Samsung SM-N930F User manual

www.samsung.com
User Manual
English. 08/2016. Rev.1.0
SM-N930F
SM-N930FD

2
Table of Contents
Getting Started
4 Read me first
6 Maintaining water and dust resistance
7 Package contents
8 Device layout
13 Battery
21 SIM or USIM card (nano-SIM card)
27 Memory card (microSD card)
30 USB connector
31 Turning the device on and off
32 Transferring data from your previous
device
Basics
36 Controlling the touchscreen
39 Home screen
45 Lock screen
47 Always On Display
49 Notification panel
52 Entering text
55 Screen capture
56 Opening apps
56 Edge screen
66 S Pen features
76 Iris recognition
82 Fingerprint recognition
86 Secure Folder
90 Multi window
94 Samsung account
96 Device and data management
98 Quick connect
100 Sharing features
102 Emergency mode
Applications
103 Installing or uninstalling apps
105 Phone
109 Contacts
114 Messages
117 Internet
119 Email
120 Camera
143 Gallery
148 Samsung Pay
152 Samsung Gear
153 Samsung Members
155 Game Launcher
158 Samsung Notes
164 PEN.UP
167 Calendar
168 S Health
171 S Voice

Table of Contents
3
173 Voice Recorder
175 My Files
175 Clock
177 Calculator
177 Google apps
178 Amazon Video
Settings
179 Introduction
179 Connections
192 Sounds and vibration
193 Notifications
193 Display
196 Wallpapers and themes
196 Advanced features
199 Device maintenance
201 Applications
201 Lock screen and security
203 Cloud and accounts
205 Google
206 Accessibility
221 General management
221 Software update
222 User manual
222 About device
223 Appendix

4
Getting Started
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider,
model specifications, or device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customise the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
You may incur additional charges for data services, such as messaging, uploading and
downloading, auto-syncing, or using location services depending on your data plan. For
large data transfers, it is recommended to use the Wi-Fi feature.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.

Getting Started
5
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
•
Be careful not to forget your unlock codes for the screen lock, accounts, and other
security features. If you forget an unlock code, you will not be able to use the device if
you do not reset it. Samsung is not responsible for any data loss or inconvenience caused
by forgotten unlock codes.
•
Depending on the region or model, some devices are required to receive approval from
the Federal Communications Commission (FCC). If your device is approved by the FCC,
you can view the FCC ID of the device. To view the FCC ID, tap
Apps
→
Settings
→
About device
→
Battery info .
•
Depending on the region, you can view the regulatory information on the device. To view
the information, tap
Apps
→
Settings
→
About device
→
Regulatory information .
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Notice: notes, usage tips, or additional information

Getting Started
6
Maintaining water and dust resistance
Your device supports water- and dust-resistance. Follow these tips carefully to maintain the
water- and dust-resistance of your device. Failure to do so may result in damage to your
device.
•
Do not immerse the device in water deeper than 1.5 m or keep it submerged for more
than 30 minutes.
•
Do not expose the device to water moving with force.
•
If the device is exposed to clean water, dry it thoroughly with a clean, soft cloth. If the
device is exposed to other liquids, such as salt water, ionised water, or alcoholic beverage,
rinse it with clean water and dry it thoroughly with a clean, soft cloth. If you do not follow
these instructions, the device’s performance and appearance may be affected.
•
If the device has been immersed in water or the microphone or speaker is wet,
sound may not be heard clearly during a call. Wipe the device with a dry cloth or dry it
thoroughly before using it.
•
The touchscreen and other features may not work properly if the device is used in water.
•
Your device has been tested in a controlled environment and certified to be water-
and dust-resistant in specific situations (meets requirements of classification IP68 as
described by the international standard IEC 60529-Degrees of Protection provided
by Enclosures [IP Code]; test conditions: 15-35 °C, 86-106 kPa, 1.5 metre, 30 minutes).
Despite this classification, it is still possible for your device to be damaged in certain
situations.

Getting Started
7
Package contents
Check the product box for the following items:
•
Device
•
USB Connector
•
Micro USB Connector
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.

