → Profiles .
2. Scroll the sound profile you
are using.
3. Press < Options > and select
Edit .
4. Select Voice call ringtone
and select a ringer for voice
calls.
5. Press < Options > and Press
Select .
6. Select Video call ringtone
and select a ringer for video
calls.
7. Press < Options > and Press
Select .
8. Press < Options > and select
Save .
Display
language
Call ringer
melody

13
Get started
To change the sound profile:
1. In Idle mode, press and
select Settings → Profiles .
2. Select the profile you want.
You can set a wallpaper for the
idle screen.
1. In Idle mode, press and
select Settings → Display →
Wallpaper .
2. Press [Left] or [Right] to
scroll to an image box .
3. Select an image and press
< Set >.
You can quickly activate the
Silent profile to avoid disturbing
other people.
Press and hold [ ] in Idle mode.
Idle mode
Wallpaper
Silent mode
You can protect the phone
against unauthorised use with a
phone password.
1. In Idle mode, press and
select Settings → Security
→ Change phone
password .
2. Enter the default password,
“00000000,” and press
< Confirm >.
3. Enter a new 4- to 8-digit
password and press
< Confirm >.
4. Enter the new password
again and press < Confirm >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and press
< Confirm >.
Phone lock

14
Make/Answer calls
Step outside the phone
Begin with your camera, games, WAP, and other special
features
Use camera
To make a voice call:
1. Enter an area code and
phone number.
2. Press [ ].
3. To end the call, press [ ].
To make a video call:
1. Enter an area code and
phone number.
2. Press [ ], and the other
person appears on the
screen.
1. When the phone is ringing,
press [ ].
2. For a video call, press
< Show me > to allow the
other person to see you.
3. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [ ] to switch between
the interior lens and exterior
lens.
3. Aim the camera lens at the
subject and adjust the image.
4. Press to take a photo. The
photo is saved automatically.
5. Press to take another
photo.
1. In Idle mode, press and
select File manager →
Images .
2. Select the photo you want.
Take a photo
View a photo

15
Step outside the phone
Play media files
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [ 1 ] to switch to Record
mode.
3. Press [ ] to switch between
the interior lens and exterior
lens.
4. Press to start recording.
5. Press to stop recording.
The video is automatically
saved.
6. Press to record another
video.
1. In Idle mode, press and
select File manager →
Videos .
2. Select the video you want.
Record a video
Play a video
Use these methods:
• Download from the wireless
web  p. 40
• Download from a computer
using Samsung PC Studio
 Samsung PC Studio User’s
Guide
• Copy files to a memory card
and insert the card into the
phone  p. 21
• Receive via IrDA or
Bluetooth  p. 73, p. 71.
1. In Idle mode, press and
select Applications → Media
player .
2. Press < Options > and select
Open play list .
3. Press < Options > and select
Add → Folder or Files .
4. Check the files you want or
scroll to the folder you want.
5. Press < Add > or < Select >.
Copy media
files to the
phone
Create a play
list

Step outside the phone
16
Play games
Browse the web
Using a built-in WAP (Wireless Access Protocol)
browser, you can get easy access to the wireless
web to receive a variety of up-to-date information
and services and to enjoy downloads of web
contents.
1. From the Media player
screen, press .
2. Select the file you want.
3. During playback, use the
following keys:
• : Pauses or resumes
play back.
• Up: Opens the play list.
• Left: Goes to the previous
file. Moves backward in a
file when held down.
• Right: Skips to the next
file. Skips forward in a file
when held down.
•/:Adjuststhevolume.
• Down: Stops playback.
1. In Idle mode, press and
select File manager →
Games & More → the game
you want.
2. Press any key, except for
[ ], to launch the game.
Play media files
Select a game
In Idle mode, press and
select Internet → Go to
homepage .
• To scroll through browser
items, press [Up] or [Down].
• To select an item, press .
• To return to the previous
page, press < Back >.
• To use browser options, press
< Options >.
Launch the
browser
Navigate the
web

17
Step outside the phone
Use Contacts
To the phone’s memory:
1. In Idle mode, enter a phone
number.
2. Press < Options > and select
Save to Contacts → Phone
→ New → a number type.
3. Specify the contact
information: First name, Last
name, Phone number, Work
Email, Home Email, Group,
Homepage, Birthday, and
More information (Job title,
Department, Company,
Nickname, and Notes).
4. Press < Options > and select
Save to save the entry.
Add an entry
To the USIM/SIM card:
1. In Idle mode, enter a phone
number.
2. Press < Options > and select
Save to Contacts → SIM →
New .
3. Specify the contact
information, depending on
your card type: Name, Phone
number, Group, and Location.
4. Press to save the entry.
1. In Idle mode, press
< Contacts >.
2. Select an entry.
3. Select a number and press
[ ] to dial, or < Options > to
access options.
Find an entry
