Samsung CLX-9201 Series User manual

A3ColorCopier
CLX-9201/9251/9301series
CLX-9201ND/NA,
CLX-9251ND/NA,CLX-9301NA
(Ver3.2)
SERVICEMANUAL
A3ColorCopierContents
1.Precautions
2.ProductSpecicationsandDescription
3.DisassemblyandReassembly
4.Troubleshooting
5.SystemDiagram
6.ReferenceInformation
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precautions........................................................................................................................................1−1
1.1.Safetywarning..........................................................................................................................1−1
1.2.Cautionforsafety......................................................................................................................1−2
1.2.1.Toxicmaterial...............................................................................................................1−2
1.2.2.Electricshockandresafetyprecautions...........................................................................1−2
1.2.3.Handlingprecautions.....................................................................................................1−4
1.2.4.AssemblyandDisassemblyprecautions.............................................................................1−4
1.2.5.Disregardingthiswarningmaycausebodilyinjury..............................................................1−5
1.3.ESDprecautions........................................................................................................................1−6
2.ProductSpecicationsandDescription....................................................................................................2−1
2.1.ProductOverview......................................................................................................................2−1
2.2.Specications............................................................................................................................2−2
2.2.1.GeneralSpecication.....................................................................................................2−2
2.2.2.PrintSpecications........................................................................................................2−3
2.2.3.ControllerandSoftwarespecication................................................................................2−6
2.2.4.Scanspecication........................................................................................................2−10
2.2.5.Copyspecication.......................................................................................................2−12
2.2.6.Faxspecication.........................................................................................................2−14
2.2.7.PaperHandlingspecication..........................................................................................2−18
2.2.8.Supplies.....................................................................................................................2−21
2.2.9.MaintenanceParts.......................................................................................................2−21
2.2.10.Option.......................................................................................................................2−22
2.3.MachineExternalView.............................................................................................................2−24
2.4.FeedingSystem.......................................................................................................................2−28
2.4.1.FeedingSystemOverview.............................................................................................2−28
2.4.2.MainComponentsandfunctions....................................................................................2−29
2.4.3.Cassette(Tray1,2,3,4)..................................................................................................2−33
2.4.4.Pick-UpUnit..............................................................................................................2−34
2.4.5.RegistrationUnit.........................................................................................................2−35
2.4.6.MPF(Multi-PurposeFeeder)Unit...................................................................................2−36
2.5.ImageCreation........................................................................................................................2−37
2.5.1.Printingprocessoverview.............................................................................................2−37
2.5.2.ImagingUnit..............................................................................................................2−38
2.5.2.1.ImagingUnitOverview..................................................................................2−38
2.5.2.2.Drumdrive..................................................................................................2−39
2.5.2.3.DeveloperUnit.............................................................................................2−40
2.5.3.ITB(IntermediateTransferBelt)Unit..............................................................................2−42
2.5.3.1.ITBUnitoverview........................................................................................2−42
iCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
2.5.3.2.Transferbeltdrive.........................................................................................2−43
2.5.3.3.Transferbeltcleaning.....................................................................................2−44
2.6.Fuserunit...............................................................................................................................2−45
2.6.1.Fuserunitoverview.....................................................................................................2−45
2.6.2.FuserUnitdrive..........................................................................................................2−46
2.6.3.Fuserunittemperaturecontrol........................................................................................2−47
2.7.Laserscanningunit(LSU).........................................................................................................2−48
2.7.1.LSUoverview.............................................................................................................2−48
2.7.2.LaserScanningOpticalpath..........................................................................................2−49
2.7.3.Lasersynchronizingdetectors........................................................................................2−50
2.7.4.Automaticlinepositionadjustment.................................................................................2−51
2.7.5.ShutterMechanism......................................................................................................2−54
2.8.DriveSystem..........................................................................................................................2−55
2.8.1.DriveMotors..............................................................................................................2−55
2.8.2.MainDriveUnit(OPC,DEVE,ITB,T1DIS/ENG)...........................................................2−57
2.8.3.PickUpDrive.............................................................................................................2−58
2.8.4.Regi/MPDrive...........................................................................................................2−59
2.8.5.FeedDrive.................................................................................................................2−60
2.8.6.Fuser/ExitDrive..........................................................................................................2−61
2.8.7.WasteTonerContainerDrive.........................................................................................2−62
2.8.8.TonerSupplyDrive......................................................................................................2−62
2.9.ScannerSystem.......................................................................................................................2−63
