Samsung SPH-I325 ACE User manual

Sprint Worldwide Services Guide
Samsung ACETM
www.sprint.com
© 2008 Sprint Nextel. All rights reserved. SPRINT and other trademarks
are trademarks of Sprint Nextel.
1/14/08
I325_InternationalGuide.book Page a Monday, January 14, 2008 6:15 PM

I325_International_Guide_AL05_PS_011408_F5
I325_InternationalGuide.book Page b Monday, January 14, 2008 6:15 PM

Table of Contents
Sprint Worldwide Wireless Service . . . . . 1
Your SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using Your Device in GSM Mode . . . . . . . . . . . . . 3
Using Your SIM Card’s PhoneBook . . . . . . . . . . . 7
Setting GSM Services Options . . . . . . . . . . . . . . . 9
Contacting Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Selecting a Network . . . . . . . . . . . . . . . . . . . . . . . . 12
I325_InternationalGuide.book Page i Monday, January 14, 2008 6:15 PM

1
Sprint Worldwide
Wireless Service
⽧Your SIM Card
⽧Using Your Device in GSM Mode
⽧Using Your SIM Card’s PhoneBook
⽧Setting GSM Services Options
⽧Contacting Sprint
⽧Services
⽧Selecting a Network
Your device allows you to roam throughout the world using both
CDMA (Code Division Multiple Access) and GSM (Global
System for Mobile Communications) networks. For a
complete list of countries and features available, visit
www.sprint.com/international.
Your SIM Card
Your device comes with a preinstalled SIM (Subscriber
Identity Module) card to support roaming on
compatible GSM networks. The SIM card must be
activated for international wireless service prior to it
initial use (outside of the United States).
To activate Sprint Worldwide service:
䊳Call Sprint Worldwide Customer Service at
1-888-226-7212, option 2.
For more help with Sprint Worldwide international
setup, press Start > More (left softkey) > International Usage
to display a brief set of onscreen GSM setup
instructions.
Note Your SIM card should be preinstalled. If you need to
reinstall your SIM card, see “Removing Your SIM Card”
on page 2. The SIM card included with your device
contains information specific to your device and
should be retained with the device for use on GSM
networks.
I325_InternationalGuide.book Page 1 Monday, January 14, 2008 6:15 PM

2
Removing Your SIM Card
The SIM card comes preinstalled but can be removed
if necessary.
1. Remove the battery cover.
䡲Press down with thumbs as indicated below.
䡲While applying pressure, slide cover away from
the camera lens (as shown below).
2. Remove the battery to gain access to the SIM card
slot.
3. Carefully remove the SIM card from the slot (shown
below).
4. Reinstall the battery.
䡲Insert the battery into the opening on the back of
the device, making sure the connectors align.
Gently press down to secure the battery.
䡲Position the battery cover and firmly slide it in until
you hear a click.
I325_InternationalGuide.book Page 2 Monday, January 14, 2008 6:15 PM

3
5. Press to turn the
device on.
䡲Your device will turn on,
search for Sprint service,
and then enter standby
mode.
䡲If your device is not yet
activated, or if it is
locked, see the “Getting
Started With Sprint
Service” section of the
Samsung ACETM User
Guide for more
information.
䡲If your device does not detect a SIM card while in
GSM mode, it will display in the upper-right
corner of the Home screen.
Using Your Device in GSM Mode
Entering GSM Mode
Once you have installed the SIM card, your device may
be used in GSM mode on GSM networks while
traveling internationally. To operate on international
GSM networks, you need to switch the device from
CDMA (default) mode to GSM mode.
Note Your device’s battery should have enough charge to
turn on, find a signal, set up your voicemail, and make
a call. You should fully charge your battery as soon as
possible. See “Charging the Battery” section of the
Samsung ACETM User Guide for more details.
X
Note Sprint offers voice service on CDMA networks in
nearly 40 countries around the world; accessing
service in these countries is as simple as powering on
your device. Call Sprint Worldwide Customer Service
before your trip to verify your service allows for
international dialing. In countries where CDMA service
is not available you will need to access a GSM
network.
I325_InternationalGuide.book Page 3 Monday, January 14, 2008 6:15 PM

