Samsung GT-I9505 User manual

N
GSM TELEPHONE
GT-I9505
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
GSM TELEPHONE CONTENTS

1. Safety Precautions
1-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of
the low margin of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use asoldering iron with apower rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replac
ement parts may not function properly.

Safety Precautions
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
1-2
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discha
rge and can be easily damaged by it. We recommend protecting these components with cond
uctive anti-static bags when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are
properly connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

2. Specification
2-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2-1. GSM General Specification
GSM850 EGSM 900 DCS1800 PCS1900 WCDMA
2100 WCDMA 900 WCMDA 850 WCDMA 1900
Freq.
Band[MHz]
Uplink/
Downlink
824~849
869~894 880~915 925~960 1710~1785 1805~1880 1850~1910 1930~1990 1922~1977 2112~2167 880~915 925~960 824~849 869~894 1852~1907 1932~1987
ARFCN
range 128~251 0~124 &
975~1023 512~885 512~810 UL:
9612~9888
DL:
10562~10838
UL:
2712~2863
DL:
2937~3088
UL:
4132~4233
DL:
4357~4458
UL:
9612~9888
DL:
10562~10838
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 45MHz 45MHz 80MHz
Mod. Bit
rate/
Bit Period
270.833kbps
3.692us 270.833kbps 3.692us 270.833kbps 3.692us 270.833kbps 3.692us 3.84Mcps 3.84Mcps 3.84Mcps 3.8Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms 576.9us 4.615ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPSK QPSKHQPSK QPSKHQPSK QPSKHQPSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm 24dBm~
-50dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm
Power Class 5pcl ~ 19pcl 5pcl ~19
pcl 0pcl ~15
pcl 0pcl ~15 pcl 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm -106.7dBm -106.7dBm
TDMAMux88888888
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-2
2-2. GSM Tx Power Class
TX Power
control
level
GSM850
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
EGSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control
level
PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-3
2-3.LTE General Specification
LTE Band1 LTE Band3 LTE Band5 LTE Band7 LTE Band8 LTE Band20
Freq.
Band[MHz]
Uplink/
Downlink
1920~1980
2110~2170
1710~1785
1805~1880
824~849
869~894
2500~2570
1805~1880
880~914.9
925~959.9
832~862
791~821
ARFCN
range
UL:
18000~18599
DL:
0~599
UL:
19200~19950
DL:
1805~1880
UL:
20400~20649
DL:
2400~2649
UL:
2500~2570
DL:
2620~2690
UL:
21450-21799
DL:
3450-3799
UL:
24150~24450
DL:
6150~6450
Tx/Rx
spacing 190MHz 95MHz 45MHz 120MHz 45MHZ -41MHz
Channel
