Samsung SM-A707F User manual

SM-A707F/A7070
Common
Mobile Device CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference Abbreviation
4.
2
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin
of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use a soldering iron with a power rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replacement parts
may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can
be easily damaged by it. We recommend protecting these components with conductive anti-static bags
when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly
connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-1. GSM General Specification
Item
EGSM 900
DCS1800
PCS1900
Freq. Band[MHz]
Uplink/Downlink
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
ARFCN range 0~124 & 975~1023 512~885 512~810
Tx/Rx spacing 45MHz 95MHz 80MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
Time Slot Period/
Frame Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Modulation GSM/
EGPRS
GMSK/
8PSK
GMSK/
8PSK
GMSK/
8PSK
MS Power 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm
Power Class 4(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
Sensitivity -102dBm -100dBm -100dBm
TDMA Mux 8 8 8

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-2. GSM Tx Power Class
TX Power
control level
EGSM900
TX Power
control level
DCS1800
TX Power
control level
PCS1900
5 33±2 dBm
0
30±3 dBm
0
30±3 dBm
6 31±2 dBm 1 28±3 dBm 1 28±3 dBm
7 29±2 dBm 2 26±3 dBm 2 26±3 dBm
8 27±2 dBm 3 24±3 dBm 3 24±3 dBm
9 25±2 dBm 4 22±3 dBm 4 22±3 dBm
10 23±2 dBm 5 20±3 dBm 5 20±3 dBm
1 1 21±2 dBm 6 18±3 dBm 6 18±3 dBm
12 19±2 dBm 7 16±3 dBm 7 16±3 dBm
13 17±2 dBm 8 14±3 dBm 8 14±3 dBm
14 15±2 dBm 9 12±4 dBm 9 12±4 dBm
15 13±2 dBm 10 10±4 dBm 10 10±4 dBm
16 11±3 dBm 1 1 8±4 dBm 1 1 8±4 dBm
17 9±3 dBm 12 6±4 dBm 12 6±4 dBm
18 7±3 dBm 13 4±4 dBm 13 4±4 dBm
19 5±3 dBm 14 2±5 dBm 14 2±5 dBm
- - 15 0±5 dBm 15 0±5 dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-3. WCDMA General Specification
Item
WCDMA2100(B1)
WCDMA1900(B2)
WCDMA850(B5)
WCDMA900(B8)
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1850~1910
1930~1990
824~849
869~894
880~915
925~960
ARFCN range
UL：9612~9888
DL：10562~10838
UL：9262~9538
DL：9662~9938
UL：4132~4233
DL：4357~4458
UL：2712~2868
DL：2937~3088
Tx/Rx spacing 190MHz 80MHz 45MHz 45MHz
Mod. Bit rate/
Bit Period
42.2Mbps(DL)
5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL)
Time Slot Period/
Frame Period
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