4
To enter GSM mode from CDMA mode:
1. Press Start > More (left softkey) > More (left softkey) >
Service Mode. The following options appear in the
selection window:
䡲Sprint CDMA
䡲Int’l GSM
2. Use the navigation key to select the Int’l GSM
service mode and then press Apply (right softkey).
A Confirm Reset dialogue box appears in the
display asking if you wish to change phone
modes.
3. Type 'yes' in the box and press OK (right softkey).
Press Cancel (left softkey) to return to the previous
screen.
䡲If you pressed OK, the device will power off and
then restart in the selected mode.
Making and Answering Calls in GSM Mode
When traveling on international GSM networks while in
GSM mode, you can place and answer calls the same
as in CDMA mode. Certain features and services are
not available in all countries.
Visit www.sprint.com/international for more information on
services that are available while roaming.
Calling Emergency Numbers in GSM Mode
When traveling on international GSM networks while in
GSM mode, you can place calls to emergency services
(even if your account is restricted or Call Barring is
active.)
To place calls to emergency services:
䊳Press .
Note While in the United States, your device will operate only
in CDMA mode; domestic GSM networks will not be
accessible via this device.
I325_InternationalGuide.book Page 4 Monday, January 14, 2008 6:15 PM

5
Using Plus (+) Code DialingPlacing calls from one
country to another country is simple with the Plus (+)
Code Dialing feature. When placing international calls,
you can use Plus Code Dialing to automatically enter
the international access code for your location (for
example, 011 for international calls placed from the
United States).
To use Plus Code Dialing to place an international call:
1. Press and hold until a “+” is displayed on the
device’s display screen.
2. Enter the country code, city code or area code,
and the phone number you’re calling, and then
press .
(The access code for international dialing will
automatically be dialed, followed by the country
code, city or area code, and the phone number.)
Direct Dial
To place an international call by dialing direct:
䊳Dial the international access code, the country
code, the city or area code, and the phone
number, and then press to send the call.
Making Calls Within a Country (Local or Long
Distance Dialing)
The steps for placing an international call within the
same country are identical to those for calling country-
to-country, except it is not necessary to enter the
country code.
Calling the United States from Another Country
To place a call to the United States from another country:
1. Press and hold to display the “+” symbol. The
“+” symbol automatically inserts the exit code for
the country from which you are calling.
2. Press to insert the U.S. country code, and then
enter the area code and number.
3. Press to finish dialing the number.
Note Your device must be in GSM mode for you to use Plus
Code Dialing.
I325_InternationalGuide.book Page 5 Monday, January 14, 2008 6:15 PM

6
Calling Other Countries
To place from one country to another country:
1. Press and hold to display the “+” symbol. The
“+” symbol automatically inserts the exit code for
the country from which you are calling.
2. Enter the country code of the person you are
calling.
3. Enter the area code without the leading zero,
followed by the number of the person you are
calling and press .
Retrieving Voicemail Messages
The Voicemail box of your GSM device is the same as
the one for your Sprint phone.
To retrieve voicemail messages:
1. Press and hold until a “+” symbol appears on
your device display.
2. Enter followed by your 10-digit phone number.
3. When you hear the voice greeting, press and
enter your password, followed by .
International Data Roaming
Sprint Worldwide Wireless Service can also keep you
connected via email and Web browsing when traveling
in countries in which Sprint offers data service. Data
services are available on both CDMA and GSM
networks; check www.sprint.com/international to
determine the services available where you are
traveling.
Note Prior to using your Sprint Worldwide GSM Data
Services, you must establish and utilize your CDMA
data services domestically on the Sprint National
Network.
I325_InternationalGuide.book Page 6 Monday, January 14, 2008 6:15 PM

