Samsung SM-A920F User manual

SM-A920F Common
Mobile Device CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference data
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin
of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use a soldering iron with a power rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replacement parts
may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can
be easily damaged by it. We recommend protecting these components with conductive anti-static bags
when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly
connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-1. GSM General Specification
Item GSM 850 EGSM 900 DCS1800 PCS1900
Freq. Band[MHz]
Uplink/Downlink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
ARFCN range 128~251 0~124 & 975~1023 512~885 512~810
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
Time Slot Period/
Frame Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Modulation GSM/
EGPRS
GMSK/
8PSK
GMSK/
8PSK
GMSK/
8PSK
GMSK/
8PSK
MS Power 32.8dBm~5dBm 33dBm~5dBm 29.5dBm~0dBm 29.8dBm~0dBm
Power Class 4(GMSK)
E2(8PSK)
4(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
1(GMSK)
E2(8PSK)
Sensitivity -109.5dBm -109.5dBm -108.5dBm -108dBm
TDMA Mux 8 8 8 8

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-2. GSM Tx Power Class
TX Power
control level GSM850 TX Power control level EGSM900 TX Power control level DCS1800 TX Power control level PCS1900
5 33±2 dBm 5 33±2 dBm 0 30±3 dBm 0 30±3 dBm
6 31±2 dBm 6 31±2 dBm 1 28±3 dBm 1 28±3 dBm
7 29±2 dBm 7 29±2 dBm 2 26±3 dBm 2 26±3 dBm
8 27±2 dBm 8 27±2 dBm 3 24±3 dBm 3 24±3 dBm
9 25±2 dBm 9 25±2 dBm 4 22±3 dBm 4 22±3 dBm
10 23±2 dBm 10 23±2 dBm 5 20±3 dBm 5 20±3 dBm
11 21±2 dBm 11 21±2 dBm 6 18±3 dBm 6 18±3 dBm
12 19±2 dBm 12 19±2 dBm 7 16±3 dBm 7 16±3 dBm
13 17±2 dBm 13 17±2 dBm 8 14±3 dBm 8 14±3 dBm
14 15±2 dBm 14 15±2 dBm 9 12±4 dBm 9 12±4 dBm
15 13±2 dBm 15 13±2 dBm 10 10±4 dBm 10 10±4 dBm
16 11±3 dBm 16 11±3 dBm 11 8±4 dBm 11 8±4 dBm
17 9±3 dBm 17 9±3 dBm 12 6±4 dBm 12 6±4 dBm
18 7±3 dBm 18 7±3 dBm 13 4±4 dBm 13 4±4 dBm
19 5±3 dBm 19 5±3 dBm 14 2±5 dBm 14 2±5 dBm
- - - - 15 0±5 dBm 15 0±5 dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-3. WCDMA General Specification
Item WCDMA2100(B1) WCDMA1900(B2) WCDMA1700(B4) WCDMA850(B5) WCDMA900(B8)
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1850~1910
1930~1990
1710~1755
2110~2155
824~849
869~894
880~915
925~960
ARFCN range UL：9612~9888
DL：10562~10838
UL：9262~9538
DL：9662~9938
UL：1312~1513
DL：1537~1738
UL：4132~4233
DL：4357~4458
UL：2712~2868
DL：2937~3088
Tx/Rx spacing 190MHz 80MHz 400MHz 45MHz 45MHz
Mod. Bit rate/
Bit Period
42.2Mbps(DL)
