Samsung SGH-Z720 User manual

World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English (EU). 09/2006. Rev. 1.0
* Depending on the software installed or your service provider or country, some of the
descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the
illustrations in this guide.

SGH-Z720
User’s Guide
Draft03
2006.09.11
Version:Z720XAFH2

Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or
illegal.
Use road safety at all times
Do not use a hand-held phone while driving.
Park the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference.
Using them in an aircraft is both illegal and
dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be
using equipment that could be sensitive to
external radio frequency energy. Follow any
regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.

1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any
area and always switch off your phone
whenever it is forbidden to use it, or when it
may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it
dry.
Sensible use
Use only in the normal position (held to the
ear). Avoid unnecessary contact with the
antenna when the phone is switched on.
Emergency calls
Key in the emergency number for your
present location, then press .
Keep your phone away from small
children
Keep the phone and all its parts, including
accessories, out of the reach of small
children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data
cables. Use of any unauthorised accessories
could damage you or your phone and may
be dangerous.
Qualified service
Only qualified service personnel may repair
your phone.
For more detailed safety information, see
"Health and safety information" on page
114.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volume, prolonged
listening to a headset can damage
your hearing.

2
About this Guide
This User’s Guide provides you with
condensed information about how to use
your phone. To quickly learn the basics for
your phone, please refer to “Get started”
and “Step outside the phone.”
In this guide, the following instruction icons
appear:
Indicates that you need to pay
careful attention to the subsequent
information regarding safety or
phone features.

Indicates that you can get more
information on the referenced page.
→ Indicates that you need to press the
Navigation keys to scroll to the
specified option and then select it.
[ ] Indicates a key on the phone.
For example, []
< > Indicates a soft key, whose function
is displayed on the phone screen.
For example, < Select >
•3G
Your phone is capable of
operating in a 3G
environment, allowing
much greater data transfer
speed, video streaming,
and video conferencing.
Special features of your phone
• Camera and camcorder
Use the camera module on
your phone to take a photo
or record a video.
• Media player
Play media files on your
phone. You can enjoy high
quality videos and music.

3
Special features of your phone
•Bluetooth
Transfer media files and
personal data and connect
to other devices using free,
wireless Bluetooth
technology.
•Webbrowser
Access the wireless web to
get up-to-the-minute
information and a wide
variety of media content.
• Get personal with photo
caller ID
See who’s calling you with
their very own photo
displays.
• Name card
Create name cards with
your number and profile.
Whenever introducing
yourself to others, use this
convenient electronic name
card.
• File viewer
Open documents in various
formats on the phone
without corruption.
• Multimedia Message
Service (MMS)
Send and receive MMS
messages with a
combination of text,
images, video, and audio.
•E-mail
Send and receive e-mails
with image, video, and
audio attachments.
•Java
Enjoy Java ™ -based
embedded games and
download new games.
•Calendar
Keep track of your daily,
weekly, and monthly
schedule.

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ...................... 7
Power on or off......................................... 8
Keys and display ...................................... 9
Access menu functions ............................ 12
Customise your phone............................. 13
Make/Answer calls .................................. 15
Step outside the phone 16
Begin with your camera, the media player, the
web, and other special features
Use the camera ...................................... 16
Play music ............................................. 17
Browse the web...................................... 18
Use Contacts.......................................... 19
Send messages ...................................... 20
View messages....................................... 22
Use Bluetooth ......................................... 23
Switch applications .................................. 24
Use a memory card ................................. 25
Enter text 27
ABC, T9, Number, and Symbol modes
Call functions 29
Advanced calling features
Menu functions 35
All menu options listed
Solve problems 112
Help and personal needs
Health and safety information 114
Index 136

5
1 Call log  p. 35
2 Contacts  p. 37
3 Media player  p. 42
4 Browser  p. 48
1 Go to Homepage
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Advanced
7 Browser Settings
 p. 48
 p. 50
 p. 50
 p. 51
 p. 51
 p. 51
 p. 52
5 Messaging  p. 52
1 Create New Message
2 Inbox
3 Email inbox
4 Drafts
5 Outbox
6 Sentbox
7 My folder
8 Templates
9 Delete all
0 Messaging settings
* Memory status
 p. 52
 p. 56
 p. 59
 p. 60
 p. 61
 p. 61
 p. 62
 p. 62
 p. 63
 p. 63
 p. 69
6 My files  p. 69
Images
Videos
Sounds
Games and more
Other files
Memory status
Memory card
1
 p. 70
 p. 72
 p. 73
 p. 74
 p. 75
 p. 78
 p. 78
7 Calendar  p. 78
8 Camera  p. 82
9 Bluetooth  p. 88
* Applications  p. 90
1 Memo
2 Tasks
3 Voice recorder
4 World clock
5 Calculator
6 Converter
7 Timer
8 Stopwatch
9 SAT
2
 p. 90
 p. 91
 p. 92
 p. 94
 p. 94
 p. 94
 p. 95
 p. 95
 p. 95
0 Alarms  p. 96
# Settings  p. 97
1 Phone profiles
2 Time & date
3 Display settings
4 Phone settings
5 Call settings
6 Security
7 Application settings
8 Network settings
9 Operator settings
3
0 Master reset
 p. 97
 p. 98
 p. 99
 p. 99
 p. 101
 p. 104
 p. 106
 p. 109
 p. 112
 p. 112
1. Shows only if a memory card is
inserted.
2. Shows only if supported by your
SIM/USIM card.
3. Shows only if supported by your
service provider.
Overview of menu functions
To access Menu mode, press [ OK ] in Idle mode.