Bandwidth 5/10/15/20 MHz 1.4/3/5/10/15/20
MHz 1.4/3/5/10 MHz 5/10/15/20 MHz 1.4/3/5/10MHz 5/10/15/20 MHz
Modulation QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM
MS Power
(MPR) -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm
Sensitivit
(QPSK)
(BW 10MHz)
-94 dBm -92 dBm -92 dBm -95dBm -95dBm -94dBm
Cell Radius >5Km >5Km >5Km >5Km >5Km >5Km

3. Operation Instruction and Installation
3-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Main Function
•Android OS v4.2.2 (Jelly Bean)
•HSPA+ 21Mbps /HSUPA 5.7Mbps
•LTE 50Mbps UL / 100Mbps DL
•13
MP, Auto Focus, LED Flash
• 5", 1920x1080 pixels, Super AMOLED capacitive touchscreen
•A-GPS and GLONASS /BT v4.0 with A2DP /USB v2.0 /WiFi (802.11 a/b/g/n/ac HT80) /NFC
•Video Recording 1080p / Playback 1080p
•Sensors: Sensor Hub /Accelerometer, Gyro, Compass, Light, Gesture(Proximity), Barometer, IRDA, Temperature,
Humidity, Magnetic, SVC LED
•Additional :
-Quad-core 1.9GHz
-Battery 2,600mAh

4. Exploded View and Parts List
4-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4-1. Cellular phone Exploded View

Exploded View and Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
4-2
Design LOC Description SEC CODE
QCR47 SCREW-MACHINE 6001-001695
QCR67 SCREW-MACHINE 6001-002083
QCR92 SCREW-MACHINE 6001-002261
QMO01 MOTOR LINEAR VIBRATION GH31-00641A
QCB01 CBF COAXIAL CABLE-94.5MM(GT_I9505) GH39-01603A
QBA01 BATTERY GH43-03833A
QSP01 MODULE-SPEAKER(GT_I9505) GH59-13081A
QJK01 MODULE-EARJACK+SENSOR(GT_I9505) GH59-13082A
QSN01 MODULE-SUB PBA+SENSOR FPCB(GT_I9505) GH59-13083A
QAR01 MODULE-RCV+SENSOR+IRLED GH59-13109A
QSM01 MODULE-SD+SIM FPCB(GT_I9505) GH59-13278A
QMP01 A/S ASSY-PBA MAIN(COMM)GT_I9505/M16 GH82-07269A
QCA01 ASSY CAMERA-13M 1/3&quot GH96-06146A
QCA02 ASSY CAMERA-VT MODULE(GT_I9505) GH96-06276A
QFR01 MEA FRONT-OCTA LCD ASSY(SVC/ZW)GT_I9505 GH97-14655A
QRE01 ASSY CASE-REAR GH98-26374A
QCK02 ASSY KEY-POWER GH98-26485A
QVO01 ASSY KEY-VOLUME GH98-26486A
QBC00 ASSY COVER-BATTERY 3G GH98-26755A
4-2. Cellular phone Parts list

5. MAIN Electrical Parts List
5-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
SEC CODE Design LOC Description
0403-001870 D901 DIODE-ZENER
0404-001250 D500 DIODE-SCHOTTKY
0406-001223 ZD1002 DIODE-TVS
0406-001267 ZD909 DIODE-TVS
0406-001267 ZD910 DIODE-TVS
0406-001267 ZD911 DIODE-TVS
0406-001390 ZD908 DIODE-TVS
0406-001413 ZD904 DIODE-TVS
0406-001413 ZD905 DIODE-TVS
0406-001413 ZD906 DIODE-TVS
0406-001459 ZD1000 DIODE-TVS
0406-001459 ZD1001 DIODE-TVS
0406-001506 ZD1004 DIODE-TVS
0406-001506 ZD1005 DIODE-TVS
0406-001506 ZD1006 DIODE-TVS
0406-001506 ZD1100 DIODE-TVS
0406-001506 ZD1101 DIODE-TVS
0406-001553 ZD903 DIODE-TVS
0406-001592 ZD900 DIODE-TVS
0406-001592 ZD901 DIODE-TVS
0406-001592 ZD1003 DIODE-TVS