Modulation QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
MS Power
(dBm) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓) 25.7 ~ -49(↓)
Power Class 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -106dBm -104dBm -104dBm -103dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-4-1. L T E General Specification [SM-A707F]
Item
LTE Band1
LTE Band3
LTE Band5
LTE Band7
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1710~1785
1805~1880
824~849
869~894
2500~2570
2620~2690
ARFCN range UL:18000~18599
DL:0~599
UL:19200~19949
DL:1200~1949
UL:20400~20649
DL:2400~2649
UL:20750~21449
DL:2750~3449
Tx/Rx spacing
(MHz) 190 95 45 120
Channel Bandwidth
(MHz) 5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK, BW
10MHz) (dBm) -96.3 -93.3 -94.3 -94.3
Item
LTE Band8
LTE Band20
LTE Band38
LTE Band40
LTE Band41
Freq. Band[MHz]
Uplink/Downlink
880~915
925~960
832~862
791~821 2570~2620 2300~2400 2555~2655
ARFCN range UL:21450-21799
DL:3450-3799
UL:24150~24449
DL:6150~6449
UL/DL:
37750 ~ 38249
UL/DL:
38650 ~ 39649
UL/DL:
40240~41140
Tx/Rx spacing (MHz) 45 -41
0
0
0
Channel Bandwidth
(MHz) 1.4/3/5/10 5/10/15/20 5/10/15/20 5/10/15/20 5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK,
BW 10MHz) (dBm) -93.3 -93.3 -96.3 -96.3 -96.3

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-4-2. L T E General Specification [SM-A7070]
Item
LTE Band1
LTE Band3
LTE Band5
LTE Band7
LTE Band8
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1710~1785
1805~1880
824~849
869~894
2500~2570
2620~2690
880~915
925~960
ARFCN range UL:18000~18599
DL:0~599
UL:19200~19949
DL:1200~1949
UL:20400~20649
DL:2400~2649
UL:20750~21449
DL:2750~3449
UL:21450-21799
DL:3450-3799
Tx/Rx spacing
(MHz) 190 95 45 120 45
Channel Bandwidth
(MHz) 5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10 5/10/15/20 1.4/3/5/10
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK,
BW 10MHz) (dBm) -96.3 -93.3 -94.3 -94.3 -93.3
Item
LTE Band34
LTE Band38
LTE Band39
LTE Band40
LTE Band41
Freq. Band[MHz]
Uplink/Downlink 2010 ~ 2025 2570~2620 1880~1920 2300~2400 2555~2655
ARFCN range UL/DL:
36200~36349 UL/DL
:37750 ~ 38249
UL/DL:
38250~38649 UL/DL:
38650 ~ 39649
UL/DL:
40240~41140
Tx/Rx spacing (MHz)
0
0
0
0
0
Channel Bandwidth
(MHz) 5/10/15/20 5/10/15/20 5/10/15/20 5/10/15/20 5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity(QPSK,
BW 10MHz) (dBm) -96.3 -96.3 -96.3 -96.3 -96.3

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
2. Specification
2-5. TDSCDMA General Specification [SM-A7070]
Item
TDSCDMA2010(B34)
TDSCDMA1880(B39)
