Samsung ML-1615 User manual

SAMSUNG Laser Printer User's Guide
ML-1610 Series

1
About the User’s Guide
This User’s Guide provides information you need for setting up your printer.
It also provides all of the detailed instructions for using your printer and information for
maintaining and troubleshooting the printer.
The Software User’s Guide which is the second section of this guide provides information
you need for installing the supplied software and using its features.
This manual is provided for information purposes only. All information included herein
is subject to change without notice. Samsung Electronics is not responsible for any
damages, direct or indirect, arising from or related to use of this manual.
© 2005 Samsung Electronics Co., Ltd. All rights reserved.
• Samsung logo is trademarks of Samsung Electronics Co., Ltd.
• Centronics is a trademark of Centronics Data Computer Corporation.
• IBM and IBM PC are trademarks of International Business Machines Corporation.
•Microsoft,Windows,Windows 98, Windows Me, Windows 2000 and Windows XP
are registered trademarks of Microsoft Corporation.
• All other brand or product names are trademarks of their respective companies or
organizations.

2
Contact SAMSUNG WORLD WIDE
If you have any comments or questions regarding Samsung products, contact
the SAMSUNG customer care center.
Country Customer Care Center Web Site
ARGENTINE 0800-333-3733 www.samsung.com/ar
AUSTRALIA 1300 362 603 www.samsung.com/au
AUSTRIA 0800-SAMSUNG (726-7864) www.samsung.com/at
BELGIUM 0032 (0)2 201 24 18 www.samsung.com/be
BRAZIL 0800-124-421 / 4004-0000 www.samsung.com/br
CANADA 1-800-SAMSUNG (7267864) www.samsung.com/ca
CHILE 800-726-7864 (SAMSUNG) www.samsung.com/cl
CHINA 800-810-5858 / 010- 6475 1880 www.samsung.com.cn
COLOMBIA 01-8000-112-112 www.samsung.com/co
COSTA RICA 0-800-507-7267 www.samsung.com/latin
CZECH
REPUBLIC
844 000 844 www.samsung.com/cz
Distributor pro Českou republiku : Samsung Zrt., česka
organizační složka Vyskočilova 4, 14000 Praha 4
DENMARK 70 70 19 70 www.samsung.com/dk
ECUADOR 1-800-10-7267 www.samsung.com/latin
EL SALVADOR 800-6225 www.samsung.com/latin
ESTONIA 800-7267 www.samsung.ee
KAZAHSTAN 8-10-800-500-55-500 www.samsung.kz
KYRGYZSTAN 00-800-500-55-500
FINLAND 030-6227 515 www.samsung.com/fi
FRANCE 3260 SAMSUNG or
08 25 08 65 65 (€ 0,15/min)
www.samsung.com/fr
GERMANY 01805 - 121213 (€ 0,14/min) www.samsung.de
GUATEMALA 1-800-299-0013 www.samsung.com/latin
HONG KONG 3698 4698 www.samsung.com/hk
HUNGARY 06-80-SAMSUNG (7267864) www.samsung.com/hu
INDIA 3030 8282 / 1800 110011 www.samsung.com/in/
INDONESIA 0800-112-8888 www.samsung.com/id
ITALIA 800-SAMSUNG(7267864)
800-048989
www.samsung.com/it
JAMAICA 1-800-234-7267 www.samsung.com/latin
JAPAN 0120-327-527 www.samsung.com/jp

