Samsung SCH-A570U User manual

YJ14.05_CB_101805_F2
SCH-a570 Series
PORTABLE Dual-Mode
MOBILE PHONE
User Guide
Please read this manual before operating your
phone, and keep it for future reference.

Intellectual Property
AllIntellectualProperty,asdefinedbelow,ownedbyorwhichis
otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to,
accessories, parts, or software relating there to (the “Phone
System”),isproprietarytoSamsungandprotectedunderfederal
laws,statelaws,andinternationaltreatyprovisions.Intellectual
Propertyincludes,butisnotlimitedto,inventions(patentableor
unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other
works ofauthorship. You may not infringe or otherwise violate
the rights secured by the Intellectual Property. Moreover, you
agreethatyou willnot (andwillnot attemptto)modify, prepare
derivative works of, reverse engineer, decompile, disassemble,
orotherwiseattempttocreatesourcecodefromthesoftware.No
titletoorownershipintheIntellectualPropertyistransferredto
you. All applicable rights of the Intellectual Property shall
remain with SAMSUNG and its suppliers.
Samsung Telecommunications America (STA),
Inc.
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein Street
Richardson, TX 75082 Plano, TX 75074
Tel: [phone] Toll Free Tel: [phone].HELP (4357)
Internet Address: http://www.samsungusa.com
©2005 Samsung Telecommunications America, Inc. is a
registered trademark of Samsung Electronics America, Inc. and
its related entities.

Licensed by Qualcomm Incorporated under one or more of the
followingpatents:U.S.PatentNo.4,901,307;5,056,109;5,099,204;
5, 101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390.
Printed in South Korea
GH68-07735A
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered Trademark RSA Security, Inc.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH
THEPRODUCT,THEPURCHASERTAKESTHEPRODUCT“AS
IS”, AND SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITYOFTHEPRODUCTORITSFITNESSFOR
ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP
OF THE PRODUCT OR THE COMPONENTS CONTAINED
THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR
CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TOTHEPRODUCT.INADDITION,SAMSUNGSHALLNOTBE
LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE OR USE OF THE PRODUCT OR
ARISINGFROMTHEBREACHOFTHEEXPRESSWARRANTY,
INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR
BENEFITS.

Table of Contents 5
Table of Contents
Table of Contents
Section 1: Getting Started .................................9
Activating Your Phone ....................................................10
Charging the Battery ......................................................12
Setting Up Your Voice Mail .............................................13
Understanding this User Manual .....................................14
Section 2: Understanding Your Phone ............15
Features of Your Phone ..................................................16
Closed View of Your Phone .............................................16
Open View of Your Phone ...............................................18
Understanding the Display Screen ..................................20
Section 3: Call Functions .................................23
Making a Call—Number Entry Dialing ............................24
Making a Call—Speed Dialing ........................................25
Making a Call—Voice Dialing .........................................26
Answering a Call ............................................................29
Ignoring a Call ................................................................30
Adjusting the Call Volume ...............................................30
Calls Log ........................................................................31
Phone Modes .................................................................35
Roaming ........................................................................40
Section 4: Menu Navigation ............................41
Menu Navigation ............................................................42
In Use Menu Outline .......................................................44
Menus and Sub-menus ..................................................45
Section 5: Entering Text ..................................53
Text Entry Modes ...........................................................54
Entering Upper and Lower Case Letters ..........................54
Entering Symbols ...........................................................55
Entering Numbers ..........................................................56

Table of Contents
6
Using T9 Mode ...............................................................56
Changing the Text Entry Mode ........................................57
Section 6: Understanding Your Contacts ........59
Your Contacts List ..........................................................60
Adding a New Contacts Entry ..........................................61
Finding a Contacts Entry .................................................66
Editing an Existing Contact Entry ....................................71
Renaming a Contacts Group ...........................................75
Deleting a Contact Entry .................................................75
Finding My Phone Number .............................................76
Memory ..........................................................................77
Section 7: Messaging ......................................79
Creating and Sending New Messages .............................80
Message Send Options ...................................................81
Retrieving New Messages ..............................................82
Voice Mail ......................................................................82
Message Folders ............................................................83
Message Settings ...........................................................87
Deleting Messages .........................................................89
Section 8: Changing Your Settings .................91
Display Settings .............................................................92
Sound Settings ...............................................................97
Location Setting ...........................................................102
Network Selection ........................................................102
Security Settings ..........................................................103
Ringer Settings .............................................................109
Call Options ..................................................................109
Shortcut .......................................................................114
Language .....................................................................115
Clock Set ......................................................................115
Version .........................................................................116
Voice Settings ..............................................................116

