Samsung CLP 610ND - Color Laser Printer User manual

Samsung Color Laser Printer The keynote of Product
High SMB/Easy of Use Tandem CLBP
- Emulation : CLP-610ND(SPL-C),
CLP-660, 660N(PostScript 3, PCL6)
- Speed : CLP-610ND( 0/ 0 ppm),
CLP-660, 660N( 4/ 4 ppm)
- Resolution : CLP-610ND(1, 00 x 600 dpi),
CLP-660N, 660ND(1, 00 x 600 dpi)
- CPU : CLP-610ND(300 MHz),
CLP-660N, 660ND(533 MHz)
- Interface : N/W
- Memory : CLP-610ND / 64 MB,
CLP-660N, 660ND/1 8 MB (Max. 640 MB)
- Duplex (Option)
- 50 CST, 1 Manual, 100 MP
- Toner Cartridge: .5K/ K (Std.), 5.5K/5K (High)
- Printer Life: Color 00K / Mono 00K pages
Manual
SERVICE
Basic Model :CLP-610ND, 660ND

1. Precautions
1.1 Safety Warning 1-1
1.2 Caution for safety 1-2
1.3 ESD Precautions 1-5
1.4 Super Capacitor or Lithium Battery Precautions 1-5
2. Product spec and feature
2.1 Product Specifications 2-1
2.1.1 Product Overview 2-1
2.1.2 Specifications 2-2
2.1.3 Maintenance List (CRU & FRU) 2-7
2.1.4 Periodic Replacing Parts 2-
2.1.5 Competitor Model 2-
2.2 System Overview 2-10
2.2.1 System Structure 2-10
2.2.2 H/W Configuration (Engine & Controller) 2-16
3. Disassembly and Reassembly
3.1 Precautions When Replacing Parts 3-1
3.1.1 Precautions when assembling and disassembling 3-1
3.1.2 Precautions when handling PBA 3-1
3.1.3 Releasing Plastic Latches 3-2
3.2 Parts for Maintenance and Repair 3-2
3.2.1 Replacement interval for parts with a limited life 3-2
3.2.2 Printer Cleaning 3-3
3.3 Information Related in Disassembly and Assembly 3-4
3.3.1 Special Service Parts 3-4
3.4 Disassembly Procedure 3-5
Contents

3.4.1 Cover Unit 3-5
3.4.2 HVPS Board 3-10
3.4.3 Main Board 3-11
3.4.4 SMPS Board 3-11
3.4.5 Fuser control Board 3-12
3.4. LSU Unit 3-12
3.4.7 CRUM 3-13
3.4.8 Fuser Drive Unit 3-13
3.4.9 Pick-up Roller 3-15
3.4.10 Feed Drive 3-15
4. Alignment & Troubleshooting
4.1 Alignment and Adjustments 4-1
4.1.1 Control Panel 4-1
4.1.2 LED Function 4-2
4.1.3 Jam Removal 4-3
4.1.4 System setup 4-10
4.1.5 Error Message 4-43
4.2 Troubleshooting 4-47
4.2.1 Procedure of Checking the Symptoms 4-47
4.2.2 The cause and solution of image quality 4-48
4.2.3 The cause and solution of the paper feeding 4- 0
4.2.4 OPE Problems 4- 5
4.2.5 Other Problems 4- 7
5. Exploded Views & Parts List
5.1 Main 5-2
5.2 Cover Unit 5-4
5.3 Top Cover 5-
Continued

5.4 OPE Unit 5-8
5.5 Front Cover 5-10
5.6 Exit Cover 5-12
5.7 MP Tray 5-14
5.8 Frame 5-16
5.9 Fee Drive 5-18
5.10 Fuser Drive 5-20
5.11 Fuser 5-22
5.12 PTB Unit 5-25
5.13 Cassette 5-28
5.14 SCF Unit 5-31
5.15 SCF Cassette 5-33
6. System Diagram
6.1 Block Diagram 6-1
6.1.1 24ppm Main Controller Block Diagram(CLP-660) 6-1
6.1.2 20ppm Main Controller Block Diagram(CLP-610) 6-2
6.1.3 CLP-610N-610ND Engine Controller Block Diagram 6-3
6.1.4 CLP-660N-660ND Engine Controller Block Diagram 6-4
6.2 Connection Diagram 6-5
6.2.1 Connection Diagram 6-5
7. Reference Information
7.1 Tools for Troubleshooting 7-1
7.2 Acronyms an Abbreviations 7-2
7.3 Select a location for the printer 7-4
7.4 A4 ISO 19752 Stan ar Pattern 7-5
7.5 Mo el List 7-6
7.6 Difference table(CLP-610 & CLP-660) 7-6
Continued

