Samsung SGH-T519 - Trace Cell Phone User manual

WB_t519_FG8_110106_F5
SGH-t519
PORTABLE Quad-Band
TELEPHONE
User Guide
Please read this manual before operating your
phone, and keep it for future reference.
t519.book Page 1 Wednesday, November 1, 2006 4:41 PM

Intellectual Property
All Intellectual Property, as defined below, owned by or which is
otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Phone, including but not limited to,
accessories, parts, or software relating there to (the “Phone
System”),isproprietarytoSamsungandprotectedunderfederal
laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or
unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other
works of authorship. You may not infringe or otherwise violate
the rights secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble,
or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to
you. All applicable rights of the Intellectual Property shall
remain with SAMSUNG and its suppliers.
Samsung Telecommunications America (STA),
Inc.
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein St.
Richardson, TX 75082 Plano, TX 75074
Toll Free Tel: [phone].HELP (4357)
Internet Address: http://www.samsungusa.com
Do you have questions about your Samsung Mobile Phone? For
24 hour information and assistance, we offer a new FAQ/ARS
System (Automated Response System) at:
©2006 Samsung Telecommunications America, Inc. is a
registered trademark of Samsung Electronics America, Inc. and
its related entities.
t519.book Page 2 Wednesday, November 1, 2006 4:41 PM

Printed in Korea
GH68-11787A
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered Trademark RSA Security, Inc.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH
THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS
IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR
ANY PARTICULAR PURPOSE OR USE; THE DESIGN,
CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP
OF THE PRODUCT OR THE COMPONENTS CONTAINED
THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR
CONTRACT PERTAINING THERETO. NOTHING
CONTAINED IN THE INSTRUCTION MANUAL SHALL BE
CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT
TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING
FROM THE PURCHASE OR USE OF THE PRODUCT OR
ARISING FROM THE BREACH OF THE EXPRESS WARRANTY,
INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR
BENEFITS.
t519.book Page 3 Wednesday, November 1, 2006 4:41 PM

t519.book Page 4 Wednesday, November 1, 2006 4:41 PM

Table of Contents 1
Table of Contents
Table of Contents
Section 1: Getting Started . . . . . . . . . . . . . . . . . . 5
Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . 11
Setting Up Your Voice mail . . . . . . . . . . . . . . . . . . . . . . . 12
Section 2: Understanding Your Phone . . . . . . . 15
Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . 16
View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Get More Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Section 3: Call Functions . . . . . . . . . . . . . . . . . . 23
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Adjusting the Call Volume . . . . . . . . . . . . . . . . . . . . . . . . 26
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Call records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Selecting Functions and Options . . . . . . . . . . . . . . . . . . . 32
Section 4: Menu Navigation . . . . . . . . . . . . . . . 43
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Menu Outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Section 5: Entering Text . . . . . . . . . . . . . . . . . . 51
Changing the Text Input Mode . . . . . . . . . . . . . . . . . . . . . 52
Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Using T9 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Using Number Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Using Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Section 6: Understanding Your Phonebook . . . 59
Storing a Number in the Phone’s Memory . . . . . . . . . . . . 60
Storing a Number in the SIM Card . . . . . . . . . . . . . . . . . . 61
t519.book Page 1 Wednesday, November 1, 2006 4:41 PM

Table of Contents
2
Finding a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . .64
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Editing a Caller Group . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Copying all SIM Phonebook Entries . . . . . . . . . . . . . . . . . .69
Deleting all of the Phonebook Entries . . . . . . . . . . . . . . . .69
My Name Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Finding My Own Phone Number . . . . . . . . . . . . . . . . . . . .71
FDN List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Section 7: Messages . . . . . . . . . . . . . . . . . . . . . .75
Types of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Voice notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Picture message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Sentbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Delete all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Broadcast Messages (SIM Dependent) . . . . . . . . . . . . . . .97
Memory status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Instant Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Section 8: Changing Your Settings . . . . . . . . .101
Time & Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Display settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
Sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
t519.book Page 2 Wednesday, November 1, 2006 4:41 PM