6
Your phone
Keys, features, and locations
Headset/
Adapter jack
Left soft key
Special
function keys
Camera lens
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Menu access/
Confirm key
Navigation keys
(Up/Down/Left/
Right)
Delete key
Dial key
Display
Earpiece
Memory card
slot
Volume keys
Camera/
Video call key
Microphone
Application
switch key
Unpack
Make sure you have each item
• Phone
•TravelAdapter
• Battery
• PC Data Cable
• PC Link CD
•User’sGuide
You can obtain various
accessories from your local
Samsung dealer.
The items supplied with
your phone and the
accessories at your
Samsung dealer may vary,
depending on your country
or service provider.

Get started
7
Get started
First steps to operating your phone
USIM/SIM card information
When you subscribe to a cellular network,
you receive a plug-in SIM (Subscriber
Identity Module) card loaded with your
subscription details, such as your PIN, and
available optional services. For 3G services,
you can purchase a USIM (Universal
Subscriber Identity Module) card.
Install and charge the phone
Remove the
battery cover.
If the phone is
already on, first turn
it off by pressing and
holding [ ].
Insert the USIM/
SIM card.
Make sure that the
gold-coloured
contacts on the card
are face down.
Install the battery. Reattach the
battery cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall
outlet.
When the phone is completely charged
(the battery icon becomes still), unplug
the adapter from the power outlet.

Get started
8
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the
phone automatically turns off. Recharge
your battery.
Power on or off
Keypad lock
When you close the phone, the keypad lock
feature locks the exposed keys so that
nothing will happen if the keys are
accidentally pressed.
To unlock the keypad, press < Unlock > and
then press < OK >.
Remove the adapter from the phone.
Switch on
Do not turn on
the phone
when mobile
phone use is
prohibited.
1. Open the phone.
2. Press and hold [ ].
3. If necessary, enter the
PIN and press
< Confirm >.
Switch off
1. Open the phone.
2. Press and hold [ ].

Get started
9
Keys and display
Keys
Perform the function indicated
on the bottom line of the display.
In Idle mode, access your
favourite menus directly.
 p. 100
In Menu mode, scroll through
menu options.
In Idle mode, access Menu
mode.
In Menu mode, select a
highlighted menu option or
confirm input.
Make or answer a call.
In Idle mode, retrieve numbers
recently dialled, missed, or
received.
Delete characters from the
display or items in an
application.
Press and hold to switch the
phone on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
Enter numbers, letters, and
some special characters.
In Idle mode, press and hold [ 1 ]
to access your voicemail server.
Press and hold [ 0 ] to enter an
international call prefix.
Enter special characters.
Press and hold [ ] to activate or
deactivate the Silent profile.
Press and hold [ ] to enter a
pause between numbers.
Adjust the phone volume.
In Idle mode, adjust the key
tone volume. With the phone
closed, press and hold to turn on
the display.

Get started
10
Display
Open the application switch
window to access other
applications without exiting the
current application.
In Idle mode, press and hold to
turn on the camera or make a
video call, depending on the
Camera key setting.
 p. 100
In Camera mode, take a photo
or record a video.
In the dialling screen, make a
video call.
Layout
Text and graphics
display messages,
instructions, and
information you
enter.
Soft key function
indicators
show the current
functions assigned
to the soft keys.
Icons
display various
icons.
Select Back
Icons
1
Received signal strength
Accessing services in a
2.5G (GPRS) network;
when transferring data,
this icon animates
Accessing services in an
EDGE network; when
transferring data, this icon
animates
Accessing services in a 3G
(UMTS) network; when
transferring data, this icon
animates
Accessing services in a
3G+ (HSDPA) network;
when transferring data,
this icon animates
Roaming network
Voice call in progress
Out of your service area;
you cannot make or
receive voice calls
Video call in progress

Get started
11
Out of your service area;
you cannot make or
receive video call
Memory card inserted
 p. 25
Bluetooth active; When
transferring data, this icon
blinks red and blue
 p. 88
Connected with PC via a
USB port
Browsing Internet on PC
using the phone as modem
Connected to secured web
page
New message:
• : SMS
• : MMS
• : E-mail
• : Voicemail
• : Push
• : Configuration
message
Inbox full:
• : SMS
• : MMS
• : E-mail
• : Voicemail
• : Push
• : Configuration
message
Profile setting  p. 98
• : Normal
• : Meeting
• : Car
• : Silent
• : Outdoor
• : Offline
Battery power level
1. Depending on your country or service provider,
the icons shown on the display may vary.