Chip rate 1.28 Mcps 1.28 Mcps
OBW 1.6 MHz 1.6 MHz
Freq. Band[MHz]
Uplink/Downlink 2010~2025
1880~1920
ARFCN range 10054~10121 9404~9596
Tx/Rx spacing
(MHz) - -
MS Power
(dBm) 24 ~ -48(↓) 24 ~ -48(↓)
Power Class 2(max+24dBm) 2(max+24dBm)
Sensitivity
(dBm /1.28 MHz) -110 -110

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swrittenauthorization is strictlyprohibited.
3. Product Function
Main Function
Item
Description
OS Android P OS V9.0
SM-A707F
[2G]
GSM : 900, 1800, 1900
[3G]
WCDMA: B1, 2, 5, 8
[4G]
LTE FDD : B1, 3, 5, 7, 8, 20
LTE TDD : 38, 40, 41
SM-A7070
[2G]
CDMA : 800
GSM : 900, 1800, 1900
[3G]
CDMA :BC0
WCDMA: B1, 2, 5, 8
TD-SCDMA : B34, 39
[4G]
LTE FDD : B1, 3, 5, 7, 8
LTE TDD : B34, 38, 39, 40, 41
Battery 4500mAh
Base Band 2.0Ghz + 1.7GHz
Other RF GPS, Glonass, Beidou, Galileo / BT5.0 / USB 2.0 / WIFI 802.11 a/b/g/n/ac / NFC /
Camera Triple Camera ( 64MP(F1.8) + 5MP(F2.2) + 8MP(F2.2)) with LED Flash / Front Camera 32MP(F2.0)
LCD 6.7", FHD+, 2400x1080
SM-A707F
RAM 6 GB / 8 GB
SM-A7070
RAM 8 GB
Storage 128 GB
Sensor Accelerometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, Hall Sensor, Proximity
Sensor, RGB Light Sensor,
Accessory
Charger: 9V/2.77A and 5V/3.0A DC charging
Data cable: 3.05pi, 1.0m(USB-C2C)
Ear phone: 3.5pi, 4pin

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1. Cellular phone Exploded View
QFR01
QAR01
QMO01
QCA01
QMP01
QCA02
QCR12
QRE01
QME01
QVO01
QSM01
QAN01
QCR205
QBC01
QSP01
QCK01
QCB01
QME02
QBA01
QIF01
QCR145
QKP01
※SVC REPAIR TAPE
QRT01

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
[SM-A707F]
Parts Code
Design LOC
Description
0401-001110 D8000 DIODE-SWITCHING
0404-001250 D6000 DIODE-SCHOTTKY
0406-001561 ZD3002,ZD4001,ZD6003 DIODE-TVS
0406-001561 ZD6005,ZD6021,ZD8000 DIODE-TVS
0406-001561 ZD8001 DIODE-TVS
0406-001728 ZD1000,ZD5000 DIODE-TVS
0406-001808 D6001 DIODE-TVS
0406-001809 ZD6017,ZD6018 DIODE-TVS
0505-003234 TR5001,TR5002 FET-SILICON
0601-003768 LED5000 LED
1001-001755 U5006 IC
1001-001911 U1008,U2005 IC
1001-001970 U1006,U2001,U2006 IC
1001-002062 U3002 IC
1001-002063 U1001 IC
1009-001076 U3006 IC
1201-003869 U3005 IC
1201-004029 U1000,U2011 IC
1201-004109 PAM2000 IC
1201-004200 U8000 IC
1201-004209 U1004 IC
1203-008251 U6001 IC
1203-008859 U7002 IC
1203-008865 U6000,U7001 IC
1203-008867 U3016,U7010 IC
1203-008872 U6004,U7009 IC
1203-009054 U6002 IC
1203-009220 U7000 IC
1203-009221 U7016 IC
1203-009240 U2000 IC
1203-009246 U5003 IC
1203-009247 U5004 IC
1203-009248 U5002 IC
1205-005106 U6003 IC
1205-005217 U7003 IC
1205-005731 U3021 IC