Precautions
Samsung Electronics
Service Manual
1-1
1
1
1. Precautions
In order to prevent accidents and to prevent damage to the equipment please read the precautions listed
below carefully before servicing the printer and follow them closely.
1.1 Safety Warning
(1) Only to be serviced by appropriately qualified service engineers.
igh voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably
trained and qualified service engineer.
(2) Use only Samsung replacement parts
There are no user serviceable parts inside the printer. Do not make any unauthorized changes or
additions to the printer, these could cause the printer to malfunction and create electric shock or fire hazards.
(3) Laser Safety Statement
The Printer is certified in the U.S. to conform to the requirements of D S 21 CFR, chapter 1 Subchapter J for
Class 1(1) laser products, and elsewhere, it is certified as a Class I laser product
conforming to the requirements of IEC 825. Class I laser products are not considered to be hazardous. The
laser system and printer are designed so there is never any human access to laser radiation above a Class I
level during normal operation, user maintenance, or prescribed service condition.
Warning >> Never operate or service the printer with the protective cover removed from Laser/Scanner assembly. The
reflected beam, although invisible, can damage your eyes. When using this product, these basic safety
pre cautions should always be followed to reduce risk of fire, electric shock, and injury to persons.
CAUTION - INVISIBLE LASER RADIATION 
W EN T IS COVER OPEN. 
DO NOT OPEN T IS COVER.
VORSIC T - UNSIC TBARE LASERSTRA LUNG, 
WENN ABDECKUNG GEÖFFNET. 
NIC T DEM STRA L AUSSETZEN.
ATTENTION - RAYONNEMENT LASER INVISIBLE EN CAS 
D’OUVERTURE. EXPOSITION DANGEREUSE 
AU FAISCEAU.
ATTENZIONE - RADIAZIONE LASER INVISIBILE IN CASO DI 
APERTURA. EVITARE L’ESPOSIZIONE AL 
FASCIO.
PRECAUCION - RADIACION LASER IVISIBLE CUANDO SE ABRE. 
EVITAR EXPONERSE AL RAYO.
ADVARSEL. - USYNLIG LASERSTRÅLNING VED ÅBNING, NÅR 
SIKKER EDSBRYDERE ER UDE AF FUNKTION. 
UNDGÅ UDSAETTELSE FOR STRÅLNING.
ADVARSEL. - USYNLIG LASERSTRÅLNING NÅR DEKSEL 
ÅPNES. STIRR IKKE INN I STRÅLEN. 
UNNGÅ EKSPONERING FOR STRÅLEN.
VARNING - OSYNLIG LASERSTRÅLNING NÄR DENNA DEL 
ÄR ÖPPNAD OC SPÄRREN ÄR URKOPPLAD. 
BETRAKTA EJ STRÅLEN. STRÅLEN ÄR FARLIG.
VARO! - AVATTAESSA JA SUOJALUKITUS O ITETTAESSA 
OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASER-
SÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.

