Samsung GT-B7702 User manual

GSM TELEPHONE
GT-B7702
GSM TELEPHONE CONTENTS
Notice
All functionality, features, specifications and o
ther product information provided in this docu
ment including, but not limited to, the benefit
s, design, pricing, components, performance,
availability, and capabiliti-es of the product
are subject to change without notice or oblig
ation. Samsung reserves the right to make
changes to this document and the product
described herein, at anytime, without
obligation on Samsung to provide notification
of such change.
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts List
6. Main Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Flow Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
instructions

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test, because the specification of cellular phone is sensitive for
surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. Otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.

SAMSUNG Proprietary-Contents may change without notice
2. Specification
This Document can not be used without Samsung's authorization
2-1
2-1. GSM General Specification
EGSM 900 DCS1800 PCS1900 TD-SCDMA
Freq. Band[MHz]
Uplink/Downlink
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990 2010~2024
ARFCN range 0~124 &
975~1023 512~885 512~810 10054~10121
Tx/Rx spacing 45MHz 95MHz 80MHz 0
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
1.28Mcps
Time Slot Period/Frame
Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms 675us/5ms
Modulation
GSM/
GPRS 0.3GMSK 0.3GMSK 0.3GMSK
QPSK
EDGE 8PSK 8PSK 8PSK
MS Power 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm +24dBm~-49dBm
Power Class 4
(max +33dBm)
1
(max +30dBm)
1
(max +30dBm)
2
(max +24dBm)
Sensitivity -102dBm -100dBm -100dBm -108dBm
TDMA Mux 8 8 8 7
Cell Radius 35Km 2Km 2Km 11Km

SAMSUNG Proprietary-Contents may change without notice
Specification
This Document can not be used without Samsung's authorization
2-2
2-2. GSM TX power class
TX Power
control level PCS1900
030±2dBm
128±3dBm
226±3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
814±3dBm
912±4dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level GSM900
5 33±2 dBm
6 31±2 dBm
7 29±2 dBm
8 27±2 dBm
9 25±2 dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
0 30±2 dBm
1 28±3 dBm
2 26±3 dBm
3 24±3 dBm
4 22±3 dBm
5 20±3 dBm
6 18±3 dBm
7 16±3 dBm
8 14±3 dBm
9 12±4 dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2-3
TX Power
control level
GSM900
GSM850
8 27±3 dBm
9 25±3 dBm
10 23±3 dBm
11 21±3 dBm
12 19±3 dBm
13 17±3 dBm
14 15±3 dBm
15 13±3 dBm
16 11±5 dBm
17 9±5 dBm
18 7±5 dBm
19 5±5 dBm
TX Power
control level DCS1800
226-4/+3dBm
324±3dBm
422±3dBm
520±3dBm
618±3dBm
716±3dBm
812±3dBm
910±3dBm
10 14±3 dBm
11 12±4 dBm
12 10±4 dBm
13 8±4dBm
14 6±4 dBm
15 4±4 dBm
2-3. GSM EDGE TX power class
TX Power
control level PCS1900
226-4/+3dBm
3 24±3 dBm
4 22±3 dBm
5 20±3 dBm
6 18±3 dBm
7 16±3 dBm
8 12±3 dBm
9 10±3 dBm
10 14±3 dBm
11 12±4 dBm
12 10±4 dBm
13 8±4dBm
14 6±4 dBm
15 4±4 dBm

SAMSUNG Proprietary-Contents may change without notice
3. Product Function
3-1
This Document can not be used without Samsung's authorization
Main Function
-TD-SCDMA HSDPA 2.8Mbps
-Dual Standby (Dual TX, Dual RX)
-5M AF Camera
-Bluetooth V.2.0
-Stereo Bluetooth Headset
-3.2" WQVGA 262K TFTwith Touch screen
-EXT. Memory
-SMS/MMS/E-Mail
-WAP 2.0 / Java MIDP 2.0
-MP3, AAC, MP4, 3GPP Decoding
-Video Recording and Messaging
-GSM/GPRS/EDGE Class 10
-FM radio, GPS
-CMCC Customized Service