1205-005833 U2009 IC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
1205-005881 U3004 IC
1205-006106 U8001 IC
1205-006111 UCP400 IC
1209-002450 U3003 IC
1209-002513 U3009 IC
1209-002628 U3000 IC
1209-002629 U3001 IC
1404-001724 TH2000,TH4000 THERMISTOR
1404-001724 THM3000 THERMISTOR
1405-001404 VR6000 VARISTOR
2007-003015 ZD6015,ZD6016 R-CHIP
2007-007099 R5004 R-CHIP
2007-007142 R7003 R-CHIP
2007-007313 R5001 R-CHIP
2007-007741 R3002,R3006,R3007 R-CHIP
2007-007741 R4007,R4010,R5008 R-CHIP
2007-007741 R5016,R5025,R5030 R-CHIP
2007-007741 R6009 R-CHIP
2007-008056 R1006,R1007 R-CHIP
2007-008167 R5000 R-CHIP
2007-008263 R4006 R-CHIP
2007-008420 R5019,R7001 R-CHIP
2007-008483 R5023 R-CHIP
2007-008516 C6037 R-CHIP
2007-008531 R7000,R7004 R-CHIP
2007-008587 R8040 R-CHIP
2007-008588 R3012,R3013 R-CHIP
2007-008766 R4016 R-CHIP
2007-008785 R1005 R-CHIP
2007-008788 R7005 R-CHIP
2007-008798 R8000,R8001 R-CHIP
2007-008808 R7006 R-CHIP
2007-009111 R3001,R5006 R-CHIP
2007-009157 R5027,R6004,R6005 R-CHIP
2007-009171 R3008 R-CHIP
2007-009212 R3005,R4021,R4022 R-CHIP
2007-009212 R4042,R5021,R5022 R-CHIP
2007-009212 R6018 R-CHIP
2007-009314 R6001 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2007-009315 R6007 R-CHIP
2007-009352 R6017 R-CHIP
2007-009408 R4008,R4009,R4013 R-CHIP
2007-009408 R4014,R4025,R4026 R-CHIP
2007-009408 R4027,R4028,R4031 R-CHIP
2007-009408 R4032,R4033,R4034 R-CHIP
2007-009408 R4037,R4038,R4040 R-CHIP
2007-009408 R4041,R6016,R8008 R-CHIP
2007-009408 R8011 R-CHIP
2007-009766 R7002 R-CHIP
2007-009801 R4015 R-CHIP
2007-009805 R1000,R1001,R1002 R-CHIP
2007-009805 R1004,R2000 R-CHIP
2007-009807 R6006 R-CHIP
2007-009920 R4002,R6002,R6003 R-CHIP
2007-009954 R6008 R-CHIP
2007-009969 R3016,R3021,R4001 R-CHIP
2007-010202 R5002 R-CHIP
2007-010233 C4094 R-CHIP
2007-011043 R4000 R-CHIP
2203-000386 C8153 C-CERAMIC,CHIP
2203-001153 C8045 C-CERAMIC,CHIP
2203-001239 C3082,C3086,C3089 C-CERAMIC,CHIP
2203-005446 C3087 C-CERAMIC,CHIP
2203-005682 C1006,C1007,C1016 C-CERAMIC,CHIP
2203-005682 C2031,C2063,C2073 C-CERAMIC,CHIP
2203-005682 C2075,C2081,C2082 C-CERAMIC,CHIP
2203-005682 C2087,C2115,C2122 C-CERAMIC,CHIP
2203-005682 C3061,C3062,C3063 C-CERAMIC,CHIP
2203-005682 C7004,L1001,L1003 C-CERAMIC,CHIP
2203-005682 L1017,L2043 C-CERAMIC,CHIP
2203-005725 C7040,L1032 C-CERAMIC,CHIP
2203-005729 C8013,C8022,C8039 C-CERAMIC,CHIP
2203-005729 L3001 C-CERAMIC,CHIP
2203-005731 C3001,C3007,C3008 C-CERAMIC,CHIP
2203-005731 C8028,C8029,C8031 C-CERAMIC,CHIP
2203-005732 C8038 C-CERAMIC,CHIP
2203-005736 C1010,C1023,C1035 C-CERAMIC,CHIP