Table of Contents 7
Table of Contents
Section 9: Personal Organizer .......................125
Planner ........................................................................126
Today ...........................................................................127
Calendar ......................................................................129
To-Do List ....................................................................130
Alarm Clock .................................................................132
Memo Pad ...................................................................134
Voice Memo .................................................................135
World Time ..................................................................137
Calculator ....................................................................138
Count Down .................................................................139
Section 10: Network Services .......................143
Call Forwarding ............................................................144
Call Waiting ..................................................................144
Three-Way Calling ........................................................145
Caller ID .......................................................................145
Call Block .....................................................................145
Section 11: easyedgeSM ..................................147
easyedgeSM Features ...................................................148
easyedgeSM Settings ....................................................148
easyedgeSM Help ..........................................................149
Section 12: Health and Safety Information ...151
Health and Safety Information ......................................152
Consumer Information on Wireless Phones ...................154
Road Safety .................................................................164
Operating Environment .................................................166
Using Your Phone Near Other Electronic Devices ..........167
Potentially Explosive Environments ...............................169
Emergency Calls ..........................................................170
FCC Notice and Cautions ..............................................171
Other Important Safety Information ...............................172
Product Performance ...................................................173

Table of Contents
8
Availability of Various Features/Ring Tones ...................174
Battery Standby and Talk Time .....................................175
Battery Precautions ......................................................175
Care and Maintenance ..................................................177
Section 13: Warranty Information .................179
Standard Limited Warranty ...........................................180
Index ...............................................................187

Section 1: Getting Started 9
Section 1
Section 1: Getting Started
Topics Covered
• Activating your phone
• Charging the Battery
• Setting Up Your Voicemail
• Understanding this User Manual
This section explains how to start using your phone
by activating your service, setting up your voice
mail, contacting customer support, or getting an
understanding of how this manual is put together.

10
Section 1
Activating Your Phone
Contact your Wireless Carrier and follow their
instructions for obtaining service, if necessary. We
suggest that you read this guide to fully understand the
services your phone supports.
Install the Battery
Note: Your phone comes packaged with a partially charged rechargeable
standard Li-Ion battery and travel adapter.
Important: You can use your phone while the battery is charging, but you
must fully charge the battery the first time you use your phone, otherwise
you could damage the battery.
1. Insert the bottom end
of the battery first,
matching the gold
contactsontheinside
ofthebatterytothose
on the phone.
2. Pressthetopendof
the battery down
into the phone until
you hear it snap
into place.

Section 1: Getting Started 11
Activating Your Phone
Section 1
Remove the Battery
1. Press and hold the key to turn off the phone (if on).
2. Slide the battery
release latch (1)
toward the top end
of the phone and
hold.
3. Lift the battery (2)
up and away from
the phone, top end first.
Turn Your Phone On
1. Fully extend the antenna for the clearest reception, then
open the folder on your phone.
2. Press the key for two or more seconds.
Note: As with any other radio-transmitting device, do not touch the
antenna while using your phone as this can affect call quality and can
cause the phone to operate at a higher power level than is necessary.
3. “US Cellular” momentarily appears in the display and
your phone begins searching for a network signal.
4. Once the phone finds a signal, the time, date and day
appear in the bottom of the display.
5. You’re now ready to place and receive calls.
Note: If you are outside of your carrier’s coverage or roaming area, the No
Service icon ( ) appears at the top of the phone’s display. If you cannot
place or receive calls, try later when service is available.
12

12
Section 1
Turn Your Phone Off
■Pressand holdthe keyfortwo ormore seconds.Your
phone powers off.
Note: If your phone is on and you press for less than one second, the
phone will not power off. This prevents your phone from being turned off
accidentally.
Charging the Battery
Your phone is powered by a rechargeable standard Li-
Ion battery. Only use Samsung-approved charging
devices and batteries. Samsung accessories are
designed to maximize battery life. Using other
accessories may invalidate your warranty and may
cause damage.
Use the Travel Adapter
The travel adapter included
with your phone is a convenient,
light-weight charger that
rapidly charges your phone
from any 120/220 VAC outlet.
1. Plug the large end of the Travel Adapter into a standard
120 VAC or 220 VAC wall outlet.
2. Insert the smaller end of the
Travel Adapter into the
charger/accessoryconnector
at the bottom end of your
phone.

Section 1: Getting Started 13
Setting Up Your Voice Mail
Section 1
Low battery indicator
The battery indicator ( ) in the upper-right corner of
the display indicates power level. Monitor the battery
strength and ensure your battery is adequately charged.
• Four bars ( ) indicate a full charge.
• An empty battery icon ( ) indicates a near empty battery.
• A blinking empty battery icon ( ) and a tone sounding
indicate you have two to three minutes before the battery is
too low to operate the phone.
If you continue to use your phone without charging its battery,
the phone shuts down.
Setting Up Your Voice Mail
1. In standby mode, press and hold the key or dial
your mobile number and press the key.
Voicemail answers and begins playing your Voicemail
account greeting message.
2. Press the key to interrupt the greeting.
3. Follow the prompts in the new user tutorial to setup you
mailbox.