Get started
12
Access menu functions
Use the
soft keys
The roles of the soft keys
vary depending on the
function you are using. The
bottom line of the display
indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to
return to the
previous
menu level.
Select Back
Select an
option
1. Press a desired soft key.
2. Press the Navigation
keys to move to the
next or previous option.
3. Press < Select > or [ OK ]
to confirm the function
displayed or option
highlighted.
4. To exit, choose either of
the following methods:
• Press < Back > to
move up one level.
• Press [ ] to return
to Idle mode.
Use
shortcuts
Press the number key
corresponding to the option
you want.

Get started
13
Customise your phone
1. In Idle mode, press [ OK ]
and select Settings →
Phone settings →
Language → Screen
text .
2. Select a language.
3. Press < Save >.
You can change the call
ringer by changing the
properties of the currently
active sound profile.
To ch ang e th e profi le
properties:
1. In Idle mode, press [ OK ]
and select Settings →
Phone profiles .
2. Scroll to the sound profile
you are using.
3. Press < Options > and
select Edit .
Display
language
Call ringer
melody
4. Select Voice call
ringtone and select a
ringtone for voice calls.
5. Select Video call
ringtone and select a
ringtone for video calls.
6. Press < Options > and
select Save .
To change the sound profile:
1. In Idle mode, press [ OK ]
and select Settings →
Phone profiles .
2. Select the profile you
want.

Get started
14
You can set a wallpaper for
the idle screen.
1. In Idle mode, press [ OK ]
and select Settings →
Display settings →
Display settings →
Wallpaper → Pictures
→ Images .
2. Scroll to an image folder .
3. Select an image.
4. Press < Set >.
You can set the Navigation
keys to function as shortcuts
to access your favourite
menus.
1. In Idle mode, press [ OK ]
and select Settings →
Phone settings →
Shortcuts .
2. Select a key.
3. Select a menu to be
assigned to the key.
Idle mode
Wallpaper
Menu
shortcuts
You can activate the Silent
profile to avoid disturbing
other people.
Press and hold [ ] in Idle
mode.
You can protect the phone
against unauthorised use
with a phone password. The
phone will require the
password on power-up.
1. In Idle mode, press [ OK ]
and select Settings →
Security → Change
phone password .
2. Enter the default
password, 00000000 ,
and press < Confirm >.
3. Enter a new 4- to 8-digit
password and press
< Confirm >.
Silent
profile
Phone lock

Get started
15
Make/Answer calls
4. Enter the new password
again and press
< Confirm >.
5. Select Phone lock .
6. Select On .
7. Enter the password and
press < Confirm >.
To make a voice call:
1. Enter an area code and
phone number.
2. Press [ ].
3. To end the call, press
[].
To ma ke a vi de o ca ll:
1. Enter an area code and
phone number.
2. Press [ ].
3. To end the call, press
[].
Make a call
1. When the phone rings,
press [ ].
2. For a video call, when a
“Allow own image to be
shown?” message
appears, select Yes to
allow the other person to
see you.
3. To end the call, press
[].
Press [ / ].
Answer
a call
Adjust the
volume
during a call

16
Step outside the phone
Begin with your camera, the media player, the
web, and other special features
Use the camera
1. Open the phone.
2. In Idle mode, press and
hold [ ] to turn on the
camera.
3. Aim the lens at the
subject and make any
desired adjustments.
4. Press [ OK ] or [ ] to
take a photo. The photo
is saved automatically.
5. Press < Back > or < >
to take another photo.
1. In Idle mode, press [ OK ]
and select My files .
2. Select the photo you
want.
Take a
View a
1. In Idle mode, press and
hold [ ] to turn on the
camera.
2. Press [ 1 ] to switch to
Record mode.
3. Press [ OK ] or [ ] to
start recording.
4. Press [ OK ] or [ ] to
stop recording. The video
is saved automatically.
5. Press < Back > to record
another video.
1. In Idle mode, press [ OK ]
and select My files .
2. Select the video you
want.
Record a
video
Play a video

Step outside the phone
17
Play music
Use these methods:
• Download from the
wireless web  p. 48
• Download from a
computer using the
optional Samsung PC
Studio  Samsung PC
Studio User’s Guide
• Receive via Bluetooth
 p. 90
•Copytoamemorycard
and insert the card into
the phone  p. 25
Copy media
files to the
phone
1. In Idle mode, press [ OK ]
and select Media player .
2. Scroll to the Music tab.
3. Press < Options > and
select Create playlist .
4. Enter the name for the
play list and press
< Save >.
5. Select the play list you
just created.
6. Press < Options > and
select Add → Playlist or
Files .
7. Scroll to the play list you
want, or press [ OK ] to
select the files you want.
8. Press < Select > or
< Add >.
Create a
play list