Getting Started
8
Device layout
Device
Microphone
Speaker
Back key
Multipurpose jack (USB
Type-C)
Front camera
Speaker
Edge screen
Power key
Touchscreen
Edge screen
Recents key
Headset jack
Home key (Fingerprint
recognition sensor)
Iris recognition LED
LED indicator
Proximity/Light sensor
SIM card / Memory card
tray
Iris recognition camera
GPS antenna

Getting Started
9
Main antenna
Volume key
NFC antenna / MST
antenna / Wireless
charging coil
Rear camera
Microphone
S Pen
Flash
•
Connectivity problems and battery drain may occur in the following situations:
–
If you attach metallic stickers on the antenna area of the device
–
If you attach a device cover made with metallic material to the device
–
If you cover the device’s antenna area with your hands or other objects while
using certain features, such as calls or the mobile data connection
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not cover the proximity/light sensor area with screen accessories, such as a
screen protector or stickers. Doing so may cause the sensor to malfunction.
•
The colours on the curved screen may look different depending on your viewing
position.

Getting Started
10
Keys
Key Function
Power
•
Press and hold to turn the device on or off.
•
Press to turn on or lock the screen.
Recents
•
Tap to open the list of recent apps.
•
Tap and hold to launch the split screen view.
Home
•
Press to turn on the screen while the screen is locked.
•
Press to return to the Home screen.
•
Press and hold to launch Google .
Back
•
Tap to return to the previous screen.
•
Tap and hold to access additional options for the current
screen.
Volume
•
Press to adjust the device volume.
S Pen
S Pen button
S Pen nib
Tweezers

Getting Started
11
Name Functions
S Pen nib
•
Use the S Pen to write, draw, or perform touch actions on the
screen. The Recents key and the Back key can be used with the
S Pen.
•
Hover the S Pen over items on the screen to access additional
S Pen features, such as the Air view feature.
S Pen button
•
Hover the S Pen over the screen and press the S Pen button to
display the Air command features.
•
While pressing and holding the S Pen button, drag the S Pen over
items to select them.
Tweezers
•
Remove the S Pen nib with the tweezers when replacing the nib.
Detaching the S Pen
Press the end of the S Pen to disengage it. Then, pull the S Pen from the slot. To store the
S Pen, push it back into the slot until you hear it click.
2
1

Getting Started
12
Replacing the S Pen nib
If the nib is dull, replace it with a new one.
1 Firmly hold the nib with the tweezers and remove it.
2 Insert a new nib into the S Pen.
Be careful not to pinch your fingers with the tweezers.

Getting Started
13
•
Do not reuse old nibs. Doing so may cause the S Pen to malfunction.
•
Do not press the nib excessively when inserting the nib into the S Pen.
•
Do not insert the round end of the nib into the S Pen. Doing so may cause damage
to the S Pen or your device.
•
Do not bend or apply excessive pressure with the S Pen while using it. The S Pen
may be damaged or the nib may be deformed.
•
If you use the S Pen at sharp angles on the screen, the device may not recognise
the S Pen actions.
•
If water enters the S Pen slot, gently shake the device to remove the water from the
slot before using it.
•
For more information about the S Pen, visit the Samsung website.
•
If the S Pen is not working properly, take it to a Samsung Service Centre.
Battery
Charging the battery
Charge the battery before using it for the first time or when it has been unused for extended
periods.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.

Getting Started
14
1 Connect the USB cable to the USB power adaptor, and plug the USB cable into the
device’s multipurpose jack.
2 Plug the USB power adaptor into an electric socket.
Charging with a Micro USB cable
Connect the Micro USB connector to charge the battery with a Micro USB cable.
Do not plug a Micro USB cable into your device’s multipurpose jack. Doing so may
damage the device and the cable.
The Micro USB connector is used for charging the battery and connecting to a
computer.

Getting Started
15
Charging other devices
Use the USB connector to charge another mobile device with your device’s battery.
Plug the USB connector into your device’s multipurpose jack, and connect your device and
the other device via the other device’s USB cable.
When charging starts, the battery charging icon will appear on the other device’s screen.
Your device The other
device
USB Connector
The other device's
USB cable
The app selection pop-up window that appears on your device is for data transfer. Do
not select an app from the pop-up window.