2.9.1.ScannerSystemOverview.............................................................................................2−63
2.9.2.ScanningSystemComponents.......................................................................................2−63
2.10.DuplexAutomaticDocumentFeeder(DADF)................................................................................2−66
2.10.1.DADFoverview..........................................................................................................2−66
2.10.2.Electricalpartslocation................................................................................................2−67
2.10.3.DADFDriveSystem....................................................................................................2−68
2.10.3.1.DADFOriginalDriveAssembly......................................................................2−69
2.10.3.2.DADFRegistration(Regi)DriveAssembly........................................................2−70
2.10.3.3.DADFFeedDriveAssembly...........................................................................2−70
2.10.3.4.DADFExitDriveAssembly............................................................................2−71
2.10.3.5.OriginalReturnDrive....................................................................................2−71
2.11.HardwareConguration............................................................................................................2−72
2.11.1.MainController..........................................................................................................2−75
2.11.2.OperationPanel(OPE)controller...................................................................................2−79
2.11.3.ADFPBA..................................................................................................................2−82
2.11.4.SMPS(SwitchingModePowerSupply)board..................................................................2−83
2.11.5.FuserDriveBoard(FDB)..............................................................................................2−85
2.11.6.HVPSboard...............................................................................................................2−86
Copyright©1995-2013SAMSUNG.Allrightsreserved.ii

Contents
2.11.7.EraserPBA................................................................................................................2−87
2.11.8.FuserPBA.................................................................................................................2−87
2.11.9.WasteSensorPBA.......................................................................................................2−88
2.11.10.CRUMPBA...............................................................................................................2−88
2.11.11.DeveCRUMJointPBA...............................................................................................2−88
2.11.12.TonerCRUMJointPBA..............................................................................................2−89
2.11.13.ITBEncoderPBA.......................................................................................................2−89
2.11.14.ScanJointPBA...........................................................................................................2−90
2.11.15.ChargeCoupledDeviceModule(CCDM)PBA..................................................................2−91
2.11.16.White-LED(WLED)CTLPBA......................................................................................2−92
2.11.17.White-LED(WLED)ALFRONTPBA............................................................................2−92
2.12.DCFUnit...............................................................................................................................2−93
2.13.Finisher.................................................................................................................................2−99
2.14.WirelessLANOption.............................................................................................................2−102
3.DisassemblyandReassembly................................................................................................................3−1
3.1.Precautionswhenreplacingparts..................................................................................................3−1
3.1.1.Precautionswhenassemblinganddisassembling.................................................................3−1
3.1.2.PrecautionswhenhandlingPBA.......................................................................................3−1
3.1.3.ReleasingPlasticLatches................................................................................................3−2
3.2.Maintenance.............................................................................................................................3−3
3.2.1.MachineCleaningformaintenance...................................................................................3−3
3.2.1.1.CleaningtheACR/CTDsensorwindow...............................................................3−3
3.2.1.2.CleaningtheLSUwindow................................................................................3−4
3.2.1.3.Cleaningthetransferroller................................................................................3−5
3.2.1.4.Cleaningthescanglass.....................................................................................3−5
3.2.2.Replacingthemaintenancepart........................................................................................3−6
3.2.2.1.DrumUnit.....................................................................................................3−6
3.2.2.2.DeveloperUnit...............................................................................................3−7
3.2.2.3.ITBCleaner...................................................................................................3−9
3.2.2.4.ITBUnit........................................................................................................3−9
3.2.2.5.Fuserunit....................................................................................................3−11
3.2.2.6.Transferroller...............................................................................................3−11
3.2.2.7.Pick-Up_Reverse_Forwardroller.....................................................................3−12
3.2.2.8.MPPickup_Reverse_Forwardroller.................................................................3−13
3.2.2.9.DADFPick-uprollerAssy..............................................................................3−14
3.2.2.10.DADFfrictionpad........................................................................................3−14
3.3.ReplacingthemainSVCpart.....................................................................................................3−15
3.3.1.LeftCover..................................................................................................................3−15
3.3.2.RearCover.................................................................................................................3−15
3.3.3.HVPSboard...............................................................................................................3−16
iiiCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
3.3.4.TemperatureSensor.....................................................................................................3−16
3.3.5.LSU..........................................................................................................................3−17
3.3.6.OPEUnit...................................................................................................................3−18
3.3.7.Mainboard.................................................................................................................3−21
3.3.8.SMPSFan..................................................................................................................3−22
3.3.9.SMPSboard...............................................................................................................3−23
3.3.10.FDBboard.................................................................................................................3−23