2203-005736 C1054,C1055,C1124 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2203-005736 C1125,C1126,C1129 C-CERAMIC,CHIP
2203-005736 C1134,C1135,C2001 C-CERAMIC,CHIP
2203-005736 C2024,C2038,C2043 C-CERAMIC,CHIP
2203-005736 C2045,C2058,C2067 C-CERAMIC,CHIP
2203-005736 C2068,C2084,C2092 C-CERAMIC,CHIP
2203-005736 C2094,C2123,C2124 C-CERAMIC,CHIP
2203-005736 C3006,C3024,C3039 C-CERAMIC,CHIP
2203-005736 C3044,C3045,C3047 C-CERAMIC,CHIP
2203-005736 C3048,C3058,L1023 C-CERAMIC,CHIP
2203-005736 L1030,L1080,L2000 C-CERAMIC,CHIP
2203-005736 L2003,L2006,L2018 C-CERAMIC,CHIP
2203-005736 L2020,L2023,L2031 C-CERAMIC,CHIP
2203-005736 L2039,L2040,L2046 C-CERAMIC,CHIP
2203-005736 L2048,L2050,L2062 C-CERAMIC,CHIP
2203-005736 L2067,L3003 C-CERAMIC,CHIP
2203-005740 C8027,C8030 C-CERAMIC,CHIP
2203-005777 C1051,C1052,C1069 C-CERAMIC,CHIP
2203-005777 C2046,C2090,C2100 C-CERAMIC,CHIP
2203-005777 C3055 C-CERAMIC,CHIP
2203-005789 C1036,C1062,C1066 C-CERAMIC,CHIP
2203-005789 C2028,C2033,C2069 C-CERAMIC,CHIP
2203-005789 C2091,C2099,C2109 C-CERAMIC,CHIP
2203-005789 C2110 C-CERAMIC,CHIP
2203-005792 C1046 C-CERAMIC,CHIP
2203-005806 C2083 C-CERAMIC,CHIP
2203-006120 C6047,C6048 C-CERAMIC,CHIP
2203-006123 C1020 C-CERAMIC,CHIP
2203-006194 C6019 C-CERAMIC,CHIP
2203-006305 C2066,C3009,C3040 C-CERAMIC,CHIP
2203-006305 C7009,C7010,C7024 C-CERAMIC,CHIP
2203-006318 L1035 C-CERAMIC,CHIP
2203-006400 C3083,C3085,C5095 C-CERAMIC,CHIP
2203-006400 C6065 C-CERAMIC,CHIP
2203-006410 C1050 C-CERAMIC,CHIP
2203-006423 C1004,C1043,C2003 C-CERAMIC,CHIP
2203-006423 C2004,C2006,C2007 C-CERAMIC,CHIP
2203-006423 C2008,C2009,C2010 C-CERAMIC,CHIP
2203-006423 C2011,C2012,C2013 C-CERAMIC,CHIP
2203-006423 C2015,C2016,C2017 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2203-006423 C2019,C2020,C2021 C-CERAMIC,CHIP
2203-006423 C2022,C2061,C3059 C-CERAMIC,CHIP
2203-006423 C3060,C5115,C6033 C-CERAMIC,CHIP
2203-006423 C7025,C8000,C8007 C-CERAMIC,CHIP
2203-006423 C8009,C8023,C8024 C-CERAMIC,CHIP
2203-006423 C8025,C8034,C8044 C-CERAMIC,CHIP
2203-006556 C1039,C1042,C1045 C-CERAMIC,CHIP
2203-006556 C2074 C-CERAMIC,CHIP
2203-006604 C3020,C3041 C-CERAMIC,CHIP
2203-006611 C1136,C3010 C-CERAMIC,CHIP
2203-006665 L1027,L1051 C-CERAMIC,CHIP
2203-006674 C2088 C-CERAMIC,CHIP
2203-006839 C1000,C1005,C1114 C-CERAMIC,CHIP
2203-006839 C1123,C2044,C2060 C-CERAMIC,CHIP
2203-006839 C3074,C3081,C4020 C-CERAMIC,CHIP
2203-006839 C4021,C4086,C4095 C-CERAMIC,CHIP
2203-006839 C4096,C5022,C5054 C-CERAMIC,CHIP
2203-006839 C5100,C8006,C8050 C-CERAMIC,CHIP