SAMSUNG Proprietary-Contents may change without notice
4. Array course control
4-1
This Document can not be used without Samsung's authorization
4-1. Software Adjustments
Test Cable (GH39-01160A)
Test Jig (GH99-36900A)
RF Test Cable (GH39-00985A) Adapter (GH99-38251A)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-2
This Document can not be used without Samsung's authorization
4-2. Software Downloading
4-2-1. Pre-requsite for Downloading
•Downloader Program(Kellan_Downloader_1.0.exe)
•GT-B7702 Mobile Phone
•Data Cable,USB cable
•Binary file, TFS file
4-2-2. S/W Downloader Program
■Load the binary download program by executing the
“Kellan_Downloader_1.0.exe”
Master Download (USB Communication)
1. Select the download mode you want.
-check MASTER
2.Select the USB.
3.Select the Erase option.
4.Push the Partition file and Select the file you want to download
5.Push the Advanced Configuration. and Check FormatBBM
=> Push the Start Button
.
Slave Download (Serial Communication)
1. Select the download mode you want.
-check SLAVE
2.Select the connected serial Port and the Rate of speed
6.Select the file you want to download
7.Select the check box, the mode you want to download.
-if the binary file wanted, check only 'BIN'
-if the tfs file wanted, check only 'TFS'
-if all the files wanted, check 'BIN+TFS'
=> Push the Start Button

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-3
This Document can not be used without Samsung's authorization

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-1
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC Discription SEC CODE
QCR67 SCREW-MACHINE 6001-002083
QCR101 SCREW-MACHINE;PH,+,M1.4,L4,NI PLT(SIL),S 6001-002005
QLC01 LCD-LMS320HF11-0 GH07-01444A
QAN03 INTENNA-BT(GT-B7702C) GH42-01928A
QBA01 INNER BATTERY PACK-1200MAH,CHI,MAIN GH43-03060A
QVK01 KEY FPCB-VOLUME KEY FPCB GH59-06935A
QME03 TOUCH/PANEL-GT-B7702C GH59-06972A
QSP01 MODULE-GTB7702_SPK+MOT GH59-07036A
QVK02 KEY FPCB-SIDE KEY ASS'Y (B7702C) GH59-07092A
QME01 KEY FPCB-KEY PBA ASSY(B7702C) GH59-07189A
QVK03 KEY FPCB-MOD KEY(GT_B7702) GH59-09562A
QMP01 A/S ASSY-GTB7702_PBA MAIN (SVC) GH82-04997A
QCA02 ASSY CAMERA-GTB7702_VGA GH96-03633A
QCA01 ASSY CAMERA-GT-B7702(5M_AF) GH96-03647A
QFR01 ASSY CASE-FRONT GH98-10681A
QKP01 ASSY KEYPAD-(CMCC/GRAY) GH98-10686A
QST01 ASSY ACCE-STYLUS PEN GH98-10688A
QBC00 ASSY COVER-BATT GH98-14843A
QLB01 ASSY BRACKET-LCD GH98-17170A
QRE01 ASSY CASE-REAR GH98-10682A
QCK02 PMO KEY-MODE GH72-51878A
QCK01 ASSY KEY-CAMERA GH98-11967A
QVO01 ASSY KEY-VOLUME GH98-11968A
QAN02 INTENNA-GT-B7702C_MASTER GH42-01930A
QCK03 PMO KEY-HOLD V2 GH72-58775A
QIF01 PMO COVER-IF V3 GH72-58776A
5-2. Cellular phone Parts list

