Samsung SM-G615F/DS User manual

www.samsung.com
User Manual
English. 05/2017. Rev.1.0
SM-G615F/DS
SM-G615FU/DS

2
Table of Contents
Basics
4 Read me first
6 Device overheating situations and
solutions
9 Package contents
10 Device layout
14 Battery
18 SIM or USIM card (nano-SIM card)
24 Memory card (microSD card)
27 Turning the device on and off
28 Understanding the screen
37 Notification panel
39 Entering text
41 Screen capture
42 Opening apps
42 Multi window
47 Samsung account
48 Transferring data from your previous
device
51 Device and data management
54 Sharing features
55 Emergency mode
Applications
56 Installing or uninstalling apps
58 Phone
62 Contacts
67 Messages
70 Internet
72 Email
73 Camera
87 Gallery
91 Samsung Pay Mini
92 Samsung Members
93 Samsung Notes
94 Game Launcher
97 Calendar
98 S Health
101 Voice Recorder
102 My Files
102 Clock
104 Calculator
104 Radio
106 USB Backup
107 S Secure
108 Secure Folder
113 Smart Glow
115 Google apps

Table of Contents
3
Settings
117 Introduction
117 Connections
126 Sounds and vibration
127 Notifications
127 Display
129 Wallpapers and themes
129 Advanced features
131 Device maintenance
135 Apps
135 Lock screen and security
142 Cloud and accounts
144 Google
144 Accessibility
145 General management
145 Software update
146 User manual
146 About phone
Appendix
147 Troubleshooting

4
Basics
Read me first
Please read this manual before using the device to ensure safe and proper use.
r
Descriptions are based on the device’s default settings.
r
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
r
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
r
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
r
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
r
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
r
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.

Basics
5
r
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
r
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
r
Depending on the region or model, some devices are required to receive approval from
the Federal Communications Commission (FCC). If your device is approved by the FCC,
you can view the FCC ID of the device. To view the FCC ID, launch the
Settings app and
tap
About phone

Battery information .
r
Depending on the region, you can view the regulatory information on the device. To view
the information, launch the
Settings app and tap About phone

Legal information .
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information

Basics
6
Device overheating situations and solutions
When the device heats up while charging the battery
While charging, the device and the charger may become hot. During wireless charging or fast
charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or
performance and is in the device’s normal range of operation. If the battery becomes too hot,
the charger may stop charging.
Do the following when the device heats up:
r
Disconnect the charger from the device and close any running apps. Wait for the
device to cool down and then begin charging the device again.
r
If the lower part of the device overheats, it could be because the connected USB
cable is damaged. Replace the damaged USB cable with a new Samsung-approved
one.
r
When using a wireless charger, do not place foreign materials, such as metal objects,
magnets, and magnetic stripe cards, between the device and the wireless charger.
The wireless charging or fast charging feature is only available on supported models.

Basics
7
When the device heats up during use
When you use features or apps that require more power or use them for extended periods,
your device may temporarily heat up due to increased battery consumption. Close any
running apps and do not use the device for a while.
The following are examples of situations in which the device may overheat. Depending on
the functions and apps you use, these examples may not apply to your model.
r
During the initial setup after purchase or when restoring data
r
When downloading large files
r
When using apps that require more power or using apps for extended periods
–
When playing high-quality games for extended periods
–
When recording videos for extended periods
–
When streaming videos while using the maximum brightness setting
–
When connecting to a TV
r
While multitasking (or, when running many apps in the background)
–
When using Multi window
–
When updating or installing apps while recording videos
–
When downloading large files during a video call
–
When recording videos while using a navigation app
r
When using large amount of data for syncing with the cloud, email, or other accounts
r
When using a navigation app in a car while the device is placed in direct sunlight
r
When using the mobile hotspot and tethering feature
r
When using the device in areas with weak signals or no reception
r
When charging the battery with a damaged USB cable
r
When the device’s multipurpose jack is damaged or exposed to foreign materials, such as
liquid, dust, metal powder, and pencil lead
r
When you are roaming