2203-006844 C3038,C6077 C-CERAMIC,CHIP
2203-006846 C1076 C-CERAMIC,CHIP
2203-006979 C3019,C3023,C3025 C-CERAMIC,CHIP
2203-006979 C3026,C3027,C3033 C-CERAMIC,CHIP
2203-006979 C3034 C-CERAMIC,CHIP
2203-007143 C6043 C-CERAMIC,CHIP
2203-007210 C4029,C4030,C4058 C-CERAMIC,CHIP
2203-007210 C6003,C6004,C6005 C-CERAMIC,CHIP
2203-007210 C6016,C6017,C8004 C-CERAMIC,CHIP
2203-007317 C2002,C3002,C3014 C-CERAMIC,CHIP
2203-007317 C3015,C3056,C6011 C-CERAMIC,CHIP
2203-007317 C6012,C7012 C-CERAMIC,CHIP
2203-007391 C3036,C3076,C6036 C-CERAMIC,CHIP
2203-007391 C6039,C8011,C8012 C-CERAMIC,CHIP
2203-007391 C8019 C-CERAMIC,CHIP
2203-007393 C2005,C2014,C2018 C-CERAMIC,CHIP
2203-007393 C2023,C2059,C3017 C-CERAMIC,CHIP
2203-007393 C3028,C3031,C3037 C-CERAMIC,CHIP
2203-007393 C5074,C5076,C5077 C-CERAMIC,CHIP
2203-007393 C5078,C5105,C5106 C-CERAMIC,CHIP
2203-007393 C5120,C5124,C5126 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2203-007393 C6013,C6015,C6032 C-CERAMIC,CHIP
2203-007393 C6073,C6074,C7016 C-CERAMIC,CHIP
2203-007393 C7017,C7020,C7021 C-CERAMIC,CHIP
2203-007393 C7022,C7029,C8001 C-CERAMIC,CHIP
2203-007456 C2056,C5083 C-CERAMIC,CHIP
2203-007474 C5110,C5111,C5129 C-CERAMIC,CHIP
2203-007474 C7026 C-CERAMIC,CHIP
2203-007544 C3042,C3043 C-CERAMIC,CHIP
2203-007781 C8005 C-CERAMIC,CHIP
2203-007796 C3013,C3018,C3021 C-CERAMIC,CHIP
2203-007796 C3022,C3030,C3032 C-CERAMIC,CHIP
2203-007796 C3070,C3071,C4000 C-CERAMIC,CHIP
2203-007796 C4001,C4002,C4003 C-CERAMIC,CHIP
2203-007796 C4004,C4006,C4007 C-CERAMIC,CHIP
2203-007796 C4008,C4009,C4010 C-CERAMIC,CHIP
2203-007796 C4011,C4012,C4013 C-CERAMIC,CHIP
2203-007796 C4014,C4016,C4017 C-CERAMIC,CHIP
2203-007796 C4018,C4022,C4024 C-CERAMIC,CHIP
2203-007796 C4025,C4026,C4027 C-CERAMIC,CHIP
2203-007796 C4028,C4032,C4036 C-CERAMIC,CHIP
2203-007796 C4038,C4039,C4042 C-CERAMIC,CHIP
2203-007796 C4043,C4044,C4045 C-CERAMIC,CHIP
2203-007796 C4047,C4049,C4050 C-CERAMIC,CHIP
2203-007796 C4051,C4052,C4054 C-CERAMIC,CHIP
2203-007796 C4055,C4056,C4057 C-CERAMIC,CHIP
2203-007796 C4059,C4060,C4061 C-CERAMIC,CHIP
2203-007796 C4062,C4068,C4069 C-CERAMIC,CHIP
2203-007796 C4070,C4071,C4072 C-CERAMIC,CHIP
2203-007796 C4076,C4097,C4098 C-CERAMIC,CHIP
2203-007796 C5068,C5069,C5070 C-CERAMIC,CHIP
2203-007796 C5071,C5072,C5073 C-CERAMIC,CHIP
2203-007796 C5075,C5079,C5092 C-CERAMIC,CHIP
2203-007796 C5104,C5107,C5108 C-CERAMIC,CHIP
2203-007796 C5109,C5112,C5113 C-CERAMIC,CHIP
2203-007796 C5114,C5116,C5122 C-CERAMIC,CHIP
2203-007796 C5123,C5125,C5128 C-CERAMIC,CHIP
2203-007796 C6000,C6001,C6006 C-CERAMIC,CHIP