5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL) 42.2Mbps(DL) 5.42Mbps(UL)
Time Slot Period/
Frame Period
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
Modulation QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
QPSK
16QAM
64QAM
MS Power
(dBm) 23.5 ~ -49(↓) 22.5 ~ -49(↓) 22.5 ~ -49(↓) 23 ~ -49(↓) 22.5 ~ -49(↓)
Power Class 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -111.0dBm -110dBm -110dBm -111.5dBm -111.5dBm

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-4. LTE General Specification
Item LTE Band1 LTE Band2 LTE Band3 LTE Band4 LTE Band5
Freq. Band[MHz]
Uplink/Downlink
1920~1980
2110~2170
1850~1910
1930~1990
1710~1785
1805~1880
1710~1755
2110~2155
824~849
869~894
ARFCN range UL:18000~18599
DL:0~599
UL:18600~19199
DL:600~1199
UL:19200~19949
DL:1200~1949
UL:19950~20399
DL:1950~2399
UL:20400~20649
DL:2400~2649
Tx/Rx spacing
(MHz) 190 80 95 400 45
Channel Bandwidth
(MHz) 5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10/15/20 1.4/3/5/10
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power
(dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity
(QPSK, BW 10MHz)
(dBm)
-100 -98.5 -99 -99 -100
Item LTE Band7 LTE Band8 LTE Band12 LTE Band13
Freq. Band[MHz]
Uplink/Downlink
2500~2570
2620~2690
880~915
925~960
699~716
729~746
777~787
746~756
ARFCN range UL:20750~21449
DL:2750~3449
UL:21450-21799
DL:3450-3799
UL:23010~23179
DL:5010~5179
UL:23180~23179
DL:5180~5279
Tx/Rx spacing
(MHz) 120 45 30 -31
Channel Bandwidth
(MHz) 5/10/15/20 1.4/3/5/10 1.4/3/5/10 5/10
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power (dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity
(QPSK, BW 10MHz)
(dBm)
-99 -100 -99 -99

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
Item LTE Band17 LTE Band20 LTE Band26 LTE Band28
Freq. Band[MHz]
Uplink/Downlink
704~716
734~746
832~862
791~821
814~849
859~894
703~748
758~803
ARFCN range UL:23730~23849
DL:5730~5849
UL:24150~24449
DL:6150~6449
UL:26690~27039
DL:8690~9039
UL:27210~27659
DL:9210~9659
Tx/Rx spacing
(MHz) 30 -41 45 55
Channel Bandwidth
(MHz) 5/10 5/10/15/20 1.4/3/5/10/15 3/5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power
(dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity
(QPSK, BW 10MHz)
(dBm))
-99 -100 -99 -98.5
Item LTE Band38 LTE Band40 LTE Band41 LTE Band66
Freq. Band[MHz]
Uplink/Downlink 2570~2620 2300~2400 2496~2690 1710~1780
2111~2200
ARFCN range UL/DL:37750 ~ 38249 UL/DL:38650 ~ 39649 UL/DL:39650 ~ 41589 UL: 131972~132671
DL: 66436~67335
Tx/Rx spacing
(MHz) 0 0 0 400
Channel Bandwidth
(MHz) 5/10/15/20 5/10/15/20 5/10/15/20 1.4/3/5/10/15/20
Modulation QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
QPSK,16/64QAM
256QAM(DL only)
MS Power