3.3.11.Fuser-DuctFan...........................................................................................................3−24
3.3.12.Mainboardshield........................................................................................................3−24
3.3.13.MainDriveunit...........................................................................................................3−25
3.3.14.Fuser/ExitDriveunit....................................................................................................3−25
3.3.15.Pick-upDriveunit.......................................................................................................3−26
3.3.16.FeedDriveunit...........................................................................................................3−26
3.3.17.Regi_MPDriveunit.....................................................................................................3−27
3.3.18.TonerSupplyDriveunit................................................................................................3−27
3.3.19.WastetonercontainerDriveunit.....................................................................................3−28
3.3.20.AutoSizesensor.........................................................................................................3−28
3.3.21.ExitUnit....................................................................................................................3−29
3.3.22.SideUnit...................................................................................................................3−30
3.3.22.1.Fuseroutsensor............................................................................................3−31
3.3.22.2.DuplexsensorandCurlsensor.........................................................................3−32
3.3.22.3.MPunit.......................................................................................................3−33
3.3.23.Fuserunit...................................................................................................................3−37
3.3.24.Pick-upUnitandsensor................................................................................................3−40
3.3.25.Feedsensor................................................................................................................3−40
3.3.26.FeedUnit...................................................................................................................3−41
3.3.27.RegistrationUnit.........................................................................................................3−42
3.3.28.DADFUnit................................................................................................................3−43
3.3.28.1.DADFCover................................................................................................3−44
3.3.28.2.DADFOpenCover........................................................................................3−46
3.3.28.3.DADFStacker..............................................................................................3−46
3.3.28.4.DADFmainboard.........................................................................................3−46
3.3.28.5.DADFmotor_solenoid_clutch.........................................................................3−47
3.3.28.6.DADFRegi_Cover_Detectsensor....................................................................3−49
3.3.28.7.DADFExitIdlesensor...................................................................................3−49
3.3.28.8.DADFExitsensor.........................................................................................3−50
3.3.28.9.DADFLength_Widthsensor...........................................................................3−50
3.3.29.ScannerUnit...............................................................................................................3−51
3.3.29.1.Scannerjointboard........................................................................................3−51
3.3.29.2.Scanglass....................................................................................................3−52
Copyright©1995-2013SAMSUNG.Allrightsreserved.iv

Contents
3.3.29.3.APSsensor..................................................................................................3−53
3.3.29.4.FRmodule...................................................................................................3−54
3.3.29.5.ScannerAssy................................................................................................3−55
3.3.30.SideCoverOpenSwitch...............................................................................................3−56
3.3.31.FrontCoverOpenSwitch..............................................................................................3−56
3.3.32.ReplacingtheHDD......................................................................................................3−57
3.3.33.DCF(DoubleCassetteFeeder).......................................................................................3−58
3.3.33.1.DCFmainboard...........................................................................................3−58
3.3.33.2.DCFFeedMotor...........................................................................................3−59
3.3.33.3.DCFPickUpMotor.......................................................................................3−59
3.3.34.Finisher.....................................................................................................................3−60
3.3.34.1.FinisherMainMotor......................................................................................3−60
3.3.34.2.FinisherBoard..............................................................................................3−63
4.Troubleshooting..................................................................................................................................4−1
4.1.Controlpanel............................................................................................................................4−1
4.1.1.Introducingthedisplayscreenandusefulbuttons................................................................4−2
4.2.UnderstandingthestatusLED......................................................................................................4−4
4.3.UpdatingFirmware....................................................................................................................4−5
4.3.1.UpdatingfromthePrinterControlPanel............................................................................4−5
4.3.2.UpdatingfromtheNetwork............................................................................................4−7
4.4.ServiceMode(TechMode)........................................................................................................4−10
4.4.1.Entering/ExitingServiceMode......................................................................................4−10
4.4.2.ServiceModeMenuTree.............................................................................................4−11
4.4.3.Information................................................................................................................4−15
4.4.3.1.General.......................................................................................................4−15
4.4.3.2.SupplyStatus...............................................................................................4−15
4.4.3.3.SoftwareVersion...........................................................................................4−16
4.4.3.4.ServiceHours...............................................................................................4−16
4.4.3.5.FaultLog.....................................................................................................4−16
4.4.3.6.PrintReports................................................................................................4−17
4.4.3.7.ExportReports..............................................................................................4−18
4.4.4.MaintenanceCounts.....................................................................................................4−19