2203-007796 C6007,C6008,C6009 C-CERAMIC,CHIP
2203-007796 C6014,C6020,C6021 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2203-007796 C6025,C6026,C6028 C-CERAMIC,CHIP
2203-007796 C6029,C6030,C6031 C-CERAMIC,CHIP
2203-007796 C6049,C6050,C6076 C-CERAMIC,CHIP
2203-007796 C7001,C7002,C7003 C-CERAMIC,CHIP
2203-007796 C7007,C7013,C7014 C-CERAMIC,CHIP
2203-007796 C7018,C7019,C7027 C-CERAMIC,CHIP
2203-007796 C7036,C8008,C8015 C-CERAMIC,CHIP
2203-008095 C3069,C4063,C4064 C-CERAMIC,CHIP
2203-008097 C1044,C5019 C-CERAMIC,CHIP
2203-008126 C3077,C3080 C-CERAMIC,CHIP
2203-008177 C6072 C-CERAMIC,CHIP
2203-008242 C3035,C6035,C6041 C-CERAMIC,CHIP
2203-008242 C6060,C7005 C-CERAMIC,CHIP
2203-008572 C5132,C5133 C-CERAMIC,CHIP
2203-008654 C6045,C6068,L5005 C-CERAMIC,CHIP
2203-008749 C5055 C-CERAMIC,CHIP
2203-008860 C2080,C3072,C4015 C-CERAMIC,CHIP
2203-008860 C4019,C4023,C5002 C-CERAMIC,CHIP
2203-008860 C5004,C5021,C5023 C-CERAMIC,CHIP
2203-008860 C5025,C5027,C5035 C-CERAMIC,CHIP
2203-008860 C5040,C5042,C5044 C-CERAMIC,CHIP
2203-008860 C5045,C5046,C5047 C-CERAMIC,CHIP
2203-008860 C5050,C5053,C5081 C-CERAMIC,CHIP
2203-008860 C5084,C5086,C5088 C-CERAMIC,CHIP
2203-008860 C5097,C5098,C5101 C-CERAMIC,CHIP
2203-008860 C6051,C6056,C6057 C-CERAMIC,CHIP
2203-008860 C6075,C6078,C7038 C-CERAMIC,CHIP
2203-008860 C7058,C7059,C8016 C-CERAMIC,CHIP
2203-008860 C8021,C8026 C-CERAMIC,CHIP
2203-008876 C1041,C2076,C3073 C-CERAMIC,CHIP
2203-008876 C3075,C3078,C3079 C-CERAMIC,CHIP
2203-008876 C6042,C6044,C6058 C-CERAMIC,CHIP
2203-008876 C6067,C7028,C7030 C-CERAMIC,CHIP
2203-008876 C7031,C7033,C7055 C-CERAMIC,CHIP
2203-008876 C7056,C8003,C8035 C-CERAMIC,CHIP
2203-008916 C4033,C4034,C4040 C-CERAMIC,CHIP
2203-008916 C4041,C4066,C4067 C-CERAMIC,CHIP
2203-008916 C6022 C-CERAMIC,CHIP
2203-009167 C3084,C3088 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2203-009444 C8041 C-CERAMIC,CHIP
2203-009618 C5030,C5031,C5034 C-CERAMIC,CHIP
2203-009618 C5037,C7061,C8042 C-CERAMIC,CHIP
2203-009618 C8052 C-CERAMIC,CHIP
2203-009733 C1047,C2057,C3029 C-CERAMIC,CHIP
2203-009733 C5000,C5026,C5028 C-CERAMIC,CHIP
2203-009733 C5032,C5033,C5036 C-CERAMIC,CHIP
2203-009733 C5038,C5043,C5049 C-CERAMIC,CHIP
2203-009733 C5052,C5056,C5064 C-CERAMIC,CHIP
2203-009733 C5065,C5066,C5085 C-CERAMIC,CHIP
2203-009733 C5090,C5096,C5103 C-CERAMIC,CHIP
2203-009733 C7000,C7006,C7008 C-CERAMIC,CHIP
2203-009733 C7011,C7015,C7035 C-CERAMIC,CHIP
2203-009733 C7042,C7062,C7063 C-CERAMIC,CHIP
2203-009733 C7064,C7065,C7066 C-CERAMIC,CHIP