(dBm) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓) 25.7~-39(↓)
Sensitivity
(QPSK, BW 10MHz)
(dBm)
-98 -98 -98 -98

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
3. Product Function
Main Function
Item Description
OS Android V8.0
RF
GSM850 / GSM900 / DCS1800 / PCS1900
WCDMA: B1/ B2/ B4/ B5/ B8
LTE: B1/ B2/ B3/ B4/ B5/ B7/ B8/ B12/ B13/ B17/ B20/ B26/ B28/ B38/ B40/ B41/ B66
Battery 3720mAh
Base Band 2.2Ghz Quad + 1.8GHz Quad
Other RF A-GPS, Glonass, BEIDOU, Galileo, BT5.0, USB 2.0 Type-C, WIFI 802.11 a/b/g/n/ac MIMO,NFC,
Camera QUAD Camera
(24MP F1.7+5M F2.2+10M F2.4+8MP F2.4) with LED Flash, 24MP F2.0 (Front)
LCD 6.3", Super AMOLED FHD+, 2220x1080
RAM 6GB
Sensor Accelerometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, Proximity Sensor, RGB Light
Sensor
Accessory
Charger: 5V/2A (AFC: 9V/1.67A)
Data cable: 3.2pi, 0.8m(Type C/ USB-A)
Ear phone: 3.5pi, 4pin

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1. Cellular phone Exploded View
QRE01
QKP01
QCR205
QFR01
QMO01
QME04
QAR01
QCA01
QMP01
QCR12
QCA02
QCB02
QCK02
QSM01
QVO02
QBC01
QSP01
QVO01
QCK01
QCR12
QME05
QCR12
QME01
QCB01
QME02
QBA01
QME03
※SVC REPAIR TAPE
QRT01, QRT02

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
Parts Code Design LOC Description
0401-001110 D8000 DIODE-SWITCHING
0404-001250 D5000,D6001 DIODE-SCHOTTKY
0406-001561 ZD6004,ZD6006,ZD6007 DIODE-TVS
0406-001561 ZD8002,ZD8004 DIODE-TVS
0406-001592 ZD3002,ZD3003,ZD3004 DIODE-TVS
0406-001592 ZD3005,ZD3006,ZD3007 DIODE-TVS
0406-001592 ZD3009,ZD3012 DIODE-TVS
0406-001728 ZD5000 DIODE-TVS
0406-001743 C3053,ZD6020 DIODE-TVS
0406-001763 D6007 DIODE-TVS
0406-001776 ZD6000,ZD6001,ZD6018 DIODE-TVS
0406-001776 ZD6019,ZD6021 DIODE-TVS
0406-001787 D6003,D6004 DIODE-TVS
0406-001789 ZD6005 DIODE-TVS
0406-001797 ZD6028,ZD6029 DIODE-TVS
0406-001808 D6000 DIODE-TVS
0406-001829 ZD4000 DIODE-TVS
0505-002088 TR5001,TR5002 FET-SILICON
0505-003234 TR5000 FET-SILICON
0601-003629 LED5000 LED
1001-001835 U3003,U3004 IC
1001-001844 U1009 IC
1001-001911 U2027 IC
1001-001968 U8003 IC
1001-001970 U1005,U2004 IC
1001-001974 U1001 IC
1001-001975 U2025 IC
1001-001994 U2000 IC
1003-002911 U5006 IC
1108-000660 UME6000 IC
1201-003869 U3009 IC
1201-003976 U1000,U1006 IC
1201-003984 U2032,U2033 IC
1201-004109 PAM2000 IC
1201-004135 U1004 IC
1201-004156 U8014 IC
1203-008249 U3000 IC
1203-008251 U5004 IC

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
1203-008379 U2003 IC
1203-008603 U3017 IC
1203-008704 U7003 IC
1203-008797 U6002 IC
1203-008819 U5002 IC
1203-008859 U7011,U7015 IC
1203-008865 U7004,U7008,U7009 IC
1203-008865 U7013,U7014 IC
1203-008867 U8008 IC
1203-008955 U7006 IC
1203-008998 U6000 IC
1203-009012 U5003 IC
1203-009014 U5005 IC
