Samsung SGH-S208 Quick start guide

SGH-S208
WAP Browser
User’s Manual
Printed in Korea
Code No.: GH68-03541A
English. 06/2003. Rev. 1.0
World Wide Web
http://www.samsungmobile.com
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.

23
Contents
About the WAP Browser. . . . . . . . . . . . . . 4
Configuring the WAP Browser . . . . . . . . . 5
Accessing the WAP Browser . . . . . . . . . . . . . 5
Configuring the WAP Browser. . . . . . . . . . . . 8
Getting Started. . . . . . . . . . . . . . . . . . . . 10
Starting the WAP Browser . . . . . . . . . . . . . 10
Exiting the WAP Browser . . . . . . . . . . . . . . 10
Using the WAP Browser . . . . . . . . . . . . . 11
Using the Soft Keys. . . . . . . . . . . . . . . . . . 11
Navigating the WAP Browser . . . . . . . . . . . 11
Entering Text, Numbers or Symbols . . . . . . 12
Using the WAP Browser Menus . . . . . . . 13
Using and Selecting Menu Options . . . . . . . 13
Reload . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Home. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Go to URL . . . . . . . . . . . . . . . . . . . . . . . . 14
Show URL . . . . . . . . . . . . . . . . . . . . . . . . 14
Edit Home . . . . . . . . . . . . . . . . . . . . . . . . 15
What is WAP?
WAP (Wireless Application Protocol) is the
gateway to a new world of mobile data. It
provides a universal standard, enabling
you to access web-based interactive
information services and applications
directly from your mobile phone.
* All product names are
trademarks or registered
trademarks of their respective
owners.

5
4
About the WAP
Browser
Your phone comes equipped with a WAP
(Wireless Application Protocol) browser, making
it possible for you to access the wireless web.
The WAP browser allows you to:
• access up-to-the-minute information via your
phone.
• view specially designed text versions of
popular Internet sites including Yahoo!®, CNN
MobileSM and the Weather Channel®.
Browsing the wireless web using your phone is
unlike using your computer, in that site providers
have:
• selected only the critical aspects of their site
for wireless phone users.
• removed most graphics.
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service
indicator icon ( or ) appears on the display
to inform you that you are:
• connected to the Wireless Web.
• will be billed accordingly. The rates vary
according to your service option.
The WAP browser ends the network connection
after a certain period of inactivity and
automatically reconnects as necessary. For this
reason, you may find that you are billed for
several network connections within a single
session. This is normal and is designed to
minimise your bill.
Configuring the WAP
Browser
Before using the WAP browser, you must set the
parameters for the proxy server used by your
service provider.
Accessing the WAP Browser
To access the WAP Browser menu:
1. When the idle screen is displayed, press the
Menu soft key to enter menu mode.
2. Press the or key until the Funbox
menu option is highlighted, and press the
Select soft key. You can also press the 7key
directly.
Service Provider
07:30
Wed 06 Mar
Menu Name
Select
Network Ser...
Messages

Configuring the WAP Browser
6
Configuring the WAP Browser
3. Press the or key to highlight WAP
Browser then press the Select soft key. You
can also press the 2key directly.
Option Description
Favorite To store a URL address, select
(continued) an empty location and enter
the address.Three submenus
are available
Select Goto URL to access the
site quickly, Edit to edit the
selected address and Erase to
delete the selected address.
http:// Allows you to enter manually
the URL address of the Web
site that you wish to access.
You can access this menu
directly by pressing and
holding the key in the WAP
browser.
Settings Allows you to set up five proxy
servers for the WAP browser.
Clear Clears the information stored in
Cache the phone’s temporary memory
which stores the most recently
accessed web pages.
Push Allows you to set whether or
Message not you will receive Web
messages from the server, and
read or delete the messages
received.
4. Press the or key one or more times to
highlight the required option and then press
the Select soft key.
Option Description
Home Connects the phone to the
network and loads the
homepage of the wireless web
service provider.
Favorite Allows you to store the URL
addresses of your favourite Web
sites. You can access this menu
directly by pressing and holding
the key while using the WAP
Browser.
Funbox
Games
WAP Browser
Downloads
WAP Browser
Home
Favorite
http://
Settings
Clear Cache
Push Message
Select
Select
7

