Samsung SyncMaster ME55A User manual

BN46-00098A-02
User Manual
ME40A
ME46A
ME55A
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.

2
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2011 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.
Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.

3
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
1. Power off the product and computer.
2. Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the product with a clean, soft and dry cloth.
zDo not use detergents that contain alcohol, solvent or
surface-active agents.
zDo not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the exterior
of the product.
5. Connect the power cord to the product when cleaning is finished.
6. Power on the product and computer.
!

4
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

5
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
zAn electric shock or fire may result.
Do not use multiple products with a single power socket.
zOverheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock may
result.
Insert the power plug all the way in so it is not loose.
zAn unsecure connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
zAn electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the power
cord under a heavy object.
zDamage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
zA fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry
cloth.
zA fire may result.
!
!
!

6
Before Using the Product
Before Using the Product
Caution
Installation
Warning
Do not disconnect the power cord while the product is being used.
zThe product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the
power cord with other products.
zA fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
zThe power cord must be disconnected to cut off power to the product when
an issue occurs.
zNote that the product is not completely powered down by using only the
power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
zAn electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
zA fire may result.
Have a technician install the wall-mount hanger.
zInstallation by an unqualified person can result in an injury.
zOnly use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
zAn increased internal temperature may cause a fire.
Install the product at least 10cm away from the wall to allow ventilation.
zAn increased internal temperature may cause a fire.
!
!
!
!
!

7
Before Using the Product
Before Using the Product
Caution
Keep the plastic packaging out of the reach of children.
zChildren may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
zThe product may fall and become damaged and/or cause an injury.
zUsing the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
zA fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
zThe product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
zThe product may fall and injure children.
zAs the front is heavy, install the product on a flat and stable surface.
Bend and keep part of the outdoor TV antenna cable hanging downwards (the
part inside the room) to prevent rainwater from entering the product.
zIf rainwater enters the product, a fire or electric shock can occur.
When using an outdoor antenna, be sure to install the antenna away from nearby
power lines to prevent the antenna from collapsing onto them in strong winds.
zA collapsed antenna can cause an electric shock or injury.
Do not drop the product while moving.
zProduct failure or personal injury may result.
Do not set down the product on its front.
zThe screen may become damaged.
!
!
!
!
!

8
Before Using the Product
Before Using the Product
Operation
Warning
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
zThe product may fall and become damaged and/or cause an injury.
zInstall the product only on cabinets or shelves of the right size.
Set down the product gently
zProduct failure or personal injury may result.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
zBe sure to consult Samsung Customer Service Center if you want to install
the product at such a place.
There is a high voltage inside the product. Never disassemble, repair or modify
the product yourself.
zA fire or electric shock may result.
zContact Samsung Customer Service Center for repairs.
Before moving the product, turn off the power switch and disconnect the power
cord, antenna cable and all other connected cables.
zDamage to the cord may result in a fire or electric shock.
If the product generates abnormal sounds, a burning smell or smoke, disconnect
the power cord immediately and contact Samsung Customer Service Center.
zAn electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
zChildren may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power switch
and disconnect the power cord. Then contact Samsung Customer Service
Center.
zContinued use can result in a fire or electric shock.
!
SAMSUNG
!
!
!

9
Before Using the Product
Before Using the Product
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of
the product.
zThe product or heavy objects may fall as children try to reach for the toys or
sweets resulting in a serious injury.
During a lightning or thunderstorm, remove the power cord and do not touch the
antenna cable.
zA fire or electric shock may result.
Do not drop objects on the product or apply impact.
zA fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
zSparks can cause an explosion or fire.
zNever touch the power cord or antenna cable when thunder or lightning is
present.
Do not lift or move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
Do not use or keep combustible spray or an inflammable substance near the
product.
zAn explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
zAn increased internal temperature may cause a fire.
!
!
!
GAS
!

10
Before Using the Product
Before Using the Product
Caution
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that
burn easily (paper, matches, etc) into the product (via the vent or input/output
ports, etc).
zBe sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Center.
zProduct failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
zBe sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Center.
zProduct failure, an electric shock or fire may result.
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
zActivate power-saving mode or a moving-picture screen saver if you will not
be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
zDust accumulation combined with heat can cause a fire, electric shock or
electric leakage.
Use the product at the recommended resolution and frequency.
zYour eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
zThe product may fall and become damaged or cause an injury.
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
100
!
!
-_-
!
!
!

