Samsung SM-A526B User manual

SM-A526B/A5260
Common
Mobile Device
CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference Abbreviation
4.
2
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Samsung Electronics Co.,Ltd
2020. 01. Rev 1.0
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
ⓒ

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any contentor datafrom this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1. Cellular phone Exploded View
QBC01
QCR249
QAN01
QME02
QCB01
QCB02
QCA01
QCA05
QCA03
QMI01
QCR12
QMO01
QMP01
QCA02
QCA04
QSM01
QVO01
QCK01
QFR01
QME06
QIF01
QCR12
QME01
QBA01
QSP01
QCR249
※SVC REPAIR TAPE
QRT01

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
7-1. Components on the Rear Case

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
7-2. Pre-requisite
Tweezers / Disass'y Stick / Screw Driver
Anti-static Gloves
Anti-static Mat
AOD
Ethyl Alcohol
Cotton Swab

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
7-3. Parts which must be changed after repair
BOM description & part code
Remarks
TAPE WP BACKCOVER
[GH02-22419A]
Replace for
Back Cover repair

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
7-4. Disassembly
※Caution
Be care of scratch
※Caution
Be care of scratch
※Caution
Be care of Rear damage.
※Caution
1) Be care of scratch.
2) Be care of Rear and connector damage.
2
Detach the Back Glass.
Detach the left side of Back glass.
3
Unscrew 16 Point and disassemble SIM Tray
from device
4
Disassemble Upper Rear.
(Use disassemble hole, left side of Rear to
detach it)
Rear Top disassemble hole.
1
Put the device in the chamber as following
below heating condition.
- SOC 68%↓: 70℃/10~20 minute
- SOC 68%↑: 70℃/10~20 minute
※
Please confirm the heating condition
released lastly, and follow it.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
※Caution
1) Be care not to damage Battery.
2) Be care not to damage Rear, Connectors, PBA.
3) Be careful of scratch.
※Caution
Be careful not to damage the Main PBA and components.
※Caution
1) Be care of scratch.
2) Be care of connector damage.
※Caution
Be careful not to damage the Sub PBA and components.
6
Unscrew Main PBA 1point.
7
Disassemble 2 point connectors and 2 point
cables of PBA and detach PBA
Finally Disassemble Rear of bottom side.
(Use disassemble hole, right side of Rear to
detach it)
5
8
Unscrew Sub PBA 1 point
Rear Top disassemble hole.
Main PBA disassemble hole (blue area)

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
※ Caution
Be care of Ear jack connector.
※ Caution
Be care of SUB PBA damage.
10
Detach other components.
9
Disassemble 3 point connectors and 2 point
cables of Sub PBA and detach Sub PBA.
- Detach Finger senor module
- Detach Sub PBA

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
7-5. Assembly
※ Caution
1) Be care of FPCB damage and tilt.
2) Be care of press power/time.
※ Caution
Be care of FPCB and PBA damage.
※Caution
Be care of chip damage nearby screw point.
※Caution
Be care of press power/time.
3
1
2
Attach Main Cam on PBA.
4
Attach SUB PBA and Finger sensor module on
Front.
Attach OCTA conn, Finger sensor conn, Main
Fpcb conn, and Cables.
Attach components on Front.
(RCV module, Motor, Battery)
Screw 1 point on Sub PBA.
* Torque Value : 1.1kgf±7%

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
※ Caution
1) Be care of scratch.
2) Assemble White cable first and blue cable later.
3) Be care of coaxial cables damage.
4) Be care of PBA and Fpcb damage.
※ Caution
1) Assemble bottom hook of Rear Bottom first, and then side
hooks later.
2) Be care of scratch and Sub PBA damage.
`
※ Caution
1) Assemble top hooks of Rear Top first, and then right side
hook and left side hooks later.
2) Be care of scratch and Main PBA damage.
※ Caution
Be care of Rear damage.
5
8
1. Assemble PBA to Front case, and screw 1
point on PBA (* Torque Value : 1.1kgf±7%)
2. Attach and assemble 2 coaxial cables on the
right side of front
3. Attach VT cam and connect connectors and
cables. (Battery conn, MAIN FPCB conn, 2
coaxial cables)
6
Assemble the Bottom REAR in sequence of
bottom part first and top part last.
Assemble the TOP REAR Assy.
7
Screw insertion 16 Point.
* Torque Value
- 10 points on Rear Top : 1.3kgf±7%
- 6 points on Rear Btm : 1.2kgf±7%

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
7. Level 2 Repair
※ Caution
Fit the tapes precisely to the inner area of back cover.
Don’t touch the attach side of tape for waterproof.
※ Caution
Be care of scratch and tilt.
9
Attach the back cover outside tape on the back
cover by hands.
Gently press all adhesive parts of tape using
disassembly stick or hands.
Press Back Glass.
- Pressing force : 1 N
- Pressing time : 60 Sec.
SIM Tray must be seperated before
pressing the backglass or the OCTA
10

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
8. Level 3 Repair
8-1. Components Layout
U7003
Ambient sensor
U1013
LB-L-PAMid
SOC8002
RCAM1 CONN
SOC8003
RCAM3 CONN
U4000
AP
CN7000
SIM/SD CARD
Socket
ANT3000
WIFI/BT
UME5000
MEM
U6000
IF PMIC
U6004
Direct charger
ANT6002, ANT6003
ANT6006
ANT6005
SIDE KEY CONTACT
ANT6000,ANT6001
Motor Contact
ANT3011
GND CCP
ANT2002
N78 TRX
C7030
CODEC
U2017,U2025
APT
SOC8000
VT CAM
CONN
MIC7000
SUB MIC
ANT2004
SUB ANT6
U3004
BT/WLAN/FM
U1016
MHB L-PAMiD
U2012
Transceiver
U1000
MHB L-PAMiD
ANT2003
SUB ANT5
SOC9000
C2C FPCB
CONN
U7001
SPK AMP
ANT3009,
ANT3010
NFC ANT
CONTACT
SOC6000
BATTERY
CONN
SOC8001
RCAM2 CONN
ANT2005
SUB ANT7
LED6000
FLASH LED
SOC8004
RCAM4 CONN
ANT1001,AN
T1000
SUB ANT1
ANT1002,ANT1004,ANT1003
SUB ANT2
U6010
S-PMIC
U6002
M-PMIC
U7004
ACC&GYRO
SENSOR
U7005
MAGNETIC SENSOR
U2001
N79 L-PAMID
U1002
N78 L-PAMID

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
8. Level 3 Repair
SOC1002
Con to Con CONN
ANT1001, ANT1002
SPK CONN
SOC1001
BTP CONN
SW1002
RF Switch
ANT1003
Ant CONN
SW1003
RF Switch
ANT1004
Ant CONN
SW1005
RF Switch
ANT1007
Ant CONN
ANT1006
Ant CONN
SW1001
RF Switch
U1003
FM LNA
ANT1009
Ant CONN
SW1004
RF Switch
CON1000
Ant CONN
ANT1000
Ant CONN
U1002
Hall IC
ANT1008
Ant CONN
ANT1010
Ant CONN
U1001
Grip Sensor
ANT1005
Ant CONN