0505-002341 Q500 FET-SILICON
0505-002341 Q600 FET-SILICON
0505-003234 Q1100 FET-SILICON
0505-003234 Q1101 FET-SILICON
0601-003322 LED900 LED
0801-003437 U1009 IC
0902-002997 UCP600 IC
0903-001886 U202 IC
1001-001546 U500 IC
1001-001650 U1003 IC
1001-001831 U103 IC
1001-001833 U1005 IC
1003-002337 U1008 IC
1003-002468 U901 IC
1009-001058 U1006 IC

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-2
SEC CODE Design LOC Description
1105-002461 UCP600UP IC-DRAM
1107-002251 UME600 IC-FLASH MEMORY
1201-003315 U1000 IC
1201-003497 PA102 IC
1201-003524 U200 IC
1201-003561 PA101 IC
1201-003562 U101 IC
1203-004776 U905 IC
1203-004819 U1001 IC
1203-004819 U1111 IC
1203-005298 U1002 IC
1203-006867 U1106 IC
1203-007324 U1107 IC
1203-007513 U1103 IC
1203-007583 U400 IC
1203-007702 U1129 IC
1203-007724 U800 IC
1203-007736 U802 IC
1203-007762 U801 IC
1203-007765 U1105 IC
1203-007776 U903 IC
1203-007778 U301 IC
1203-007795 U906 IC
1204-003457 U1007 IC
1204-003458 U1110 IC
1205-004444 U1004 IC
1205-004535 U900 IC
1205-004566 U300 IC
1205-004647 U501 IC
1205-004753 U1109 IC
1205-004767 U203 IC
1209-002142 U205 IC
1209-002167 U204 IC
1209-002209 U207 IC
1301-002097 U904 IC
1404-001724 V100 THERMISTOR

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-3
SEC CODE Design LOC Description
1404-001724 V800 THERMISTOR
1404-001724 V802 THERMISTOR
1405-001183 V1001 VARISTOR
1405-001183 V1003 VARISTOR
1405-001183 V1100 VARISTOR
1405-001183 V1101 VARISTOR
1405-001346 V1000 VARISTOR
1405-001371 V1002 VARISTOR
2007-001308 R504 R-CHIP
2007-007134 R1024 R-CHIP
2007-007484 R636 R-CHIP
2007-007741 R904 R-CHIP
2007-007741 R910 R-CHIP
2007-007741 R1137 R-CHIP
2007-008044 R112 R-CHIP
2007-008045 R110 R-CHIP
2007-008045 R111 R-CHIP
2007-008047 R930 R-CHIP
2007-008048 R223 R-CHIP
2007-008049 R509 R-CHIP
2007-008051 R1146 R-CHIP
2007-008052 R1101 R-CHIP
2007-008052 R1135 R-CHIP
2007-008052 R1136 R-CHIP
2007-008052 R1138 R-CHIP
2007-008052 R1142 R-CHIP
2007-008052 R1143 R-CHIP
2007-008052 R214 R-CHIP
2007-008052 R215 R-CHIP
2007-008052 R225 R-CHIP
2007-008052 R619 R-CHIP
2007-008052 R620 R-CHIP
2007-008052 R909 R-CHIP
2007-008055 R1121 R-CHIP
2007-008055 R1122 R-CHIP
2007-008055 R1123 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-4
SEC CODE Design LOC Description
2007-008055 R1125 R-CHIP
2007-008055 R1126 R-CHIP
2007-008055 R1127 R-CHIP
2007-008055 R113 R-CHIP
2007-008055 R1134 R-CHIP
2007-008055 R907 R-CHIP
2007-008294 R601 R-CHIP
2007-008294 R662 R-CHIP
2007-008403 R925 R-CHIP
2007-008419 R1000 R-CHIP
2007-008419 R224 R-CHIP
2007-008419 R804 R-CHIP
2007-008419 R806 R-CHIP
2007-008420 R1002 R-CHIP
2007-008420 R1028 R-CHIP
2007-008420 R1029 R-CHIP
2007-008420 R1032 R-CHIP
2007-008420 R500 R-CHIP
2007-008420 R931 R-CHIP