Samsung Electronics
Service Manual
Precautions
1-2
1.2 Caution for safety
1.2.1 Toxic material
This product contains toxic materials that could cause illness if ingested.
(1) If the LCD control panel is damaged it is possible for the liquid inside to leak. This liquid is toxic. Contact with the skin
should be avoided, wash any splashes from eyes or skin immediately and contact your doctor. If the liquid gets into
the mouth or is swallowed see a doctor immediately.
(2) Please keep toner cartridges away from children. The toner powder contained in the toner cartridge may be harmful
and if swallowed you should contact a doctor.
1.2.2 Electric Shock and Fire Safety Precautions
Failure to follow the following instructions could cause electric shock or potentially cause a fire.
(1) Use only the correct voltage, failure to do so could damage the printer and potentially cause a fire or electric
shock.
(2) Use only the power cable supplied with the printer. Use of an incorrectly specified cable could cause the cable
to overheat and potentially cause a fire.
(3) Do not overload the power socket, this could lead to overheating of the cables inside the wall and could lead to
a fire.
(4) Do not allow water or other liquids to spill into the printer, this can cause electric shock. Do not allow paper
clips, pins or other foreign objects to fall into the printer these could cause a short circuit leading to an electric
shock or fire hazard..
(5) Never touch the plugs on either end of the power cable with wet hands, this can cause electric shock. When
servicing the printer remove the power plug from the wall socket.
(6) Use caution when inserting or removing the power connector. The power connector must be inserted com-
pletely otherwise a poor contact could cause overheating possibly leading to a fire. When removing the power
connector grip it firmly and pull.
(7) Take care of the power cable. Do not allow it to become twisted, bent sharply round corners or otherwise
damaged. Do not place objects on top of the power cable. If the power cable is damaged it could overheat and
cause a fire or exposed cables could cause an electric shock. Replace a damaged power cable immediately,
do not reuse or repair the damaged cable. Some chemicals can attack the coating on the power cable,
weakening the cover or exposing cables causing fire and shock risks.
(8) Ensure that the power sockets and plugs are not cracked or broken in any way. Any such defects should be
repaired immediately. Take care not to cut or damage the power cable or plugs when moving the machine.
(9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from
the power source when such weather conditions are expected. Do not touch the machine or the power cord if it
is still connected to the wall socket in these weather conditions.
(10) Avoid damp or dusty areas, install the printer in a clean well ventilated location. Do not position the machine
near a humidifier. Damp and dust build up inside the machine can lead to overheating and cause a fire.
(11) Do not position the printer in direct sunlight. This will cause the temperature inside the printer to rise possibly
leading to the printer failing to work properly and in extreme conditions could lead to a fire.
(12) Do not insert any metal objects into the machine through the ventilator fan or other part of the casing, it could
make contact with a high voltage conductor inside the machine and cause an electric shock.

Precautions
Samsung Electronics
Service Manual
1-3
1.2.3 andling Precautions
The following instructions are for your own personal safety, to avoid injury and so as not to damage the printer
(1) Ensure the printer is installed on a level surface, capable of supporting its weight. Failure to do so could cause
the printer to tip or fall.
(2) The printer contains many rollers, gears and fans. Take great care to ensure that you do not catch your fingers,
hair or clothing in any of these rotating devices.
(3) Do not place any small metal objects, containers of water, chemicals or other liquids close to the printer which if
spilled could get into the machine and cause damage or a shock or fire hazard.
(4) Do not install the machine in areas with high dust or moisture levels, beside on open window or close to a
humidifier or heater. Damage could be caused to the printer in such areas.
(5) Do not place candles, burning cigarettes, etc. on the printer, these could cause a fire.
1.2.4 Assembly / Disassembly Precautions
Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also
cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.
Please carry out the following procedures before dismantling the printer or replacing any parts.
(1) Check the contents of the machine memory and make a note of any user settings. These will be erased if the
mainboard is replaced.
(2) Ensure that power is disconnected before servicing or replacing any electrical parts.
(3) Disconnect printer interface cables and power cables.
(4) Only use approved spare parts. Ensure that part number, product name, any voltage, current or temperature
rating are correct.
(5) When removing or re-fitting any parts do not use excessive force, especially when fitting screws into plastic.
(6) Take care not to drop any small parts into the machine.
(7) andling of the OPC Drum
- The OPC Drum can be irreparably damaged if it exposed to light.
Take care not to expose the OPC Drum either to direct sunlight or to fluorescent or incandescent room
lighting. Exposure for as little as 5 mins can damage the surface’s photoconductive properties and will result
in print quality degradation. Take extra care when servicing the printer. Remove the OPC Drum and store it in
a black bag or other lightproof container. Take care when working with the covers(especially the top cover)
open as light is admitted to the OPC area and can damage the OPC Drum.
- Take care not to scratch the green surface of OPC Drum Unit.
If the green surface of the Drum Cartridge is scratched or touched the print quality will be compromised.