TX1_TR_OUT_HB
VOL_UP/DN
SW_ON(PM_SW_ON)
TSP_SCL/SDA_1P8
TSP_INT
OCTA_RST_N
NVBUSOK
IF_PMIC_SCL/SDA_1P8
VREG_L11A_1P8
USB_AP_D_P/N
VBUS_OVP
MUIC_D_P/N
VBATTERY_SR
EL_ON1/2
VPH_PWR VDD_LCD_ELVDD_4P6 / VDD_LCD_ELVSS_-4P4 / VDD_LCD_ELAVDD_7P9
VPH_PWR
OCTA_MIPI_CLK_P/N / OCTA_MIPI_D0~3_P/N
VDD_NFC_SIM1_1P8_3P0
SIM1_RST / SIM1_CLK / SIM1_DATA
AP_UART_TXD/RXD
SAMSUNG CONFIDENTIAL
EAR_OUT_L/R / EAR_OUT_FB
RCV_AMP_OUT_P
RCV_AMP_OUT_N
MAIN_MIC_P/N
MAIN_MICBIAS_1P8
EAR_MICBIAS_2P8
EAR_MIC_P/N
EAR_L/G_DET
SPK_AMP_OUT_P
SPK_AMP_OUT_N
VBUS_IF
VPH_PWR
A526B Block Diagram
LIGHT_SCL/SDA_1P8
SUB_MIC_P/N
SUB_MICBIAS_1P8
SDC2_CLK/CMD/D0~3
SIM_DET / T_FLASH_DET
VREG_L9E_2P96
QLINK0_WMSS_RESET_N
NFC_SWP1
VPH_PWR
VDD_NFC_SIM1_1P8_3P0
NFC_FIRM / NFC_IRQ / NFC_CLK_REQ
NFC_SWP1
NFC_SCL/SDA_1P8
NFC_EN
VDD_LCD_3P0
RCAM1_AFVDD_2P8
RCAM1_DVDD_1P1
RCAM1_SENSOR_I2C_SCL/SDA_1P8 / CAM_AF_EEP_I2C_SCL/SDA_1P8
RCAM1_RST_N / RCAM1_MCLK
RCAM_FSYNC
CAM_VDDIO_1P8
FCAM_RCAM2_RCAM3_RCAM4_SENSOR_I2C_SCL/SDA_1P8
RCAM2_RST_N / RCAM2_MCLK
RCAM_FSYNC
MIPI_RCAM2_CLK_P/N / MIPI_RCAM2_D0~1_P/N
CAM_VDDIO_1P8
FCAM_RCAM2_RCAM3_RCAM4_SENSOR_I2C_SCL/SDA_1P8 / CAM_AF_EEP_I2C_SCL/SDA_1P8
RCAM3_RST_N / RCAM3_MCLK
RCAM_FSYNC
MIPI_RCAM3_CLK_P/N / MIPI_RCAM3_D0~3_P/N
FCAM_DVDD_1P05
FCAM_AVDD_2P9
CAM_VDDIO_1P8
FCAM_RCAM2_RCAM3_RCAM4_SENSOR_I2C_SCL/SDA_1P8 / CAM_AF_EEP_I2C_SCL/SDA_1P8
FCAM_RST_N / FCAM_MCLK
MIPI_FCAM_CLK_P/N / MIPI_FCAM_D0~3_P/N
VREG_L7E_3P008
VREG_L13A_0P6
VREG_S1A_1P13
VREG_L12A_1P8
EBI0/1_CA_0~5
EBI0/1_CLK_P/M / EBI0/1_CKE_0/1
EBI0/1_CS_0/1 / EBI0/1_DMI_0/1
EBI0/1_DQ(0~15)
EBI0/1_DQS_0/1_P/M
UFS_TX/RX_D0/1_P/N
UFS_REFCLK
DDR_RESET_N
UFS_RESET_N
VREG_L11A_1P8
OCTA_CON_DET / FG_ERR / DISP_TE / OCTA_ESD_DET
BTP_RST_N
BTP_SPI_CLK/CS_N/MISO/MOSI
SDM_RFFE0_CLK/DATA
GRIP2_SCL/SDA_1P8
IF_PMIC_INTB
NFC_ESE_CLK/CS_N/MISO/MOSI
6AXIS_INT1/INT2
MAGNETIC_SCL/SDA_1P8
WLAN_SW_CTRL
WL_CH0/1_BB_I/Q_P/N
VREG_WIFI_FEM_3P3
VREG_L9A_1P7
GNSS_L1_LNA_IN
VBAT_PA0
VRF_MIPI_IO_1P8
RCAM3_DVDD_1P05
CAM_VDDIO_1P8
FCAM_RCAM2_RCAM3_RCAM4_SENSOR_I2C_SCL/SDA_1P8
RCAM4_RST_N / RCAM4_MCLK
MIPI_RCAM4_CLK_P/N / MIPI_RCAM4_D0~1_P/N
RCAM_FSYNC
VPH_PWR
VDD_LCD_1P8
VDD_TSP_3P0
RCAM2_RCAM4_AVDD_2P8
RCAM3_AVDD_2P8
RCAM2_RCAM4_DVDD_1P2
RCAM2_RCAM4_AVDD_2P8
CC1/2
HALL_INT2 / GRIP_INT2 / FM_LNA_EN
Front
Camera
(32M)
Conn.
VBAT_SENSE / VBATGND_SENSE / CSP / VBATTERY_CON
CC_SCL/SDA_1P8
RCAM2_RCAM4_DVDD_1P2
VREG_S2A_1P904
RCAM3_LDO_EN
VREG_BOB
RCAM2_RCAM4_LDO_EN
VREG_BOB
RCAM3_LDO_EN
CAM_VDDIO_1P8
CAM_SEL
MIPI_RCAM3_4_CLK_P/N / MIPI_RCAM3_4_D0~3_P/N
VREG_L8E_1P8
VREG_L8E_1P8
Magnetometer
VREG_L8E_1P8
VREG_L11A_1P8
VREG_BOB
SWR_TX/RX_CLK
SWR_TX_DATA0~2 / SWR_RX_DATA0~1
CODEC_RST_N
PA_THM
VDD_NFC_IO_1P8
PMK8003_NFC_CLK
VREG_L2E_1P304
WIFI_SW_CTL_CH0