1203-009158 U7000,U7001 IC
1203-009169 U8000 IC
1204-003685 U8010 IC
1205-005106 U6001 IC
1205-005217 U7002,U7073 IC
1205-005821 U3002 IC
1205-005830 UCP4000 IC
1205-005833 U2029 IC
1205-005979 U3021 IC
1205-006037 U4000 IC
1209-002450 U3010 IC
1209-002513 U3020 IC
1404-001724 TH2000,TH4000,TH5000 THERMISTOR
1404-001724 THM3000 THERMISTOR
1405-001395 VR2001 VARISTOR
1405-001398 VR3001,VR3002 VARISTOR
1405-001403 V2000 VARISTOR
1405-001412 VR1007 VARISTOR
1405-001415 VR2000 VARISTOR
1405-001428 VR6010,VR6015 VARISTOR
1405-001434 VR2002 VARISTOR
1405-001458 V3000 VARISTOR
2007-003015 R6014,R6016 R-CHIP
2007-007014 R3010 R-CHIP
2007-007142 R6060,R7003,R7016 R-CHIP
2007-007190 R6005,R6006 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-007308 R5029 R-CHIP
2007-007741 R3000,R3002,R4032 R-CHIP
2007-007741 R4034,R4042,R4046 R-CHIP
2007-007741 R5040,R5047,R5054 R-CHIP
2007-007741 R6015,R6023,R6026 R-CHIP
2007-007741 R6051 R-CHIP
2007-008056 R1008,R1009 R-CHIP
2007-008211 R7012 R-CHIP
2007-008263 R4007 R-CHIP
2007-008298 R3006 R-CHIP
2007-008403 R8011 R-CHIP
2007-008420 R3011,R7002 R-CHIP
2007-008516 R6013 R-CHIP
2007-008531 R5005,R7001,R7008 R-CHIP
2007-008531 R7011,R7015,R8003 R-CHIP
2007-008588 C3084,C3085,R4001 R-CHIP
2007-008588 R4002,R4003,R4008 R-CHIP
2007-008588 R4009,R4010,R4011 R-CHIP
2007-008588 R4013,R4014,R4015 R-CHIP
2007-008588 R4016,R4017,R4021 R-CHIP
2007-008588 R4022,R4023,R4024 R-CHIP
2007-008588 R4025,R4026,R4028 R-CHIP
2007-008588 R4029,R4030,R4031 R-CHIP
2007-008766 R4005,R4006 R-CHIP
2007-008785 R1007 R-CHIP
2007-008800 R6025 R-CHIP
2007-009111 R3001 R-CHIP
2007-009155 R5009,R5020,R8006 R-CHIP
2007-009157 R5019,R5022,R5026 R-CHIP
2007-009157 R5038,R6019,R8007 R-CHIP
2007-009158 R5003 R-CHIP
2007-009201 R4019,R4020,R8021 R-CHIP
2007-009201 R8022 R-CHIP
2007-009212 R4045,R4047,R5014 R-CHIP
2007-009212 R8000 R-CHIP
2007-009223 R6037 R-CHIP
2007-009315 R5011,R6002,R6056 R-CHIP
2007-009315 R6057,R6058,R6059 R-CHIP
2007-009315 R6061,R6062,R6063 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-009315 R6064,R6065,R6066 R-CHIP
2007-009352 R4033,R7006 R-CHIP
2007-009408 R4037,R4038,R5036 R-CHIP
2007-009408 R5037,R6032 R-CHIP
2007-009766 R6001,R6007,R7000 R-CHIP
2007-009766 R7014,R8002 R-CHIP
2007-009793 R6018 R-CHIP
2007-009801 R4049,R8023,R8024 R-CHIP
2007-009805 R1000,R1001,R1002 R-CHIP
2007-009805 R1003,R1004,R2001 R-CHIP
2007-009866 R5016,R7013,R7017 R-CHIP
2007-009920 R4050,R5043,R5044 R-CHIP
2007-009920 R6009,R6010 R-CHIP
2007-009954 R5027,R5028,R5030 R-CHIP
2007-009954 R6011 R-CHIP
2007-009969 R3024,R3025,R4018 R-CHIP
2007-009969 R8001 R-CHIP
2007-010202 R5041 R-CHIP
2007-010233 R4048 R-CHIP
2007-010685 R6000 R-CHIP
2007-011043 R4027 R-CHIP