2007-008478 R1131 R-CHIP
2007-008478 R1139 R-CHIP
2007-008478 R1140 R-CHIP
2007-008478 R1141 R-CHIP
2007-008483 R201 R-CHIP
2007-008483 R202 R-CHIP
2007-008483 R203 R-CHIP
2007-008483 R204 R-CHIP
2007-008483 R205 R-CHIP
2007-008483 R206 R-CHIP
2007-008483 R207 R-CHIP
2007-008483 R208 R-CHIP
2007-008486 R515 R-CHIP
2007-008486 R912 R-CHIP
2007-008516 R1015 R-CHIP
2007-008516 R1030 R-CHIP
2007-008516 R1109 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-5
SEC CODE Design LOC Description
2007-008516 R1144 R-CHIP
2007-008516 R1145 R-CHIP
2007-008516 R1147 R-CHIP
2007-008516 R1161 R-CHIP
2007-008516 R213 R-CHIP
2007-008516 R405 R-CHIP
2007-008516 R406 R-CHIP
2007-008516 R501 R-CHIP
2007-008516 R502 R-CHIP
2007-008516 R503 R-CHIP
2007-008516 R512 R-CHIP
2007-008516 R513 R-CHIP
2007-008516 R521 R-CHIP
2007-008516 R610 R-CHIP
2007-008516 R640 R-CHIP
2007-008516 R644 R-CHIP
2007-008516 R651 R-CHIP
2007-008516 R652 R-CHIP
2007-008516 R653 R-CHIP
2007-008516 R654 R-CHIP
2007-008516 R665 R-CHIP
2007-008516 R921 R-CHIP
2007-008516 R922 R-CHIP
2007-008516 R923 R-CHIP
2007-008516 R924 R-CHIP
2007-008516 R932 R-CHIP
2007-008516 R933 R-CHIP
2007-008516 R934 R-CHIP
2007-008516 R935 R-CHIP
2007-008516 R936 R-CHIP
2007-008516 R937 R-CHIP
2007-008531 R1152 R-CHIP
2007-008531 R1153 R-CHIP
2007-008531 R407 R-CHIP
2007-008531 R408 R-CHIP
2007-008548 R643 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-6
SEC CODE Design LOC Description
2007-008588 R211 R-CHIP
2007-008588 R212 R-CHIP
2007-008588 R216 R-CHIP
2007-008588 R218 R-CHIP
2007-008588 R219 R-CHIP
2007-008588 R615 R-CHIP
2007-008588 R616 R-CHIP
2007-008588 R621 R-CHIP
2007-008588 R622 R-CHIP
2007-008588 R623 R-CHIP
2007-008588 R624 R-CHIP
2007-008588 R625 R-CHIP
2007-008588 R626 R-CHIP
2007-008588 R627 R-CHIP
2007-008588 R628 R-CHIP
2007-008588 R629 R-CHIP
2007-008588 R630 R-CHIP
2007-008588 R638 R-CHIP
2007-008588 R639 R-CHIP
2007-008588 R927 R-CHIP
2007-008588 R928 R-CHIP
2007-008672 R1110 R-CHIP
2007-008672 R1111 R-CHIP
2007-008672 R1112 R-CHIP
2007-008672 R1113 R-CHIP
2007-008672 R1114 R-CHIP
2007-008672 R1115 R-CHIP
2007-008672 R1116 R-CHIP
2007-008672 R1117 R-CHIP
2007-008672 R1118 R-CHIP
2007-008672 R1156 R-CHIP
2007-008774 R901 R-CHIP
2007-008774 R902 R-CHIP
2007-008774 R903 R-CHIP
2007-008808 R807 R-CHIP
2007-009084 R1001 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-7
SEC CODE Design LOC Description
2007-009084 R1014 R-CHIP
2007-009084 R1151 R-CHIP
2007-009084 R913 R-CHIP
2007-009108 R114 R-CHIP
2007-009157 R107 R-CHIP
2007-009157 R1150 R-CHIP
2007-009157 R409 R-CHIP
2007-009157 R808 R-CHIP
2007-009157 R809 R-CHIP
2007-009157 R814 R-CHIP
2007-009171 R1017 R-CHIP
2007-009171 R303 R-CHIP
2007-009208 R1005 R-CHIP
2007-009208 R1006 R-CHIP