Basics
8
Do the following when the device heats up:
r
Keep the device updated with the latest software.
r
Conflicts between running apps may cause the device to heat up. Restart the device.
r
Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.
r
Close apps that increase battery consumption or that run in the background when
not in use.
r
Delete unnecessary files or unused apps.
r
Decrease the screen brightness.
r
If the device overheats or feels hot for a prolonged period, do not use it for a while. If
the device continues to overheat, contact a Samsung Service Centre.
Device limitations when the device overheats
When the device heats up, the features and performance may be limited or the device may
turn off to cool down. The feature is only available on supported models.
r
If the device becomes hotter than usual, a device overheating message will appear. To
lower the device’s temperature, the screen brightness and the performance speed will be
limited and battery charging will stop. Running apps will be closed and you will only be
able to make emergency calls until the device cools down.
r
If the device overheats or feels hot for a prolonged period, a power off message will
appear. Turn off the device, and wait until it cools down.

Basics
9
Precautions for operating environment
Your device may heat up due to the environment in the following conditions. Use caution to
avoid shortening the battery’s lifespan, damaging the device, or causing a fire.
r
Do not store your device in very cold or very hot temperatures.
r
Do not expose your device to direct sunlight for extended periods.
r
Do not use or store your device for extended periods in very hot areas, such as inside a
car in the summertime.
r
Do not place the device in any areas that may overheat, such as on an electric heating
mat.
r
Do not store your device near or in heaters, microwaves, hot cooking equipment, or high
pressure containers.
r
Never use a damaged charger or battery.
Package contents
Check the product box for the following items:
r
Device
r
Quick start guide
r
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
r
The supplied items are designed only for this device and may not be compatible
with other devices.
r
Appearances and specifications are subject to change without prior notice.
r
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
r
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
r
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

Basics
10
Device layout

SM-G615F/DS:
Microphone
Headset jack
Back key
Multipurpose jack
Proximity sensor
Flash
Speaker
Power key
Touchscreen
Recents key
Home key (Fingerprint
recognition sensor)
Front camera
Speaker

Basics
11
Main antenna
Volume key
Rear camera
Flash
Smart glow
GPS antenna
SIM card tray
SIM card / Memory card
tray

SM-G615FU/DS:
Microphone
Headset jack
Back key
Multipurpose jack
Proximity sensor
Flash
Speaker
Power key
Touchscreen
Recents key
Home key (Fingerprint
recognition sensor)
Front camera
Speaker

Basics
12
Main antenna
Volume key
Rear camera
Flash
SIM card tray
SIM card / Memory card
tray
GPS antenna
r
Connectivity problems and battery drain may occur in the following situations:
–
If you attach metallic stickers on the antenna area of the device
–
If you attach a device cover made with metallic material to the device
–
If you cover the device’s antenna area with your hands or other objects while
using certain features, such as calls or the mobile data connection
r
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
r
Do not cover the proximity sensor area with screen accessories, such as a screen
protector or stickers. Doing so may cause the sensor to malfunction.
r
Do not allow water to contact the touchscreen. The touchscreen may malfunction
in humid conditions or when exposed to water.

Basics
13
Keys
Key Function
Power
r
Press and hold to turn the device on or off.
r
Press to turn on or lock the screen.
Recents
r
Tap to open the list of recent apps.
Home
r
Press to turn on the screen while the screen is locked.
r
Press to return to the Home screen.
r
Press and hold to launch Google .
Back
r
Tap to return to the previous screen.
r
Tap and hold to access additional options for the current
screen.
Volume
r
Press to adjust the device volume.

Basics
14
Battery
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
1 Connect the USB cable to the USB power adaptor, and plug the USB cable into the
device’s multipurpose jack.
2 Plug the USB power adaptor into an electric socket.
3 After fully charging, disconnect the device from the charger. First unplug the charger
from the device, and then unplug it from the electric socket.

Basics
15
Viewing the estimated charging time
While charging, launch the Settings app and tap Device maintenance

Battery .
The actual charging time may vary depending on the status of your device and the
charging conditions. The estimated charging time may not be displayed when you
charge the device in very cold or very hot conditions.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
r
Optimise the device using the device maintenance feature.
r
When you are not using the device, turn off the screen by pressing the Power key.
r
Activate power saving mode.
r
Close unnecessary apps.
r
Deactivate the Bluetooth feature when not in use.
r
Deactivate the Wi-Fi feature when not in use.
r
Deactivate auto-syncing of apps that need to be synced, such as emails.
r
Decrease the backlight time.
r
Decrease the screen brightness.
Battery charging tips and precautions
r
When the battery power is low, the battery icon appears empty.
r
If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
r
If you use multiple apps at once, network apps, or apps that need a connection to
another device, the battery will drain quickly. To avoid losing power during a data
transfer, always use these apps after fully charging the battery.
r
Using a power source other than the charger, such as a computer, may result in a slower
charging speed due to a lower electric current.