11
Before Using the Product
Before Using the Product
Do not use humidifiers or stoves around the product.
zA fire or electric shock may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
zEye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store small accessories out of the reach of children.
Exercise caution when adjusting the product angle or stand height.
zYour hand or finger may get stuck and injured.
zTilting the product at an excessive angle may cause the product to fall and
an injury may result.
Do not place heavy objects on the product.
zProduct failure or personal injury may result.
!
!
!

Table Of Contents 12
Table Of Contents
BEFORE USING THE
PRODUCT
2 Copyright
3 Cleaning
3Storage
4 Safety Precautions
4Symbols
5 Electricity and Safety
6 Installation
8Operation
PREPARATIONS 22 Checking the Contents
22 Removing the Packaging
23 Checking the Components
25 Parts
25 Control Panel
27 Reverse Side
28 Anti-theft Lock
29 Remote Control
32 Before Installing the Product (Installation
Guide)
32 Tilting Angle and Rotation
33 Ventilation
35 Dimensions
36 Installing the Wall Mount
36 Preparing before installing Wall-Mount
36 Installing the Wall Mount Kit
36 Wall Mount Kit Specifications (VESA)
38 Remote Control (RS232C)
38 Cable Connection
40 Control Codes
CONNECTING AND USING
A SOURCE DEVICE
51 Before Connecting
51 Pre-connection Checkpoints

Table Of Contents
Table Of Contents 13
52 Connecting and Using a PC
52 Connecting to a PC
55 Changing the Resolution
57 Connecting to a Video Device
57 Connection Using the AV Cable
57 Connection Using the Component Cable
58 Connection Using an HDMI-DVI Cable
58 Connection Using an HDMI Cable
59 Connecting an External Monitor
60 Connecting to an Audio System
60 Connecting to an Antenna
61 Changing the Input source
61 Source
62 Connecting the network box
62 MagicInfo
USING MDC 66 Configuring Settings for Multi Control
66 Configuring settings for Multi Control
67 Connection Using an RS232C-stereo
Cable
67 Connection Using a LAN Cable
68 Connection Using the RS232C-stereo
and LAN Cables
69 MDC Program Installation/Uninstallation
69 Installation
69 Uninstallation
WHAT IS MDC? 70 Connecting to MDC
70 Using MDC via RS-232C (serial data
communications standards)
70 Using MDC via Ethernet
71 Connection Management
72 Auto Set ID

Table Of Contents
Table Of Contents 14
73 Cloning
74 Command Retry
75 Getting Started with MDC
77 Main Screen Layout
78 Menus
78 Home
78 Volume
79 Alert
80 Screen Adjustment
80 Custom
82 Options
83 Size
84 Sound Adjustment
84 Bass
84 Treble
84 Balance (L/R)
84 SRS TS XT
85 System Setup
85 Video Wall
87 PIP
88 General
88 Fan & Temperature
89 Security
89 OSD Display
90 Time
92 Screen Burn Protection
94 Tool Settings
94 Security
94 Reset
95 Edit Column
95 Information

Table Of Contents
Table Of Contents 15
96 Other Functions
96 Resizing a Window
97 Group Management
99 Schedule Management
101 Troubleshooting Guide
102 How display properties are shown when
multiple displays are used
SCREEN ADJUSTMENT 103 Picture Mode
103 If the input source is PC, DVI or DisplayPort
103 If the input source is AV, Component, HDMI or
TV
104 Backlight / Contrast / Brightness /
Sharpness / Color / Tint (G/R)
105 Screen Adjustment
105 Picture Size
107 Position
107 PC Screen Adjustment
108 Resolution Select
108 Auto Adjustment
109 Advanced Settings
109 Black Tone
109 Dynamic Contrast
109 Shadow Detail (-2~+2)
110 Gamma
110 Expert Pattern
110 RGB Only Mode
110 Color Space
110 White Balance
111 10p White Balance (Off / On)
111 Flesh Tone
111 Edge Enhancement (Off / On)
111 Motion Lighting (Off / On)
111 LED Motion Plus (Off / On)