Samsung Electronics
Service Manual
Precautions
1-4
1.2.5 Disregarding this warning may cause bodily injury
(1) Be careful with the high temperature part.
The fuser unit works at a high temperature. Use caution when working on the printer. Wait for the fuser to cool
down before disassembly.
(2) Do not put finger or hair into the rotating parts.
When operating a printer, do not put hand or hair into the rotating parts (Paper feeding entrance, motor, fan,
etc. . If do, you can get harm.
(3) hen you move the printer.
This printer weighs 25.6 Kg(56.44 lbs including with consumables. Use safe lifting and handling techniques.
Back injury could be caused if you do not lift carefully.
(4) Ensure the printer is installed safely.
The printer weighs 25.6 Kg(56.44 lbs , ensure the printer is installed on a level surface, capable of supporting
its weight. Failure to do so could cause the printer to tip or fall possibly causing personal injury or damaging the
printer.
(5) Do not install the printer on a sloping or unstable surface. After installation, double check that the printer is stable.

Precautions
Samsung Electronics
Service Manual
1-5
1.3 ESD Precautions
Certain semiconductor devices can be easily damaged by static electricity. Such components are commonly called
“Electrostatically Sensitive (ES) Devices”, or ESDs. Examples of typical ESDs are: integrated circuits, some field
effect transistors, and semiconductor “chip” components.
The techniques outlined below should be followed to help reduce the incidence of component damage caused by
static electricity.
Caution >>Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
1. Immediately before handling a semiconductor component or semiconductor-equipped assembly, drain off any
electrostatic charge on your body by touching a known earth ground. Alternatively, employ a commercially avail-
able wrist strap device, which should be removed for your personal safety reasons prior to applying power to the
unit under test.
2. After removing an electrical assembly equipped with ESDs, place the assembly on a conductive surface, such as
aluminum or copper foil, or conductive foam, to prevent electrostatic charge buildup in the vicinity of the assem-
bly.
3. Use only a grounded tip soldering iron to solder or desolder ESDs.
4. Use only an “anti-static” solder removal device. Some solder removal devices not classified as “anti-static” can
generate electrical charges sufficient to damage ESDs.
5. Do not use Freon-propelled chemicals. When sprayed, these can generate electrical charges sufficient to dam-
age ESDs.
6. Do not remove a replacement ESD from its protective packaging until immediately before installing it. Most
replacement ESDs are packaged with all leads shorted together by conductive foam, aluminum foil, or a compa-
rable conductive material.
7. Immediately before removing the protective shorting material from the leads of a replacement ESD, touch the pro-
tective material to the chassis or circuit assembly into which the device will be installed.
8. Maintain continuous electrical contact between the ESD and the assembly into which it will be installed, until com-
pletely plugged or soldered into the circuit.
9. Minimize bodily motions when handling unpackaged replacement ESDs. Normal motions, such as the brushing
together of clothing fabric and lifting one’s foot from a carpeted floor, can generate static electricity sufficient to
damage an ESD.
1. Exercise caution when replacing a super capacitor or Lithium battery. There could be a danger of explosion and
subsequent operator injury and/or equipment damage if incorrectly installed.
2. Be sure to replace the battery with the same or equivalent type recommended by the manufacturer.
3. Super capacitor or Lithium batteries contain toxic substances and should not be opened, crushed, or burned for
disposal.
4. Dispose of used batteries according to the manufacture’s instructions.
1.4 Super Capacitor or Lithium Battery Precautions

Product spec and feature
Samsung Electronics
Service Manual
2-1
2
2
2. Product specification and feature
2.1 Product Specifications
2.1.1 Product Overview
Concept Low CPP/Easy of Use Tandem CLBP
Tar et SMB (Small work roup/biz)
20/20 ppm
1,200 x 1,200 dpi
effective output
CHORUS (SOC)
GDI, N/W
250 CST, 100 MP
Duplex
2.5K/2K (Std.)
5.5K/5K (High)
< CLP-610 Series >
24/24 ppm
1,200 x 1,200 dpi
effective output
5 MHz
PCL6/PS , N/W
250 CST, 100 MP
Duplex
2.5K/2K (Std.)
5.5K/5K (High)
< CLP-660 Series >