4.4.4.1.FaultCount.................................................................................................4−19
4.4.4.2.JamCount...................................................................................................4−19
4.4.4.3.PartReplacementCount.................................................................................4−20
4.4.4.4.FinisherHandlingCount.................................................................................4−21
4.4.5.Diagnostics................................................................................................................4−22
4.4.5.1.EngineDiagnostics........................................................................................4−22
4.4.5.2.FaxDiagnostics............................................................................................4−28
4.4.5.3.ScannerDiagnostics.......................................................................................4−30
vCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
4.4.5.4.Adjustment..................................................................................................4−32
4.4.5.5.ACS(AutoColorSensing).............................................................................4−38
4.4.5.6.ImageManagement......................................................................................4−39
4.4.6.ServiceFunctions........................................................................................................4−44
4.4.6.1.MainMemoryClear......................................................................................4−44
4.4.6.2.HardDiskMaintenance..................................................................................4−44
4.4.6.3.CountSettingofLargePage...........................................................................4−44
4.4.6.4.TonerSave..................................................................................................4−44
4.4.6.5.Port............................................................................................................4−45
4.4.6.6.DebugLog...................................................................................................4−45
4.4.6.7.CaptureLog.................................................................................................4−45
4.4.6.8.SystemRecovery..........................................................................................4−47
4.4.6.9.TRControlMode.........................................................................................4−50
4.4.6.10.UserDataManagement.................................................................................4−51
4.4.7.SFE(SpecialFeatureEnablement)..................................................................................4−52
4.5.ErrorCodeandTroubleshooting.................................................................................................4−53
4.5.1.Ax-xxxxtypeerrorcode...............................................................................................4−63
4.5.2.Cx-xxxxtypeerrorcode...............................................................................................4−89
4.5.3.H1-xxxxtype(DCF)errorcode....................................................................................4−119
4.5.4.H2-xxxx(Finisher)typeerrorcode...............................................................................4−131
4.5.5.Mx-xxxxtypeerrorcode.............................................................................................4−144
4.5.6.Sx-xxxxtypeerrorcode..............................................................................................4−164
4.5.7.U1-xxxxtype(Fuser)errorcode...................................................................................4−184
4.5.8.U2-xxxxtype(LSU)errorcode....................................................................................4−196
4.5.9.U3-xxxxtypeerrorcode.............................................................................................4−199
4.6.Imagequalityproblemsandsolutions........................................................................................4−204
4.6.1.VerticalBlackBand...................................................................................................4−207
4.6.2.VerticalWhiteBand,LightBand..................................................................................4−208
4.6.3.HorizontalperiodicBlackBandorDot..........................................................................4−210
4.6.4.HorizontalperiodicLight/DarkBandorDot...................................................................4−211
4.6.5.FoggyImage............................................................................................................4−212
4.6.6.LightImage..............................................................................................................4−213
4.6.7.BlurredImage...........................................................................................................4−214
4.6.8.Incorrectcolorregistration.........................................................................................4−215
4.6.9.Unevenpitchandjitterimage......................................................................................4−216
4.6.10.Skewedimage...........................................................................................................4−217
4.6.11.Blankcopy...............................................................................................................4−218
4.6.12.Poorfusingperformance.............................................................................................4−219
4.6.13.Stainonthepaperbackside.........................................................................................4−220
4.7.AdjustingtheLSUskewerror..................................................................................................4−221
Copyright©1995-2013SAMSUNG.Allrightsreserved.vi

Contents
4.8.AdjustingtheDADFskew.......................................................................................................4−223
4.9.TroubleshootingGuide...........................................................................................................4−224
5.SystemDiagram..................................................................................................................................5−1
6.ReferenceInformation..........................................................................................................................6−1
6.1.ToolsforTroubleshooting............................................................................................................6−1
6.2.Glossary...................................................................................................................................6−3
6.3.PolarisTrainingFrequentlyAskedQuestions..................................................................................6−9
viiCopyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.Precautions
Inordertopreventaccidentsanddamagestotheequipmentpleasereadtheprecautionslistedbelowcarefullybefore
servicingtheproductandfollowthemclosely.
1.1.Safetywarning
1)Onlytobeservicedbyafactorytrainedservicetechnician.
Highvoltagesandlasersinsidethisproductaredangerous.Thisproductshouldonlybeservicedbyafactorytrained
servicetechnician.
2)UseonlySamsungreplacementparts.
Therearenouserserviceablepartsinsidetheproduct.Donotmakeanyunauthorizedchangesoradditionstothe
productasthesecouldcausetheproducttomalfunctionsandcreateanelectricshocksorrehazards.
3)LaserSafetyStatement
TheprinteriscertiedintheU.S.toconformtotherequirementsofDHHS21CFR,chapter1SubchapterJfor
ClassI(1)laserproducts,andelsewhereiscertiedasaClassIlaserproductconformingtotherequirementsofIEC
60825-1.ClassIlaserproductsarenotconsideredtobehazardous.Thelasersystemandprinteraredesignedso
thereisneveranyhumanaccesstolaserradiationaboveaClassIlevelduringnormaloperation,usermaintenance
orprescribedservicecondition.
•Wavelength:800nm
•Beamdivergence
-Paraller:11degrees
-Perpendicular:35degrees
•Maximumpowerofenergyoutput:12mW
WARNING
NeveroperateorservicetheproductwiththeprotectivecoverremovedfromLaser/Scannerassembly.Thereected
beam,althoughinvisible,candamageyoureyes.
