Samsung SCH-U540T User manual

* Some of the contents of this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com

SCH-U540T
User’s Guide

Intellectual Property
All Intellectual Property, as defined below, owned by or
which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is
proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions.
Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade
secrets, copyrights, software, computer programs, and
related documentation and other works of authorship.
You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify,
prepare derivative works of, reverse engineer,
decompile, disassemble, or otherwise attempt to create
source code from the software. No title to or ownership
in the Intellectual Property is transferred to you. All
applicable rights of the Intellectual Property shall
remain with SAMSUNG and its suppliers.
Samsung Telecommunications
America (STA), Inc.
Headquarters:
1301 East Lookout Drive Suite 150 Richardson,
TX 75082
Tel: [phone]
Customer Care Center:
1601 E. Plano Parkway, Suite 150 Plano, TX 75074
Toll Free Tel: [phone].HELP (4357)
Fax: [phone]
Internet Address: http://www.samsungusa.com
©2004 Samsung Telecommunications America, Inc. is a
registered trademark of Samsung Electronics America,
Inc. and its related entities.
Licensed by Qualcomm Incorporated under one or more of
the following patents: U.S. Patent No. 4, 901, 307; 5, 056,
109; 5, 099, 204; 5,101, 501; 5, 103, 459; 5, 107, 225;
5, 109, 390.
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered TrademarSk RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED ON THE WARRANTY PAGE ENCLOSED
WITH THE PRODUCT, THE PURCHASER TAKES THE
PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS
OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT
NOT LIMITED TO THE MERCHANTABILITY OF THE
PRODUCT OR ITS FITNESS FOR ANY PARTICULAR
PURPOSE OR USE; THE DESIGN, CONDITION OR
QUALITY OF THE PRODUCT; THE PERFORMANCE OF
THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT
OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION
OR CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG
SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY
KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF
ANTICIPATED PROFITS OR BENEFITS.

Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.

Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press [ ].
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 17.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
Contents
Unpack 3
Make sure you have each item
Your phone 3
Buttons, features, and locations
Get started 4
First steps to operate your phone
Menu functions 8
All menu options listed
Solve problems 17
Help and personal needs
Health and safety information 19

3
Unpack
Make sure you have each item
You can obtain the following accessories for your
phone from your local Samsung dealer.
Phone Travel Adapter
Battery User’s Manual
• Standard battery • Extended battery
• Battery charger • Leather case
• Headset • Data link cable
• Car charger/
adapter
•Travel chager/
adapte
• Portable hands free kit

4
Get started
First steps to operate your phone
Install and charge the phone
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Install the battery:
To remove the battery,
slide the battery catch
toward the top of the
phone and hold it.
Plug the adapter into
the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon stops blinking), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
1 2
3
4
5
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [] to turn on
the phone.
3. If necessary, enter the PIN and
press < OK >
Power off 1. Open the phone.
2. Press and hold [] .

5
Get started
Keys and display
Key(s) Description
Soft keys Perform the function indicated on the bottom
line of the display.
Navigation
keys
In Idle mode, access menu options directly.
In Menu mode, scroll through the menu
options.
Menu/OK
key
In Idle mode, enters Menu mode.
In Menu mode, selects the highlighted menu
option.
Send key
Sends or answers a call.
In Idle mode, retrieves the last number
dialled, missed, or received.
Back key
Deletes characters from the display.
In Menu mode, returns to the previous menu
level.
Key(s) Description
End key
Ends a call. Hold down to switch the phone
on and off.
In Menu mode, cancels input and returns the
phone to Idle mode.
Numeric
keys
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1] down to access your
voicemail.
*/# key
Enter special characters.
Use for some special functions.
R-Link key
(on the left)
Accesses the Ready link list.
Makes and answers a R-Link call.

6
Get started
Volume
keys (on the
left)
Adjusts the phone volume.
In Idle mode, with the phone open, adjusts
the keypad tone volume. With the phone
closed, hold down to turn on the backlight.
In Menu mode, scrolls through the menu
options.
Speaker
phone key
(on the right)
Turns on the external speaker during a call.
In Idle mode, retrieves the last number
dialed, received, or missed.
Holde down to start the voice recognition.