WL_RFI/O_5G_CH0
WL_BT_RFIO_2G_CH0 (WIFI_2G)
WCSS_CH0_CMD_CLK/DATA
WL_BT_COEX_CLK/DATA
CP_WLAN_COEX_TXD/RXD
BT_FM_SB_CLK/DATA
PMK8003_WLAN_CLK
BT_UART_TXD/RXD/CTS/RTS
QLINK0_REQ
QLINK0_EN
SDR_RFFE_SLAVE_CLK/DATA
GNSS_L1_LNA_EN
RFCLK1_SDR735
VPA_APT0
GNSS_RF_L1_IN
WIFI_THM
FM_ANT
AP_MCU_SCL/SDA_1P8
MCU_nRST
MCU_BOOT0_SWCLK
CAM_OIS_SCL/SDA_1P8
CAM_SPI_SCK/CS/MISO/MOSI
CAM_VDDIO_1P8
VREG_BOB
RCAM1_LDO_EN CAM_OIS_VDD_2P8
FM_ANT
SUB_REV
VPH_PWR
FCAM_AVDD_2P9
CAM_VDDIO_1P8
RCAM2_RCAM4_DVDD_1P2
RCAM1_AVDD_2P9
CAM_PMIC_I2C_SCL/SDA_1P8
VREG_S8E_1P352
VREG_S2A_1P904
FCAM_DVDD_1P05
RCAM1_DVDD_1P1
RCAM1_AFVDD_2P8
RCAM1_AVDD_2P9
RCAM1_AVDD_1P8
VREG_BOB
MIPI_RCAM1_A~C0 / MIPI_RCAM1_A~C1 / MIPI_RCAM1_A~C2
6AXIS_I3C_SCL/SDA_1P8
CAM_SPI_SCK/CS/MISO/MOSI
SIM2_RST / SIM2_CLK / SIM2_DATA
VREG_L14A_1P8
VPH_PWR
VDD_AMP_1P8
SPK_AMP_EN
SPK_AMP_SCL/SDA_1P8
SPK_I2S3_BCLK/WS/DI/DO
SPK_AMP_INT
VPH_PWR
VDD_AMP_1P8
SPK_AMP_EN
SPK_AMP_SCL/SDA_1P8
SPK_I2S3_BCLK/WS/DI/DO
SPK_AMP_INT
TYPE_C_INT
NVBUSOK
SW_ON
SUB_REV
eSE_CHECK
MST_CHECK
VREG_L11A_1P8
VREG_S2A_1P904
NFC_LDO_EN
LDO
VREG_L4E_UIM1_1P8_3P0
QLINK0_L0~4_P/M
QLINK0_CLK_P/M
BAT_THM
VDD_GRIP_3P3
SPK
Sub MIC
Main MIC
Earjack
RCV
ALS
6-axis Motion
MOT_EN
VPH_PWR
VREG_1P8_SYS
VREG_L15A_1P2
SPMI_CLK/DATA
PMK8003_AP_WLAN_CLK
SLEEP_CLK_32K
RFCLK1_SDR735
PMK8003_WLAN_CLK
PMK8003_AP_CXO
PMK8003_NFC_CLKPMK_VREG_BB
PMIC_DVDD_BYP
SPMI_CLK/DATA
SPMI_CLK/DATA
SPMI_CLK/DATA
PM_FAULT_N
PM_FAULT_N
PM_FAULT_N
RTC_ALARM
RTC_ALARM
PMK8003_AP_CXO
PMK8003_AP_WLAN_CLK
SLEEP_CLK_32K
CHG_THM
CAM_FLASH_EN
CAM_TORCH_EN
OVP
Flash
LED
AP_THM
uMCP Memory
SLEEP_CLK_32K
VDD_0P8_DIG_L20A
VDD_0P875_L18A
VDD_1P8_DIG_L11A
VDD_0P8_ANA_L21A
VDD_1P2_ANA_L19A
VDD_1P7_ANA_L5A
PRX_TR_IN_LB
PRX_TR_IN_P_LMH
PRX_TR_IN_P_JMH
PRX_TR_IN_P_MH
PRX_TR_IN_N78
PRX_TR_IN_N79
PRX_TR_IN_N78_4RX
PRX_TR_IN_N79_4RX
DRX_TR_IN_LB
DRX_TR_IN_D_LMH
DRX_TR_IN_D_JMH
DRX_TR_IN_D_MH
DRX_TR_IN_N79
DRX_TR_IN_N78
DRX_TR_IN_N78_4RX
COUPLING_OUT
TX0_TR_OUT_GSMLB
TX0_TR_OUT_LB
TX0_TR_OUT_GSMHB
TX0_TR_OUT_MB
TX0_TR_OUT_HB
TX1_TR_OUT_N78
TX1_TR_OUT_N79
SDR_RFFE0_CLK/DATA
SDR_RFFE1_CLK/DATA
SDR_RFFE0_CLK/DATA
VRF_MIPI_IO_1P8
DRX_TR_IN_N7_N41_4RX
VBAT_PA1
VRF_MIPI_IO_1P8
VPA_APT1
SDR_RFFE4_CLK/DATA
VBAT_PA2
VRF_MIPI_IO_1P8
VPA_APT2
SDR_RFFE5_CLK/DATA
VRF_MIPI_IO_1P8
SDR_RFFE3_CLK/DATA
CPL_OUT_MHB
NR_CPL_N79
NR_CPL_N78
CPL_OUT_LB
VPH_PWR
VRF_MIPI_IO_1P8
VPA_ET2
VRF_LNA_1P8
SDR_RFFE5_CLK/DATA
NR_CPL_N78
MIMO_RX_LNA_IN_3
VRF_LNA_1P8
VRF_MIPI_IO_1P8
VPH_PWR
VPA_APT1
VRF_MIPI_IO_1P8
SDR_RFFE4_CLK/DATA
ANT_CON_DET_1
ANT_CON_DET_2 ANT_CON_DET_2
TRX_ANT_MHB
VRF_MIPI_IO_1P8
SDR_RFFE5_CLK/DATA
SRS_OUT1_N79
VRF_LNA_1P8
VRF_MIPI_IO_1P8
VRF_LNA_1P8
VRF_MIPI_IO_1P8
SDR_RFFE2_CLK/DATA
SDR_RFFE2_CLK/DATA
VRF_LNA_1P8