Basics
16
r
The device can be used while it is charging, but it may take longer to fully charge the
battery.
r
If the device receives an unstable power supply while charging, the touchscreen may not
function. If this happens, unplug the charger from the device.
r
While charging, the device and the charger may heat up. This is normal and should not
affect the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging.
r
If you charge the device while the multipurpose jack is wet, the device may be damaged.
Thoroughly dry the multipurpose jack before charging the device.
r
If the device is not charging properly, take the device and the charger to a Samsung
Service Centre.
Power saving mode
Activate power saving mode to extend the battery’s usage time.
1 Launch the
Settings app and tap Device maintenance

Battery

MID .
2 Tap
CUSTOMISE to change the power saving settings before entering power saving
mode.
3 Tap
APPLY .
Maximum power saving mode
In maximum power saving mode, the device decreases battery consumption by applying the
dark theme and limiting the apps and features available. Network connections, except for the
mobile network, will be deactivated.
1 Launch the
Settings app and tap Device maintenance

Battery

MAX .
2 Tap
CUSTOMISE to change the power saving settings before entering maximum power
saving mode.

Basics
17
3 Tap
APPLY .
After entering maximum power saving mode, on the Home screen, tap and select an app
to use. To remove apps, tap

Edit and select an app with .
To deactivate maximum power saving mode, tap

Turn off Maximum power saving
mode
.
The estimated battery usage time may vary depending on your device settings and
operating conditions.
Planning battery consumption
Manage your battery consumption by setting how the device will utilise your device’s
remaining battery power.
The following features may not be available depending on the region or service
provider.
Reserve battery mode
Save the battery power by reserving it for calls and messages. In reserve battery mode, you
can use only the
Phone and Messages apps.
To use reserve battery power mode, Launch the
Settings app and tap Device maintenance

Battery

Reserve battery for calls , and then tap the switch to activate it. Then, drag the
bar to set the amount of battery power reserved for calls and messages. When your battery
power reaches the preset level, the device will alert you and activate reserve battery mode.
To deactivate reserve battery mode, tap the switch.
Extending the battery life
Extend the battery life by automatically activating ultra power saving mode when the battery
reaches a certain percentage.
Launch the
Settings app and tap Device maintenance

Battery

Extend battery time ,
tap the switch to activate it, and then select a level.

Basics
18
Forwarding calls
Set the device to forward incoming calls to a preset phone number when the device turns off
due to low battery power.
Launch the
Settings app and tap Device maintenance

Battery

Fwd calls when no
battery
, and then tap the switch to activate it. Tap ENTER NUMBER or CONTACTS and add a
phone number or contact. To send a message to notify the contact or number that your calls
will be forwarded to them, tap the
Auto send text message switch to activate it.
r
Make sure that your service provider supports call forwarding.
r
You may incur additional charges when using this feature.
SIM or USIM card (nano-SIM card)
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
Use caution not to lose or let others use the SIM or USIM card. Samsung is not
responsible for any damages or inconveniences caused by lost or stolen cards.
r
In some areas, data transfer speeds may be slower if two SIM cards are inserted in
the device than when one SIM card is inserted.
r
Some LTE services may not be available depending on the service provider. For
more information about service availability, contact your service provider.

Basics
19

SIM card tray 1:
1 3 42

Basics
20

SIM card tray 2:
1 3 42
1 Insert the ejection pin into the hole on the tray to loosen the tray.
Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may
be damaged.
2 Pull out the tray gently from the tray slot.
3 Place the SIM or USIM card on the tray with the gold-coloured contacts facing
downwards.
Place the primary SIM or USIM card on the tray 1 and the secondary SIM or USIM card on
the tray 2.
4 Gently press the SIM or USIM card into the tray to secure it.
If the card is not fixed firmly into the tray, the SIM card may leave or fall out of the tray.