Whenusingthisproduct,thesebasicsafetyprecautionsshouldalwaysbefollowedtoreduceriskofre,electric
shock,andpersonalinjury.
4)Lithiumbatterynotreplaceablebyuser
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-1

1.Precautions
1.2.Cautionforsafety
1.2.1.Toxicmaterial
Thisproductcontainstoxicmaterialsthatcouldcauseillnessifingested.
1)Pleasekeepimagingunitandtonercartridgeawayfromchildren.Thetonerpowdercontainedintheimagingunitand
tonercartridgemaybeharmful,andifswallowed,youshouldcontactadoctor.
1.2.2.Electricshockandresafetyprecautions
Failuretofollowthefollowinginstructionscouldcauseelectricshockorpotentiallycauseare.
1)Useonlythecorrectvoltage,failuretodosocoulddamagetheproductandpotentiallycauseareorelectricshock.
2)Useonlythepowercablesuppliedwiththeproduct.Useofanincorrectlyspeciedcablecouldcausethecableto
overheatandpotentiallycauseare.
3)Donotoverloadthepowersocket,thiscouldleadtooverheatingofthecablesinsidethewallandcouldleadtoare.
4)Donotallowwaterorotherliquidstospillintotheproduct,thiscancauseelectricshock.Donotallowpaperclips,pins
orotherforeignobjectstofallintotheproduct,thesecouldcauseashortcircuitleadingtoanelectricshockorrehazard.
5)Nevertouchtheplugsoneitherendofthepowercablewithwethands,thiscancauseelectricshock.Whenservicing
theproduct,removethepowerplugfromthewallsocket.
6)Usecautionwheninsertingorremovingthepowercord.Whenremovingthepowercord,gripitrmlyandpull.The
powercordmustbeinsertedcompletely,otherwiseapoorcontactcouldcauseoverheatingleadingtoare.
7)Takecareofthepowercable.Donotallowittobecometwisted,bentsharplyaroundcornersorpowercablemaybe
damaged.Donotplaceobjectsontopofthepowercable.Ifthepowercableisdamageditcouldoverheatandcausea
re.Exposedcablescouldcauseanelectricshock.Replacethedamagedpowercableimmediately,donotreuseor
repairthedamagedcable.Somechemicalscanattackthecoatingonthepowercable,weakeningthecoverorexposing
cablescausingreandshockrisks.
1-2Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
8)Ensurethatthepowersocketsandplugsarenotcrackedorbrokeninanyway.Anysuchdefectsshouldberepaired
immediately.Takecarenottocutordamagethepowercableorplugswhenmovingthemachine.
9)Usecautionduringthunderorlightningstorms.Samsungrecommendsthatthismachinebedisconnectedfromthe
powersourcewhensuchweatherconditionsareexpected.Donottouchthemachineorthepowercordifitisstill
connectedtothewallsocketintheseweatherconditions.
10)Avoiddampordustyareas,installtheproductinacleanwellventilatedlocation.Donotpositionthemachineneara
humidierorinfrontofanairconditioner.Moistureanddustbuiltupinsidethemachinecanleadtooverheatingand
causeareorcausepartstorust.
11)Donotpositiontheproductindirectsunlight.Thiswillcausethetemperatureinsidetheproducttorisepossiblyleading
totheproductfailingtoworkproperlyandinextremeconditionscouldleadtoare.
12)Donotinsertanymetalobjectsintothemachinethroughtheventilatorfanorotherpartofthecasing,itcouldmake
contactwithahighvoltageconductorinsidethemachineandcauseanelectricshock.
13)WhenreplacingtheSMPSboard,pleasewait5minutesafterunpluggingthepowercord,thenreplaceit.Y ou
cangetashockbytheelectricdischarge.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-3

1.Precautions
1.2.3.Handlingprecautions
Thefollowinginstructionsareforyourownpersonalsafetytoavoidinjuryandsoasnottodamagetheproduct.
1)Ensuretheproductisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcause
theproducttotiporfall.
2)Theproductcontainsmanyrollers,gearsandfans.Takegreatcaretoensurethatyoudonotcatchyourngers,hairor
clothinginanyoftheserotatingdevices.
3)Donotplaceanysmallmetalobjects,containersofwater,chemicalsorotherliquidsclosetotheproductwhichifspilled
couldgetintothemachineandcausedamageorashockorrehazard.
4)Donotinstallthemachineinareaswithhighdustormoisturelevels,besideonopenwindoworclosetoahumidieror
heater.Damagecouldbecausedtotheproductinsuchareas.