Samsung Electronics
Service Manual
Product spec and feature
2-2
2.1.2 Specifications
Product Specifications are subject to change without notice. See below for product specifications.
2.1.2.1 General Print Engine
Item CLP-610N CLP-660N/660N
Engine Speed Simplex B&W : Up to 0 ppm in A4 ( 1 ppm in Letter) B&W : Up to 0 ppm in A4 ( 5 ppm in Letter)
Color : Up to 0 ppm in A4 ( 1 ppm in Letter) Color : Up to 0 ppm in A4 ( 5 ppm in Letter)
Duplex CLP-610N : Manual CLP-660/660N : Manual
CLP-610ND : Built-in CLP-660ND : Built-in
Warmup time Less than 0 sec Less than 0 sec
FPOT (B&W) From Ready Less than 1 sec Less than 1 sec
From Idle Less than 3 sec Less than 3 sec
From Coldboot Less than 3 sec Less than 3 sec
FPOT (Color) From Ready Less than 1 sec Less than 1 sec
From Idle Less than 3 sec Less than 3 sec
From Coldboot Less than 3 sec Less than 3 sec
Resolution Optical 600 x 600 dpi 600 x 600 dpi
Support Max : 1, 00 x 1, 00dpi effetive output Max : 1, 00 x 1, 00dpi effetive output
Default : 1, 00 x 600dpi Default : 1, 00 x 600dpi
Min : 600 x 600 dpi Min : 600 x 600 dpi

Product spec and feature
Samsung Electronics
Service Manual
2-3
2.1.2.2 Controller & S/W
Item CLP-610N CLP-660N/660N
CPU CHORUS3(SOC) Mips 533MHz+ SPGPXm
Memory Std. 1 8MB(DDR ) 1 8MB(DDR1)
Max. 1 8MB(DDR ) 640 MB
Memory Expansion N/A 1 Slot
Printer Languages SPL-C (Samsung Printer Language Color) PostScript 3, PCL6
Fonts Windows Fonts 45 scalable and 1 bitmap PCL and 136 PS
Driver Supporting OS Windows 98/Me/ 000/XP/ 003/Vista Windows 98/Me/ 000/XP/ 003/Vista
Various Linux including Red Hat 8.0~9.0, Various Linux including Red Hat 8.0~9.0,
Mandrake 9. ~10.1, SuSE 8. ~9. and Mandrake 9. ~10.1, SuSE 8. ~9. and
Fedora Core 1~4 Fedora Core 1~4
Mac OS 10.3~10.4 and Universal Mac Mac OS 10.3~10.4 and Universal Mac
Default Driver - SPL-C (Samsung Printer Language Color) - PCL6c
WHQL Windows 000/XP/ 003/Vista Windows 000/XP/ 003/Vista
Language Korean, English, French, German, Italian, Korean, English, French, German, Italian,
Localization Spanish, Russian, Dutch, B.Portuguese, Spanish, Russian, Dutch, B.Portuguese,
E.Portuguese, Finish, Swedish, Norwegian, E.Portuguese, Finish, Swedish, Norwegian,
Danish, S.Chinese, T.Chinese, Polish, Danish, S.Chinese, T.Chinese, Polish,
Hungarian, Czech Hungarian, Czech
Application RCP USB / Network CLP-660 : USB
CLP-660N/660ND : USB / Network
Smart Panel Yes Yes
Network Set IP, Samsung Web Admin Service 4.0 Set IP, Samsung Web Admin Service 4.0
Management (SWAS 4.0)(Linux, SWAS: Iexplorer 5.0 or (SWAS 4.0)(Linux, SWAS: Iexplorer 5.0 or
higher, Mac: not supported) higher, Mac: not supported)
SmarThru4 N/A N/A
2.1.2.3 Interface
Item CLP-610N CLP-660N/660N
Parallel N/A N/A
USB USB .0 USB .0
Network Ethernet 10/100 Base TX CLP-660 : Option
CLP-660N/660ND : Ethernet 10/100 Base TX
Network Protocol TCP/IP,SNMP,HTTP1.1 CLP-660 : N/A
CLP-660N/660ND : TCP/IP,SNMP,HTTP1.1
LCD & Button LCD, 6 key LCD, 6 key
LED 1 LED for status (Green/Red) 1 LED for status (Green/Red)