7
Overview of menu functions
To access Menu mode, press [OK] in Idle mode.
1 Missed Alerts
2 Call History
1 Missed Calls
2 Incoming Calls
3 Outgoing Calls
4 Recent Calls
5 Erase History
6 Call Timers
3 Contacts
1 Find
2 Add New Entry
3 Speed Dial #’s
4 Groups
5 My Name Card
4 Messaging
1 Voice Mail
2 Text and Multimedia
3 Web Alert
4 E-Mail
5 IM & Chat
6 Short Codes
5 Pictures
1 Camera
2 Camcorder
3 My Albums
6 Shop
1 Launch
7 My Content
8 Games
9 Music
1 TELUS Music Player
2 My Music List
0 Web
3
* Tools
1 Alarm
2 Bluetooth
3 Calculator
4 Calendar
5 Mass storage
6 Memo Pad
7 World Time
8 Voice Memo
9 Voice Services
0 Set Time
# Settings
1 Display
2 Sounds
3 Games/Tools
4 Text Entry
5 Phone infomation
6 More...

8
Menu functions
All menu options listed
Missed Alerts
Missed events is a simple way of viewing all missed calls,
missed tasks, scheduler events, etc. A list is displayed
onscreen that allows you to scroll through all the events
using the navigation key.
To view missed events:
From the standby by screen, press the navigation key up
to view the Missed Events screen.
Call History
You can use the Call History menu to:
• .View and dial the missed, outgoing or incoming
numbers.
• Erase the numbers in the Call Log memory.
Missed Calls
This option lets you view the last 10 calls missed. (if
you are subscribed to the caller ID service). When you
access this menu, the last missed calls are displayed.
Incoming Calls
This option lets you view the last 10 calls received. (if
you are subscribed to the caller ID service). When you
access this menu, the last incoming calls are
displayed.
Outgoing Calls
The phone stores up to 10 outgoing calls you dialed.
When you access this menu, the list of outgoing calls
is displayed.
Recent Calls
Use All recent to view received, dialed, and missed
calls for your phone. You can also use All recent to
erase your call history and view Call Timers.

Menu functions
9
While viewing All recent, you have options such as
saving recent call numbers to your Phonebook,
sending messages to recent call numbers, and
prepending (editing) numbers before saving.
Erase History
Use this menu to erase the entries stored in each of
call logs.
Call Timers
Contacts
You can store phone numbers in your phone.
To access this menu, press [ ] in Idle mode and
select Contacts .
Find
This menu allows you to find an entry using a person’s
name, entry number, or group name in your Contacts.
Add New Entry
This menu allows you to add a new entry to your
Contacts. A name can contain up to 6 numbers in
different categories; Home, Work, Mobile, Paper, Fax,
and No label.
Speed Dial #s
Speed dialing allows you to press and hold a key (or
keys) to dial the number associated with those key(s).
There are three types of speed dialing; 1-touch, 2-
touch, and 3-touch dialing.
Groups
In this menu, you can change the default group names
and ringer melodies.
My Name Card
My Name Card allows you to create a virtual business
card. Once completed, you can send thecard to
recipients as a V-card attachment.

10
Menu functions
Messaging
Use the Messaging menu to send and receive short
text messages to and from other mobile phones. In
addition, your phone supports the Enhanced
Messaging Service (EMS), which enables you to
include simple pictures, melodies, and animated
images in your messages. You can also use the voice
mail feature.
To access this menu, press [ OK ] in Idle mode and
select Messaging .
Voice Mail
Use this menu to dial to the voice mail server and
access your voice mails. You can also delete voice
mails you have received.
Text and Multimedia
You can create and send new text and multimedia
messages including voice SMS messages and e-mails.
You can view the messages you have received, sent,
or saved separately in this message box. When you
access each message box, a list of messages displays.
Web Alert
Use this menu to allow you to view specific Web alerts
from your service provider.
E-Mail
Use this menu to allow you to access your e-mail
messages.
IM & Chat
TUse this menu to allow you send and receive
messages to and from popular IM (Instant
Messaging) services and chat .
You must enter the voice server number before you
can access your voice mails. Your service provider
can give the voice server number.