VRF_MIPI_IO_1P8
SDR_RFFE2_CLK/DATA
VRF_MIPI_IO_1P8
SDR_RFFE3_CLK/DATA SRS_OUT2_N41
VRF_LNA_1P8
VRF_LNA_1P8
VRF_MIPI_IO_1P8
N7_N41_4RX_SEL0N7_N41_4RX_SEL0
SDR_RFFE5_CLK/DATA
VDD_BTP_3P3 Finger Print
Sensor
Conn.
(Sub PBA)
SDM_RFFE2_CLK/DATA
SBU1/2
VDD_OIS_MCU_1P8
RCAM1_LDO_EN
MIPI Switch
LDO
LDO
Audio CODEC
Audio AMP
Camera PMIC
SDR_RFFE2_CLK/DATA
VRF_MIPI_IO_1P8
SDR_RFFE5_CLK/DATA
N78_TRX_SUB_3
VPH_PWR
VPA_APT2
VRF_MIPI_IO_1P8
VRF_LNA_1P8
NR_CPL_N79
SDR_RFFE5_CLK/DATA
SDR_RFFE0_CLK/DATA
Camera MCU
PRX_TR_IN_PM_JMH
PRX_TR_IN_PM_MH
DRX_TR_IN_DM_JMH
DRX_TR_IN_DM_MHMIMO_DRX_IN_1
MIMO_DRX_IN_2 SDR_RFFE0_CLK/DATA
VRF_MIPI_IO_1P8
SDR_RFFE2_CLK/DATA
VRF_LNA_1P8
VRF_MIPI_IO_1P8
SDR_RFFE2_CLK/DATA
VRF_LNA_1P8
CPL_OUT_MHB
SDR_RFFE0_CLK/DATA
VPH_PWR
VPA_APT0
VRF_MIPI_IO_1P8
VRF_LNA_1P8
B28_N28_RX_LNA_IN
LB_PA_OUT_B28_N28 SDR_RFFE0_CLK/DATA
SDR_RFFE1_CLK/DATA
B28_N28_TRX
TRX_ANT_LB
ANT_CON_DET_1
DRX_TR_IN_N7_N41_4RX
Audio AMP
Thermister
Thermister
Thermister
Thermister
Thermister
76.8 MHz
Clock Buffer
TX1_TR_OUT_LB
VRF_LNA_1P8
N7_N41_SEL
Display PMIC
VRF_MIPI_IO_1P8
SDR_RFFE3_CLK/DATA
SRS_OUT2_N79
SRS_OUT3_N41
MIMO_RX_LNA_IN_4
VRF_LNA_1P8
VRF_MIPI_IO_1P8
Sub PBA
Conn.
LDO
LDO
Rear
Camera 2
(5M)
Conn.
LDO Rear
Camera 3
(12M)
Conn.
Rear
Camera 4
(5M)
Conn.
Rear
Camera 1
(64M)
Conn.
VREG_L5E_UIM2_1P8_3P0
T-Flash
/ SIM
(3in2)
Socket
CPL_MHB2
TX1_TR_OUT_MB
PRX_4RX_SEL0
SRS_OUT_N78
PRX_LNA_IN_N78_4RX
VRF_LNA_1P8 MIMO_RX_LNA_IN_1
MIMO_RX_LNA_IN_2
N78_N79_DRX
DRX_LNA_IN_N78_4RX
SDR_RFFE5_CLK/DATA
SRS_OUT_N78
SRS_OUT1_N41
VPH_PWR
VPA_APT2
SDR_RFFE2_CLK/DATA
CPL_MHB2
VRF_MIPI_IO_1P8
SDR_RFFE5_CLK/DATA SRS_OUT1~3_N41
GNSS_L1_LNA_IN
SAW
LNA
VRF_LNA_1P8
Diplexer
4P4T
Switch
Diplexer
DPDT
Switch
SAW
SAW
VPA_ET2
WIFI_2G
NFC
VREG_S2A_1P904
OCTA_DDI_EN LDO
Key FPCB
Contact
LDO Vibration
Motor
VBAT_SENSE / VBATGND_SENSE
VBATTERY_SR
VBUS_IFIF_PMIC_SCL/SDA_1P8
DC_THM
Thermister
IF PMIC
Battery
Conn.
Direct Charger
Sub
PMIC
Main
PMIC
VREG_L10E_3P3
VREG_L7A_1P8
VREG_L11A_1P8
BT/WLAN/FM
SRS_OUT1~3_N79
SPDT
Switch
BPF
Diplexer
ETDAC1_OUTA_P/M
N78_N79_SEL_0
SA4_CON_DET
VRF_MIPI_IO_1P8
N78_N79_SEL_0
VRF_MIPI_IO_1P8
SA4_CON_DET N78_TRX_SUB_3
N78_TRX
PAM
SPDT
Switch
SPDT
Switch
SP4T
Switch
DRX_TR_IN_N79_4RXVRF_LNA_1P8
VRF_MIPI_IO_1P8
SDR_RFFE2_CLK/DATA
VRF_MIPI_IO_1P8
SRS_OUT3_N79
SDR_RFFE3_CLK/DATA
DRX_LNA_IN_N78_4RX
LNA
FEM
Diplexer
SP4T
Switch
SAW
SAW SPDT
Switch
SP4T
Switch
Duplexer
SP4T
Switch
LPAMiD
MIMO_RX_LNA_IN_1
MIMO_RX_LNA_IN_2
MIMO_RX_LNA_IN_3
MIMO_RX_LNA_IN_4
Diplexer
Extractor
N78_TRX
AP
APT
APT
ET/APT
Diplexer
LPAMiD
RF Transceiver
FEM
SP4T
Switch
FEM
SP4T
Switch
SPDT
Switch
FEM
LNA
LNA
LNA
SP4T
Switch
LPAMiD
Diplexer
LFEM
VREG_L11A_1P8
Display
Conn.
SM-A526B/A5260
Common