Samsung Electronics
Service Manual
Product spec and feature
2-4
2.1.2.4 Paper Handling
Item CLP-610N CLP-660N/660N
Standard Capa. 50-sheet Cassette Tray, 1 Manual 50-sheet Cassette Tray, MP 100
Max. Capa. 850 sheets @ 75g/ 850 sheets @ 75g/
Printing Max. Size 16 x 356mm (8.5" x 14") 16 x 356mm (8.5" x 14")
Min. Size 76 x1 7mm (3" x 5") 76 x1 7mm (3" x 5")
Margin(T/B/L/R) 4 mm, 4 mm, 4 mm, 4 mm 4 mm, 4 mm, 4 mm, 4 mm
MP Tray Capacity 100 sheets @ 75g/ 100 sheets @ 75g/
MP Tray Sensing Empty sensing Empty sensing
No size sensor No size sensor
Standard Cassette Capacity 50 sheets @ 75g/ 50 sheets @ 75g/
Cassette Size sensor N/A N/A
Cassette Paper Sensing Paper empty sensor Paper empty sensor
SCF Cassette Capacity 500 sheets @ 75g/ 500 sheets @ 75g/
SCF Cassette Size sensor N/A N/A
SCF Cassette Paper Sensing Empty sensing Empty sensing
Output Stacking FaceUp N/A N/A
FaceDown 00 sheets @ 75g/ (TBD) 00 sheets @ 75g/ (TBD)
Output Full sensing N/A N/A
Duplex Supporting Std. Std.
2.1.2.5 CRU
CLP-610ND CLP-660N/660ND
4 (C/M/Y/K toner)
K toner cartridge: CLP-K660A
C toner cartridge: CLP-C660A
M toner cartridge: CLP-M660A
Y toner cartridge: CLP-Y660A
4 (C/M/Y/K toner)
K toner cartridge: CLP-K660A
C toner cartridge: CLP-C660A
M toner cartridge: CLP-M660A
Y toner cartridge: CLP-Y660A
Black
2,500 A4/Letter pages Standard yield ,at 5% Coverage,
5,500 A4/Letter pages High yield, at 5% Coverage
(Ships with Standard yield Starter toner cartridge)
2,500 A4/Letter pages Standard yield ,at 5% Coverage
5,500 A4/Letter pages High yield, at 5% Coverage
(Ships with Standard yield Starter toner cartridge)
Color
2,000 A4/Letter pages Standard yield ,at 5% Coverage
5,000 A4/Letter pages High yield, at 5% Coverage
(Ships with Standard yield Starter toner cartridge)
2,000 A4/Letter pages Standard yield ,at 5% Coverage
5,000 A4/Letter pages High yield, at 5% Coverage
(Ships with Standard yield Starter toner cartridge)
Key Unique, Electronic key(CRUM) Unique, Electronic key(CRUM)
Replace
method
CRUM for appropriate installation of each cartridge
3 step for install/replacing
CRUM for appropriate installation of each cartridge
3 step for install/replacing
50,000 Pages 50,000 Pages
Item
No. of CRUs
Toner
PTB

Product spec and feature
Samsung Electronics
Service Manual
2-5
2.1.2.6 FRU
2.1.2.7 Reliability & Service
Item CLP-610N CLP-660N/660N
Printing Volume(AMPV) 630 page ( B&W : 5 page, Color : 378 pages) 630 page ( B&W : 5 page, Color : 378 pages)
Max Monthly Duty 100,000 pages 100,000 pages
MTTR <30 min. <30 min.
Product Life 00,000 image or 5 years whitchever comes first 00,000 image or 5 years whitchever comes first
System information record Total page count (color/mono) Total page count (color/mono)
Fuser life Fuser life
Transfer belt life Transfer belt life
Toner image count (CMYK) Toner image count (CMYK)
Tray roller life Tray roller life
First operation date(Not revealed to Users) First operation date(Not revealed to Users)
Test Print Configuration Sheet Configuration Sheet
Menu Map Sheet Menu Map Sheet
Demo Sheet Demo Sheet
RDC Comm. Mode USB & NW USB & NW
Operation TBD(Status report TBD(Status report
F/W reset/writing F/W reset/writing
NV-RAM operation NV-RAM operation
Record tracking Record tracking
Administration alert) Administration alert)
Temperature Operating 15~3 .5 (59~90.5) 15~3 .5 (59~90.5)
Storage - 0~40(-4~104) - 0~40(-4~104)
Humidity Operating -10" ~ 80RH -10" ~ 80RH
Storage 0~95RH 0~95RH
CLP-610ND CLP-660N/660ND
100,000 Pages 100,000 Pages
70,000 Pages 70,000 Pages
70,000 Pages 70,000 Pages
Item
Fuser
Pick-up Roller
Friction pad