Menu functions
11
Short Codes
allows you to view specific information and links from
your service provider
Pictures
Use the Pictures menu to use camera feature.
To access this menu, press [ OK ] in Idle mode and
select Pictures .
Camera
In this menu, you can take a picture. The camera
produces JPEG pictures.
Camcorder
Your phone is capable of recording short videos (and
audio) of up to a few seconds in length. Saved videos
are stored in the My Videos.
My Albums
Your phone’s picture storage area is called My Albums.
There are two types of folders that can be used
separately according to your needs:
•InPhone
• Online Albums
Shop
With your new Web-enabled phone, you have access
to a variety of services such as downloadable ring
tunes, games, images, tools and other applications.
My Content
This menu allows you to download various multimedia
files, such as games, ringers, screen savers, and
applications, from the wireless web.
To access this menu, press [ OK ] in Idle mode and
select My Content .
Games
You can play games already stored on your phone, or
download additional ones.

12
Menu functions
Music
You can connect to a preset website and search for
a music file and follow the on screen instructions to
download it.
Web
With Web access on your Phone, you can browse full-
color graphic versions of your favorite Web sites,
making it easier than ever to stay informed while on
the go. Follow sports scores and breaking news and
weather and shop on your Phone anywhere on the
Sprint Nationwide PCS Network.
In addition to the features already covered in this
section, the service provider home page offers access
to these colorful, graphically rich Web categories,
including News, Weather, Entertainment, Sports,
Finance, Travel, Shopping, Tools, and Business Links,
as well as useful management options including My
Account and Search. Many sites are available under
more than one menu . choose the one that's most
convenient for you.
Tools
The Tools menu provides you various convenient
features like a calendar, task list, memo pad, D-day
counter, alarm, and calculator.
To access this menu, press [ ] in Idle mode and
select Tools .
Alarm
This menu allows you to set an alarm to ring at a
specific time.
Bluetooth
Use this menu to activate the Bluetooth feature.
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
You cannot use the Bluetooth feature while using
multimedia features such as voice recorder,
camera, and MP3 player, or vice versa.

Menu functions
13
Calculator
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
Calendar
Mass Storage
The mass storage tool allows you to connect a USB
data cable from your phone to a PC, manage your files
using the file manager, and check the available
memory information.
Memo pad
This feature allows you to make and view memos of
important things you need to remember.
World Time
You can use this menu to find out what time it is in
another part of the world.
Voice Memo
You can use your phone’s Voice Services to record
brief memos to remind you of important events, phone
numbers, or grocery list items.
Voice Service
Your Sprint PCS Phone’s Voice Services let you place
calls using your voice. This section includes easy-to-
follow instructions on using voice-activated dialing.
Set Time
This menu is displayed when there is no time
information.
Settings
Many different features of your phone can be
customized to suit your preferences.
To access this menu, press [ OK ] in Idle mode and
select Settings .
Display

14
Menu functions
This menu enables you to customize various settings
for display and the lights.
In this menu, you can:
• change the idle screen image.
• change the menu display style.
• set the caller ID image for incoming calls.
• set a greeting message to be displayed.
• specify the length of time the backlight of the
display or keypad turns on. You can also select
whether or not the phone use the backlight.
• adjust the brightness of the main and front display.
• select whether or not the service light is on.
Sounds
This menu enables you to customize various settings
for sounds.
In this menu, you can:
• adjust the ringer volume for calls, messages, and
alarms.
• set the unique ringer melodies for incoming calls,
alarm melodies, scheduler alert, or roaming alert.
• customize additional tones for the phone.
• select the key tone type and adjust the key tone
volume and length.
• set the sound settings for using downloaded
applications.
Games/Tools
Text Entry
Text Entry settings allow you to configure the options
associated with the text messages sent from your
phone.
Phone Infomation
Phone Info displays the following menu:
• Phone Number
• Icon Glossary
•Version
•Advanced
More...
In this menu, you can:

15
• lock your phone and serivces so that other people
cannot use your phone and the additional services.
• change your current lock code to a new one.
• store emergency numbers.
• erase your Contacts entries and downloaded items.
• reset your phone.
• select a roaming mode.
• set the phone to remind you when you are making
or receiving a roaming call.
• set digits, such as area codes and network feature
activation codes, to the beginning of a phone
number before dialling it.
• activate the contact match feature.
• restrict outgoing calls.
• set how to answer incoming calls.
• turn the automatic redealing or answering features
on or off.
• select one of several languages for the display
text.
• activate or deactivate Airplane mode, the location
feature, Headset mode, or Key Guard mode.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the PIN check menu.