2007-009212 R1007 R-CHIP
2007-009212 R302 R-CHIP
2007-009212 R506 R-CHIP
2007-009223 R1010 R-CHIP
2007-009323 R812 R-CHIP
2007-009323 R813 R-CHIP
2007-009358 R301 R-CHIP
2007-009398 R227 R-CHIP
2007-009408 R1020 R-CHIP
2007-009408 R1021 R-CHIP
2007-009410 R805 R-CHIP
2007-009793 R1011 R-CHIP
2007-009801 R1162 R-CHIP
2007-009801 R1163 R-CHIP
2007-009801 R1164 R-CHIP
2007-009801 R1165 R-CHIP
2007-009801 R1166 R-CHIP
2007-009801 R1167 R-CHIP
2007-009866 R1149 R-CHIP
2007-009920 R505 R-CHIP
2007-009920 R508 R-CHIP
2007-009920 R641 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-8
SEC CODE Design LOC Description
2007-009920 R646 R-CHIP
2007-009920 R647 R-CHIP
2007-009920 R648 R-CHIP
2007-009920 R649 R-CHIP
2007-009969 R1008 R-CHIP
2007-010202 R1012 R-CHIP
2007-011043 R637 R-CHIP
2203-000311 C232 C-CERAMIC,CHIP
2203-000311 C261 C-CERAMIC,CHIP
2203-000438 C205 C-CERAMIC,CHIP
2203-000725 C926 C-CERAMIC,CHIP
2203-001101 C931 C-CERAMIC,CHIP
2203-001239 C940 C-CERAMIC,CHIP
2203-005249 C947 C-CERAMIC,CHIP
2203-005659 C238 C-CERAMIC,CHIP
2203-005659 C260 C-CERAMIC,CHIP
2203-005682 C1033 C-CERAMIC,CHIP
2203-005682 C104 C-CERAMIC,CHIP
2203-005682 C1045 C-CERAMIC,CHIP
2203-005682 C105 C-CERAMIC,CHIP
2203-005682 C1181 C-CERAMIC,CHIP
2203-005682 C120 C-CERAMIC,CHIP
2203-005682 C123 C-CERAMIC,CHIP
2203-005682 C136 C-CERAMIC,CHIP
2203-005682 C137 C-CERAMIC,CHIP
2203-005682 C167 C-CERAMIC,CHIP
2203-005682 C197 C-CERAMIC,CHIP
2203-005682 C300 C-CERAMIC,CHIP
2203-005682 C935 C-CERAMIC,CHIP
2203-005683 C107 C-CERAMIC,CHIP
2203-005683 C245 C-CERAMIC,CHIP
2203-005683 C246 C-CERAMIC,CHIP
2203-005725 C1100 C-CERAMIC,CHIP
2203-005725 C1101 C-CERAMIC,CHIP
2203-005725 C1134 C-CERAMIC,CHIP
2203-005725 C1135 C-CERAMIC,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-9
SEC CODE Design LOC Description
2203-005725 C1180 C-CERAMIC,CHIP
2203-005725 C1185 C-CERAMIC,CHIP
2203-005726 C1002 C-CERAMIC,CHIP
2203-005726 C1004 C-CERAMIC,CHIP
2203-005726 C942 C-CERAMIC,CHIP
2203-005727 C223 C-CERAMIC,CHIP
2203-005727 C917 C-CERAMIC,CHIP
2203-005729 C1003 C-CERAMIC,CHIP
2203-005729 C1005 C-CERAMIC,CHIP
2203-005729 C1009 C-CERAMIC,CHIP
2203-005729 C1010 C-CERAMIC,CHIP
2203-005729 C132 C-CERAMIC,CHIP
2203-005729 C222 C-CERAMIC,CHIP
2203-005729 C329 C-CERAMIC,CHIP
2203-005729 C608 C-CERAMIC,CHIP
2203-005729 C609 C-CERAMIC,CHIP
2203-005729 C943 C-CERAMIC,CHIP
2203-005731 C1041 C-CERAMIC,CHIP
2203-005731 C1042 C-CERAMIC,CHIP
2203-005734 C902 C-CERAMIC,CHIP
2203-005734 C930 C-CERAMIC,CHIP
2203-005736 C1046 C-CERAMIC,CHIP
2203-005736 C161 C-CERAMIC,CHIP
2203-005736 C162 C-CERAMIC,CHIP
2203-005736 C171 C-CERAMIC,CHIP
2203-005736 C185 C-CERAMIC,CHIP
2203-005736 C201 C-CERAMIC,CHIP
2203-005736 C202 C-CERAMIC,CHIP