SAMSUNG CONFIDENTIAL
A52 5G Sub6 EUR/LA
RF Block Diagram
2021.01.14
SUB ANT 1
LB DRX
B1,B3,B66 DRX MIMO
N1,B3,N66 DRX MIMO
QAT5515
ANT S/W
SDR735
Transceiver
GNSS_IN_L1
SDR_RFFE0,1,2,3,4,5_CLK/DATA
RFFE_SLAVE_CLK/DATA
SM7225-QLINK_L0~L4
-QLINK_CLK/REQ/EN
QET6105
APT Booster #0
(for LB LPAMiD) SDR_RFFE1
TX0_LB2
FBRX_IN COUPLING_OUT
TX0_TR_OUT_LB
TX1_TR_OUT_LB
TX0_TR_OUT_GSMLB
PRX_TR_IN_LB
B1250
B28 DPX
LB_PA_OUT_B28_N28B28_N28_RX_LNA_IN
B28_N28_TRX
COAXIAL
CABLE
ANT_CON_DET_1
(SM7225 GPIO_112)
TX0_TR_OUT_MB
TX0_TR_OUT_HB
TX0_TR_OUT_GSMHB
PRX_TR_IN_P_MH
PRX_TR_IN_P_JMH
PRX_TR_IN_P_LMH
PRX_TR_IN_PM_JMH
PRX_TR_IN_PM_MH
MIMO_RX_LNA_IN_4
MIMO_RX_LNA_IN_1
CPL_OUT_LB
CPL_OUT_MHB
TRX_ANT_LB
TRX_ANT_MHB
LFD181G65MPUF177
Diplexer
COAXIAL
CABLE
ANT_CON_DET_2
(SM7225 GPIO_116)
N78_N79_DRX
DRX_TR_IN_LB
BGS14MPA9
SP4T
MAIN ANT 1
LB TRX
MAIN ANT 2
MHB TRX
N41,N78 DRX
(N41,N78 SRS)
DPX202700DT-4062A1
Diplexer
SRS_OUT2_N41 SAFFB2G65AA0F0A
N7 SAW BGAH1A10
N7_N41 LNA
SAFFB2G59AA1F3K
N41 SAW
MXD8621E
SPDT
NR_CPL_N78
PRX_TR_IN_N78
TX1_TR_OUT_N78
SUB ANT 4
N79 TRX
SRS_OUT3_N41
SAFFB2G65AA0F0A
N7 SAW
SAFFB2G59AA1F3K
N41 SAW
MXD8621E
SPDT
SUB ANT 5
B7/38/41 PRX MIMO
N7 PRX MIMO
N38/41 DRX MIMO
(N41 SRS)
SUB ANT 6
B1/3/66 PRX MIMO
N1/3/66 PRX MIMO
N78 PRX MIMO
(N78 SRS) SAWFD1G84AA2F3K
B1_66/3 Dual SAW
LFD181G65MPUF177
Diplexer
SUB ANT 7
B7/38/41 DRX MIMO
N7/78 DRX MIMO
N38/41 PRX MIMO
(N41,N78 SRS)
GNSS_RF_L1_IN
QDM5877
N78 LFEM
DRX_TR_IN_N78
MXD8643RM
SP4T
CPL_OUT_MHB
NR_CPL_N79
NR_CPL_N78
CPL_OUT_LB
TX1_LB1
TX0_GSM_LB1
P_L
TX0_MB2_5GH_ELAA
TX0_HB1
TX0_GSM_MB1
P_MH
P_JMH
P_LMH
PM_JMH
PM_MH
D_UN
D_L
P_UN
TX1_5GLM_UHB
DM_JMH
DM_MH
QET6105
APT Booster #1
(for OMH LPAMiD#1) SDR_RFFE4
QET5100
ET Modulator
(for OMH LPAMiD#2,
N78/N79 LPAMiD) SDR_RFFE5
TX : SDR_RFFE1
RX : SDR_RFFE0
TX : SDR_RFFE4
RX : SDR_RFFE0
SDM_RFFE2
SDR_RFFE2
SDR_RFFE2
N7_N41_4RX_SEL0
(SM7225 GPIO_123)
SDR_RFFE3
SDR_RFFE3
TX : SDR_RFFE5
RX : SDR_RFFE0
N7_N41_SEL
(SDR735 W_GRFC_0)
XO_IN RFCLK1_SDR735
MAIN1 ANT
LB
MAIN2 ANT
MB/HB
Ant Switch
QAT5515
Ant Switch
QAT3516
Ant Switch
QAT5515
Ant Switch
QAT3516
Ant Switch
QAT5515
Receptacle
20449-001E
Receptacle
20449-001E
Coaxial Cable
Coaxial Cable
SUB ANT 2
MHB DRX
N41 TRX
MS-156C
RF Switch
QM28014
MHB/GNSS/WiFi Antplexer
SFML5E0K001
LB LFEM
DRX_TR_IN_D_LMH
DRX_TR_IN_D_MH
DRX_TR_IN_D_JMH
D_LMH
D_MH
D_JMH
TX1_HB1
QPM6810
LB L-PAMiD
LFD181G65MPUF177
Diplexer
QPM6815 #1
OMH L-PAMiD
SDR_RFFE3
BGS14MPA9
SP4T
SDM_RFFE0
SDM_RFFE2
SDM_RFFE0
SDM_RFFE0
SDM_RFFE0
CPL_MHB2
SAFFB1G47AA0F3K
B32 SAW
DRX_TR_IN_N7_N41_4RX
MIMO_RX_LNA_IN_4
SAFFB1G47AA0F3K
B32 SAW
MIMO_RX_LNA_IN_2
MS-156C
RF Switch
SRS_OUT1_N41
DRX_TR_IN_N78_4RX
DM_UN
SW : SDR_RFFE5
RX : SDR_RFFE2
TX : SDR_RFFE5
RX : SDR_RFFE2
QPM6815 #2
OMH L-PAMiD
CPL_MHB2
(Connect to Sub2)
WIFI_2G
QPM5877
N78 LPAMiD
PRX_TR_IN_N78_4RX PM_UN
PRX_LNA_IN_N78_4RX
SRS_OUT_N78
SRS_OUT_N78
PRX_LNA_IN_N78_4RX
B3
B66
DRX_LNA_IN_N78_4RX
DRX_LNA_IN_N78_4RX
MXD8648MS
SP4T
SDR_RFFE5
SRS_OUT1_N41
SRS_OUT3_N41
SRS_OUT2_N41
TX1_TR_OUT_HB
TX1_MB1
TX1_TR_OUT_MB
BGAH1A10
B3 LNA
MIMO_DRX_IN_1
BGAH1A10
B1 LNA
MIMO_DRX_IN_2
BGSX44MA12
4P4T
DRX_TR_IN_N7_N41_4RX
DRX_TR_IN_DM_JMH
DRX_TR_IN_DM_MH
SDR_RFFE2
SDR_RFFE2
SDR_RFFE0
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
1
2
3
4
1
2
3
4
H
L
H
L
MIMO_RX_LNA_IN_3
MIMO_RX_LNA_IN_3
PRX_4RX_SEL0
(SDR735 W_GRFC_1)
MIMO_RX_LNA_IN_1
MIMO_RX_LNA_IN_2
2
4
1
3
BGSX22G5A10
DPDT
B3
B66
(Connect to Sub5)
(Connect to Sub5)
(Connect to Sub6)
(Connect to Sub6)
(Connect to Sub2)
(Connect to Sub7)
(Connect to Sub4)
(Connect to Sub1)
(Connect to Main1)
(Connect to Sub6)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Sub4)
(Connect to Main2)
(Connect to Sub7)
GNSS_RF_L1_LNA_IN
SAWFD1G84AA2F3K
B1_66/3 Dual SAW
SUB ANT 3
N78 TRX
LFD213G65PA9F072
Diplexer
WIFI_5G
MXD8625ES
SPDT
N78_N79_SEL_0
(SDR735 W_GRFC_14)
H
L
SA4_CON_DET
(connect to
SUB ANT 4 Con DET)
BGS12P2L6
SPDT
H
L
SA4_CON_DET
SM-A516B

