Samsung NZ30K7880US User manual

Electric Cooktop
User manual
NZ30K7880U*
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 1 2018-03-09  12:08:33

2 English
Regulatory Notice
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 2 2018-03-09  12:08:33

English 3
Regulatory Notice
General safety instructions
This unit has been tested and found to comply with the limits for a class
B digital device, pursuant to Part 18 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This unit generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful interference to radio
or television reception, which can be determined by turning the unit off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorienting or relocating the receiving antennae.
• Increasing the distance between the unit and receiver.
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV.
2. IC Notice
The term "IC" before the radio certication number only signies
that Industry Canada technical specications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 3 2018-03-09  12:08:33

4 English
Contents
ContentsContents
Important safety instructions 5
Before you start 15
About induction cooktop cooking 15
Location of the induction cooktop elements and controls 16
Virtual ame technology 17
Magnetic Knob 18
Residual heat indicator 18
Cooking areas 18
Initial cleaning 19
Digital display 19
Safety shutoff 19
Operation 19
Switching the appliance on 19
Selecting a cooking zone and power setting 19
Switching the appliance off 20
Using the child lock 21
Timer 21
Power boost control 22
Power management 22
Pause 22
Flex zone 23
Sound on/off 24
Virtual ame on/off 25
Before using the cooktop 25
Cookware for induction cooking zones 26
Using the correct size cookware 27
Pot and pan sizes 27
Operating noises 27
Using suitable induction cookware 28
Temperature detection 28
Protecting the cooktop surface 29
Using the smart connect feature 29
Using the hood control feature 30
Maintaining your appliance 30
Care and cleaning of the glass cooktop 30
Troubleshooting 32
Troubleshooting 32
Information codes 34
Warranty (U.S.A) 34
Warranty (CANADA) 36
Appendix 37
Open source announcement 37
Model name & serial number 38
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 4 2018-03-09  12:08:33

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
Important safety instructions
Read and follow all instructions before using your cooktop to
prevent the risk of re, electric shock, personal injury, or damage
when using the cooktop. This guide does not cover all possible
conditions that may occur. Always contact your service agent or the
manufacturer about problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your cooktop.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your cooktop, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 5 2018-03-09  12:08:35

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
STATE OF CALIFORNIA PROPOSITION
65 WARNING US ONLY
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include cooktop, the cooktop facing, and
areas near the cooktop.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not store items of interest to children in cabinets above
the cooktop surface. Children climbing on the cooktop to
reach items could be seriously injured.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the cooktop to
avoid spreading the ames. Smother the re or ames or
use a dry chemical, baking soda, or foam-type extinguisher.
• Storage in or on the appliance. Do not store ammable
materials near the surface units. Be sure all packing
materials are removed from the appliance before operating
it. Keep plastics, clothes, and paper away from parts of the
appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not
let the potholder touch hot heating elements. Do not use a
towel or other bulky cloth.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 6 2018-03-09  12:08:35

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
SURFACE COOKING UNITS
• Never leave surface units unattended at high heat settings.
Boilovers cause smoking and greasy spillovers that may
ignite.
• Protective Liners – Do not use aluminum foil to line surface
unit drip bowls or oven bottoms, except as suggested in the
manual. Improper installation of these liners may result in a
risk of electric shock or re.
• Do not lift the cooktop. Lifting the cooktop can damage the
cooktop and cause the cooktop to malfunction.
• Never use the glass cooktop surface as a cutting board.
• Use care when touching the cooktop. The glass surface of
the cooktop will retain heat after the controls have been
turned off.
• Use proper pan sizes. This appliance is equipped with
surface units of different size. Select pots and pans that
have at bottoms large enough to cover the surface area of
the heating element. Using undersized cookware will expose
a portion of the heating element to direct contact and may
result in the ignition of clothing. Matching the size of the
pot or pan to the burner will also improve efciency.
• Teach children not to play with the controls or any other
part of the cooktop.
Be sure your appliance is properly installed and grounded by a
qualied technician.
• Avoid scratching or striking the cooktop. Doing so may lead
to glass breakage. Do not cook on a cooktop with broken
glass. Shock, re, or cuts may occur.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the cooktop.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualied
persons to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Do not lean on the cooktop as you may turn the control
knobs inadvertently.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 7 2018-03-09  12:08:35