3
LATVIA 800-7267 www.samsung.com/lv/
index.htm
LITHUANIA 8-800-77777 www.samsung.com/lt
LUXEMBURG 0035 (0)2 261 03 710 www.samsung.com/be
MALAYSIA 1800-88-9999 www.samsung.com/my
MEXICO 01-800-SAMSUNG (7267864) www.samsung.com/mx
NETHERLANDS 0900 20 200 88 (€ 0,10/min) www.samsung.com/nl
NEW ZEALAND 0800SAMSUNG(726-7864) www.samsung.com/nz
NORWAY 815-56 480 www.samsung.com/no
PANAMA 800-7267 www.samsung.com/latin
PHILIPPINES 1800-10-SAMSUNG (7267864) www.samsung.com/ph
POLAND 0 801 801 881 / 022-607-93-33 www.samsung.com/pl
PORTUGAL 80 8 200 128 www.samsung.com/pt
PUERTO RICO 1-800-682-3180 www.samsung.com/latin
REP. DOMINICA 1-800-751-2676 www.samsung.com/latin
REPUBLIC OF
IRELAND
0818 717 100 www.samsung.com/uk
RUSSIA 8-800-555-55-55 www.samsung.ru
SINGAPORE 1800-SAMSUNG (7267864) www.samsung.com/sg
SLOVAKIA 0800-SAMSUNG (726786) www.samsung.com/sk
SOUTH AFRICA 0860 726 7864 (SAMSUNG) www.samsung.com/za
SPAIN 902 10 11 30 www.samsung.com/es
SWEDEN 0771-400 200 www.samsung.com/se
SWITZERLAND 0800-7267864 www.samsung.com/ch/
TAIWAN 0800-329-999 www.samsung.com/tw
THAILAND 1800-29-3232 / 02-689-3232 www.samsung.com/th
TRINIDAD &
TOBAGO
1-800-7267-864 www.samsung.com/latin
TURKEY 444 77 11 www.samsung.com.tr
U.A.E 800-SAMSUNG (7267864) www.samsung.com/mea
U.K 0870 SAMSUNG (7267864) www.samsung.com/uk
U.S.A. 1-800-SAMSUNG (7267864) www.samsung.com
UKRAINE 8-800-502-0000 www.samsung.ua
UZBEKISTAN 8-800-120-0400 www.samsung.com.uz
VENEZUELA 0-800-100-5303 www.samsung.com/latin
VIETNAM 1 800 588 889 www.samsung.com/vn
Country Customer Care Center Web Site

4
CONTENTS
Chapter 1: INTRODUCTION
Special Features .................................................. 1.2
Printer Driver Features ......................................... 1.3
Printer Components ............................................. 1.4
Front View ..................................................... 1.4
Rear View ...................................................... 1.5
Understanding the Control Panel ............................ 1.6
On Line/Error and Toner Save LEDs ................... 1.6
Cancel button ................................................. 1.7
Chapter 2: SETTING UPYOUR PRINTER
Unpacking .......................................................... 2.2
Selecting a Location ........................................ 2.3
Installing the Toner Cartridge ................................ 2.4
Loading Paper ..................................................... 2.7
Connecting a Printer Cable .................................... 2.9
Turning the Printer on .........................................2.10
Printing a Demo Page .......................................... 2.11
Installing Printer Software ................................... 2.12
System Requirements .................................... 2.12
Chapter 3: USING PRINT MATERIALS
Choosing Paper and Other Materials ....................... 3.2
Typeand Capacities ........................................ 3.3
Guidelines for Paper and SpecialMaterials .......... 3.3
Verifying the Output Location ................................ 3.6
Loading Paper ..................................................... 3.6
Using the Tray ................................................ 3.6
Using Manual Feed Mode ................................. 3.7
Printing on Special Materials ................................. 3.8
Canceling a Print Job ........................................... 3.10

5
Chapter 4: MAINTAINING YOUR PRINTER
Maintaining the Toner Cartridge ............................. 4.2
Redistributing Toner ........................................ 4.3
Replacing the Toner Cartridge .......................... 4.5
Using the Toner Save Mode ................................... 4.5
Cleaning the Printer ............................................. 4.6
Cleaning the Outside ....................................... 4.6
Cleaning the Inside ......................................... 4.6
Consumables and Replacement Parts ..................... 4.9
Chapter 5: SOLVING PROBLEMS
Troubleshooting Checklist ..................................... 5.2
Solving General Printing Problems .......................... 5.3
Clearing Paper Jams ............................................. 5.6
In the Paper Exit Area ..................................... 5.6
In the Paper Feed Area .................................... 5.8
Around the Toner Cartridge .............................. 5.9
Tips for Avoiding Paper Jams ........................... 5.10
Solving Print Quality Problems .............................. 5.10
Print Quality Checklist .................................... 5.10
Solving Print Quality Problems ......................... 5.11
Troubleshooting Error Messages ........................... 5.16
Common Windows Problems ................................ 5.17
Common Linux Problems ..................................... 5.18
Chapter 6: SPECIFICATIONS
Printer Specifications ............................................ 6.2
Paper Specifications ............................................. 6.3
Overview ....................................................... 6.3
Supported Sizes of Paper ................................. 6.4
Guidelines for Using Paper ............................... 6.5
Paper Specifications ........................................ 6.6
Paper Output Capacity ..................................... 6.6
Printer and Paper Storage Environment ............. 6.7

