Samsung SyncMaster 400CX-2 User manual

SyncMaster 400CX-2, 400CXN-2, 460CX-2, 460CXN-2
LCD Display
User Manual

Safety Instructions
Notational
Note
These safety instructions must be followed to ensure your safety and prevent property
damage.
Make sure to read the instructions carefully and use the product in the correct manner.
Warning / Caution
Failure to follow directions noted by this symbol could result in
bodily harm or damage to the equipment.
Note
Prohibited Important to read and un-
derstand at all times
Do not disassemble Disconnect the plug from
the outlet
Do not touch Ground to prevent an elec-
tric shock
Power
When not used for extended period of time, set your computer to
DPM.
If using a screen saver, set it to active screen mode.
The images here are for reference only, and are not applicable in all
cases (or countries).
Shortcut to Anti-Afterimage Instructions
Do not use a damaged power cord or plug or a damaged
or loose power outlet.
• Otherwise, this may result in electric shock or fire.
Do not touch the power plug with wet hands when removing
or plugging the plug into the outlet.
• Otherwise, this may result in electric shock.
Make sure to connect the power cord to a grounded power
outlet.
• Otherwise, it may result in electric shock or personal injury.
1

Ensure that the power plug is plugged into the power outlet
firmly and correctly.
• Otherwise, this may result in fire.
Do not forcefully bend or pull the power plug and do not
place any heavy material on it.
• Otherwise, this may result in fire.
Do not connect multiple appliances to the same power out-
let.
• Otherwise, this may cause fire due to overheating.
Do not disconnect the power cord while using the product.
• Otherwise, this may result in damage to the product due to
electric shock.
To disconnect the apparatus from the mains, the plug must
be pulled out from the mains socket, therefore the mains plug
shall be readily operable.
• Otherwise, this may cause electric shock or fire.
Use only the power cord provided by our company. Do not
use the provided power cord of another product.
• Otherwise, this may result in fire or electric shock.
Installation
Be sure to contact an authorized Service Center when installing your
monitor in a location with heavy dust, high or low temperatures, high
humidity, and exposed to chemical substances and where it operates
for 24 hours such as at airports, train stations etc.
Failure to do so may cause serious damage to your monitor.
Ensure that at least two persons lift and move the product.
• Otherwise, it may be dropped and cause personal injury,
and/or damage the product.
When installing the product in a cabinet or rack, make sure
that the front end of the bottom of the product does not
project out.
• Otherwise, it may fall or cause personal injury.
• Use a cabinet or rack of a size appropriate to the product.
DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGA-
RETTES AND ANY HEATING APPLIANCES NEAR THE PROD-
UCT.
• Otherwise, this may result in fire.
Safety Instructions
2

Keep heating appliances as far away from the power cord
or the product as possible.
• Otherwise, this may result in electric shock or fire.
Do not install it in a badly ventilated location such as a
bookcase or closet.
• Otherwise, this may result in fire due to an increase in the
internal temperature.
When putting the product down, make sure to put it down
softly.
• Otherwise, this may result in damage to the screen display.
Do not place the front of the product on the floor.
• Otherwise, this may result in damage to the screen display.
Ensure that an authorized installation company installs the
wall mount.
• Otherwise, it may fall and cause personal injury.
• Make sure to install the specified wall mount.
Install your product in a well ventilated location. Ensure that
there is a clearance of more than 4 inches (10 cm) from the
wall.
• Otherwise, it may result in fire due to an increase in the
internal temperature.
Bend the outdoor antenna cable downwards at the location
where it goes in so that rainwater does not flow in.
• If rainwater enters the product, it may result in electric
shock or fire.
Install the antenna far away from any high voltage cables.
• If the antenna touches or falls onto a high voltage cable, it
may result in electric shock or fire.
Ensure that the packaging vinyl is kept away from children.
• Otherwise, it may result in serious harm (suffocation) if
children play with it.
If the height of your monitor is adjustable, do not place any
object or part of your body on the stand when lowering it.
• This may cause damage to the product or the person car-
rying it.
Safety Instructions
3

Clean
When cleaning the monitor case or the surface of the TFT-LCD
screen, wipe with a slightly moistened, soft cloth.
Do not spray cleaner directly onto the surface of the prod-
uct.
• Otherwise, this may result in the discoloration and distor-
tion of the structure and the screen surface may peel off.
When cleaning the power plug pins or dusting the power
outlet, clean it with a dry cloth.
• Otherwise, it may result in fire.
When cleaning the product, make sure to disconnect the
power cord.
• Otherwise, it may result in electric shock or fire.
When cleaning the product, disconnect the power cord and
clean it with a slightly moistened, soft cloth.
• (Do not use chemicals such as wax, benzene, alcohol,
thinner, mosquito repellant, lubricant, or cleaner.) These
may change the appearance of the product surface and
peel off the indication labels on the product.
When cleaning the product, do not spray water directly onto
the main body of the product.
• Ensure that water does not enter the product and that it is
not wet.
• Otherwise, this may result in electric shock, fire or a mal-
function.
Others
The product is a high voltage product. Do not disassemble,
repair or modify the product yourself.
• Otherwise, this may result in electric shock or fire. If the
product needs to be repaired, contact a Service Center.
If there is a strange smell or a strange sound or smoke is
coming from the product, disconnect the power plug imme-
diately and contact a Service Center.
• Otherwise, this may result in electric shock or fire.
Do not place this product in a location exposed to moisture,
dust, smoke, water, or in a car.
• Otherwise, this may result in electric shock or fire.
Safety Instructions
4
Since the product housing is easily scratched, make sure
to use the specified cloth only.