2203-009733 C7067,C7068,C7071 C-CERAMIC,CHIP
2203-009733 C7072,C7073,C7074 C-CERAMIC,CHIP
2203-009733 C7075,C7076 C-CERAMIC,CHIP
2203-009735 C4073,C4074 C-CERAMIC,CHIP
2203-009787 C5039,C5067 C-CERAMIC,CHIP
2203-009859 C7032 C-CERAMIC,CHIP
2203-010085 C4075,C5087,C5094 C-CERAMIC,CHIP
2703-002309 L8017,L8018 INDUCTOR-SMD
2703-002649 C2089,L1002,L2019 INDUCTOR-SMD
2703-002901 C1032,C3053,L1015 INDUCTOR-SMD
2703-002903 L1012,L1018,L3006 INDUCTOR-SMD
2703-002903 L3013 INDUCTOR-SMD
2703-002951 C1028,C2098,L1050 INDUCTOR-SMD
2703-002953 C3049 INDUCTOR-SMD
2703-002959 L3009,L3016,L8016 INDUCTOR-SMD
2703-002961 L8010 INDUCTOR-SMD
2703-002999 C2049 INDUCTOR-SMD
2703-004000 L1022,L1041 INDUCTOR-SMD
2703-004012 C2032,C2095,L1039 INDUCTOR-SMD
2703-004012 L2010,L2034,L2064 INDUCTOR-SMD
2703-004013 L1008,L2045,L2054 INDUCTOR-SMD
2703-004014 L1009 INDUCTOR-SMD
2703-004018 L2053,L2057 INDUCTOR-SMD
2703-004034 L1028 INDUCTOR-SMD

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission,orinfringementofanycontentordatafromthisdocumentwithoutSamsung’swritten authorizationis strictlyprohibited.
5. MAIN Electrical Parts List
2703-004036 L2002,L2009 INDUCTOR-SMD
2703-004038 L1007,L2001,L2004 INDUCTOR-SMD
2703-004038 L2021,L2024 INDUCTOR-SMD
2703-004286 C3046,C3050,L1037 INDUCTOR-SMD
2703-004286 L1058,L2028,L2029 INDUCTOR-SMD
2703-004286 L2035,L2042,L3014 INDUCTOR-SMD
2703-004286 L2051 INDUCTOR-SMD
2703-004287 C1033,C1137,L1005 INDUCTOR-SMD
2703-004287 L1042,L1043,L1045 INDUCTOR-SMD
2703-004287 L1053,L2032,L2038 INDUCTOR-SMD
2703-004287 L3007,L3008 INDUCTOR-SMD
2703-004288 C3051,L2005,L2026 INDUCTOR-SMD
2703-004288 L2049,L2061 INDUCTOR-SMD
2703-004289 L2047 INDUCTOR-SMD
2703-004295 L1036 INDUCTOR-SMD
2703-004300 L1044 INDUCTOR-SMD
2703-004302 C2085,L1040,L3015 INDUCTOR-SMD
2703-004317 C3052,L3000 INDUCTOR-SMD
2703-004328 C3000 INDUCTOR-SMD
2703-004362 L2016 INDUCTOR-SMD
2703-004703 L2007,L2014,L6001 INDUCTOR-SMD
2703-004763 L2065 INDUCTOR-SMD
2703-004853 L3010 INDUCTOR-SMD
2703-004862 L1038,L2058,L2063 INDUCTOR-SMD
2703-004862 L3002 INDUCTOR-SMD
2703-005058 L2017 INDUCTOR-SMD
2703-005066 L2025 INDUCTOR-SMD
2703-005088 L2030 INDUCTOR-SMD
2703-005295 L2013 INDUCTOR-SMD
2703-005418 L7006 INDUCTOR-SMD
2703-005419 L7007 INDUCTOR-SMD
2703-005505 L8000 INDUCTOR-SMD
2703-005555 L3017,L3018 INDUCTOR-SMD
2703-005581 L5007 INDUCTOR-SMD
2703-005660 L5000,L5002,L5003 INDUCTOR-SMD
2703-005660 L5006,L5008,L5009 INDUCTOR-SMD
2703-005660 L5010,L5011,L5016 INDUCTOR-SMD
2703-005660 L5020,L5022,L5023 INDUCTOR-SMD
2703-005731 L7009 INDUCTOR-SMD