6
Important Precautions and Safety Information
When using this machine, these basic safety precautions should always be followed
to reduce risk of fire, electric shock, and injury to people:
1 Read and understand all instructions.
2 Use common sense whenever operating electrical appliances.
3 Follow all warnings and instructions marked on the machine and in the literature
accompanying the machine.
4 If an operating instruction appears to conflict with safety information, heed the
safety information. You may have misunderstood the operating instruction. If
you cannot resolve the conflict, contact your sales or service representative for
assistance.
5 Unplug the machine from the AC wall socket before cleaning. Do not use liquid or
aerosol cleaners. Use only a damp cloth for cleaning.
6 Do not place the machine on an unstable cart, stand or table. It may fall, causing
serious damage.
7 Your machine should never be placed on, near or over a radiator, heater, air
conditioner or ventilation duct.
8 Do not allow anything to rest on the power cable. Do not locate your machine
where the cords will be abused by persons walking on them.
9 Do not overload wall outlets and extension cords. This can diminish
performance, and may result in the risk of fire or electric shock.
10 Do not allow pets to chew on the AC power or PC interface cords.
11 Never push objects of any kind into the machine through case or cabinet
openings. They may touch dangerous voltage points, creating a risk of fire or
shock. Never spill liquid of any kind onto or into the machine.
12 To reduce the risk of electric shock, do not disassemble the machine. Take it to a
qualified service technician when repair work is required. Opening or removing
covers may expose you to dangerous voltages or other risks. Incorrect
reassembly could cause electric shock when the unit is subsequently used.

7
13 Unplug the machine from the PC and AC wall outlet, and refer servicing to
qualified service personnel under the following conditions:
•When any part of the power cord, plug, or connecting cable is damaged or
frayed.
•If liquid has been spilled into the machine.
•If the machine has been exposed to rain or water.
•If the machine does not operate properly after instructions have been followed.
•If the machine has been dropped, or the cabinet appears damaged.
•If the machine exhibits a sudden and distinct change in performance.
14 Adjust only those controls covered by the operating instructions. Improper
adjustment of other controls may result in damage, and may require extensive
work by a qualified service technician to restore the machine to normal
operation.
15 Avoid using this machine during a lightning storm. There may be a remote risk of
electric shock from lightning. If possible, unplug the AC power for the duration of
the lightning storm.
16 If you continuously print multiple pages, the surface of the output tray may
become hot. Be careful not to touch the surface, and keep children away from
the surface.
17 SAVE THESE INSTRUCTIONS.

8
Environmental and Safety Consideration
Laser Safety Statement
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR,
chapter 1 Subchapter J for Class I(1) laser products, and elsewhere, is certified as a
Class I laser product conforming to the requirements of IEC 825.
Class I laser products are not considered to be hazardous. The laser system and
printer are designed so there is never any human access to laser radiation above a
Class I level during normal operation, user maintenance, or prescribed service
condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/
Scanner assembly. The reflected beam, although invisible, can damage your eyes.
When using this product, these basic safety precautions should always be followed to
reduce risk of fire, electric shock, and injury to persons:

9
Ozone Safety
During normal operation, this machine produces ozone. The ozone produced does not
present a hazard to the operator. However, it is advisable that the machine be
operated in a well ventilated area.
If you need additional information about ozone, please contact your nearest Samsung
dealer.
Power Saver
This printer contains advanced energy conservation technology that reduces power
consumption when it is not in active use.
When the printer does not receive data for an extended period of time, power
consumption is automatically lowered.
The energy star emblem does not represent EPA endorsement of any product or
service.
Recycling
Please recycle or dispose of the packaging material for this product in an
environmentally responsible manner.

10
Radio Frequency Emissions
FCC regulations
Thisdevice complies with Part15of the FCC Rules.Operation is subject tothe
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1 Reposition the receiving antenna.
2 Increase the separation between the equipment and receiver.
3 Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4 Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user’s authority to operate the equipment.
Canadian Radio Interference Regulations
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the interference-causing equipment standard
entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux
appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:
“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.