14
Section 1
Understanding this User Manual
The chapters of this guide generally follow the same
order as the menus and sub-menus in your phone.
Also included is important safety information that you
should know before using your phone. Most of this
information is near the back of the guide, beginning on
page 151.
If you still have questions, we’ll be happy to answer
them. Just call our Samsung Customer Care Center toll-
free at 1.888.987.HELP (4357).

Section 2: Understanding Your Phone 15
Section 2
Section 2: Understanding Your Phone
Topics Covered
• Features of Your Phone
• Closed View of Your Phone
• Open View of Your Phone
• Understanding the Display Screen
This section outlines some key features of your
phone. This section also explains the screen and the
icons that are displayed when the phone is in use.

16
Section 2
Features of Your Phone
• 128 X 160 pixel Liquid Crystal Display
• High speed data (CDMA 2000 1X Technology)
• Global Positioning Technology (GPS)
• PIM functions (Scheduler, To Do List,and so on)
• Text Messaging (SMS)
• Voice Dial
• 32-Note Polyphonic Ringtones
Closed View of Your Phone
Command Keys and Features
1. Headset Connector—Used for handsfree,
Teletypewriter (TTY), and Telecommunication Device for
the Deaf (TDD) equipment.

Section 2: Understanding Your Phone 17
Closed View of Your Phone
Section 2
2. Volume Key—Lets you adjust the ringer volume in
standby mode (with the folder open) or adjust the voice
volume during a call. To mute the ringer during an
incoming call, press the volume key up or down.
3. Speaker—The speaker, on the front of the folder, plays
sounds such as ring tones and alerts.
4. External LCD—Indicates when you have an incoming
call or a message.
5. Service LED—The Service LED on the top of the phone
has the following functions.
䢇Lights red while charging. Green when charging is complete.
䢇Flashes to indicate an incoming call or message.
䢇Lights momentarily when you power up the phone and flashes
red when the phone is in need of a charge
6. Antenna—Used to obtain receptions

18
Section 2
Open View of Your Phone
Command Keys and Features
7. Display—This screen displays all the information
needed to operate your phone.
8. Settings—In Idle mode, launches the Settings menu.
9. Left Soft Key—Performs the functions indicated by the
screen text on the bottom of the display.
10.SEND Key—This key is used to initiate your calls.

Section 2: Understanding Your Phone 19
Open View of Your Phone
Section 2
11.OK/Menu Key—Pressing when navigating through a
menu accepts the highlighted choice in the menu.
Pressing when in standby mode displays the first of
several menus.
12.Voice Mail Key—Press and hold to automatically dial
your voicemail.
13.Alphanumeric Key Pad—Use these keys to enter
numbers, letters, and characters.
14.Hot Key—Lets you enter and exit silent mode.
15.Charger/PC Data Link Cable Jack—The Charger/PC
Data Link Cable Jack is used to plug in the charging
accessories and connect any available accessory cable
16.Microphone—The microphone used during phone calls
and voice memo recordings.
17.CLR (clear) Key—Deletes characters from the display
whenyou are intext entry mode. Whenin amenu, press
to return to the previous menu.
18.User Defined Shortcut—Lets you customize key.
19.END/Power/Exit Menu Key—Ends a call. Press and
hold this key for a few seconds to turn your phone On or
Off. When you receive an incoming call, press to mute
the ringer and send the call to voicemail.
20.Right Soft Key—Performsthefunctionsindicatedbythe
screen text on the bottom of the display.
21.easyedgeSM—In Idle mode, launches easyedgeSM.
22.Sounds—In Idle mode, launches the Sounds menu.
23.Earpiece—Used to listen.

20
Section 2
Understanding the Display Screen
The top line of your phone’s
display contains icons that
indicate network status, battery
power, signal strength,
connection type, and more. The
following list contains icons that
may appear in your display.
Display screen icons
Signal strength—Always appears when your phone is
on and indicates the current signal strength. More lines
indicate higher signal strength.
Service indicator—Indicates a call in progress. When
dialing a number, this icon flashes until the call connects.
No service indicator—Indicates your phone cannot find
a signal because you’re outside a service area. You
cannot make or receive calls. Wait for a signal or move
into an open area to try and find a signal. The no service
indicator always appears when you turn on your phone
and disappears once service is located.
Roam—Extended roaming indicator. Roaming occurs
when you use your phone outside your home area. While
roaming, a wireless system other than your Wireless
Provider's handles your call, so the service rate for the
call may be higher than those made within your home
area. Please refer to information from your Wireless
Provider on roaming rates.
New Message—Indicates that you’ve received a new
text,page, orweb alert message.You’realso notifiedby a
visual and audible alert.