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-1
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
ZD707 0403-001547 DIODE-ZENER
D401,D402 0404-001153 DIODE-SCHOTTKY
D705 0404-001172 DIODE-SCHOTTKY
D702,ZD710 0406-001201 DIODE-TVS
ZD1001,ZD1003 0406-001231 DIODE-TVS
ZD701,ZD704 0406-001286 DIODE-TVS
D707,D708,D712,D713 0406-001288 DIODE-TVS
D714,D715,ZD702 0406-001288 DIODE-TVS
ZD703,ZD705,ZD708 0406-001288 DIODE-TVS
U302,U305 0504-001151 TR-DIGITAL
U803 0505-001802 FET-SILICON
U1001,U202 0801-003022 IC
U1006,U507 0801-003065 IC
U1005,U101,U103,U104 0801-003139 IC
U1106,U812,U813,U814 0801-003139 IC
U501,U502,U506 1001-001429 IC
U600 1001-001453 IC
U102,U601,U602 1001-001470 IC
U709 1003-002047 IC
UME800 1106-001505 IC-SRAM
UME1001 1108-000099 MEMORY
U603 1201-002736 IC
PAM300 1201-002765 IC
PAM100,PAM901 1201-002773 IC
U301 1203-004147 IC
U304 1203-004416 IC
U815 1203-004419 IC
U713 1203-004604 IC
U805 1203-004776 IC
U806,U811 1203-004792 IC
U809,U810 1203-004793 IC
U1103 1203-004802 IC
U1104 1203-004806 IC
U706 1203-005503 IC
U702 1203-005031 IC
U505 1203-005069 IC
UPL1001 1203-005072 IC
U804 1203-005225 IC
U504 1203-005254 IC
U802 1203-005403 IC
U807 1203-005487 IC
U801 1203-005690 IC
U105 1204-002926 IC
UCP1001 1205-003082 IC