Table Of Contents
Table Of Contents 16
112 Picture Options
112 Color Tone
112 Color Temp.
113 Digital Noise Filter
113 MPEG Noise Filter
113 HDMI Black Level
113 Film Mode
113 Reset Picture
SOUND ADJUSTMENT 114 Sound Mode
115 Sound Effect
116 Broadcast Audio Options
117 Speaker Settings
117 Reset Sound
MEDIA 118 Favorites
119 Functions on the Favorites Screen
119 Using Edit Mode to Delete a Favorite
120 Channel
120 Channel Manager
123 Antenna
123 Auto Program
124 Clear Scrambled Channel
124 Fine Tune
125 MagicInfo Lite
125 Videos
125 Playing a Video
129 Photos
129 Viewing a Photo (or Slide Show)
130 Music
130 Playing Music

Table Of Contents
Table Of Contents 17
132 Videos / Photos / Music - Additional
Functions
132 Sorting the file lists
133 Videos / Photos / Music Play Option menu
135 Source
135 Source
136 Edit Name
136 Edit Favorites
136 Information
136 Refresh
137 AllShare
NETWORK 138 Network Setting
138 Connecting to a Wired Network
139 Wired Network Settings
142 Connecting to a Wireless Network
143 Wireless Network Setting
145 WPS(PBC) Network Setup
146 One Foot Connection Network Setup
147 Ad Hoc Network Setup
148 Network Status
148 AllShare Settings
149 Media
150 MagicInfo Lite Settings
SYSTEM 151 Plug & Play
152 Multi Control
152 Configuring settings for Multi Control
153 Time
153 Clock
154 Sleep Timer
154 On Timer
155 Off Timer
155 Holiday Management

Table Of Contents
Table Of Contents 18
156 Menu Language
156 Eco Solution
156 Energy Saving
157 Eco Sensor (Off / On)
157 No Signal Power Off
157 Auto Power Off (Off / On)
158 Caption
158 Caption
158 Caption Mode
159 Digital Caption Options
160 Security
160 Safety Lock (Off / On)
160 Button Lock (Off / On)
161 Program Rating Lock (Off / On)
163 Change PIN
163 PIP
164 Auto Protection Time
165 Screen Burn Protection
165 Pixel Shift
166 Timer
166 Pixel
166 Side Gray
167 Video Wall
167 Video Wall
168 Format
168 Horizontal
168 Vertical
169 Screen Position
170 Source AutoSwitch Settings

Table Of Contents
Table Of Contents 19
171 General
171 Max. Power Saving
171 Game Mode
172 BD Wise
172 Auto Power
172 Standby Control
172 Lamp Schedule
172 OSD Display
173 Power On Adjustment
173 Temperature Control
173 Device Name
174 Anynet+(HDMI-CEC)
174 Anynet+(HDMI-CEC)
175 Auto Turn Off (No / Yes)
177 DivX® Video On Demand
178 Network Remote Control
178 Reset System
178 Reset All
SUPPORT 179 Software Upgrade
179 By USB
180 Alternative Software
180 Contact Samsung
MAGICINFO LITE 181 File Formats Compatible with MagicInfo
Lite Player
181 Video / Audio
185 Network Schedule
185 Connecting to a server
186 MagicInfo Lite Settings
186 Approving a connected device from the server
189 Setting the current time
190 Local Schedule

Table Of Contents
Table Of Contents 20
190 Local Schedule Manager
190 Registering a Local Schedule
193 Modifying a Local Schedule
194 Deleting a Local Schedule
196 Running a Local Schedule
197 Stopping a Local Schedule
198 Viewing the details of a Local Schedule
199 Contents Manager
199 Copying content
200 Deleting content
201 Internal AutoPlay
201 Running Internal AutoPlay
201 USB AutoPlay
201 Running Internal AutoPlay
202 When Content is Running
202 Viewing the details of the content that is running
203 Changing the settings for the content that is
running
TROUBLESHOOTING
GUIDE
204 Requirements Before Contacting
Samsung Customer Service Center
204 Testing the Product
204 Checking the Resolution and Frequency
205 Check the followings.
208 Q & A
SPECIFICATIONS 210 General
211 PowerSaver
212 Preset Timing Modes
214 License
APPENDIX 215 Contact SAMSUNG WORLDWIDE