2007-011648 R6047,R6048 R-CHIP
2007-012068 R5049 R-CHIP
2203-000254 C5068,C5074 C-CERAMIC,CHIP
2203-000278 C3007 C-CERAMIC,CHIP
2203-001072 C3102 C-CERAMIC,CHIP
2203-001239 C3062,C3063 C-CERAMIC,CHIP
2203-005344 C5014 C-CERAMIC,CHIP
2203-005682 C1023,C2030,C2031 C-CERAMIC,CHIP
2203-005682 C2045,C2046,C2051 C-CERAMIC,CHIP
2203-005682 C2121,C2127,C2128 C-CERAMIC,CHIP
2203-005682 C3017,C6063,C6064 C-CERAMIC,CHIP
2203-005682 C6069,C7138,C7148 C-CERAMIC,CHIP
2203-005682 L1001,L1020,L1029 C-CERAMIC,CHIP
2203-005682 L1040,L1046,L1049 C-CERAMIC,CHIP
2203-005682 L2079 C-CERAMIC,CHIP
2203-005717 C1007,C1027,C1030 C-CERAMIC,CHIP
2203-005717 C1050,C1121,C1122 C-CERAMIC,CHIP
2203-005717 C2003,C2011,C2023 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-005717 C2029,C2043,C2055 C-CERAMIC,CHIP
2203-005717 C2076,C2077,C2096 C-CERAMIC,CHIP
2203-005717 U8066 C-CERAMIC,CHIP
2203-005719 C1118,C2085,C2086 C-CERAMIC,CHIP
2203-005719 C3037,C3914,C4011 C-CERAMIC,CHIP
2203-005725 C3079,C7079 C-CERAMIC,CHIP
2203-005726 C8039 C-CERAMIC,CHIP
2203-005729 C7073,C8000,C8009 C-CERAMIC,CHIP
2203-005729 C8017 C-CERAMIC,CHIP
2203-005731 C3040,C3041,C3058 C-CERAMIC,CHIP
2203-005731 C3059,C6041,C6044 C-CERAMIC,CHIP
2203-005732 C2092,C8002 C-CERAMIC,CHIP
2203-005734 C6042,C6043 C-CERAMIC,CHIP
2203-005736 C1014,C1016,C1032 C-CERAMIC,CHIP
2203-005736 C1033,C1036,C1037 C-CERAMIC,CHIP
2203-005736 C1046,C1095,C1096 C-CERAMIC,CHIP
2203-005736 C1104,C1125,C1128 C-CERAMIC,CHIP
2203-005736 C1129,C2006,C2007 C-CERAMIC,CHIP
2203-005736 C2012,C2015,C2016 C-CERAMIC,CHIP
2203-005736 C2017,C2021,C2040 C-CERAMIC,CHIP
2203-005736 C2053,C2059,C2060 C-CERAMIC,CHIP
2203-005736 C2078,C2080,C3009 C-CERAMIC,CHIP
2203-005736 C3029,C3031,C3036 C-CERAMIC,CHIP
2203-005736 C3039,C3046,C3049 C-CERAMIC,CHIP
2203-005736 C3051,C5123,C5124 C-CERAMIC,CHIP
2203-005736 L1004,L1048,L1062 C-CERAMIC,CHIP
2203-005736 L1070,L2001,L2004 C-CERAMIC,CHIP
2203-005736 L2005,L2012,L2019 C-CERAMIC,CHIP
2203-005736 L2020,L2023,L2027 C-CERAMIC,CHIP
2203-005736 L2048,L2057,L2058 C-CERAMIC,CHIP
2203-005736 L3016,L3025 C-CERAMIC,CHIP
2203-005777 C1006,C1080,C1086 C-CERAMIC,CHIP
2203-005777 C1090,C1092,C1126 C-CERAMIC,CHIP
2203-005777 C1127,C2036,C2038 C-CERAMIC,CHIP
2203-005777 C2082,C2088,C2095 C-CERAMIC,CHIP
2203-005789 C1031,C2025,C2093 C-CERAMIC,CHIP
2203-005789 C2094,L2061,L2062 C-CERAMIC,CHIP
2203-005792 C1013,C1078,C1094 C-CERAMIC,CHIP
2203-005792 C1101,C1106 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-005806 C2044,C2074,C2081 C-CERAMIC,CHIP
2203-005806 C5017 C-CERAMIC,CHIP
2203-006120 C8134,C8135 C-CERAMIC,CHIP
2203-006121 C6045 C-CERAMIC,CHIP
2203-006123 C1114,C3006 C-CERAMIC,CHIP
2203-006187 C2028,C2033 C-CERAMIC,CHIP