Table of Contents 3
Table of Contents
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Software update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Reset settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Section 9: Fun & Apps . . . . . . . . . . . . . . . . . . . 123
My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Music player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Organizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Section 10: Camera and Camcorder . . . . . . . . 147
Using the Camera and Camcorder . . . . . . . . . . . . . . . . . 148
Take and send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Record video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
My photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
My videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
My Album . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
My Journal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Section 11: t-zones . . . . . . . . . . . . . . . . . . . . . 161
t-zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Section 12: Health and Safety Information . . . 167
Health and Safety Information . . . . . . . . . . . . . . . . . . . . 168
UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . 170
Consumer Information on Wireless Phones . . . . . . . . . . 171
Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . 183
Using Your Phone Near Other Electronic Devices . . . . . . 183
Potentially Explosive Environments . . . . . . . . . . . . . . . . 185
Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . 187
Other Important Safety Information . . . . . . . . . . . . . . . . 187
Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Availability of Various Features/Ring Tones . . . . . . . . . . 190
t519.book Page 3 Wednesday, November 1, 2006 4:41 PM

Table of Contents
4
Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . .190
Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . .192
Section 13: Warranty Information . . . . . . . . . .195
Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . .196
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203
t519.book Page 4 Wednesday, November 1, 2006 4:41 PM

Section 1: Getting Started 5
Section 1
Section 1: Getting Started
Topics Covered
• Activating Your Phone
• Switching the Phone On or Off
• Setting Up Your Voicemail
This section describes how to start using your phone by
activating your service and setting up your voice mail.
t519.book Page 5 Wednesday, November 1, 2006 4:41 PM

6
Section 1
Activating Your Phone
When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, any optional
services available, and many others.
Installing the SIM Card
Important! The plug-in SIM card and its contacts can be easily damaged
by scratching or bending, so be careful when handling, inserting, or
removing the card.
Keep all SIM cards out of reach of small children.
1. If necessary, switch off the phone by holding down the
key until the power-off image displays.
2. If necessary, disconnect the Travel Adapter from the
phone. See “Charging a Battery” on page 9 for more
information.
3. Remove the battery cover.
To do so, press the ridged area on the battery cover
using your thumb and gently slide it in the direction of
the arrow. Remove the battery cover.
t519.book Page 6 Wednesday, November 1, 2006 4:41 PM

Section 1: Getting Started 7
Activating Your Phone
Section 1
4. Grasp the top of the battery with your finger and lift up in
the direction of the arrow. Remove the battery.
5. Slide the SIM card into the SIM card socket so that the
card locks into place. Make sure the gold contacts of the
card face into the phone.
t519.book Page 7 Wednesday, November 1, 2006 4:41 PM

8
Section 1
Note: When you need to remove the SIM card, slide it, as shown, and take
it out of the socket.
6. Place the battery so that the 3 brass tabs on the end
align with the 3 brass prongs at the bottom of the battery
compartment. The arrow on the battery should be
pointing down. Press the battery down until it clicks into
place.
t519.book Page 8 Wednesday, November 1, 2006 4:41 PM

Section 1: Getting Started 9
Activating Your Phone
Section 1
7. Place the battery cover on and slide it into place until it
clicks.
Charging a Battery
Your phone is powered by a rechargeable Li-ion
battery.
A Travel Adapter comes with your phone for charging
the battery. Use only approved batteries and chargers.
Ask your local Samsung dealer for further details.
You can use the phone while the battery is charging, but
doing so will require additional charging time.
Note: You must fully charge the battery before using your phone for the
first time. A discharged battery recharges fully in approximately 2 hours.
1. With the battery in position in the phone, plug the
connector of the Travel Adapter into the jack on the side
of the phone.
t519.book Page 9 Wednesday, November 1, 2006 4:41 PM