When you drop the product or the case is broken, turn the
power off and disconnect the power cord. Contact a Service
Center.
• Otherwise, this may result in electric shock or fire.
If thunder or lightning is occurring, do not touch the power
cord or antenna cable.
• Otherwise, this may result in electric shock or fire.
Do not try to move the monitor by pulling only the wire or
the signal cable.
• Otherwise, it may fall and result in electric shock, damage
to the product or fire due to damage to the cable.
Do not lift or move the product back and forwards or right
and left while only holding the power cord or signal cables.
• Otherwise, it may fall and result in electric shock, damage
to the product or fire due to damage to the cable.
Make sure that the ventilating opening is not blocked by a
table or curtain.
• Otherwise, it may result in fire due to an increase in the
internal temperature.
Do not place any containers containing water, vases, flow-
erpots, medicines as well as any metal on the product.
• If water or a foreign material enters the product, discon-
nect the power cord and contact a Service Center.
• This may result in a product malfunction, electric shock, or
fire.
Do not use or keep combustible spray or flammable material
near the product.
• Otherwise, this may result in an explosion or fire.
Do not insert any metal, such as chopsticks, coins, pins and
steel, or flammable objects, such as matches or paper, inside
the product (through the ventilating openings, input and out-
put terminals, etc).
• If water or foreign material enters the product, disconnect
the power cord and contact a Service Center.
• Otherwise, this may result in electric shock or fire.
When using a fixed screen for a long time, an afterimage or
stain may occur.
• If you are not using your product for a long period of time,
put it into sleep mode or use a moving screen saver.
Set a resolution and frequency appropriate to the product.
• Otherwise, your eyesight may be damaged.
Safety Instructions
5

When using headphones or earphones, do not turn the vol-
ume too high.
• Having the sound too loud may damage your hearing.
To avoid eyestrain, do not sit too close to the product.
Take a rest for at least five (5) minutes after using the mon-
itor for one (1) hour.
This reduces eye fatigue.
Do not install it in an unstable location such as an unstable
rack or uneven surface or a location exposed to vibrations.
• Otherwise, it may fall and cause personal injury and/or
damage the product.
• If you use the product in a location exposed to vibrations,
it may damage the product and result in fire.
When moving the product, turn the power off and discon-
nect the power plug, antenna cable, and all the cables con-
nected to the product.
• Otherwise, it may result in electric shock or fire.
Ensure that children do not hang onto the product or climb
up onto the product.
• The product may fall and cause personal injury or death.
If you do not use the product for a long period of time, dis-
connect the power cord from the power outlet.
• Otherwise, this may result in overheating or fire due to dust,
and may result in fire due to electric shock or leakage.
Do not place any heavy items or toys or confectionery, such
as cookies etc. that may attract the attention of children and
to the product.
• Your children may hang onto the product causing it to fall
and this may result in personal injury or death.
Be careful that children do not place the battery in their
mouths when removed from the remote control. Place the
battery in a location that children or infants cannot reach.
• If children have had the battery in their mouths, consult
your doctor immediately.
When replacing the battery, insert it with the right polarity
(+, -).
• Otherwise, the battery may become damaged or it may
cause fire, personal injury or damage due to leakage of the
internal liquid.
Safety Instructions
6

Use only the specified standardized batteries, and do not
use a new battery and a used battery at the same time.
• Otherwise, the batteries may be damaged or cause fire,
personal injury or damage due to a leakage of the internal
liquid.
The batteries (and rechargeable batteries) are not ordinary
refuse and must be returned for recycling purposes. The cus-
tomer is responsible for returning the used or rechargeable
batteries for recycling.
• The customer can return used or rechargeable batteries to
a nearby public recycling center or to a store selling the
same type of the battery or rechargeable battery.
Do not place the product in a location exposed to direct
sunlight or near any heat such as a fire or heater.
• This may reduce the lifetime of the product, and may result
in fire.
Do not drop any objects onto the product or cause any im-
pact to the product.
• Otherwise, this may result in electric shock or fire.
Do not use a humidifier near the product.
• Otherwise, this may result in electric shock or fire.
When there is a gas leak, do not touch the product or the
power plug; ventilate immediately.
• If a spark occurs, it may cause an explosion or fire.
If the product has been turned on for a long time, the display
panel becomes hot. Do not touch it.
Keep the small accessories in a location out of the reach of
children.
Be careful when adjusting the angle of the product or the
height of the stand.
• This may result in personal injury as your hand or fingers
may become caught.
• Also, if you tilt the product too far, it may fall and cause
personal injury.
Do not install the product in a location low enough for chil-
dren to reach.
• Otherwise, it may fall and result in personal injury.
Safety Instructions
7

• Since the front part of the product is heavy, install the
product on a level and stable surface.
Do not put any heavy objects on the product.
• This may result in personal injury and/or damage to the
product.
Safety Instructions
8

Introduction
Package Contents
Note
Please make sure the following items are included with your LCD Display.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Checking the Contents of the Package
Remove the lock from the package box, as shown in the figure above.
Lift up the package box
by holding the grooves
on both sides of the
package box.
Check the contents of
the package. Remove the Styrofoam and vinyl cover.
Note
• After unpacking the package, make sure to check the contents of the package.
• Make sure to keep the package box for transporting the product in the future.
Unpacking
LCD Display
9
