Samsung SPH-A420 User manual

SPH-A420
User’s Guide
Draft
2005. 12. 15

Intellectual Property
All Intellectual Property, as defined below, owned
by or which is otherwise the property of Samsung
or its respective suppliers relating to the SAMSUNG
Phone, including but not limited to, accessories,
parts, or software relating there to (the “Phone
System”), is proprietary to Samsung and protected
under federal laws, state laws, and international
treaty provisions. Intellectual Property includes, but
is not limited to, inventions (patentable or
unpatentable), patents, trade secrets, copyrights,
software, computer programs, and related
documentation and other works of authorship. You
may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover, you
agree that you will not (and will not attempt to)
modify, prepare derivative works of, reverse
engineer, decompile, disassemble, or otherwise
attempt to create source code from the software.
No title to or ownership in the Intellectual Property
is transferred to you. All applicable rights of the
Intellectual Property shall remain with SAMSUNG
and its suppliers.
Samsung Telecommunications
America (STA), Inc.
Headquarters:
1301 East Lookout Drive Suite 150 Richardson,
TX 75082
Internet Address: http://www.samsungusa.com
©2005 Samsung Telecommunications America, Inc. is
a registered trademark of Samsung Electronics Amer-
ica, Inc. and its related entities.
Licensed by Qualcomm Incorporated under one or more
of the following patents: U.S. Patent No. 4, 901, 307;
5, 056, 109; 5, 099, 204; 5,101, 501; 5, 103, 459; 5,
107, 225; 5, 109, 390.
Openwave® is a registered Trademark of Openwave,
Inc.
RSA® is a registered TrademarSk RSA Security, Inc.

Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS
WARRANTY CONTAINED ON THE WARRANTY PAGE
ENCLOSED WITH THE PRODUCT, THE PURCHASER
TAKES THE PRODUCT "AS IS", AND SAMSUNG
MAKES NO EXPRESS OR IMPLIED WARRANTY OF
ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT, INCLUDING BUT NOT LIMITED TO THE
MERCHANTABILITY OF THE PRODUCT OR ITS
FITNESS FOR ANY PARTICULAR PURPOSE OR USE;
THE DESIGN, CONDITION OR QUALITY OF THE
PRODUCT; THE PERFORMANCE OF THE PRODUCT;
THE WORKMANSHIP OF THE PRODUCT OR THE
COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE,
SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE
INSTRUCTION MANUAL SHALL BE CONSTRUED TO
CREATE AN EXPRESS OR IMPLIED WARRANTY OF
ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE
LIABLE FOR ANY DAMAGES OF ANY KIND
RESULTING FROM THE PURCHASE OR USE OF THE
PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS.

1
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.

2
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 18.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

3
Contents
Unpack 4
Make sure you have every item
Your phone 4
Buttons, features, and locations
Get started 5
First steps to operate your phone
Install and charge the phone ..................................... 5
Power on or off........................................................ 6
Keys and display ..................................................... 7
Menu functions 9
All menu options listed
Solve problems 16
Help and personal needs
Health and safety information 18

4
Unpack
Make sure you have every item
You can obtain the following accessories for
your phone from your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
• Standard Battery • Extended Battery
• Battery Charger • Leather Case
• Portable Hands free kit • Data Cable
• Car Charger/Adaptor • Headset
• Travel Charger/Adapter
Your phone
Buttons, features, and locations
Left soft key
Volume keys
Dial key
Special
function keys
Headset jack
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
OK key
Speaker key
Back key

5
Get started
Get started
First steps to operate your phone
Install and charge the phone
Remove the battery
cover
If the phone is already
on, first turn it off by
holding [ ].
Install the battery.
Replace the cover. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.

6
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [] to turn on
the phone.
Power off 1. Open the phone.
2. Press and hold [] .

7
Get started
Keys and display
Key(s) Description
Perform the function indicated on the
bottom line of the display.
In Idle mode, access menu options directly.
In Menu mode, scroll through the menu
options.
In Menu mode, select the highlighted menu
option.
In Idle mode, enter Menu mode.
Send or answer a call.
In Idle mode, retrieve the last number
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
Activate the Speakerphone feature.
Key(s) Description
End a call. Hold down to switch the phone
on and off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[ 1 ] to access
your voicemail.
Enter special characters.
In Idle mode, press and hold
[] to access
the Sprint Voice Command feature.
(on the left)
Adjust the volume of various sounds for the
phone.
In Idle mode, with the phone open, adjust
the ringer volume for calls.