5)Donotplacecandles,burningcigarettes,etcontheproduct,Thesecouldcauseare.
6)Ensurethatthemachineisinstalledandusedinproperareatomeetthetemperatureandhumidityspecications.
•IfthemachineisstoredatbelowzeroCelsiusforalongtime,donotusethemachineinstantlyaftermovement.It
canmalfunction.Takecareofthemachinestorage.IfthemachineisstoredatbelowzeroCelsiusforalongtime,
keepthemachineatroomtemperatureandinstallit.
1.2.4.AssemblyandDisassemblyprecautions
1)ReplacepartscarefullyandalwaysuseSamsungparts.Takecaretonotetheexactlocationofpartsandalsocable
routingbeforedismantlinganypartofthemachine.Ensureallpartsandcablesarereplacedcorrectly.Pleasecarryout
thefollowingproceduresbeforedismantlingtheproductorreplacinganyparts.
2)Ensurethatpowerisdisconnectedbeforeservicingorreplacinganyelectricalparts.
3)Disconnectinterfacecablesandpowercables.
4)Onlyuseapprovedspareparts.Ensurethatpartnumber,productname,anyvoltage,currentortemperaturerating
arecorrect.
5)Whenremovingorre-ttinganypartsdonotuseexcessiveforce,especiallywhenttingscrewsintoplastic.
6)Takecarenottodropanysmallpartsintothemachine.
7)HandlingoftheOPCDrum
•TheOPCDrumcanbeirreparablydamagedifitexposedtolight.TakecarenottoexposetheOPCDrumeither
todirectsunlightortouorescentorincandescentroomlighting.Exposureforaslittleas5minutescandamage
thesurfaceofthephotoconductivepropertiesandwillresultinprintqualitydegradation.Takeextracarewhen
servicingtheproduct.RemovetheOPCDrumandstoreitinablackbagorotherlightproofcontainer.Take
carewhenworkingwiththeCovers(especiallythetopcover)openaslightisadmittedtotheOPCareaandcan
damagetheOPCDrum.
•TakecarenottoscratchthegreensurfaceofOPCDrumUnit.IfthegreensurfaceoftheDrumCartridgeis
scratchedortouchedtheprintqualitywillbecompromised.
1-4Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.2.5.Disregardingthiswarningmaycausebodilyinjury
1)Becarefulwiththehightemperaturepart.
Thefuserunitworksatahightemperature.Usecautionwhenworkingontheprinter.Waitforthefuserunitto
cooldownbeforedisassembly.
2)Donotputngersorhairintotherotatingparts.
Whenoperatingaprinter,donotputhandorhairintotherotatingparts(Paperfeedingentrance,motor,fan,etc.).
Ifdo,youcangetharm.
3)Whenyoumovetheprinter,usesafeliftingandhandlingtechniques.
Thisprinterisheavy.Usetheliftinghandleslocatedoneachsideofthemachine.Backinjurycouldbecausedif
youdonotliftcarefully.
4)Ensuretheprinterisinstalledsafely.
Ensuretheprinterisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcausethe
printertotiporfallpossiblycausingpersonalinjuryordamagingtheprinter.
5)Donotinstalltheprinteronaslopingorunstablesurface.Afterinstallation,doublecheckthattheprinterisstable.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-5

1.Precautions
1.3.ESDprecautions
Certainsemiconductordevicescanbeeasilydamagedbystaticelectricity.Suchcomponentsarecommonlycalled
“ElectrostaticallySensitive(ES)Devices”orESDs.ExamplesoftypicalESDsare:integratedcircuits,someeldeffect
transistors,andsemiconductor“chip”components.Thetechniquesoutlinedbelowshouldbefollowedtohelpreducethe
incidenceofcomponentdamagecausedbystaticelectricity.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
1)Immediatelybeforehandlingasemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,employacommerciallyavailable
wriststrapdevice,whichshouldberemovedforyourpersonalsafetyreasonspriortoapplyingpowertotheunit
undertest.
2)AfterremovinganelectricalassemblyequippedwithESDs,placetheassemblyonaconductivesurface,suchas
aluminumorcopperfoil,orconductivefoam,topreventelectrostaticchargebuildupinthevicinityoftheassembly.
3)UseonlyagroundedtipsolderingirontosolderordesolderESDs.
4)Useonlyan“anti-static”solderremovaldevice.Somesolderremovaldevicesnotclassiedas“anti-static”can
generateelectricalchargessufcienttodamageESDs.
5)DonotuseFreon-propelledchemicals.Whensprayed,thesecangenerateelectricalchargessufcienttodamageESDs.
6)DonotremoveareplacementESDfromitsprotectivepackaginguntilimmediatelybeforeinstallingit.Most
replacementESDsarepackagedwithallleadsshortedtogetherbyconductivefoam,aluminumfoil,oracomparable
conductivematerial.