2203-006194 C3028,C3030,C3033 C-CERAMIC,CHIP
2203-006194 C3070,C3071,C3072 C-CERAMIC,CHIP
2203-006194 C3073,C3074,C3075 C-CERAMIC,CHIP
2203-006194 C3076,C3077,C3078 C-CERAMIC,CHIP
2203-006194 C6052 C-CERAMIC,CHIP
2203-006305 C1020,C1077,C3012 C-CERAMIC,CHIP
2203-006305 C7011,C7019,L1035 C-CERAMIC,CHIP
2203-006318 C1089,L1064 C-CERAMIC,CHIP
2203-006400 C2052,C3101,C3103 C-CERAMIC,CHIP
2203-006400 C5054,C6031,C8004 C-CERAMIC,CHIP
2203-006400 C8133 C-CERAMIC,CHIP
2203-006410 C1047,C1093 C-CERAMIC,CHIP
2203-006423 C4082,C6071,C8015 C-CERAMIC,CHIP
2203-006462 C8026,C8027 C-CERAMIC,CHIP
2203-006556 C1065,C1071,C1074 C-CERAMIC,CHIP
2203-006556 C2070 C-CERAMIC,CHIP
2203-006611 C3008,C3010,C6053 C-CERAMIC,CHIP
2203-006648 C4077 C-CERAMIC,CHIP
2203-006707 C3018,L2043 C-CERAMIC,CHIP
2203-006839 C3106,C3109,C4083 C-CERAMIC,CHIP
2203-006839 C5011,C5019,C5037 C-CERAMIC,CHIP
2203-006839 C5071,C5084,C5087 C-CERAMIC,CHIP
2203-006839 C5120,C6067 C-CERAMIC,CHIP
2203-006846 C6008,C6033,C6046 C-CERAMIC,CHIP
2203-006846 C6047,C6058,C6059 C-CERAMIC,CHIP
2203-006846 L1066 C-CERAMIC,CHIP
2203-006872 C3026,C3065,C3107 C-CERAMIC,CHIP
2203-006872 C5076,C5078,C5079 C-CERAMIC,CHIP
2203-006872 C5080,C7004,C7076 C-CERAMIC,CHIP
2203-006979 C2050 C-CERAMIC,CHIP
2203-007143 C5059 C-CERAMIC,CHIP
2203-007194 C3015 C-CERAMIC,CHIP
2203-007210 C3027,C4004,C4006 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007210 C4028,C4029,C4037 C-CERAMIC,CHIP
2203-007210 C4038 C-CERAMIC,CHIP
2203-007317 C2099,C2102,C2111 C-CERAMIC,CHIP
2203-007317 C2115,C2120,C2123 C-CERAMIC,CHIP
2203-007317 C3021,C3034,C3069 C-CERAMIC,CHIP
2203-007317 C3908,C5035,C5038 C-CERAMIC,CHIP
2203-007317 C5069,C5075,C5077 C-CERAMIC,CHIP
2203-007317 C5081,C6014,C6068 C-CERAMIC,CHIP
2203-007317 C7013,C7075,C7077 C-CERAMIC,CHIP
2203-007317 C8024 C-CERAMIC,CHIP
2203-007391 C3024,C3025,C3035 C-CERAMIC,CHIP
2203-007391 C3087,C3088,C3108 C-CERAMIC,CHIP
2203-007391 C6072,C6075 C-CERAMIC,CHIP
2203-007393 C2124,C5043,C5052 C-CERAMIC,CHIP
2203-007393 C5122,C6040,C6065 C-CERAMIC,CHIP
2203-007425 C5095 C-CERAMIC,CHIP
2203-007449 C7024 C-CERAMIC,CHIP
2203-007474 C3023,C7018 C-CERAMIC,CHIP
2203-007486 C6036 C-CERAMIC,CHIP
2203-007544 C3019,C3910,C3911 C-CERAMIC,CHIP
2203-007781 C6039,C8012 C-CERAMIC,CHIP
2203-007796 C3001,C3105,C4000 C-CERAMIC,CHIP
2203-007796 C4001,C4002,C4007 C-CERAMIC,CHIP
2203-007796 C4008,C4009,C4010 C-CERAMIC,CHIP
2203-007796 C4012,C4013,C4016 C-CERAMIC,CHIP
2203-007796 C4017,C4039,C4040 C-CERAMIC,CHIP
2203-007796 C4041,C4042,C4043 C-CERAMIC,CHIP
2203-007796 C4044,C4046,C4047 C-CERAMIC,CHIP
2203-007796 C4055,C4068,C4069 C-CERAMIC,CHIP
2203-007796 C4070,C4071,C4072 C-CERAMIC,CHIP
2203-007796 C4073,C4074,C4075 C-CERAMIC,CHIP