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
U200,U900 1205-003283 IC
U710 1205-003288 IC
UCP401 1205-003376 IC
U100 1205-003419 IC
U300 1205-003598 IC
UCP300 1205-003603 IC
U1102 1209-001817 IC
VR401 1404-001224 THERMISTOR
R1002,R1016,R1024 2007-000138 R-CHIP
R103,R107,R478,R501 2007-000138 R-CHIP
R512,R521,R530,R600 2007-000138 R-CHIP
R601,R610,R801,R835 2007-000138 R-CHIP
R836 2007-000138 R-CHIP
R1011,R200,R300,R520 2007-000140 R-CHIP
R902,R903 2007-000140 R-CHIP
R1001,R842,R854 2007-000141 R-CHIP
R201,R311,R904 2007-000143 R-CHIP
R1003,R1004,R1008 2007-000148 R-CHIP
R1009,R1012,R1022 2007-000148 R-CHIP
R1111,R1112,R408 2007-000148 R-CHIP
R426,R467,R604,R605 2007-000148 R-CHIP
R706,R721,R823,R850 2007-000148 R-CHIP
U1107,U1108 2007-000148 R-CHIP
R506,R524 2007-000149 R-CHIP
R513,R514,R515,R517 2007-000157 R-CHIP
R1018,R1019,R1020 2007-000162 R-CHIP
R320,R504,R701,R712 2007-000162 R-CHIP
R805,R806,R807,R808 2007-000162 R-CHIP
R809,R810,R811,R812 2007-000162 R-CHIP
R813,R830,R832,R838 2007-000162 R-CHIP
R843,R845 2007-000162 R-CHIP
R831 2007-000163 R-CHIP
R522 2007-000166 R-CHIP
R511,R519 2007-000170 R-CHIP
R837 2007-000173 R-CHIP
R1005,R1007,R1010 2007-000758 R-CHIP
R718 2007-000775 R-CHIP
R402 2007-000831 R-CHIP
R510,R518,R853 2007-001290 R-CHIP
R104,R105,R106 2007-001305 R-CHIP
R212 2007-001308 R-CHIP
R202,R203,R204,R205 2007-001316 R-CHIP
R901,R906,R907,R908 2007-001316 R-CHIP
R1013,R1014,R421 2007-001319 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
R422,R729,R802,R803 2007-001319 R-CHIP
R413,R414 2007-001333 R-CHIP
R833 2007-001339 R-CHIP
R611,R612 2007-003001 R-CHIP
R1107,R405,R525,R705 2007-007107 R-CHIP
R716 2007-007107 R-CHIP
R523 2007-007132 R-CHIP
R403,R404 2007-007135 R-CHIP
R419,R420,R606,R607 2007-007137 R-CHIP
R1106,R1108 2007-007139 R-CHIP
R303,R305,R306,R307 2007-007142 R-CHIP
R313,R316,R319,R417 2007-007142 R-CHIP
R423,R425,R719 2007-007142 R-CHIP
R727,R728,R730,R731 2007-007197 R-CHIP
R1100,R207,R210 2007-007306 R-CHIP
R424 2007-007308 R-CHIP
R839 2007-007310 R-CHIP
R720 2007-007312 R-CHIP
R602,R603,R613,R614 2007-007317 R-CHIP
R315,R317,R608,R609 2007-007318 R-CHIP
R710 2007-007318 R-CHIP
R717 2007-007480 R-CHIP
R102 2007-007489 R-CHIP
R211,R213 2007-007491 R-CHIP
R704,R722 2007-007573 R-CHIP
R314,R318 2007-007698 R-CHIP
R714 2007-007861 R-CHIP
R852 2007-007942 R-CHIP
R702,R703 2007-007981 R-CHIP
R723 2007-008354 R-CHIP
R725,R726 2007-008420 R-CHIP
C123,C124,C125,C145 2203-000233 C-CERAMIC,CHIP
C151,C209,C219,C355 2203-000233 C-CERAMIC,CHIP
C528,C901,C911 2203-000233 C-CERAMIC,CHIP
C1003,C1031,C1101 2203-000254 C-CERAMIC,CHIP
C302,C331,C342,C343 2203-000254 C-CERAMIC,CHIP
C352,C724,C733 2203-000254 C-CERAMIC,CHIP
C110,C148,C201,C607 2203-000278 C-CERAMIC,CHIP
C610,C909,C910 2203-000278 C-CERAMIC,CHIP
C335 2203-000311 C-CERAMIC,CHIP
C112,C861,C862 2203-000330 C-CERAMIC,CHIP
C216 2203-000359 C-CERAMIC,CHIP
C114,C322,C332,C346 2203-000386 C-CERAMIC,CHIP
C734,C735,C736,C737 2203-000386 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-4
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
C1026,C1027,C1105 2203-000425 C-CERAMIC,CHIP
C1114,C530,C532 2203-000425 C-CERAMIC,CHIP
