Samsung NZ30K7880U Series User manual

Electric Cooktop
User manual
NZ30K7880U*
NZ30K7880U_DG68-00823A-06_EN+MES+CFR.indb 1 2018-08-29  2:27:50

2 English
Regulatory Notice
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
NZ30K7880U_DG68-00823A-06_EN+MES+CFR.indb 2 2018-08-29  2:27:50

English 3
Regulatory Notice
General safety instructions
This unit has been tested and found to comply with the limits for a class
B digital device, pursuant to Part 18 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This unit generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful interference to radio
or television reception, which can be determined by turning the unit off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorienting or relocating the receiving antennae.
• Increasing the distance between the unit and receiver.
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV.
2. IC Notice
The term "IC" before the radio certication number only signies
that Industry Canada technical specications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
NZ30K7880U_DG68-00823A-06_EN+MES+CFR.indb 3 2018-08-29  2:27:50

4 English
Contents
ContentsContents
Important safety instructions 5
Before you start 15
About induction cooktop cooking 15
Location of the induction cooktop elements and controls 16
Virtual ame technology 17
Magnetic Knob 18
Residual heat indicator 18
Cooking areas 18
Initial cleaning 19
Digital display 19
Safety shutoff 19
Operation 19
Switching the appliance on 19
Selecting a cooking zone and power setting 19
Switching the appliance off 20
Using the child lock 21
Timer 21
Power boost control 22
Power management 22
Pause 22
Flex zone 23
Sound on/off 24
Virtual ame on/off 25
Before using the cooktop 25
Cookware for induction cooking zones 26
Using the correct size cookware 27
Pot and pan sizes 27
Operating noises 27
Using suitable induction cookware 28
Temperature detection 28
Protecting the cooktop surface 29
Using the smart connect feature 29
Using the hood control feature 30
Maintaining your appliance 30
Care and cleaning of the glass cooktop 30
Troubleshooting 32
Troubleshooting 32
Information codes 34
Warranty (U.S.A) 34
Warranty (CANADA) 36
Appendix 37
Open source announcement 37
Model name & serial number 38