8
1 Voice kit
1 Voice dial
2 Voice memo
2 Messaging
1 Send message
2 Inbox
3 Outbox
4 Draft
5 Voicemail
6 Settings
3 Tools
1 Today
2 Scheduler
3 Task list
4 Memo pad
5 World time
6 Alarm clock
7 Calculator
8 Countdown
9 Set time
4 Settings
1 Display
2 Sounds
3 Security
4 Roaming
5 Launch pad
6 Others
7 Phone info
5 Call history
1 Outgoing calls
2 Incoming calls
3 Missed calls
4 Erase history
6 Contacts
1 Find
2 Add new entry
3 My phone #
4 Speed dial #s
5 Group setting
6 Services
Overview of menu functions
To access Menu mode, press < Menu > in Idle mode.

9
Menu functions
All menu options listed
Voice kit (Menu 1)
Use the Voice kit menu to use the voice dial feature
and record voice memos.
To access this menu, press < Menu > in Idle mode and
select Voice kit .
Voice dial (Menu 1.1)
The voice dial feature allows you to make phone calls
by saying one of names you have saved in Contacts.
In this menu, you can:
• register phone numbers to your phone to dial them
by voice command.
• view the list of voice tags you have registered and
erase all voice tags.
• set how you want to initiate voice dialing.
Voice memo (Menu 1.2)
The voice memo feature allows you to record your
important memos.
In this menu, you can:
•recordvoicememos.
• review the voice memos you have recorded.
• rename the default name of voice memos or erase
all voice memos.
• view information about voice memos.
Messaging (Menu 2)
Use the Messaging menu to send and receive short
text messages to and from other mobile phones. You
can also use the voicemail feature.
To access this menu, press < Menu > in Idle mode and
select Messaging .

10
Menu functions
Send message (Menu 2.1)
You can create new text messages including simple
emoticons and then send them to multiple destination.
Inbox (Menu 2.2)
You can view the messages you have received in this
message box. When you access this menu, a list of
messages displays.
Outbox (Menu 2.3)
You can view the messages you have sent in this
message box. When you access this menu, a list of
messages displays.
Draft (Menu 2.4)
you can view the messages you have saved in this
message box while creating a message.
Voicemail (Menu 2.5)
Use this menu to dial to the voicemail server and
access your voicemails. You can also delete voicemails
you have received.
Settings (Menu 2.6)
You can change the various settings for using the
message feature.
In this menu, you can:
• select the message notification settings.
• change the message sending settings.
• preset a message template and use it when
composing a message.
• edit your signature.
• change the message alert settings.
• set the phone to save outgoing messages after
sending then in the Outbox.
You must enter the voice server number before you
can access your voicemails. Your service provider
can give the voice server number.

11
Menu functions
Too l s
(Menu 3)
• set the phone to erase the oldest message in order
to free up memory space to receive a new
message when the memory for storing incoming
messages is full.
Tools (Menu 3)
The Tools menu provides you various convenient
features such as scheduler, task list, memo pad, world
time clock, alarm clock, calculator, and countdown
timer.
To access this menu, press < Menu > in Idle mode and
select Tools .
Today (Menu 3.1)
You can schedule multiple events for the current day,
indicating each event’s starting and ending time. You
can even have your phone’s calendar alert you before
an event commences. Events scheduled for future
dates automatically appear on your Today events
schedule on that day.
Scheduler (Menu 3.2)
This menu allows you to view the current month, as
well as past or future months in calendar format.
On the calendar, the current day is indicated by a blue
box and the selected day is highlighted. Days with
scheduled events are indicated by a yellow box on the
calendar day.
Task list (Menu 3.3)
This feature allows you to enter a list of tasks you
need to be done and assign both a priority and a
deadline to them.
Memo pad (Menu 3.4)
This feature allows you to make memos of important
things you need to remember.

12
Menu functions
World time (Menu 3.5)
You can use this menu to find out what time it is in
another part of the world.
Select the city corresponding to your time zone by
pressing the Navigation keys once or repeatedly. The
local time and date display.
To apply the DST (Daylight Savings Time) setting on,
press Options , select DST setting , and then On .
Alarm clock (Menu 3.6)
This menu allows you to set an alarm to ring at a
specific time.
Calculator (Menu 3.7)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
Countdown (Menu 3.8)
This menu helps you know how many time it takes for
you to do something or how many days until a specific
event occurs
Settings (Menu 4)
Many different features of your phone can be
customized to suit your preferences.
To access this menu, press < Menu > in Idle mode and
select Settings .
Display (Menu 4.1)
This menu enables you to customize various settings
for display and the lights.
In this menu, you can:
• change the idle screen image.
• select a display style for the main menu screen.
• select a font color for the numbers entered while
dialing. You can also select a font size.

