Samsung GH68-09404A User manual

* Depending on the software installed or your service provider or country, some
of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-09404A
English(SEA). 03/2006. Rev. 1.0

SGH-D520
User’s Guide

Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.

Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 89.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.

Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu >
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special features of your phone
• Image editor
Crop, resize, rotate, and decorate
your photos.
•Musicplayer
Play MP3 music files using your
phone as a music player.
• File viewer
Open documents in various
formats on the phone without
corruption.

3
Special features of your phone
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology. You can also use a
Bluetooth stereo headset to let you
enjoy music with high quality
stereo sound.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
•Namecard
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
• E-mail
Send and receive e-mails with images, video,
and audio attachments.
•Webbrowser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.
•Java
Enjoy Java ™ -based embedded
games and download new games.
• Voice recorder
Record memos or sounds.

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with your camera, the music player, the web, and
other special features
Use the camera...................................................... 14
Play music............................................................. 15
Browse the web...................................................... 16
Use Phonebook ...................................................... 17
Send messages...................................................... 18
View messages....................................................... 19
Use Bluetooth ........................................................ 20
Enter text 22
AB, T9, Number, and Symbol modes
Call functions 24
Advanced calling features
Menu functions 28
All menu options listed
Solve problems 87
Help and personal needs
Health and safety information 89
Index 96

5
Overview of menu functions
To access Menu mode, press < Menu > in Idle mode.
1 Call log  p. 28
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
 p. 28
 p. 29
 p. 29
 p. 29
 p. 29
 p. 29
 p. 30
2 Phonebook  p. 30
1 Contact list
2 Create contact
3 Group
4 Speed dial
5 My namecard
6 Own number
7 Management
8 Service number
*
 p. 30
 p. 31
 p. 32
 p. 32
 p. 33
 p. 33
 p. 33
 p. 34
3 Applications  p. 34
1 Music player
2 Voice recorder
3 Image editor
4 Java world
5 World time
6 Alarm
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
11 Key management
12 SIM AT
*
 p. 34
 p. 37
 p. 38
 p. 40
 p. 40
 p. 41
 p. 41
 p. 42
 p. 42
 p. 43
 p. 43
 p. 43
4 Browser  p. 43
1 Home
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Clear cache
7 Browser settings
 p. 44
 p. 45
 p. 45
 p. 46
 p. 46
 p. 46
 p. 46
5 Messages  p. 46
1 Create message
2 My messages
3 Templates
4 Delete all
5 Settings
6 SOS messages
7 Memory status
 p. 47
 p. 50
 p. 54
 p. 55
 p. 55
 p. 60
 p. 60
6 My files  p. 61
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
 p. 61
 p. 62
 p. 63
 p. 64
 p. 64
 p. 66
7 Calendar  p. 66
8 Camera  p. 69
9 Settings  p. 75
1 Time and date
2 Phone settings
3 Display settings
4 Sound settings
5 Light settings
6 Network services
7 Bluetooth
8 Security
9 Connect settings
10 Reset settings
 p. 75
 p. 75
 p. 77
 p. 77
 p. 79
 p. 79
 p. 82
 p. 84
 p. 85
 p. 87
* Shows only if supported by your
SIM card.

6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Buttons, features, and locations
Special
function keys
Earpiece
Left soft key
Volume keys
Dial key
Alphanumeric
keys
Navigation keys
(Up/Down/Left/
Right)
Headset jack
Display
Power on/off/
Menu exit key
Microphone
Right soft key
Web access/
Confirm key
Delete key
Camera key
Camera lens
Flash

7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the phone is already
on, first turn it off by
pressing and holding
[].
Insert the SIM card.
Make sure that the gold-
coloured contacts are
face down.
Install the battery. Replace the battery
cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.

8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Keypad lock
When you close the phone, the keypad lock feature
locks the exposed keys so that nothing will happen if
the keys are accidentally pressed.
To unlock the keypad, press < Unlock > and press
< OK >.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press < OK >.
Switch off
1. Open the phone.
2. Press and hold [ ].

9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
 p. 76
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display or an
item in an application.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1] to access
your voicemail server. Press and hold [
0 ] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Quiet mode. Press and hold
[ ] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, press and hold to turn on the display.
In Idle mode, press and hold to turn on the
camera.
In Camera mode, take a photo or record a
video.