10
Section 1
Note: The following illustration is the incorrect method for connecting the
charger. If attempted, damage to the accessory port will occur therefore
voiding the phone’s warranty.
2. Plug the adapter into a standard AC wall outlet.
Note: For connection to an electrical supply not located in the U.S., you
must use an adaptor of the proper configuration for the power outlet. Use
of the wrong adapter could damage your phone and void your warranty.
3. When charging is finished, unplug the Travel Adapter
from the power outlet and disconnect it from the phone.
t519.book Page 10 Wednesday, November 1, 2006 4:41 PM

Section 1: Getting Started 11
Switching the Phone On or Off
Section 1
Important!: You must unplug the Travel Adapter before you remove the
battery from the phone during charging; otherwise, the phone could be
damaged.
Low Battery Indicator
When the battery is weak and only a few minutes of
talk time remain, a warning tone sounds and the
“Warning low battery” message repeats at regular
intervals on the display. When this happens, your
phone turns off the backlight to conserve the remaining
battery power.
When the battery level becomes too low, the phone
automatically turns off.
Switching the Phone On or Off
1. Press and hold the key until the phone switches on.
2. If the phone asks for a PIN, enter the PIN and press the
OK soft key or the key. For further details, see “PIN
check” on page 117.
t519.book Page 11 Wednesday, November 1, 2006 4:41 PM

12
Section 1
The phone searches for your network and after finding it,
the name of your service provider appears on your
display. Now, you can make or receive calls.
Note: The display language is preset to English at the factory. To change
the language, use the Language menu. For further details, see “Language”
on page 103.
3. When you wish to switch off the phone, press and hold
the key until the power-off image displays.
Setting Up Your Voice mail
For new users, follow the instructions below to set up
Voice mail:
1. In Idle mode, press and hold the key on the keypad.
2. Follow the tutorial to create a password, a greeting, and
your name.
Note: These steps may be different depending on your network.
Accessing Your Voice mail
You can access your Voice mail by pressing and holding
the key on the keypad or by going to the menu. To
access Voice Mail using the menu:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Highlight Messages and press the Select soft key or the
key.
3. Highlight Voice mail and press the Select soft key or the
key.
t519.book Page 12 Wednesday, November 1, 2006 4:41 PM

Section 1: Getting Started 13
Setting Up Your Voice mail
Section 1
4. Highlight Call voice mail and press the OK soft key or
the key.Your phone dials the specified voice mail
number. When connected, follow the voice prompts from
the Voice mail center.
Changing the Voice mail Number
Your SIM card gives you the default service number of
the Voice mail center. However, should you need to
change the number or add a second Voice server
number, use the following procedures:
1. In Idle mode, press the Menu soft key to access the
Menu mode.
2. Highlight Messages and press the Select soft key or the
key.
3. Highlight Voice mail and press the Select soft key or
the key.
4. Highlight Voice server number and press the OK soft
key or the key. Highlight Voice mail and press the OK
soft key.
5. Press the Edit soft key. Edit the number, then press the
OK soft key. The number will be saved.
6. Press the key to return to Idle mode.
t519.book Page 13 Wednesday, November 1, 2006 4:41 PM

14
Section 1
t519.book Page 14 Wednesday, November 1, 2006 4:41 PM

Section 2: Understanding Your Phone 15
Section 2
Section 2: Understanding Your Phone
Topics Covered
• Features of Your Phone
• View of Your Phone
•Keys
• Display Layout
•GetMoreHelp
This section outlines some key features of your phone. It
also describes the screen and the icons that are displayed
when the phone is in use.
t519.book Page 15 Wednesday, November 1, 2006 4:41 PM

16
Section 2
Features of Your Phone
Your phone is lightweight, easy-to-use and offers many
significant features. The following list outlines a few of
the features included in your phone.
• 1.3 Megapixel Camera and Camcorder
• Bluetooth® Wireless Technology
• Instant Messaging capability
• Multimedia capability
• Fun & Apps feature provides My Files, music player, games,
alarms, calendar, task list, calculator, world time, unit
conversion, timer, and stopwatch.
View of Your Phone
The following illustrations show the main elements of
your phone:
t519.book Page 16 Wednesday, November 1, 2006 4:41 PM
