Samsung R100 User manual

Quick-Start Guide
pms226pms1235pms2603 pms298

Your Samsung R100
Earpiece
Volume
Display
Navigation Key
Left Select Key
Send Key
Microphone
Headphone
Jack
Power
Connector
OK/Select Key
Right Select Key
End Key
Clear Key
1

Installing and removing the battery
Your phone comes packaged with a partially-
charged rechargeable Lithium-Ion battery
and travel adapter.
You must fully charge the battery the rst
time you use your phone, otherwise you
could damage the battery.
Battery cover
Remove the battery cover to access the battery.
•To remove the battery cover,
press on the arrow while
sliding the cover, then lift the
battery cover slightly and slide
the cover off.
•To replace the battery cover,
press the top end of the
battery cover down lightly,
and slide it over the battery
until it clicks into place.
2

•Match the gold
contacts on the
battery to those on
the phone, then press
the battery down into
the phone.
Remove the battery
Before removing the battery, turn off the phone by
pressing and holding down the END key .
•Lift the end of the battery up and out of
the phone.
3
Install the battery

4
Charging the battery
Your phone is powered by a rechargeable standard
Lithium-Ion battery. Only use Samsung-approved
charging devices and batteries. Samsung accessories
are designed to maximize battery life. Use of other
accessories may invalidate your warranty and may
cause damage.
Using the travel charger
The travel charger included with your phone is a
convenient, lightweight charger that rapidly charges
your phone from any 120/220 VAC outlet.
1. Plug the large end of the travel charger into a
standard 120 VAC or 220 VAC wall outlet.
incorrect
correct