2203-007796 C4076,C4078,C4079 C-CERAMIC,CHIP
2203-007796 C4080,C4081,C4084 C-CERAMIC,CHIP
2203-007796 C4086,C4087,C4088 C-CERAMIC,CHIP
2203-007796 C4089,C4091,C4092 C-CERAMIC,CHIP
2203-007796 C4093,C4094,C4096 C-CERAMIC,CHIP
2203-007796 C4097,C4099,C4100 C-CERAMIC,CHIP
2203-007796 C5010,C5012,C5031 C-CERAMIC,CHIP
2203-007796 C5044,C5048,C5050 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007796 C5060,C5061,C5062 C-CERAMIC,CHIP
2203-007796 C5065,C5066,C5067 C-CERAMIC,CHIP
2203-007796 C5083,C5085,C5086 C-CERAMIC,CHIP
2203-007796 C5088,C5089,C5090 C-CERAMIC,CHIP
2203-007796 C5091,C5092,C6004 C-CERAMIC,CHIP
2203-007796 C6005,C6006,C6007 C-CERAMIC,CHIP
2203-007796 C6012,C6013,C6015 C-CERAMIC,CHIP
2203-007796 C6018,C6019,C6021 C-CERAMIC,CHIP
2203-007796 C6022,C6023,C6024 C-CERAMIC,CHIP
2203-007796 C6025,C6026,C6027 C-CERAMIC,CHIP
2203-007796 C6028,C6029,C6049 C-CERAMIC,CHIP
2203-007796 C6050,C6051,C7000 C-CERAMIC,CHIP
2203-007796 C7002,C7005,C7006 C-CERAMIC,CHIP
2203-007796 C7017,C7021,C7022 C-CERAMIC,CHIP
2203-007796 C7023,C7030,C7031 C-CERAMIC,CHIP
2203-007796 C7032,C7033,C7034 C-CERAMIC,CHIP
2203-007796 C7036,C7044,C7045 C-CERAMIC,CHIP
2203-007796 C7053,C7055,C7056 C-CERAMIC,CHIP
2203-007796 C7057,C7059,C7063 C-CERAMIC,CHIP
2203-007796 C7064,C7078,C7083 C-CERAMIC,CHIP
2203-007796 C7092,C8005,C8019 C-CERAMIC,CHIP
2203-007796 C8020,C8028,C8030 C-CERAMIC,CHIP
2203-007796 C8034,C8038 C-CERAMIC,CHIP
2203-008097 C1000,C1003,C1004 C-CERAMIC,CHIP
2203-008097 C1044,C1066,C1072 C-CERAMIC,CHIP
2203-008097 C1073,C1075,C1113 C-CERAMIC,CHIP
2203-008097 C1117,C1131,C2002 C-CERAMIC,CHIP
2203-008097 C2005,C2020,C2100 C-CERAMIC,CHIP
2203-008097 C2101,C2103,C2104 C-CERAMIC,CHIP
2203-008097 C2105,C2106,C2107 C-CERAMIC,CHIP
2203-008097 C2108,C2109,C2110 C-CERAMIC,CHIP
2203-008097 C2112,C2113,C2114 C-CERAMIC,CHIP
2203-008097 C2116,C2117,C2118 C-CERAMIC,CHIP
2203-008097 C2119,C3052,C4048 C-CERAMIC,CHIP
2203-008097 C4049,C4090,C5049 C-CERAMIC,CHIP
2203-008097 C6000,C6001,C6002 C-CERAMIC,CHIP
2203-008097 C6003,C8010,C8013 C-CERAMIC,CHIP
2203-008097 C8021,C8025,R8012 C-CERAMIC,CHIP
2203-008242 C3092,C4050,C4051 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-008242 C4052,C4053,C5039 C-CERAMIC,CHIP
2203-008242 C6016,C6017 C-CERAMIC,CHIP
2203-008529 C3016,C3081,C6066 C-CERAMIC,CHIP
2203-008529 C7012 C-CERAMIC,CHIP
2203-008749 C6035 C-CERAMIC,CHIP
2203-008860 C2072,C3000,C3086 C-CERAMIC,CHIP
2203-008860 C5022,C5025,C5064 C-CERAMIC,CHIP
2203-008860 C7020,C7025,C7029 C-CERAMIC,CHIP
2203-008860 C7035,C7039,C7042 C-CERAMIC,CHIP
2203-008860 C7043,C7080,C7082 C-CERAMIC,CHIP
2203-008860 C7086,C8007 C-CERAMIC,CHIP
2203-008876 C1067,C2073,C3066 C-CERAMIC,CHIP
