Business-Class 23.6" Desktop Monitor with
Improved Panel Technology
One glimpse of the Samsung S24C650PL is all it takes to change your
perception of what a business desktop monitor can be. With upgraded
panel technology, the S24C650PL delivers more accurate color. It’s a more
true-to-life visual experience, even when viewed from the side, thanks
to the 178° wide-viewing angle capability. There’s front-mounted tactile
buttons for easy and intuitive operation, and a clean design that saves
space and minimizes clutter. And to ensure everyone remains comfortable,
focused and productive while enjoying the on-screen brilliance, the height-
adjustable stand also swivels, tilts and pivots. The Samsung S24C650PL.
Business. Innovated.


Samsung AD-PLS panels are a more cost-competitive
alternative to our high-end PLS panel technology. They
deliver outstanding image quality, as well as wide 178°
viewing angles.
More Connectivity Options
VGA, HDMI and DisplayPort give users flexibility in high-
speed connectivity. So whatever devices users need to
connect today or in the future, the S24C650P keeps
everyone’s options open.
Built-In Speakers
The integrated 2-way speaker delivers outstanding stereo
sound for an enhanced multimedia experience, whether
watching movies or listening to music.

Samsung LED technology requires up to 40% less energy
than conventional monitors, and users can easily adjust
brightness settings for an extra energy savings of up to
50%. This enables enterprise users to significantly reduce
energy usage.
Ultra-Slim Design That Fits Any Desk
The sleek, stylish design and low profile stands take up less
desk space and contribute to a cleaner-looking office. The
built-in cable management feature also adds to a clutter-free
work environment.

The monitor swivels, tilts, pivots and is height-adjustable.
And since the monitor is VESA compatible, installation on
a wall or separate mounting arms is easy.
Samsung S24C650PL Desktop Monitor
Learn more }1-800-SAMSUNG |1-866-SAM4BIZ |samsung.com/monitor or samsung.com/business
Follow us: @SamsungBizUSA
|
youtube.com/samsungbizusa

Display Model Number S24C650PL
Screen Size 23.6" Wide
Display Type AD-PLS, LED Backlight
Resolution 1920 x 1080
Pixel Pitch 0.2715mm (H) x 0.2715mm (V)
Aspect Ratio 16:9
Brightness 250 cd/m2
Contrast Ratio (Typical / Dynamic) 1000:1 / Mega Infinity
Viewing Angle (Horizontal / Vertical) 178˚ / 178˚
Color Support 16.7M
Speakers 1W x 2
Response Time 5ms (GTG)
Video Input
Signal
Analog VGA
Digital DisplayPort, HDMI
Power Voltage 100-240V (50 / 60 Hz)
Power Supply Type Internal
Power Consumption (Max / ENERGY STAR®)35W / 28W
Power Consumption (Standby) < 0.3W
Features Special Eco Saving, Samsung MagicBright 3, Off Timer, Image Size, Key Repeat Time supported, MagicTune, MultiScreen, MagicRotation
Stand Height Adjustable Stand (HAS) Range: 130mm, Tilt Range: -3° to +25°, Pivot: -1 to +95°, Swivel Range: -45° to +45°
Wall Mount (Size mm) 100 x 100 Wall Mount Supported, VESA Compliant
Cabinet Color Matte Black
Dimensions Product Dimensions (W x H x D) Max: 21.8" x 19.2" x 8.8", Min: 21.8" x 14.1" x 8.8"
Product Dimensions (without stand) 21.8" x 13.0" x 2.2"
Shipping Carton 24.9" x 7.3" x 16.0"
Front Bezel Size (Left, Top, Right, Bottom) 13.7mm (.53"), 15.2mm (.59"), 13.7mm (.53"), 16.2mm (.63")
Panel Depth 2.2"
Stand Base (Length x Depth) 8.81" x 9.84"
Weight With Stand / Without Stand 12.0 lbs. / 8.3 lbs.
Shipping Weight 15.2 lbs.
Service Standard Warranty 3-Year Parts / Labor / Backlight
Accessories Included VGA Cable, HDMI to DVI Cable, Audio Cable, 1.5m Power Cable, E-manual, Install CD, Quick Setup Guide
Green
Management
ENERGY STAR Compliant Yes (6.0)
TCO Yes
Packaging Recyclability Some Packing Materials Recyclable
EPEAT Rating Gold
ROHS Yes
Certification and
Compliance
Safety UL (USA): UL 60950-1, CSA (Canada): CSA C22.2 No. 60950-1, NOM (Mexico): NOM-019-SCFI-1993; other countries available upon request
EMC FCC (USA) FCC Part 15, Subpart B class A; other countries available upon request
 For complete product specifications, visit samsung.com/monitor