2203-005736 C203 C-CERAMIC,CHIP
2203-005736 C206 C-CERAMIC,CHIP
2203-005736 C216 C-CERAMIC,CHIP
2203-005736 C301 C-CERAMIC,CHIP
2203-005736 C306 C-CERAMIC,CHIP
2203-005736 C326 C-CERAMIC,CHIP
2203-005739 C858 C-CERAMIC,CHIP
2203-005739 C859 C-CERAMIC,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-10
SEC CODE Design LOC Description
2203-005777 C118 C-CERAMIC,CHIP
2203-005777 C131 C-CERAMIC,CHIP
2203-005777 C150 C-CERAMIC,CHIP
2203-005777 C156 C-CERAMIC,CHIP
2203-005777 C190 C-CERAMIC,CHIP
2203-005777 C195 C-CERAMIC,CHIP
2203-005777 C200 C-CERAMIC,CHIP
2203-005789 C113 C-CERAMIC,CHIP
2203-005789 C115 C-CERAMIC,CHIP
2203-005789 C163 C-CERAMIC,CHIP
2203-005789 C170 C-CERAMIC,CHIP
2203-005789 C218 C-CERAMIC,CHIP
2203-005806 C233 C-CERAMIC,CHIP
2203-005806 C236 C-CERAMIC,CHIP
2203-005806 C427 C-CERAMIC,CHIP
2203-006048 C927 C-CERAMIC,CHIP
2203-006048 C928 C-CERAMIC,CHIP
2203-006121 C919 C-CERAMIC,CHIP
2203-006121 C920 C-CERAMIC,CHIP
2203-006187 C174 C-CERAMIC,CHIP
2203-006194 C234 C-CERAMIC,CHIP
2203-006194 C324 C-CERAMIC,CHIP
2203-006194 C844 C-CERAMIC,CHIP
2203-006305 C1183 C-CERAMIC,CHIP
2203-006305 L120 C-CERAMIC,CHIP
2203-006318 C199 C-CERAMIC,CHIP
2203-006348 C900 C-CERAMIC,CHIP
2203-006348 C901 C-CERAMIC,CHIP
2203-006379 C323 C-CERAMIC,CHIP
2203-006399 C604 C-CERAMIC,CHIP
2203-006400 C106 C-CERAMIC,CHIP
2203-006410 C208 C-CERAMIC,CHIP
2203-006423 C1038 C-CERAMIC,CHIP
2203-006423 C1044 C-CERAMIC,CHIP
2203-006423 C1138 C-CERAMIC,CHIP
2203-006423 C1140 C-CERAMIC,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-11
SEC CODE Design LOC Description
2203-006423 C1141 C-CERAMIC,CHIP
2203-006423 C1142 C-CERAMIC,CHIP
2203-006423 C1144 C-CERAMIC,CHIP
2203-006423 C1161 C-CERAMIC,CHIP
2203-006423 C166 C-CERAMIC,CHIP
2203-006423 C204 C-CERAMIC,CHIP
2203-006423 C219 C-CERAMIC,CHIP
2203-006423 C220 C-CERAMIC,CHIP
2203-006423 C221 C-CERAMIC,CHIP
2203-006423 C249 C-CERAMIC,CHIP
2203-006423 C262 C-CERAMIC,CHIP
2203-006423 C406 C-CERAMIC,CHIP
2203-006423 C518 C-CERAMIC,CHIP
2203-006423 C936 C-CERAMIC,CHIP
2203-006423 C937 C-CERAMIC,CHIP
2203-006423 C946 C-CERAMIC,CHIP
2203-006423 C950 C-CERAMIC,CHIP
2203-006556 C1035 C-CERAMIC,CHIP
2203-006556 C1036 C-CERAMIC,CHIP
2203-006556 C1037 C-CERAMIC,CHIP
2203-006556 C109 C-CERAMIC,CHIP
2203-006556 C114 C-CERAMIC,CHIP
2203-006562 C905 C-CERAMIC,CHIP
2203-006611 C101 C-CERAMIC,CHIP
2203-006626 C224 C-CERAMIC,CHIP
2203-006626 C226 C-CERAMIC,CHIP
2203-006648 C1000 C-CERAMIC,CHIP
2203-006648 C1001 C-CERAMIC,CHIP
2203-006665 C151 C-CERAMIC,CHIP
2203-006665 C154 C-CERAMIC,CHIP
2203-006665 C213 C-CERAMIC,CHIP
2203-006707 C172 C-CERAMIC,CHIP
2203-006839 C1006 C-CERAMIC,CHIP
2203-006839 C1011 C-CERAMIC,CHIP
2203-006839 C1013 C-CERAMIC,CHIP
2203-006839 C1016 C-CERAMIC,CHIP