7)ImmediatelybeforeremovingtheprotectiveshortingmaterialfromtheleadsofareplacementESD,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
8)MaintaincontinuouselectricalcontactbetweentheESDandtheassemblyintowhichitwillbeinstalled,until
completelypluggedorsolderedintothecircuit.
9)MinimizebodilymotionswhenhandlingunpackagedreplacementESDs.Normalmotions,suchasthebrushingtogether
ofclothingfabricandliftingone’sfootfromacarpetedoor,cangeneratestaticelectricitysufcienttodamageanESD.
1-6Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.ProductSpecicationsandDescription
2.1.ProductOverview
•PrintingSpeed(Mono/Color)
•CLX-9301series
-Upto30ppminA4(30ppminLetter)
-Upto15ppminA3(15ppmin11x17)
•CLX-9251series
-Upto25ppminA4(25ppminLetter)
-Upto13ppminA3(13ppmin11x17)
•CLX-9201series
-Upto20ppminA4(20ppminLetter)
-Upto10ppminA3(10ppmin11x17)
•Processor
•DualCore1GHz
•Memory
•1GBDDR3SDRAM
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-1

2.ProductSpecicationsandDescription
2.2.Specications
ProductSpecicationsaresubjecttochangewithoutnotice.
2.2.1.GeneralSpecication
ItemSpeccation
Conguration•NDmodel:Platencovermodel.
•NAmodel:DADFmodel.
Operating10to32°C(50to90°F)
TemperatureStorage-20to40°C(-4to104°F)
Operating20to80%RH
HumidityStorage10to90%RH
PrintingSimplex/
Duplex
•CLX-9301series:50/52dB
•CLX-9251series:49/51dB
•CLX-9201series:48/50dB
CopyingSimplex/
Duplex
•CLX-9301series:53/55dB
•CLX-9251series:53/55dB
•CLX-9201series:53/55dB
Standby(Fuseroff)30dB
AcousticNoise
Level(Sound
Power/Pressure)
Sleep27dB
Europe:AC220-240V(-10%~6%)/4A
USA:AC110~127V(-10%~6%)/10A InputV oltage
Korea:AC220-240V(-10%~6%)/4A
PowerSupply
RatedFrequency50/60Hz
Ready100Watt
A VG.(Normal
Operation)800Watt
Max/Peak<1500Wattmax
Power
Consumption
Sleep/PowerOff3Watt/0Watt
Dimension(WxD
xH)Set(mm)
•560x600x787.3mm(22x23.6x31inches)(includesPlatenCover)
•560x600x844.3mm(22x23.6x33.2inches)(includesDADF)
•560x600x1046.6mm(22x23.6x41.2inches)(includesPlatenCover,
Stand)
•560x600x1106.3mm(22x23.6x43.6inches)(includesDADF,DCF)
WeightSet(Kg)
•Basicmachine(includesdeveloperunit):67.6Kg(149lb)
•PlatenCover:2.4Kg(5.3lb)
•DADF:4.9Kg(10.8lb)
•DCF:19.5Kg(43lb)
•Stand:12Kg(26.5lb)
•JobSeparator:1.5Kg(3.3lb)
•InnerFinisher:8.5Kg(18.7lb)
•DrumUnitandTonerCartridges:6.5Kg(14.3lb)
2-2Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
ItemSpeccation
Recommended
PrintingV olume
(AMPV)
•CLX-9301series:7,500sheets/month
•CLX-9251series:5,000sheets/month
•CLX-9201series:3,500sheets/month
Reliability&
Service
Max.Monthly
PrintV olume
100,000sheets/month
2.2.2.PrintSpecications
ItemSpecication
Simplex
•CLX-9301series
•B&W:Upto30ppminA4(30ppminLetter)
•Color:Upto30ppminA4(30ppminLetter)
•B&W:Upto15ppminA3(15ppmin11X17)
•Color:Upto15ppminA3(15ppmin11X17)
•CLX-9251series
•B&W:Upto25ppminA4(25ppminLetter)
•Color:Upto25ppminA4(25ppminLetter)
•B&W:Upto13ppminA3(13ppmin11X17)
•Color:Upto13ppminA3(13ppmin11X17)
•CLX-9201series
•B&W:Upto20ppminA4(20ppminLetter)
•Color:Upto20ppminA4(20ppminLetter)
•B&W:Upto10ppminA3(10ppmin11X17)