9
Configuring the WAP Browser
8
Configuring the WAP Browser
Configuring the WAP Browser
To configure the WAP browser:
1. In the WAP Browser menu, highlight Settings
using the and keys, then press the
Select soft key. You can also press the 4key
directly.
2. Select a proxy server and press the Select soft
key. Contact your service provider for details
Parameter Description
Profile Name Name of the HTTP proxy
server.
Homepage Address of your startup
URL homepage. When the default
homepage is displayed, you
can delete it using the Ckey
and enter your own choice.
Security Data transmission mode.
Choose Secure to protect
your data against
unauthorised access;
otherwise, choose Non-
Secure.
IP Address WAP gateway address
required to connect to the
Internet.
Bearer Bearer to be used for each
type of network address
accessed; GPRS or Data.
The remaining options depend on the Bearer
setting, as indicated on the next page.
When the bearer is set to Data
Parameter Description
Login Name PPP server login ID.
Password PPP server password.
Dial-up PPP server phone
Number number.
Data Call Data call type; Analogue
Type or ISDN.
When the bearer is set to GPRS
Parameter Description
User Name User ID required to connect
to the GPRS network.
Password Password required to
connect to the GPRS
network.
APN Access point name used for
the address of the GPRS
network gateway.
Note: The WAP browser settings may vary,
depending on the service provider.
Contact your service provider for further
information.
3. After selecting each of these settings, a
dialogue box displays; you can either enter
the information required or choose between
given options. When you are satisfied with
your input, press the OK soft key.
4. When you finish configuring the WAP browser,
press the key or the right soft key.

11
10
Getting Started
Starting the WAP Browser
To start the WAP browser when the idle screen is
displayed, press the key or press the Menu
soft key, followed by the 7, 2and 1keys.
A connection is established with your service
provider and the corresponding homepage
displays.
The contents of the WAP browser startup
homepage depends on your Wireless Web
service provider. To scroll through the screen,
use the and keys.
Note: To access the startup homepage from any
other screen in the WAP browser, use the
Home option. For more information about
the WAP browser menus, refer to page
13.
Exiting the WAP Browser
To exit the browser at any time, simply press the
key or press and hold the key.
Using the WAP
Browser
Using the Soft Keys
A bar containing browser commands is located
at the bottom of the WAP browser display. The
soft keys ( ) below the bar are used to
execute these commands. The two keys are
called soft keys because their function changes
depending on the WAP browser application in
use.
Navigating the WAP Browser
To Then
scroll through press the or key
and select until the symbol points
browser items to the required item, and
then press the OK soft key
to confirm the selection.
select a numbered press the corresponding
item numeric key.
return to the press the Back soft key or
previous page the Ckey.
return to the select the Home menu
startup homepage option; for more
information about this
option, refer to page 13.

13
12
Using the WAP Browser
Entering Text, Numbers or Symbols
When you are prompted to enter text, the
current text entry mode is indicated on the
screen. The following modes are available:
Mode Description
Allows you to enter letters in the
alphabet. Press the corresponding key
until the required letter displays.
Allows you to enter numbers.
Note: To enter symbols, press the 1key until the
required symbol displays.
To Then
change modes press the key one or
more times.
enter the Chinese press and hold the key.
text
enter a space press the key.
edit text • set the cursor to the right
of the character to be
corrected.
• press the Ckey as
needed.
• enter the correct
character(s).
Using the WAP
Browser Menus
Using and Selecting Menu Options
Various menu options are available when you are
using the WAP browser to navigate the wireless
web.
To access a menu option:
1. Press and hold the key.
A menu is displayed.
2. Highlight the required menu option by
pressing the or key.
3. Select the option by pressing the Select soft
key.
4. If necessary, select the secondary option
using the and keys, and press the
Select soft key to confirm.
Note: The menus may vary, depending on your
version of the WAP browser.
Reload
This option reloads the current page.
Home
This option takes you back at any time to the
homepage of the wireless web service provider.

15
Using the WAP Browser Menus
14
Using the WAP Browser Menus
Go to URL
This option allows you to enter manually the URL
address of the required web page.
After entering an address, press the OK soft key
to go there directly.
Show URL
This feature displays the URL address of the site
to which you are currently connected. It also
enables you to declare the current site as the
startup homepage.
To Press the
declare the current Option soft key, select
page as your startup the Save to Home option
homepage and press Select.
set a bookmark for Option soft key, select
the current page the Save to Bookmark
option and press Select.
cancel your setting Back soft key.
Edit Home
With this feature, you can change the startup
homepage manually.
To change the homepage, enter the required
URL and press the OK soft key.
For more information on entering text, numbers
or symbols, refer to page 12.