SAMSUNG CONFIDENTIAL
A52 5G Sub6_CHN
RF Block Diagram
2021.01.19
SUB ANT 1
LB DRX
B1,B3 DRX MIMO
N1,N3 DRX MIMO
QAT5515
ANT S/W SDR735
Transceiver
GNSS_IN_L1
SDR_RFFE0,1,2,3,4,5_CLK/DATA
RFFE_SLAVE_CLK/DATA
SM7225-QLINK_L0~L4
-QLINK_CLK/REQ/EN
QET6105
APT Booster #0
(for LB LPAMiD) SDR_RFFE1
TX0_LB2
FBRX_IN COUPLING_OUT
TX0_TR_OUT_LB
TX1_TR_OUT_LB
TX0_TR_OUT_GSMLB
PRX_TR_IN_LB
B1250
B28 DPX
LB_PA_OUT_B28_N28B28_N28_RX_LNA_IN
B28_N28_TRX
COAXIAL
CABLE
ANT_CON_DET_1
(SM7225 GPIO_112)
TX0_TR_OUT_MB
TX0_TR_OUT_HB
TX0_TR_OUT_GSMHB
PRX_TR_IN_P_MH
PRX_TR_IN_P_JMH
PRX_TR_IN_P_LMH
PRX_TR_IN_PM_JMH
PRX_TR_IN_PM_MH
MIMO_RX_LNA_IN_4
MIMO_RX_LNA_IN_1
CPL_OUT_LB
CPL_OUT_MHB
TRX_ANT_LB
TRX_ANT_MHB
LFD181G65MPUF177
Diplexer
COAXIAL
CABLE
ANT_CON_DET_2
(SM7225 GPIO_116)
N78_N79_DRX
DRX_TR_IN_LB
BGS14MPA9
SP4T
MAIN ANT 1
LB TRX
MAIN ANT 2
MHB TRX
N41,N78,N79 DRX
(N41,N78,N79 SRS)
DPX202700DT-4062A1
Diplexer
SRS_OUT2_N41 SAFFB2G65AA0F0A
N7 SAW BGAH1A10
N7_N41 LNA
SAFFB2G59AA1F3K
N41 SAW
MXD8621E
SPDT
NR_CPL_N78
PRX_TR_IN_N78
TX1_TR_OUT_N78
SUB ANT 4
N79 TRX
SRS_OUT3_N41
SAFFB2G65AA0F0A
N7 SAW
SAFFB2G59AA1F3K
N41 SAW
PRX_TR_IN_N79_4RX
MXD8621E
SPDT
SRS_OUT2_N79
SUB ANT 5
B7,B41 PRX MIMO
N7,79 PRX MIMO
N41 DRX MIMO
(N41,N79 SRS)
SUB ANT 6
B1,B3 PRX MIMO
N1,N3,N78 PRX MIMO
(N78 SRS) SAWFD1G84AA2F3K
B1_66/3 Dual SAW
LFD181G65MPUF177
Diplexer
SUB ANT 7
B7,B41 DRX MIMO
N7,N78,N79 DRX MIMO
N41 PRX MIMO
(N41,N78,N79 SRS)
GNSS_RF_L1_IN
QDM5877
N78 LFEM
HFQRX2MJB-454
N79 LFEM BGS14MPA9
SP4T
SRS_OUT1_N79
DRX_TR_IN_N78
DRX_TR_IN_N79
MXD8643RM
SP4T
CPL_OUT_MHB
NR_CPL_N79
NR_CPL_N78
CPL_OUT_LB
TX1_LB1
TX0_GSM_LB1
P_L
TX0_MB2_5GH_ELAA
TX0_HB1
TX0_GSM_MB1
P_MH
P_JMH
P_LMH
PM_JMH
PM_MH
D_NA
D_UN
D_L
P_UN
TX1_5GLM_UHB
PM_NA
DM_JMH
DM_MH
QET6105
APT Booster #1
(for OMH LPAMiD#1) SDR_RFFE4
QET5100
ET Modulator
(for OMH LPAMiD#2,
N78/N79 LPAMiD) SDR_RFFE5
TX : SDR_RFFE1
RX : SDR_RFFE0
TX : SDR_RFFE4
RX : SDR_RFFE0
SDR_RFFE5
SDR_RFFE2
SDM_RFFE2
SDR_RFFE2
SDR_RFFE2
N7_N41_4RX_SEL0
(SM7225 GPIO_123)
SDR_RFFE3
SDR_RFFE3
TX : SDR_RFFE5
RX : SDR_RFFE0
SDR_RFFE0
N7_N41_SEL
(SDR735 W_GRFC_0)
XO_IN RFCLK1_SDR735
MAIN1 ANT
LB
MAIN2 ANT
MB/HB
Ant Switch
QAT5515
Ant Switch
QAT3516
Ant Switch
QAT5515
Ant Switch
QAT3516
Ant Switch
QAT5515
Receptacle
20449-001E
Receptacle
20449-001E
Coaxial Cable
Coaxial Cable
NR_CPL_N79
TX : SDR_RFFE5
RX : SDR_RFFE0
PRX_TR_IN_N79
TX1_TR_OUT_N79
BGS14MPA9
SP4T
SRS_OUT3_N79
SRS_OUT2_N79
SRS_OUT1_N79
SDR_RFFE5
SUB ANT 2
MHB DRX
N41 TRX
MS-156C
RF Switch
QM28014
MHB/GNSS/WiFi Antplexer
P_NA
TX1_5GH_ELAA
SFML5E0K001
LB LFEM
DRX_TR_IN_D_LMH
DRX_TR_IN_D_MH
DRX_TR_IN_D_JMH
D_LMH
D_MH
D_JMH
TX1_HB1
QPM6810
LB L-PAMiD
LFD181G65MPUF177
Diplexer
QPM6815 #1
OMH L-PAMiD
SDR_RFFE3
BGS14MPA9
SP4T
SDM_RFFE0
SDM_RFFE2
SDM_RFFE0
SDM_RFFE0
SDM_RFFE0
CPL_MHB2
DRX_TR_IN_N7_N41_4RX
MIMO_RX_LNA_IN_4
SRS_OUT3_N79
SDR_RFFE3
MXD8648MS
SP4T DRX_TR_IN_N79_4RX
SDR_RFFE2
DM_NA
MIMO_RX_LNA_IN_2
MS-156C
RF Switch SRS_OUT1_N41
DRX_TR_IN_N78_4RX
DM_UN
SW : SDR_RFFE5
RX : SDR_RFFE2
QM78079
N79 LPAMiD
TX : SDR_RFFE5
RX : SDR_RFFE2
QPM6815 #2
OMH L-PAMiD
CPL_MHB2
(Connect to Sub2)
WIFI_2G
QPM5877
N78 LPAMiD
PRX_TR_IN_N78_4RX PM_UN
PRX_LNA_IN_N78_4RX
SRS_OUT_N78
SRS_OUT_N78
PRX_LNA_IN_N78_4RX
B3
B66
DRX_LNA_IN_N78_4RX
(From Main2)
DRX_LNA_IN_N78_4RX
MXD8648MS
SP4T
SDR_RFFE5
SRS_OUT1_N41
SRS_OUT3_N41
SRS_OUT2_N41
TX1_TR_OUT_HB
TX1_MB1
TX1_TR_OUT_MB
BGAH1A10
B3 LNA
MIMO_DRX_IN_1
BGAH1A10
B1 LNA
MIMO_DRX_IN_2
BGSX44MA12
4P4T
DRX_TR_IN_N7_N41_4RX
DRX_TR_IN_DM_JMH
DRX_TR_IN_DM_MH
SDR_RFFE2
SDR_RFFE2
SDR_RFFE0
HFQRX2MJB-454
N79 LFEM
HFQRX2MJB-454
N79 LFEM
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
RF1
RF2
RF3
RF4
1
2
3
4
1
2
3
4
H
L
H
L
MIMO_RX_LNA_IN_3
MIMO_RX_LNA_IN_3
PRX_4RX_SEL0
(SDR735 W_GRFC_1)
MIMO_RX_LNA_IN_1
MIMO_RX_LNA_IN_2
2
4
1
3
BGSX22G5A10
DPDT
B3
B66
(Connect to Sub5)
(Connect to Sub5)
(Connect to Sub6)
(Connect to Sub6)
(Connect to Sub2)
(Connect to Sub7)
(Connect to Sub4)
(Connect to Sub1)
(Connect to Main1)
(Connect to Sub6)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Main2)
(Connect to Sub2)
(Connect to Main2)
(Connect to Sub7)
GNSS_RF_L1_LNA_IN
SAWFD1G84AA2F3K
B1_66/3 Dual SAW
SUB ANT 3
N78 TRX
LFD213G65PA9F072
Diplexer
WIFI_5G
MXD8625ES
SPDT
N78_N79_SEL_0
(SDR735 W_GRFC_14)
H
L
SA4_CON_DET
(connect to
SUB ANT 4 Con DET)
BGS12P2L6
SPDT
H
L
SA4_CON_DET
SM-A5160