Samsung Electronics
Service Manual
Product spec and feature
2-6
2.1.2.8 Environment
Item CLP-610N CLP-660N/660N
Printing Less than 50 dBA Less than 50 dBA
Standby Less than 35 dBA Less than 35 dBA
Sleep Background noise level Background noise level
Input Voltages 110-1 7 VAC, 50/60Hz 110-1 7 VAC, 50/60Hz
0- 40 VAC,50/60Hz 0- 40 VAC,50/60Hz
Power Switch Power Switch
AVG. Less than 600W Less than 600W
Sleep Less than 35W Less than 35W
Dimension Set 43 x 4 8 x 4 6 mm 43 x 4 8 x 4 6 mm
(W x D x H)
Weight Set (with 5.6 kg (with consumables) 5.6 kg (with consumables)
consumables)
Acoustic Noise
Level(Sound
Power/Pressure)
Power
Consumption
2.1.2.9 Accessory
Item CLP-610N CLP-660N/660N
In-Box Machine Machine
K/C/M/Y Toner (K: .5K , C/M/Y: K) K/C/M/Y Toner (K: .5K , C/M/Y: K)
Power cord Power cord
USB cable (China, Korea, CIS, India) USB cable (China, Korea, CIS, India)
Set-up CD Set-up CD
QIG(Quick installation Guide sheet) QIG(Quick installation Guide sheet)
Warranty book Warranty book
Manual Book: Domestic Only Manual Book: Domestic Only
N/W CD (Application, manual) N/W CD (Application, manual)
2.1.2.10 Options
Item CLP-610N CLP-660N/660N
Memory N/A N/A
Second Cassette 500- sheet Cassette 500- sheet Cassette
PostScript N/A N/A
Network Built-in Built-in
Wireless Network N/A N/A
Hard Disk N/A N/A

Product spec and feature
Samsung Electronics
Service Manual
2-7
2.1.3 Maintenance List (CRU & FRU)
Life (Expected Average based on AMPV usage ratio) Max. Life
CRU ModesExpected LifeTotal Image TotalPageColor onlyMono
pages Images (page) only(page)
SET Mono (40%) 80K 80K 200,000 200,000 200,000 0
Color (60%) 120K 120K 0 200,000
Toner Cyan 5,000 5,000 5,000 5,000
Cartridge Magenta 5,000 5,000 5,000 5,000
(5% coverage) Yellow 5,000 5,000 5,000 5,000
Black 5,500 5,500 5,500 5,500
PTB nit Color 50,000 50,000 50,000 50,000 50,000
Mono 50,000 50,000 -
Fuser nit Color 100,000 100,000 0
Mono 100,000 0 100,000
Pick p Color / Mono 70,000 70,000 70,000
Friction Pad Color / Mono 70,000 70,000 70,000
* Toner Cartridge yield : Average CMY Cartridge Yield 5000 standard pages
Average K Cartridge Yield 5500 standard pages
Declared yield value in accordance with ISO/IEC 19798