Getting Started
16
Viewing the estimated charging time
While charging, open the Home screen and tap Apps
→
Settings
→
Device maintenance
→
Battery .
The actual charging time may vary depending on the status of your device and the
charging conditions. The estimated charging time may not be displayed when you
charge the device in very cold or very hot conditions.
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
•
Optimise the device using the device maintenance feature.
•
When you are not using the device, turn off the screen by pressing the Power key.
•
Activate power saving mode.
•
Close unnecessary apps.
•
Deactivate the Bluetooth feature when not in use.
•
Deactivate the Wi-Fi feature when not in use.
•
Deactivate auto-syncing of apps that need to be synced, such as emails.
•
Decrease the backlight time.
•
Decrease the screen brightness.
Battery charging tips and precautions
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
•
If you use multiple apps at once, network apps, or apps that need a connection to
another device, the battery will drain quickly. To avoid losing power during a data
transfer, always use these apps after fully charging the battery.

Getting Started
17
•
Using a power source other than the charger, such as a computer, may result in a slower
charging speed due to a lower electric current.
•
The device can be used while it is charging, but it may take longer to fully charge the
battery.
•
If the device receives an unstable power supply while charging, the touchscreen may not
function. If this happens, unplug the charger from the device.
•
While charging, the device and the charger may heat up. This is normal and should not
affect the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging.
•
If you charge the device while the multipurpose jack is wet, the device may be damaged.
Thoroughly dry the multipurpose jack before charging the device.
•
If the device is not charging properly, take the device and the charger to a Samsung
Service Centre.
Fast charging
The device has a built-in fast charging feature. You can charge the battery more quickly while
the device or its screen is turned off.
About Fast charging
•
Fast charging uses battery charging technology that charges the battery faster by
increasing the charging power. The device supports Samsung’s Adaptive fast charging
feature and Qualcomm Quick Charge 2.0.
•
To use Fast charging on your device, connect it to a battery charger that supports
Adaptive fast charging or Quick Charge 2.0.

Getting Started
18
Increasing the charging speed
To increase the charging speed, turn the device or its screen off when you charge the battery.
While charging the battery when the device is turned off, the icon appears on the screen.
If the fast charging feature is not activated, on the Home screen, tap
Apps
→
Settings
→
Device maintenance
→
Battery
→ →
Advanced settings , and then tap the Fast cable
charging
switch to activate it.
•
You cannot use the built-in fast charging feature when you charge the battery
using a standard battery charger.
•
If the device heats up or the ambient air temperature rises, the charging speed may
decrease automatically. This is a normal operating condition to prevent damage to
the device.
Wireless charging
The device has a built-in wireless charging coil. You can charge the battery using a wireless
charger (sold separately).
Fast wireless charging
You can charge your device faster using the fast wireless charging feature. To use this feature,
you must use a charger and components that support the fast wireless charging feature.
A fan inside the charger may produce noise during fast wireless charging. To reduce
the fan noise, you must deactivate the fast wireless charging feature. The on/off
option will be added in your device’s settings menu when you first place it on the
charger. On the Home screen, tap
Apps
→
Settings
→
Device maintenance
→
Battery
→ →
Advanced settings , and then tap the Fast wireless charging switch
to deactivate it. Deactivating this feature will reduce noise, but may result in slower
charging times.

Getting Started
19
Charging the battery
Place the centre of the device’s back on the centre of the wireless charger.
The estimated charging time will appear on the screen. The actual charging time may vary
depending on the charging conditions.
When using the wireless charger, do not place foreign materials, such as metal
objects, magnets, and magnetic stripe cards, between the device and the wireless
charger. The device may not charge properly or may overheat.
•
If you use the wireless charger in areas with weak network signals, you may lose
network reception.
•
Use Samsung-approved wireless chargers. If you use other wireless chargers, the
battery may not charge properly.

Getting Started
20
Power saving mode
Activate power saving mode to extend the battery’s usage time.
1 On the Home screen, tap
Apps
→
Settings
→
Device maintenance
→
Battery
→
MID .
2 Tap
CUSTOMISE to change the power saving settings before entering power saving
mode.
3 Tap
APPLY .
Maximum power saving mode
In maximum power saving mode, the device decreases battery consumption by applying the
dark theme and limiting the apps and features available. Network connections, except for the
mobile network, will be deactivated.
1 On the Home screen, tap
Apps
→
Settings
→
Device maintenance
→
Battery
→
MAX .
2 Tap
CUSTOMISE to change the power saving settings before entering maximum power
saving mode.
3 Tap
APPLY .
After entering maximum power saving mode, on the Home screen, tap and select an app
to use. To remove apps, tap
→
Edit and select an app with .
To deactivate maximum power saving mode, tap
→
Disable Maximum power saving
mode
.
The estimated battery usage time may vary depending on your device settings and
operating conditions.