ANT2002 ANT3000
ANT3004
ANT3005
ANT3011
ANT6000 ANT6001
ANT6002
ANT6003
ANT6005
ANT6006
BOTHHOLE4000
BOTHHOLE4001
BOTHHOLE4002
BOTHHOLE4003
BOTHHOLE4005
BOTHHOLE4006
BOTHHOLE4007
BOTHHOLE4008
C1009
C1010
C1014C1016
C1020
C1028C1034
C1046
C1047
C1048
C1049
C1050 C1051
C1057
C1069
C1085
C1093
C2016
C2038
C2051
C2068
C2071
C2079
C2082
C2084
C2085
C2090
C2093
C2094
C2097
C2098
C2099
C2106
C2110
C2114
C2117
C2118
C2120
C2121
C2123
C2124
C3000
C3005
C3036
C3037
C3039
C3040
C3041
C3043
C3044 C3045
C3046
C3047
C3048
C3052
C3061
C4002
C4003C4004
C5008
C5009
C5081
C5082
C5084
C5085
C5087
C5101
C5102
C5103
C5104
C5105
C5106
C5107
C5108
C5109
C5110
C5111
C5113
C5114
C5116
C5117
C5118
C5119
C5122
C6000
C6001
C6002
C6003
C6004
C6005
C6006
C6007
C6008
C6009
C6013
C6014
C6015
C6016
C6017
C6020
C6027
C6034
C6035
C6037
C6038
C6044
C6065
C6066
C6068
C6069 C6070
C6071
C6072
C6073
C6076
C6078
C6079
C6080
C6083 C6084
C6094
C6095 C6096
C6109
C6112
C6113 C6114
C6115
C6116
C6117
C7001
C7002 C7010
C7011
C7016
C7017
C7018
C7021
C7024
C7025
C7026
C7027
C7030
C7032
C7033
C7034
C7035
C7046
C7048
C7049
C7050 C7051
C7052C7053
C8004
C8005
C8006
C8008
C8010
C8011
C8012
C8016
C8017
C8018
C8019
C8020
C8025
C8026
C8027
C8030
C8031
C8034
C8035
C8036
C8037
C8038
C8039
C8040
C8041 C8042
C8043
C8044
C8045
C8046 C8047 C8048
C8049
C8050 C8051
C8054 C8055
C8058
C8059
C8067
C8068
C9001
C9002
C9003
C9004
C9005
C9006
C9007 C9008 C9009
C9010
C9011
C9012
C9013
C9014 C9015
C9016 C9017
C9018
CN7000
CON4001
D6000
D6001
D6003
GND
GND1
JTAG4000 JTAG4001
JTAG4002
L1005
L1029L1031
L1045
L1051
L1073
L2008
L2031
L2035
L2038
L2039
L2040
L2041
L2045
L2048 L2053
L2055
L3012
L3013
L6001
L6007
L6016
L6017 L6019
L7004
L7006
L7007
L7011
L7013
L7018
L7019
L8001
L8004
L9000
L9001
L9002
L9003
L9004
L9005
OSC6000
R1000
R1001
R2003
R2004
R4000
R4001
R4002
R4003
R4006
R4007
R4008 R4009
R4010 R4011
R4013
R4016
R4020
R4022
R4023 R4024
R4025 R4026
R4027
R4031
R4032
R4033
R4034
R4035
R4036
R4037
R4040 R4041 R4042
R4046
R4047
R4051
R4052
R5000R5001
R6000
R6001
R6002
R6003
R6004 R6005
R6006
R6007
R6008
R6009
R6010
R6011
R6012
R6013
R6014
R6016
R6017 R6019
R6021
R6022
R6030
R7007
R7008
R7009
R7010
R7012
R7013
R7014 R7017
R8000
R8001
R8002
R8003
R8004
R8005
R8006
R8007
R8008
R8009 R8010
R8011
SC9001
SC9002
SOC8002
SOC8003
SUS4000
TH4000
TH6000
TH6001
TP_AP_PS_HOLD
TP_D3000
TP_ESE_CLK
TP_ESE_CS_N
TP_ESE_MISO
TP_ESE_MOSI
TP_NFC_CLK_REQ
TP_NFC_EN
TP_NFC_FIRM
TP_NFC_IRQ
TP_SWDIO
TP_SWIO3000
TP_TCK
TP_UB1
TP2000
TP2001
TP5000
TP5001
TP5002
TP5003
TP5004
TP5005
TP5006
TP6002
TP6003
TP6010TP6011
TP7000
TP7002TP7003 TP7004
TP7005
TP7006TP7007
TP7008
TP7009
TP7011
TP7020 TP7021TP7022 TP7023
TP8003
TP8004TP8005
U1013
U2016
U2017 U2025
U3003
U3005
U3007
U4000
U6000
U6003
U6004
U6007
U6008
U7003
U8001
U8004
U8005
U8006
U8007
U8008
U9000
U9001
UME5000
VBUS
ZD6000
ZD6001
ZD6003
ZD6004 ZD6005
ZD6006
VX_Setup(2020-04-08)_HHP
Created date of PCB data : 2020/12/24 17:29:11
Model :
Revision :
Manufacture Count :
Charge :
Contact :
Date :
Routing :
Resin :
VX_Setup(2020-04-08)_HHP
Created date of PCB data : 2020/12/24 17:29:11
SM-A516B