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• Be careful when placing spoons or other stirring utensils
on the glass cooktop surface when it is in use. They may
become hot and could cause burns.
• Cleaning. Read and follow all instructions and warnings on
the cleaning cream labels.
• Be sure you know which control knob operates each surface
unit. Make sure you have turned on the correct surface unit.
• When preparing aming foods under the hood, turn the fan
on.
• Do not store heavy items above the cooktop surface that
could fall and damage it.
• Do not Use Decorative Surface Element Covers – If an
element is accidentally turned on, the decorative cover
will become hot and possibly melt. Burns will occur if the
hot covers are touched. Damage may also be done to the
cooktop.
• Appliance is not intended to be operated by means of an
external timer or separate remote-control system.
• Cookware Handles Should Be Turned Inward and Not
Extend Over Adjacent Surface Units – To reduce the risk
of burns, ignition of ammable materials, or spillage due
to unintentional contact with cookware, position cookware
handles so that they are turned inward and do not extend
over adjacent surface units.
• Glazed cookware. Only certain types of glass, glass/ceramic,
ceramic, earthenware, or other glazed cookware can be
used for rangetop service without breaking due to sudden
changes in temperature.
• Always turn the surface units off before removing cookware.
• Keep an eye on foods being fried at high or medium high
heat settings.
• To avoid oil spillover and re, use a minimum amount of oil
when shallow pan-frying and avoid cooking frozen foods
that have excessive amounts of ice.
• Do not operate the cooktop without cookware. If the
cooktop operates without cookware, the control knobs will
become hot.
• Do not move the container and bowl in a horizontal position
on cooktop surface.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 8 2018-03-09  12:08:35

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
WARNING
If the surface is cracked, switch off and unplug the appliance to avoid
the possibility of electrical shock. Do not use your cooktop until the
glass surface has been replaced.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children or inrm
persons without the adequate supervision of a responsible adult.
• Young children should be supervised to ensure that they do not
play with the appliance.
• The cooking zones will become hot when you cook. To keep small
children from being burned, always keep them away from the
appliance while you are cooking.
WARNING
Accessible parts may become hot during use. To avoid burns, young
children should be kept away.
ELECTRICAL SAFETY
Use factory installed exible cord to connect to power supply only,
do not use power supply cord kit.
• The cooktop should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals
may cause injury or a serious malfunction. If your appliance
is in need of repair, contact a Samsung authorized service
center. Failure to follow these instructions may result in
damage and void the warranty.
• Flush - mounted appliances may be operated only after they
have been installed in cabinets and workplaces that conform
to the relevant standards. This ensures that the appliances
are installed in compliance with the appropriate safety
standards.
• If your appliance malfunctions or if fractures, cracks, or
splits appear:
-switch off all cooking zones
-unplug the cooktop from the AC wall outlet
-contact your local Samsung service center.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 9 2018-03-09  12:08:35

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
Clean the cooktop with caution. If a wet sponge or cloth is used
to wipe spills on a hot cooking area, be careful to avoid steam
burns. Some cleaners can produce noxious fumes if applied to a
hot surface.
CRITICAL INSTALLATION WARNINGS
WARNING
• This appliance must be installed by a qualied technician or
service company.
-Failing to have a qualied technician install the cooktop
may result in electric shock, re, an explosion, problems
with the product, or injury.
• Unpack the cooktop, remove all packaging material and
examine the cooktop for any damage such as dents. If there
is any damage, do not operate the cooktop and notify your
dealer immediately.
• Plug the power cord into a properly grounded outlet with
the proper conguration. Your cooktop should be the only
item connected to this circuit.
• Keep all packaging materials out of the reach of children.
Children may use them for play and injure themselves.
VENTILATING HOOD
• Clean ventilating hoods frequently. Do not let grease
accumulate on the hood or lter.
• When aming foods under the hood, turn the fan on.
GLASS/CERAMIC COOKING SURFACES
• DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS.
Surface units may be hot even though they are dark in color.
Areas near surface units may become hot enough to cause
burns. During and after use, do not touch, or let clothing or
other ammable materials contact the surface units or areas
near the units until they have had sufcient time to cool.
Among these areas are the cook-top and the facing of the
cooktop.
• Do not cook on a broken cooktop. If the cooktop should
break, cleaning solutions and spillovers may penetrate the
broken cooktop and create a risk of electric shock. If your
cooktop breaks, contact an authorized Samsung service
center immediately.
NZ30K7880U_DG68-00823A-04_EN+MES+CFR.indb 10 2018-03-09  12:08:35