•Color:Upto10ppminA3(10ppmin11X17)
EngineSpeed
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-3

2.ProductSpecicationsandDescription
ItemSpecication
Duplex
•CLX-9301series
•[Basic(Without2ndEXIT)]
-B&W:Upto21ipminA4(21ipminLetter)
-Color:Upto21ipminA3(21ipmin11×17)
-B&W:Upto11ipminA4(11ipminLetter)
-Color:Upto11ipminA3(11ipmin11×17)
•[With2ndEXIT(Option)]
-B&W:Upto30ipminA4(30ipminLetter)
-Color:Upto30ipminA3(30ipmin11×17)
-B&W:Upto11ipminA4(11ipminLetter)
-Color:Upto11ipminA3(11ipmin11×17)
•CLX-9251series
•[Basic(Without2ndEXIT)]
-B&W:Upto17ipminA4(17ipminLetter)
-Color:Upto17ipminA3(17ipmin11×17)
-B&W:Upto9ipminA4(9ipminLetter)
-Color:Upto9ipminA3(9ipmin11×17)
•[With2ndEXIT(Option)]
-B&W:Upto25ipminA4(25ipminLetter)
-Color:Upto25ipminA3(25ipmin11×17)
-B&W:Upto9ipminA4(9ipminLetter)
-Color:Upto9ipminA3(9ipmin11×17)
•CLX-9201series
•[Basic(Without2ndEXIT)]
-B&W:Upto14ipminA4(14ipminLetter)
-Color:Upto14ipminA3(14ipmin11×17)
-B&W:Upto7ipminA4(7ipminLetter)
-Color:Upto7ipminA3(7ipmin11×17)
•[With2ndEXIT(Option)]
-B&W:Upto20ipminA4(20ipminLetter)
-Color:Upto20ipminA3(20ipmin11×17)
-B&W:Upto7ipminA4(7ipminLetter)
-Color:Upto7ipminA3(7ipmin11×17)
FromReady
•CLX-9301series:Lessthan9/11sec(B&W/Color)
•CLX-9251series:Lessthan9.5/11.5sec(B&W/Color)
•CLX-9201series:Lessthan10/12.5sec(B&W/Color)
FromSleep
•CLX-9301series:Lessthan27/29sec(B&W/Color)
•CLX-9251series:Lessthan28/30sec(B&W/Color)
•CLX-9201series:Lessthan29/31sec(B&W/Color)
FPOT(B&Wand
Color)
FromColdbootLessthan100/100sec(B&W/Color)
Optical600x600dpi
ResolutionEnhanced
•Normal:2400*600dpiEffectiveOutput(600x600x2bit)
•Best:9600*600dpiEffectiveOutput(600x600x4bit)
•HighQuality:Real1200*1200dpi
2-4Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
ItemSpecication
PrinterLanguagesPCL5Ce,PCL6Ce,PostScriptLevel3C,TIFF,PDF1.4,JPEG
FontsPCL:93scalable,1bitmap,OCR-A,OCR-B,PS:136
DownloadableFontsYes(PCL&PS3S/WFont)
SecurePrintingYes
Delayed
(Shceduled)
Printing
No
ProofprintingNo
SpoolYes
StoredPrintingYes
PrintJob(with
HDD)
FormoverlaysNo
USBMemoryDirectPrintJpeg,Tiff,PDF,SamsungPRN,TXT
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-5

2.ProductSpecicationsandDescription
2.2.3.ControllerandSoftwarespecication
ItemSpecication
MPUChorus4NDualCore1GHz
ProcessorImageProcessorEmbeddedinChorus4N
Std.1GBDDR3SDRAM
DRAMMax.1GBDDR3SDRAM
MemoryExpansionN.A.
Storage
320GBHDDStandard
NOTE
HDDPartitionMap
-Mandatory,157GBforusers,EXT3lesystem
HDD_DOCpartitionisavailablefortheuserdatastorage.
[Windows]
•Windows2000/XP(32/64bit)/2003(32/64bit)/Vista(32/64bit)/2008/Win7/
2008R2(64only)
[Linux]
•RedHatEnterpriseLinuxWS4,5(32/64bit)
•Fedora5,6,7,8,9,10,11,12,13(32/64bit)
•SuSELinux10.1(32bit)
•OpenSuSE10.210.3,11.0,11.1,11.2(32/64bit)
•Mandriva2007,2008,2009,2009.1,2010(32/64bit)
•Ubuntu6.06,6.10,7.04,7.10,8.048.10,9.04,9.10,10.04(32/64bit)
•SuSELinuxEnterpriseDesktop10,11(32/64bit)
•Debian4.0,5.0(32/64bit)
SupportingOS
[Mac]
•MacOSX10.5~10.7
DefaultDriverPCL6(ForWindows),PS(forMac,Linux)
Printerdriver
2-6Copyright©1995-2013SAMSUNG.Allrightsreserved.