ANT1000
ANT1001 ANT1002 ANT1003ANT1004
ANT2001
ANT2003
ANT2004
ANT2005
ANT3001
ANT3002ANT3003
ANT3009 ANT3010
ANT7000
ANT7001
ANT8000
BOOT0
BOTHHOLE4004
C1000
C1001
C1002
C1003
C1004
C1005
C1006
C1007
C1008 C1011
C1012
C1013
C1015 C1017
C1018
C1019
C1021
C1022 C1023
C1024
C1025
C1026
C1027
C1029
C1030
C1031
C1032 C1033
C1035 C1036
C1037
C1038 C1039
C1044
C1045
C1052
C1053
C1055
C1058
C1059
C1060
C1061
C1062
C1063
C1064
C1065
C1066
C1067
C1068
C1070
C1072
C1073
C1074
C1075 C1076
C1077
C1081
C1082
C1083
C1084
C1086
C1087
C1088
C1089
C1090
C1091
C1092
C1094
C2001
C2002
C2003 C2004 C2005 C2006
C2007 C2008 C2009
C2010 C2011
C2014
C2017
C2018
C2019
C2020
C2021
C2022
C2023
C2024
C2025 C2026 C2027
C2028
C2029 C2030
C2031
C2032
C2033
C2034
C2035
C2036
C2037
C2039
C2040
C2041
C2042
C2043
C2044 C2045 C2046 C2047
C2048 C2049
C2050
C2053
C2054
C2055 C2056 C2057
C2058C2059
C2063
C2064
C2066
C2067
C2069
C2070
C2072 C2073
C2074
C2075
C2078
C2080
C2081
C2086
C2087
C2088
C2089
C2091
C2092 C2095
C2096
C2100
C2101
C2102
C2103
C2104
C2105
C2107
C2109
C2112
C2113
C2115
C2119
C2122
C2126
C2127
C2128
C2131
C3001
C3002
C3003
C3004
C3006
C3007
C3009
C3010
C3011
C3012
C3013
C3014
C3015
C3016
C3017
C3018
C3019
C3020
C3021
C3022
C3023
C3024
C3025
C3026
C3027
C3028 C3029
C3030
C3031
C3032
C3033
C3034
C3035
C3038
C3042
C3049
C3050
C3051 C3053
C3054 C3055
C3056
C3057
C3058
C3059
C3060
C3062
C4000
C4001
C5000
C5001
C5002
C5003
C5004
C5005
C5006
C5007
C5010
C5011
C5012
C5013
C5014 C5015
C5016 C5017
C5018
C5019
C5020
C5021
C5022 C5023
C5024
C5025
C5026
C5027
C5028
C5029
C5030
C5031 C5033
C5034
C5035
C5036
C5037
C5038 C5039 C5040
C5041
C5042
C5043
C5044
C5045
C5046
C5047
C5049 C5053
C5054
C5057
C5058
C5059
C5060
C5061
C5064
C5065
C5066
C5067
C5068
C5069
C5070 C5071
C5072
C5073
C5074
C5075
C5076
C5078
C5079
C5080
C5083
C5086
C5088
C5089
C5090
C5091
C5092
C5093
C5094
C5095
C5120
C5121
C5123
C5124
C5125
C5126
C5127
C5128
C5129
C5130
C5132
C5133
C5134
C5137
C5138
C5139
C5140
C5141
C5143
C5145
C5147
C5148
C5149
C5150
C5151
C5152
C5153
C5154
C5156
C5158 C5159
C5161
C5162
C5163 C5164
C6010
C6011
C6012
C6018
C6019
C6021
C6022
C6023
C6024 C6025
C6026
C6028
C6029
C6030
C6031
C6032
C6033
C6036
C6039
C6040
C6041
C6042
C6043
C6045
C6046
C6047
C6048
C6049
C6050
C6051
C6052
C6053
C6054 C6055
C6056
C6057
C6058
C6059
C6060
C6061
C6062
C6063
C6064
C6067
C6074
C6075
C6077
C6081
C6082
C6085
C6086 C6087 C6088
C6089
C6090
C6091
C6092 C6093
C6097
C6098
C6099
C6100
C6101
C6102
C6103
C6104
C6105
C6106
C6107
C6108
C6110
C6111
C6120
C6121
C6122
C6123
C6124
C6125
C6126
C6127
C6128
C7000
C7003
C7004
C7005
C7006 C7007
C7008
C7009
C7012
C7013
C7014C7015
C7019
C7020
C7022
C7023
C7028
C7029
C7031
C7036 C7037 C7038
C7039 C7040
C7041
C7044
C7045
C7047
C7054
C7055
C7056
C8001
C8002
C8003
C8013
C8014
C8015
C8021 C8022
C8023
C8028
C8029
C8032
C8033
C8062
C9000 C9019
C9020 C9021
C9022
C9023 C9024
C9025
C9026 C9027
C9028
C9070
C9071
CON4002
F1000
F1001
F1002
F1003
F1004
F1008
F2000 F2001
F2002
F2003
F2004
F2005 F2006
F2007
F3000
F3003
F3004
HDC4000
ID
L1000
L1001 L1002
L1003
L1004
L1006
L1007
L1008
L1009
L1010
L1013
L1014
L1015
L1016
L1017
L1018
L1019
L1020
L1021
L1022
L1023
L1026
L1027
L1028
L1030
L1032
L1033
L1034
L1035
L1036
L1037
L1038
L1039
L1040
L1041
L1042
L1043
L1044
L1046 L1047
L1048
L1049
L1050
L1052
L1053
L1055 L1056
L1057
L1058
L1059
L1060
L1061
L1062 L1063
L1067
L1079 L1080
L1081 L1082
L1083
L1086
L1087
L1088 L1089
L2000
L2001
L2002
L2004
L2005
L2006
L2009
L2011
L2012
L2013
L2014
L2015
L2017
L2018
L2019
L2020 L2021
L2022
L2023
L2024
L2025
L2026
L2027
L2028L2029
L2036
L2037
L2042
L2043
L2044
L2046
L2047
L2050
L2052
L2056
L2057
L2058
L2059
L2060
L2061
L2062
L2063
L3001
L3004
L3005
L3010
L3011
L3014 L3015
L3016 L3017
L3019
L3020
L3021
L6000
L6002
L6003
L6004
L6005
L6006
L6008
L6009
L6010 L6011
L6012
L6013
L6014
L6015
L6018
L7000
L7001
L7002
L7003
L7005
L7008
L7009
L7010 L7012
L7014
L7015
L7016 L7017
L8000
L8002
L8003
L8005
LED6000
MIC7000
R2000
R2001
R2002
R2005
R2006
R2007
R2008 R2009
R2010
R3000
R3001
R3002
R3003
R4004 R4005
R4012
R4014
R4015
R4017 R4018
R4019 R4021
R4028
R4029
R4030
R4038
R4039
R4043 R4044
R4049 R4050
R6015
R6018
R6020
R6023
R6024
R6025
R6026
R6027
R6028
R6029
R7000
R7002
R7003
R7011
R7018
R7019 R7020
R7021
R7022
R9000
R9001
R9002 R9003
R9004
R9008
RFC1000
RFC1001
RFS1000
RFS2000
SC9003
SC9004
SOC6000
SOC8000
SOC8001
SOC8004
SOC9000
TA3000
TH1000
TH3000
TP_FAULT_N
TP_MST_DATA_ATP_MST_DATA_B
TP_SDM1000 TP_SDM1001
TP_UB0
TP_UB4000
TP_WCSS_CLK
TP_WCSS_DATA
TP1000
TP1001
TP2003
TP2004
TP2005
TP2006
TP2007
TP2008
TP2009 TP2010
TP2011
TP3000TP3001
TP3002
TP3003
TP3004
TP3005
TP3006
TP3007 TP3008
TP7010
TP7014
TP7015
TP7016
TP7017
TP7018
TP7019
TP9000TP9001
U1000
U1001
U1002
U1003
U1004
U1005
U1008
U1009
U1016
U1021
U2003
U2005
U2006
U2007
U2008
U2009
U2012
U2020 U2021
U2023
U3000
U3001
U3002
U3004
U3006
U6001
U6002
U6005
U6010
U7000
U7001
U7002
U7004
U7005
U8002
U8003
U9002
USB_N
USB_P
ZD6002
ZD9000ZD9001
VX_Setup(2020-04-08)_HHP
Created date of PCB data : 2020/12/24 17:29:11
Model :
Revision :
Manufacture Count :
Charge :
Contact :
Date :
Routing :
Resin :
VX_Setup(2020-04-08)_HHP
Created date of PCB data : 2020/12/24 17:29:11
SM-A516B