C102,C212,C213,C215 2203-000438 C-CERAMIC,CHIP
C337,C928 2203-000438 C-CERAMIC,CHIP
C108,C150 2203-000466 C-CERAMIC,CHIP
C351 2203-000585 C-CERAMIC,CHIP
C832 2203-000627 C-CERAMIC,CHIP
C723 2203-000714 C-CERAMIC,CHIP
C1002,C1012,C1032 2203-000812 C-CERAMIC,CHIP
C106,C117,C119,C130 2203-000812 C-CERAMIC,CHIP
C131,C140,C141,C147 2203-000812 C-CERAMIC,CHIP
C200,C205,C401,C411 2203-000812 C-CERAMIC,CHIP
C415,C538,C540,C605 2203-000812 C-CERAMIC,CHIP
C608,C611,C626,C645 2203-000812 C-CERAMIC,CHIP
C716,C731,C906,C907 2203-000812 C-CERAMIC,CHIP
C912,C920,C921,C936 2203-000812 C-CERAMIC,CHIP
C937 2203-000812 C-CERAMIC,CHIP
C348,C864 2203-000854 C-CERAMIC,CHIP
C621,C628,C631,C632 2203-000995 C-CERAMIC,CHIP
C202,C914 2203-001221 C-CERAMIC,CHIP
C606,C609,C612,C627 2203-001259 C-CERAMIC,CHIP
C210,C211,C934,C935 2203-002525 C-CERAMIC,CHIP
C1104,L910 2203-002668 C-CERAMIC,CHIP
C1021,C103,C142,C144 2203-002709 C-CERAMIC,CHIP
C850 2203-002709 C-CERAMIC,CHIP
C320,C336 2203-005050 C-CERAMIC,CHIP
C942 2203-005056 C-CERAMIC,CHIP
C120,C121,C122,C126 2203-005234 C-CERAMIC,CHIP
C903,C904 2203-005234 C-CERAMIC,CHIP
C129,C132,C137,C900 2203-005288 C-CERAMIC,CHIP
C902,C905,C908,C930 2203-005288 C-CERAMIC,CHIP
C1107,C349 2203-005395 C-CERAMIC,CHIP
C206,C208,C221,C520 2203-005482 C-CERAMIC,CHIP
C602,C603,C613,C614 2203-005482 C-CERAMIC,CHIP
C619,C623,C720 2203-005482 C-CERAMIC,CHIP
C203 2203-005682 C-CERAMIC,CHIP
C634,C638 2203-005993 C-CERAMIC,CHIP
C1001,C1004,C1005 2203-006048 C-CERAMIC,CHIP
C1011,C1013,C1018 2203-006048 C-CERAMIC,CHIP
C1028,C1029,C1030 2203-006048 C-CERAMIC,CHIP
C1033,C1100,C1102 2203-006048 C-CERAMIC,CHIP
C111,C139,C207,C214 2203-006048 C-CERAMIC,CHIP
C306,C307,C309,C311 2203-006048 C-CERAMIC,CHIP
C312,C313,C314,C315 2203-006048 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-5
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
C323,C324,C328,C329 2203-006048 C-CERAMIC,CHIP
C402,C403,C404,C405 2203-006048 C-CERAMIC,CHIP
C406,C407,C408,C409 2203-006048 C-CERAMIC,CHIP
C410,C413,C419,C428 2203-006048 C-CERAMIC,CHIP
C429,C430,C431,C432 2203-006048 C-CERAMIC,CHIP
C433,C434,C435,C436 2203-006048 C-CERAMIC,CHIP
C437,C438,C439,C440 2203-006048 C-CERAMIC,CHIP
C441,C531,C539,C541 2203-006048 C-CERAMIC,CHIP
C543,C617,C618,C633 2203-006048 C-CERAMIC,CHIP
C732,C809,C810,C811 2203-006048 C-CERAMIC,CHIP
C812,C813,C820,C823 2203-006048 C-CERAMIC,CHIP
C824,C825,C826,C827 2203-006048 C-CERAMIC,CHIP
C829,C830,C831,C834 2203-006048 C-CERAMIC,CHIP
C863,C867,C868,C869 2203-006048 C-CERAMIC,CHIP
C872,C913,C916,C923 2203-006048 C-CERAMIC,CHIP
C924,C927 2203-006048 C-CERAMIC,CHIP
C220 2203-006137 C-CERAMIC,CHIP
C345 2203-006208 C-CERAMIC,CHIP
C1010,C1014,C1015 2203-006257 C-CERAMIC,CHIP
C1016,C1017,C1020 2203-006257 C-CERAMIC,CHIP
C303,C304,C321,C504 2203-006257 C-CERAMIC,CHIP
C510,C511,C512,C513 2203-006257 C-CERAMIC,CHIP
C514,C515,C516,C518 2203-006257 C-CERAMIC,CHIP
C127,C308,C310,C316 2203-006260 C-CERAMIC,CHIP
C420,C421,C422,C423 2203-006260 C-CERAMIC,CHIP
C424,C425,C426,C427 2203-006260 C-CERAMIC,CHIP
C629,C630 2203-006260 C-CERAMIC,CHIP
C1019,C344 2203-006324 C-CERAMIC,CHIP
C701,C702 2203-006348 C-CERAMIC,CHIP
TA1001 2203-006361 C-CERAMIC,CHIP