2203-008876 C3067,C3091,C5000 C-CERAMIC,CHIP
2203-008876 C5007,C5009,C5013 C-CERAMIC,CHIP
2203-008876 C5020,C5021,C5041 C-CERAMIC,CHIP
2203-008876 C5042,C5045,C5046 C-CERAMIC,CHIP
2203-008876 C5047,C5051,C5053 C-CERAMIC,CHIP
2203-008876 C5056,C5058,C6010 C-CERAMIC,CHIP
2203-008876 C6011,C7015,C7016 C-CERAMIC,CHIP
2203-008876 C7038,C7040,C7081 C-CERAMIC,CHIP
2203-008876 C7084 C-CERAMIC,CHIP
2203-009064 C4005,C4018,C4019 C-CERAMIC,CHIP
2203-009064 C4020,C4030,C4031 C-CERAMIC,CHIP
2203-009167 C3100,C3104 C-CERAMIC,CHIP
2203-009328 C3032 C-CERAMIC,CHIP
2203-009444 C5018 C-CERAMIC,CHIP
2203-009618 C5028,C5029,C7007 C-CERAMIC,CHIP
2203-009618 C7008,C7027 C-CERAMIC,CHIP
2203-009733 C1076,C2049,C3020 C-CERAMIC,CHIP
2203-009733 C3022,C3907,C5001 C-CERAMIC,CHIP
2203-009733 C5002,C5003,C5004 C-CERAMIC,CHIP
2203-009733 C5005,C5030,C5094 C-CERAMIC,CHIP
2203-009733 C5100,C5101,C5102 C-CERAMIC,CHIP
2203-009733 C5103,C5104,C5105 C-CERAMIC,CHIP
2203-009733 C5106,C5107,C7001 C-CERAMIC,CHIP
2203-009733 C7003,C7058,C7074 C-CERAMIC,CHIP
2203-009733 C7134 C-CERAMIC,CHIP
2203-009734 C5055 C-CERAMIC,CHIP
2203-009735 C4057,C4058 C-CERAMIC,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-009738 C4003,C4999,C5008 C-CERAMIC,CHIP
2203-009738 C5057,C6020 C-CERAMIC,CHIP
2203-009858 C5015,C5016,C5023 C-CERAMIC,CHIP
2203-009858 C5073,C5108,C5109 C-CERAMIC,CHIP
2203-009858 C7026,C8003,C8006 C-CERAMIC,CHIP
2203-009859 C7009,C7010 C-CERAMIC,CHIP
2203-009969 C5096,C5097,C8011 C-CERAMIC,CHIP
2203-010085 C6009,C6057 C-CERAMIC,CHIP
2703-002649 C2024,C2122,L2065 INDUCTOR-SMD
2703-002900 L1005 INDUCTOR-SMD
2703-002901 C1024,C6060,L1021 INDUCTOR-SMD
2703-002901 L1071,L6001,L6005 INDUCTOR-SMD
2703-002901 L6006,L6008,L6009 INDUCTOR-SMD
2703-002903 L2010,L2071 INDUCTOR-SMD
2703-002953 L1033,L6000 INDUCTOR-SMD
2703-002955 L2016,L3022 INDUCTOR-SMD
2703-002958 C1034,L3004 INDUCTOR-SMD
2703-002959 L3916 INDUCTOR-SMD
2703-003970 C1035 INDUCTOR-SMD
2703-004000 C1098,L3020 INDUCTOR-SMD
2703-004001 L2014 INDUCTOR-SMD
2703-004012 C1018,L1008,L1059 INDUCTOR-SMD
2703-004012 L2036,L2050,L2055 INDUCTOR-SMD
2703-004012 L2076,L2081,L3013 INDUCTOR-SMD
2703-004012 L8018 INDUCTOR-SMD
2703-004013 L1009,L1023 INDUCTOR-SMD
2703-004014 L1006,L1024,L1074 INDUCTOR-SMD
2703-004014 L3008 INDUCTOR-SMD
2703-004018 C1029,L1002,L1031 INDUCTOR-SMD
2703-004018 L1057 INDUCTOR-SMD
2703-004032 C1005 INDUCTOR-SMD
2703-004034 C1040,C1115,L2009 INDUCTOR-SMD
2703-004034 L2067,L3014,L3017 INDUCTOR-SMD
2703-004034 L3023 INDUCTOR-SMD
2703-004035 C1010 INDUCTOR-SMD
2703-004036 L1063,L2003,L2008 INDUCTOR-SMD
2703-004038 L1028,L1038,L2002 INDUCTOR-SMD
2703-004038 L2006,L2021,L2022 INDUCTOR-SMD
2703-004038 L2051,L2066,L2068 INDUCTOR-SMD