10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive calls
GPRS network
Connecting to GPRS network
Connected to Internet
Roaming network
New message
New e-mail
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
New voicemail
Call diverting feature active
 p. 79
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Connected to Bluetooth hands-free
car kit or headset
Bluetooth active
 p. 82
Synchronised with PC
MP3 playback in progress
MP3 playback paused
Alarm set
 p. 41
Call ringer set to vibrate
 p. 78
Quiet mode (Vibration)
Quiet mode (Mute)
Mute mode, during a call
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.

11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Se
l
ect Bac
k
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press < Select >, < OK >, or
[ ] to confirm the function
displayed or option highlighted.
4. To exit, choose either of the
following methods:
•Press< Back > to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts Press the number key
corresponding to the option you
want. For the index numbers 10, 11
and 12, press [ 0 ], [ ], and [ ],
respectively.

12
Get started
Customise your phone
1. In Idle mode, press < Menu >
and select Settings → Phone
settings → Language .
2. Select a language.
1. In Idle mode, press < Menu >
and select Settings → Sound
settings → Incoming call →
Ringtone .
2. Select a ringtone category.
3. Select a ringtone.
4. Press < Save >.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press < Menu >
and select Settings → Display
settings → Wallpaper → Main
display .
2. Select an image category.
3. Select an image.
4. Press < Save >.
You can change the colour for the
display components, such as title
bars and highlighted bars.
1. In Idle mode, press < Menu >
and select Settings → Display
settings → Skin .
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour

13
Get started
You can set the Navigation keys to
function as shortcuts to access
your favourite menus.
1. In Idle mode, press < Menu >
and select Settings → Phone
settings → Shortcut .
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quiet
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Quiet mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press < Menu >
and select Settings →
Security → Change
password .
2. Enter the default password,
00000000 , and press < OK >.
3. Enter a new 4- to 8-digit
password and press < OK >.
4. Enter the new password again
and press < OK >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and press
< OK >.
Phone lock

14
Make/Answer calls
Step outside the phone
Begin with your camera, the music player, the web, and
other special features
Use the camera
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. Open the phone.
2. In Idle mode, press and hold
[ ] to turn on the camera.
3. Aim the lens at the subject and
make any desired adjustments.
4. Press [ ] or [ ] to take a
photo. The photo is saved
automatically.
5. Pres s < Preview > to take
another photo.
1. In Idle mode, press < Menu >
and select My files → Images
→ My photos .
2. Select the photo you want.
Take a photo
View a photo

15
Step outside the phone
Play music
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [ 1 ] to switch to Record
mode.
3. Press [ ] or [ ] to start
recording.
4. Press [ ], < >, or [ ] to
stop recording. The video is
saved automatically.
5. Press < Preview > to record
another video.
1. In Idle mode, press < Menu >
and select My files → Videos →
My video clips .
2. Select the video you want.
Record a video
Play a video
Use these methods:
• Download from the wireless
web  p. 43
• Download from a computer
using the optional Samsung PC
Studio  Samsung PC Studio
User’s Guide
• Receive via Bluetooth  p. 84
1. In Idle mode, press < Menu >
and select Applications →
Music player .
2. Press < Options > and select
Add music → Add all or Add
files .
Copy music
files to the
phone
Create a play
list

16
Step outside the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information, and to download web content.
3. For Add files , press [ ] to
select the files you want and
press < Select >.
4. Press < Back > to return to the
music player screen.
1. From the music player screen,
press [ ].
2. During playback, use the
following keys:
• : pauses or resumes
playback.
• Left: returns to the previous
file.
• Right: skips to the next file.
• Up: opens the play list.
• / : adjusts the volume.
• Down: stops playback.
Create a play
list
(continued)
Play music files
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press < Back >.
• To move to the next page, press
< Options > and select Go →
Forward .
• To access options, press
< Options >.
Launch the
web browser
Navigate the
web

17
Step outside the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press < Options >.
2. Select Save contact → Phone
→ a number type.
3. Specify contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Caller ID, Ringtone, Group, and
Note.
4. Press < Save > to save the entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press < Options >.
2. Select Save contact → SIM .
3. Enter a name.
4. Press < Save > to save the entry.
Add an entry
1. In Idle mode, press
< Contacts >.
2. Enter the first few letters of the
name you want.
3. Select an entry.
4. Scroll to a number and press
[] to dial, or press [ ] to
edit contact information.
1. In Idle mode, press < Menu >
and select Phonebook → My
namecard .
2. Specify your contact
information.
3. Press < Save > to save the
name card.
4. To send the name card, press
< Options > and select Send
via → a sending method.
Find an entry
Create and
send a name
card