7
Getting Started with Data Services
Before you can use Sprint Worldwide Data Services,
you must first have these services activated on your
account.
䊳To activate, call Sprint Worldwide Customer
Service at 1-888-226-7212, option 2. Representatives
are available 24 hours a day, 7 days a week to
assist you.
Once your services are activated, you may need to
select a GSM data services provider for the country
you’re in. (See “Selecting a Network” on page 12.)
Accessing Your Email and Data Services
on CDMA Networks
If data service is available on a CDMA network, then
you only need to set the phone to CDMA mode; you will
not need to select the specific carrier. See “Using Your
Device in GSM Mode” on page 3.
Selecting a specific carrier is only necessary for
providers on the GSM network. If your device has
automatically selected a GSM network while traveling,
you will need to set the device to CDMA to access
CDMA data services.
Visit www.sprint.com/international for a list of services
available for each country.
Using Your SIM Card’s PhoneBook
Your SIM card contains its own phone book that is
separate from your device’s internal Contacts list. You
can update and maintain the SIM PhoneBook
whenever your device is in GSM mode, even if you are
not in a GSM service area.
Note Your device must be in GSM mode for you to access
the SIM card.
Note While the phone is in GSM mode, device can edit
Contacts stored within both the device and SIM card.
While the device is in CDMA mode, the device can not
access Contacts stored on the SIM card.
I325_InternationalGuide.book Page 7 Monday, January 14, 2008 6:15 PM

8
When storing a Contacts entry into your SIM card, note
that only the name and number are saved. Entries
stored on the card do not contain any detailed
information that may be stored in the device's internal
memory. To store additional information for a particular
contact, such as email address, or dates, it is important
to save that information to your device’s onboard
memory.
When a SIM card is active, the Contacts list will then
display up to four types of entries:
Each Contacts entry stored on the SIM card can use
only one phone number, and the entry’s name can be a
maximum of 255 characters.
Adding Entries to the SIM PhoneBook
Adding new entries to your SIM PhoneBook is similar
to adding entries to the device’s internal Contacts list.
To add a new SIM card phone book entry:
1. Press Start > Contacts > New (left softkey) > SIM
Contact.
2. Enter a name and phone number for the new
entry.
3. Press Done (left softkey) to store the new entry into
the SIM card’s Contacts list.
Contacts entry - SIM Card
Contacts entry - Phone
I325_InternationalGuide.book Page 8 Monday, January 14, 2008 6:15 PM

9
Move or Copy Contacts Entries to the SIM
PhoneBook
You can also copy entries from your device’s Contacts
to your SIM PhoneBook.
To copy Contacts entries to your SIM PhoneBook:
1. Press Start > Contacts > Menu (right softkey) > Copy
All.
2. Select a copy option:
䡲SIM to Phone to copy all your contacts from your
SIM Card to your device's onboard memory.
䡲Phone to SIM to copy all your Contacts from your
device to your SIM card. Note that only the name
and number will be saved to the card.
Deleting All SIM PhoneBook Entries
To delete all SIM PhoneBook entries:
1. Press Start > Contacts > Menu (right softkey) > Delete
All > SIM.
2. Press Yes (left softkey) to delete all contacts from
the SIM card or No (right softkey) to cancel.
Setting GSM Services Options
There are several user options available for GSM
operation under your device’s Settings menu, including
Call Diverting, Call Barring, Call Waiting, and GSM
Network Selection. All these options require that your
device be in GSM mode and in a GSM roaming
coverage area. (See www.sprint.com/international for
maps showing where international GSM coverage is
available, and see “Entering GSM Mode” on page 3.)
Note The SIM PhoneBook provides three default fields
(Name, Phone Number, and Index). This information is
stored on your SIM card to provide information
mobility. When phonebook entries are moved or
copied to Contacts, all input fields are available for
entry; however this information is not stored on the
SIM card.
I325_InternationalGuide.book Page 9 Monday, January 14, 2008 6:15 PM

