Samsung SRD-442 User manual

4 CHANNEL DVR
Quick Guide
English
SRD-442

2_ English
Before starting
Please take note of the followings before using this product.
• Do not use the product outdoor.
• Do not spill water or liquid in the connection part of the product.
• Do not impose the system to excessive shock or force.
• Do not pull out the power plug forcefully.
• Do not disassemble the product on your own.
• Do not exceed the rated input/output range.
• Use a certified power cord only.
• For the product with an input ground, use a grounded power plug.
Package Contents
Please unwrap the product, and place the product on a flat place or in the place to be installed.
Check if the main unit and all the following accessories are included in the product package.
3
2
1
4
MODE
USB
MENU
PLAY
STOP
SEARCH
REC
DVR Adapter Power Cable
Mouse Remote Control / Battery (AAA x 2) Network Viewer Software /
User Manual CD
User Manual (optional) Quick Guide (optional) Terminal Block
HDD Fixing Screw

English _3
Wiring diagram for external devices
Recording Schedule
1. Press the [MENU] button on the remote control.
2. Use the left/right button (
_ + ) to select <Record>.
Record menu is selected.
3. Use the up/down buttons (
▲▼ ) to move to <Recording
Schedule>, and press [ENTER] button.
4. A window of scheduled recording setup appears.
5. Use direction buttons (
▲▼_ + ) to move to a desired item, and
set the value.
• Apply to All CH : If selected <Apply to All CH>, “Apply to All CH”
window appears.
Press <OK> to apply the setup to all channels.
6. When the recording schedule setup is done, press <OK>.
Record
Logout Return
Recording Schedule
Event Record Duration
REC Quality & Resolution
Record Option
All 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23
Sun
Mon
Tue
Wed
Thu
Fri
Sat
Hol
No Recording Continuous Event
Both(Cont&Evnt)
Apply to All CH
OK Cancel
Recording Schedule
CH1
VIDEO OUT
(SPOT)
SERIAL
VGA
NETWORK
1 2
USB
CONSOLE DC 12V
AUDIO IN
AUDIO OUT
VIDEO IN
34GG1COM
ALARM
IN
ALARM
OUT
RS-485

4_ English
Event Record Duration
1. Use the up/down buttons ( ▲▼ ) in <Record> window to move to
<Event Record Duration>, and press [ENTER] button.
2. Use direction buttons (
▲▼_ + ) to move to a desired item, and
set the value.
•
Pre Event : The recording of an event will start at a pre-determined time
prior to the actual occurrence of the event.
If it is set to 5 seconds, the recording begins from 5 seconds before
the event.
• POST Event : The recording will continue for a pre-determined time
after the actual end of an event.
If it is set to 5 seconds, the recording ends in 5 seconds after an
event.
3. When the event recording duration setup is done, press <OK>.
Setting the Backup
1. Press the [MENU] button on the remote control.
2. Use the left/right button (
_ + ) to select <Backup>.
Backup menu is selected.
3. Press the [ENTER] button.
A backup window appears.
You can directly access it from the “Live screen menu”.
4. Use direction buttons (
▲▼_ + ) to move to a desired item, and
set the value.
5. When the backup setup is done, press <OK>.
`If no available device is recognized for backup, <OK> button is not activated.
Backup
1. Select a data item and click <Play> in the Search menu.
The selected data is played and the play launcher appears on the
screen.
2. Click < > to set the current time to the start time of backup;
you can specify a backup area using the mouse (yellow triangle).
3. Click < > again to set the current time to the end time of the
backup and the “Backup Range” window appears.
4.
If you want to return to the Live screen in Play mode, click < >
in the launcher menu or press the [
@
] button on the remote control.
Event Record Duration
OK Cancel
CH Pre Event POST Event 
1 OFF 1 min 
2 OFF 1 min 
3 OFF 1 min 
4 OFF 1 min 
Backup
Used
Free
Check capacity
OK Cancel
Backup
Start End
2012-01-01 00:01:06 ~ 2012-01-01 08:25:45
Overlap List0
Device USB-Storage Type DVR
Folder \20120101\ Filename 0001
1 2 3 4All
Change
Backup 0
Used 0
Free 0
Check capacity
OK Cancel
Backup Range
Start End
2012-01-01 00:01:06 2012-01-01 01:10:25
Device USB Storage Type DVR
Folder \20120101\ Filename 0001 Change
2012-01-01 01:10:25
REC

English _5
Network Connection
Port forwarding
1. Check the “Default Gateway” from the network properties of the
PC connected through the router.
2. From <Network> - <Connection Mode>, select <Connection>.
A window of connection mode setup appears.
3. Use direction buttons (
▲▼_ + ) to move to a desired item, and
set the value.
4. Enter the gateway address found in step 1 into the browser’s
address field to display the router settings.
5. Select the “Advanced” tab in the “Virtual Server” menu, enter the
IP address and port and click the <Apply> button.
M `Above instructions are based on D-LINK DI-624 router. Port forwarding
setup may differ from the router’s manufacturer.
REC
Connection Mode
Connection Protocol
Connection Mode Static IP
Bandwidth 2Mbps
OK Cancel
IP 192.168. 1.200
Gateway 192.168. 1. 1
Subnet Mask 255.255.255. 0
DNS Manual 168.126. 63. 1
SERIAL
VGA
NETWORK
1 2
USB DC 12V
AUDIO IN
AUDIO OUTVIDEO OUT
(SPOT)
VIDEO IN
3 4 GG 1 COM
ALARM
IN
ALARM
OUT
RS-485
CONSOLE
Local PC
Broadband
Router or HUB Broadband Modem
Remote PC
Internet