Samsung Electronics
Service Manual
Product spec and feature
2-8
2.1.4 Periodic Replacing Parts
Samsung shall specify parts requiring replacement and the frequency of replacement. The parts identified may be
deemed customer replaceable parts. Periodic replacement parts shall be recommended as follows
** Based on Printing Volume ratio of 6 % Color and 4 % B/W
Toner Cartridge 2K(Color), 2.5K(Mono) Page5K(Color), Initial Toner, User replaceableUser
5.5K (Mono) pages replaceable
PTB Unit 5 K(Color/Mono) Images User replaceable
Pick up(FCF, SCF, MPF) 7 K(Color/Mono) pages Field replaceable
Friction Pad(FCF, SCF, MPF) 7 K(Color/Mono) pages Field replaceable
2.1.5 Competitor Model
SEC Model
CLP-610N CLP-660N CLP-660N
Speed (ppm) 2 /2 24/24 24/24
Resolution (dpi) 1,2 x 6 1,2 x 6 1,2 x 6
CPU (MHz) 266 533 533
Memory (MB) 64 128 (Max.64 ) 128 (Max.64 )
FPOT (sec) 12 12 12
N/W N/W N/W N/W
Duplex Built in Manual Built in
Paper Handling 25 CST 25 CST 25 CST
1 MP 1 MP 1 MP
Toner 2.5K / 2K / 5.5K / 5K 2.5K / 2K / 5.5K / 5K 2.5K / 2K / 5.5K / 5K
SCF 5 sheet 5 sheet 5 sheet

Product spec and feature
Samsung Electronics
Service Manual
2-9
Model Name Samsung CLP- 610N HP CLJ 2605n OKI 3400N
Speed (ppm) 2 /2 12/1 2 /16
FPOT 12 2 9/13
Resolution 1,2 x 6 dpi 2,4 x 6 dpi 1,2 x 6 dpi
Processor 266 3 2
Ram(Max.) 32 64 (32 ) 32 (288)
Emulation GDI PDL GDI
Interface USB 2. , N/W USB 2. , N/W USB 2. , N/W
Paper Input 25 CST, 1 Manual 25 CST, 1 Manual
(Capa./Type) 5 SCF 25 SCF 25 CST
Toner 2.5K / 2K / 5.5K / 5K 2.5K / 2K -
Competitor Model
Model Name Samsung CLP- 660N HP CLJ 3600n Lexmark C524N OKI 5500N KM 5430 L
Speed (ppm) 24/24 17/17 19/19 24/2 2 /2
FPOT 12 sec 14 sec 13 sec 9/13 sec 14 sec
Resolution 1,2 x 6 dpi 3,6 x 6 dpi 1,2 x 1,2 dpi 1,2 x 6 dpi 2,4 x 6 dpi
Processor 533 36 5 2 2
Ram(Max.) 128 (64 ) 64 128 (64 ) 32 (288) 64 (576)
Emulation PDL GDI PDL GDI GDI
Interface USB 2. , N/W USB 2. , N/W USB 2. , N/W USB 2. , N/W USB 2. , N/W
Paper Input 25 CST 25 CST 25 CST 3 CST 25 CST
(Capa./Type) 1 MP 1 MP 1 MP 1 MP 5 SCF
5 SCF 5 SCF 5 SCF 53 SCF
Toner 2.5K/2K/5.5K/5K 6K/4K 8K/5K (initial 1.5K) 5K/5K (initial 1.5K) 6K/6K (initial 3K)

Samsung Electronics
Service Manual
Product spec and feature
2-10
2.2 System Overview
This chapter describes the functions and operating principles of the main components.
2.2.1 System Structure
2.2.1.1 Main Parts of System
8
3
10
67
2
5
14
11
9
7Pressure Roller
1OPC (Organic
Photo Conductor)
2Charge Roller
3P Roller
4Deve Roller
5Transfer Roller
6Heat Roller 10 Exit Roller
11 Duplex Roller
8Pick_up Roller
9Rigi Roller

Product spec and feature
Samsung Electronics
Service Manual
2-11
1) Toner Cartrid e
* Method of Toner supply : Toner is transported to the developing roller by supply belt.
* Regulating Toner level : Regulating Toner level by S S. Blade
* OPC Cleaning: Collect the toner by using Cleaning Blade (urethane)
* OPC Drum protecting Shutter : No (Take care of impact)
2) PTB(Paper Transfer Belt)
* The life span: Print over 50,000 sheets
* Specification: Similar to DaVinci(CLP-600) Ass y.
* TANDEM Method Paper Transporting nit by using Paper Transfer Belt
* Belt Driving Method : Friction Driving by Drive Roller
* Belt Cleaning : Collect the toner by using Rubber Blade
* Management of waste toner : The Waste Toner Tank Be equipped
3) Transfer Roller
Once the complete, full colour, image, has been built up on the ITB the Transfer Roller is used to
transfer the image onto paper. This is called the T2 Transfer (T2 Transfer is none)