C300,C301,C637,C639 2203-006399 C-CERAMIC,CHIP
C204 2203-006423 C-CERAMIC,CHIP
C1023,C1034,C1112 2203-006562 C-CERAMIC,CHIP
C1113,C501,C527,C542 2203-006562 C-CERAMIC,CHIP
C620,C622,C624,C703 2203-006562 C-CERAMIC,CHIP
C704,C705,C707,C708 2203-006562 C-CERAMIC,CHIP
C709,C710,C711,C712 2203-006562 C-CERAMIC,CHIP
C713,C714,C722,C728 2203-006562 C-CERAMIC,CHIP
C729,C730,C738,C739 2203-006562 C-CERAMIC,CHIP
C836,C837 2203-006562 C-CERAMIC,CHIP
C1024,C1025,C635 2203-006681 C-CERAMIC,CHIP
C1007,C1008,C1009 2203-006824 C-CERAMIC,CHIP
C356,C357,C505,C506 2203-006824 C-CERAMIC,CHIP
C507,C508,C517,C521 2203-006824 C-CERAMIC,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-6
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
C544,C840,C852 2203-006824 C-CERAMIC,CHIP
C1006,C334,C416,C502 2203-006825 C-CERAMIC,CHIP
C503,C509,C519,C646 2203-006825 C-CERAMIC,CHIP
C865,C866 2203-006825 C-CERAMIC,CHIP
C1103,C1109,C1110 2203-006838 C-CERAMIC,CHIP
C1111,C526,C625,C636 2203-006838 C-CERAMIC,CHIP
C640,C719,C806,C807 2203-006838 C-CERAMIC,CHIP
C818,C819,C842 2203-006838 C-CERAMIC,CHIP
C529,C535,C536,C814 2203-006841 C-CERAMIC,CHIP
C815,C816,C817,C833 2203-006841 C-CERAMIC,CHIP
C847,C848,C849,C851 2203-006841 C-CERAMIC,CHIP
C853,C854,C855,C856 2203-006841 C-CERAMIC,CHIP
C857,C858 2203-006841 C-CERAMIC,CHIP
C115 2203-006842 C-CERAMIC,CHIP
C100,C101,C104,C116 2203-006872 C-CERAMIC,CHIP
C822,C828 2203-006890 C-CERAMIC,CHIP
C1022,C533,C534,C537 2203-007147 C-CERAMIC,CHIP
C835 2203-007270 C-CERAMIC,CHIP
C718,C803,C804,C841 2203-007271 C-CERAMIC,CHIP
C845,C846,C870,C871 2203-007271 C-CERAMIC,CHIP
TA603 2404-001225 C-TA,CHIP
TA300,TA301,TA302 2404-001381 C-TA,CHIP
TA303,TA800,TA801 2404-001381 C-TA,CHIP
TA1002 2404-001430 C-TA,CHIP
TA600,TA601 2404-001496 C-TA,CHIP
TA100,TA304,TA703 2404-001506 C-TA,CHIP
TA900 2404-001506 C-TA,CHIP
L114 2703-001178 INDUCTOR-SMD
L113 2703-001737 INDUCTOR-SMD
C932 2703-001749 INDUCTOR-SMD
L115 2703-001750 INDUCTOR-SMD
L302,L303 2703-001751 INDUCTOR-SMD
L107,L911 2703-001990 INDUCTOR-SMD
L102 2703-002201 INDUCTOR-SMD
L112 2703-002206 INDUCTOR-SMD
L304 2703-002207 INDUCTOR-SMD
L608,L609 2703-002269 INDUCTOR-SMD
L105 2703-002308 INDUCTOR-SMD
L902,L905 2703-002314 INDUCTOR-SMD
L104 2703-002365 INDUCTOR-SMD
L909 2703-002558 INDUCTOR-SMD
L111,L907 2703-002586 INDUCTOR-SMD
L1101,L1102 2703-002596 INDUCTOR-SMD
L109 2703-002608 INDUCTOR-SMD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-7
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Discription
C929,L901 2703-002700 INDUCTOR-SMD
L310,L501 2703-002840 INDUCTOR-SMD
L502 2703-003194 INDUCTOR-SMD
L308,L800,L801 2703-003260 INDUCTOR-SMD
L704 2703-003285 INDUCTOR-SMD
L1001 2703-003297 INDUCTOR-SMD
OSC501 2801-004339 CRYSTAL-UNIT
OSC800 2801-004458 CRYSTAL-UNIT
OSC100 2801-004560 CRYSTAL-UNIT
OSC900 2801-004587 CRYSTAL-UNIT
TCX200 2809-001303 OSCILLATOR-VCTCXO
F702,F703 2901-001286 FILTER-EMI SMD
F704,F705 2901-001462 FILTER-EMI SMD
Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.

SAMSUNG Proprietary-Contents may change without notice
7. Block Diagrams
7-1
This Document can not be used without Samsung's authorization
1) Total Block Diagram
2) BlueTooth Block Diagram