13
Menu functions
Settings
(Menu 4)
• set a greeting message to be displayed.
• specify the length of time the backlight of the
display or keypad turns on. You can also activate
Power saving mode for backlight use.
• adjust the contrast of the display for varying
lighting conditions.
• activate or deactivate the service light.
Sounds (Menu 4.2)
This menu enables you to customize various settings
for sounds.
In this menu, you can:
• adjust the ringer volume for calls, messages, and
alarms.
• set the unique ringer melodies for incoming calls,
messages, scheduler alert, or roaming alert.
• customize additional tones for the phone.
• select the key tone type and adjust the key tone
volume.
• select the key tone length.
Security (Menu 4.3)
Your phone provides you with various security options,
including a user-programmable lock code and special
number features.
To access the Security menu, you must enter the 4-
digit lock code. It is preset to 0000 at the factory.
In this menu, you can:
• lock your phone from unauthorized use.
• change your current lock code to a new one.
• store up to 3 emergency numbers.
• erase all Contacts entries.
• reset the phone’s settings you have changed.
Roaming (Menu 4.4)
Roaming is a feature, which is only relevant in areas
where there are at least two cellular service providers
having valid roaming agreements. Roaming allows you
to register your phone on one of the networks, but use
the facilities of the other if your own network is not
available.

14
Menu functions
In this menu, you can:
• select a roaming mode.
• set the phone to remind you when you are making
or receiving a roaming call.
Launch pad (Menu 4.5)
You can set the Navigation keys as shortcuts to access
specific menus directly from Idle mode.
Others (Menu 4.6)
In this menu, you can:
• set digits, such as area codes and network feature
activation codes, to the beginning of a phone
number before dialing it.
• activate the contact match feature.
• restrict outgoing calls.
• set how to answer incoming calls.
• turn the automatic answering feature on or off.
• change the language to be displayed for the
display text.
• activate or deactivate Airplane mode, the location
feature, and TTY mode.
Phone info (Menu 4.7)
In this menu, you can:
• check your phone number and the MSID number.
• view information of the icons to be displayed on
the screen.
• view the software and hardware version of your
phone.
• view network information, such as SID, the
channel, the technology, and the frequency.
Call history (Menu 5)
Use this menu to view the calls you have dialed,
received, or missed, the length of your calls, and the
cost of your calls.
To access this menu, press < Menu > in Idle mode and
select Call history .

15
Menu functions
Contacts
(Menu 6)
Outgoing calls (Menu 5.1)
If Caller Line Identification is available, your phone
keeps a list of the most recent outgoing calls that you
have made. Contact your service provider for the
availability.
Incoming calls (Menu 5.2)
This menu lets you view the most recent calls you
have received if you are a subscribe to the Caller Line
Identification service. Contact your service provider
for further details about this service. When you access
this menu, a list of the incoming calls displays.
Missed calls (Menu 5.3)
The phone stores up to the most recent numbers you
have failed to answer. When you access this menu, a
list of the missed calls displays.
Erase history (Menu 5.4)
In this menu, you can erase the entries stored in each
of three call logs; outgoing, incoming, and missed
calls.
Contacts (Menu 6)
The Contacts menu allows you to store frequently
used phone numbers and the associated names in
your personal directory to make it easy for you to
make a call without having to remember or enter the
phone number.
To access this menu, press < Menu > in Idle mode and
select Contacts .
Find (Menu 6.1)
This menu allows you to find an entry using a person’s
name, entry number, or group name in your Contacts.
Add new entry (Menu 6.2)
This menu allows you to add a new entry to your
Contacts. A name can contain up to 6 numbers and
enter additional information in different categories;
Mobile, Home, Work, Pager, Others, E-mail, Memo,
Group, Ringer, and Image.
Press Contacts in Idle mode to quickly access
this menu.

16
My phone # (Menu 6.3)
Use this feature to check your phone number.
Speed dial #s (Menu 6.4)
Once you have stored phone numbers in Contacts, you
can set up to 98 speed dial entries and then dial them
easily whenever you want, simply by pressing and
holding the associated number key(s) in Idle mode.
Group setting (Menu 6.5)
In this menu, you can change the default group names
and ringer melodies.
Services (Menu 6.6)
In this menu, you can dial the service center preset by
your service provider and get a variety of information,
such as your phone account, customer services, and
the directory assistance service. For details, contact
your service provider.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the
following messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the PIN check menu.

17
Solve problems
“Enter PUK”
• The PIN code was entered incorrectly three times
in succession, and the phone is now blocked. Enter
the PUK supplied by your service provider.
“No Service,” “Network Failure,” or “Not
Done” displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialed
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure your phone is switched on. ( [] pressed
for more than one second.)
• Be sure you are accessing the correct cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot hear you speaking
• Be sure you have switched off the microphone.
• Be sure you are holding the phone close enough to
your mouth. The microphone is located at the
bottom of the phone.
The phone starts beeping and “Low Battery
Recharge Soon” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