10
Using Call Barring (GSM)
Call Barring allows you to block certain types of
incoming and outgoing calls on your device. This
would be useful, for example if you allowed someone
to use your device for a short period of time.
To activate Call Barring (GSM):
1. Press Start > Settings > Phone > Call Barring.
2. Follow the onscreen instructions.
Contacting Sprint
Sprint Worldwide Customer Service is available to
answer your questions 24 hours a day, 7 days a week.
Please call the numbers below if you need assistance.
While in the United States:
䊳Call 1-888-226-7212, option 2.
While traveling outside the United States:
䊳Call [phone], option 2.
There is no charge for this call from your Sprint wireless
device.
From a landline phone when outside the United States:
Sprint Worldwide Customer Service can be reached
from a landline phone at [phone], option 2.
Access or connection fees may apply. The toll free
numbers below can also be used to contact Sprint
Worldwide Customer Service in the following countries.
Country From Landline Phone
Anguilla 1-888-226-7212
Barbados 1-888-226-7212
Cayman Islands 1-888-226-7212
China 00-1-800-713-0750
Dominican Republic 1-888-226-7212
France 0800-903200
Germany 0800-180-0951
Italy 800-787-986
I325_InternationalGuide.book Page 10 Monday, January 14, 2008 6:15 PM

11
Services
Caller ID
Caller ID displays the number (and name, if in your
PhoneBook) of incoming calls. Caller ID in GSM mode
must be enabled by the user.
To enable or disable caller ID:
1. Press Start (left softkey) >Settings > Phone > Caller ID.
2. Press Everyone, No one or Only my contacts and
press .
Call Waiting
Call Waiting notifies you of an incoming call even while
you’re in a call. You can then accept, reject, or ignore
the incoming call. Unlike Call Waiting in CDMA mode,
Call Waiting in GSM mode must first be activated.
To use Call Waiting Internationally:
Call waiting in GSM mode must first be enabled as
follows:
1. Press Start (left softkey) >Settings > Phone > Call
Waiting.
2. Place a check mark in the “Provide call waiting
notifications” field and press .
Voicemail and Text Messages
To activate voicemail settings:
1. Press Start (left softkey) >Settings > Phone > Call
Options.
2. Select the Voicemail number field. The number to
call your voicemail is then displayed.
Mexico 001-877-294-9003
Trinidad and Tobago 1-800-201-7545
United Kingdom 0808-234-6616
Country From Landline Phone
I325_InternationalGuide.book Page 11 Monday, January 14, 2008 6:15 PM

12
3. To change the number, press and hold to
erase the numbers, then use the keypad to enter a
new number and press .
Selecting a Network
To access your email and browse the Web when
traveling, you may need to manually select the carrier
that provides Sprint service in your location. You can
find a list of carriers for each country where GSM data
service is offered at www.sprint.com/international. Then,
follow the instructions below to select the appropriate
carrier network on your device.
To select a GSM data service for a specific country:
1. Press Start (left softkey) >Settings > Phone > More... >
Networks.
䡲The Current Network field displays a description
of the currently active network.
2. From the Network selection field, select Automatic or
Manual.
3. Press Menu (right softkey) >Find a New Network.
4. Press Set Networks. The settings are sent to the
network.
5. Press .
Viewing Your Preferred Networks
1. Press Start (left softkey) >Settings > Phone > More... >
Networks.
䡲The Current Network field displays a description
of the currently active network.
2. From the Network selection field, select Manual.
3. Press Menu (right softkey) >Preferred Networks.
Note This number is automatically set up when you receive
your device. You will probably not need to change it
unless otherwise instructed by your carrier.
Note When traveling, it may be necessary to select a new
compatible GSM data service carrier each time you
enter a new country.
I325_InternationalGuide.book Page 12 Monday, January 14, 2008 6:15 PM

13
To add a new preferred network:
1. Repeat steps 1 - 3 from “Viewing Your Preferred
Networks” to access the Preferred Networks
screen.
2. Press Menu (right softkey) >Add.
3. Use the navigation key to select a new network
from the available list and press Select (left softkey).
(This newly added network then appears on the
Preferred Networks screen.)
I325_InternationalGuide.book Page 13 Monday, January 14, 2008 6:15 PM