11
Declaration of Conformity (European Countries)
Approvals and Certifications
The CE marking applied to this product symbolizes Samsung Electronics Co., Ltd.
Declaration of Conformity with the following applicable 93/68/EEC Directives of the
European Union as of the dates indicated:
January 1, 1995: Council Directive 73/23/EEC Approximation of the laws of the
member states related to low voltage equipment.
January 1, 1996: Council Directive 89/336/EEC (92/31/EEC), approximation of the
laws of the Member States related to electromagnetic compatibility.
March 9, 1999: Council Directive 1999/5/EC on radio equipment and
telecommunications terminal equipment and the mutual recognition of their
conformity.
A full declaration, defining the relevant Directives and referenced standards can be
obtained from your Samsung Electronics Co., Ltd. representative.

12

1Introduction
Congratulations on the purchase of your Printer!
This chapter includes:
• Special Features
• Printer Driver Features
• Printer Components
• Understanding the Control Panel

I NTRODUCTION
1.2
Special Features
Your new printer is equipped with special features that improve
the print quality, giving you a competitive edge. You can:
Print with excellent quality and high speed
• You can print at 600 dots per inch (dpi).
• Up to
16 ppm in A4 ( 17 ppm in Letter ).
Handle paper flexibly
• Standard 150-sheet tray supports various sizes and types
of paper.
• 50-sheet output tray supports convenient access.
Create professional documents
• You can customize your documents using Watermarks , such
as “Confidential.” For details, See
Software User’s Guide .
• Print
Posters . The text and pictures of each page of your
document are magnified and printed across the selected sheet
of paper. After the document has printed, trim off the white
edges of each sheet. Tape the sheets together to form a
poster. For details, see
Software User’s Guide .
Save your time and money
• Allows you to use the Toner Save mode to save toner. For
details, see
Software User’s Guide and page 4.5.
• Allows you to print multiple pages on one single sheet of paper
to save paper (
N-Up printing ). For details, see Software
User’s Guide
.
• You can use preprinted forms and letterhead on plain paper.
For details, see
Software User’s Guide .
• This printer meets
Energy Star guidelines for energy
efficiency.
Print in various environments
• You can print in Windows 98/Me/2000/XP .
• Your printer is compatible with various
Linux OS .
• Your printer comes with the
USB interface.
WORLD BEST
Dear ABC
Regards

I NTRODUCTION
1.3
1
Printer Driver Features
Your printer drivers will support the following standard
features:
• Paper source selection
• Paper size, orientation and media type
• number of copies
Table below lists a general overview of features supported by
your printer drivers.
Feature
Printer Driver
Win98/Me/2000/XP
Toner Save Y
Print quality option Y
Poster printing Y
Multiple pages per sheet (N-up) Y
Fit to page printing Y
Scale printing Y
Watermark Y
Overlay Y

I NTRODUCTION
1.4
Printer Components
Front View
Front cover
Paper output tray
(Face down)
Control panel
Paper input tray
Top cover
Output support
Inside view
Toner cartridge
Rear guide Side guides

I NTRODUCTION
1.5
1
Rear View
USB port
Power receptacle
Power switch

I NTRODUCTION
1.6
Understanding the Control Panel
On Line/Error and Toner Save LEDs
LED Description
If the On Line/Error lights green, the printer is ready to
print.
If the
On Line/Error lights red, the printer is experiencing
an error,such as jammed paper,no paper,the open top or
front cover, or the empty toner cartridge.
See “Troubleshooting Error Messages” on page 5.16.
If you press the
Cancel button while the printer is receiving
data, the
On Line/Error LEDblinks redto cancel printing.
In Manual Feed mode, if there is no paper in the tray, the
On
Line/Error
LEDblinks green.
Load paper into the tray and the LED stops blinking.
If the printer is receiving data, the
On Line/Error LED slowly
blinks green.
If the printer is printing the received data, the
On Line/
Error
LED blinks green fast.

I NTRODUCTION
1.7
1
Cancel button
If you press the Cancel button in Ready mode, this LED is on
and the Toner Save mode is enabled.
If you press this button once again, this LED is off and the
Toner Save mode is disabled.
If the
On Line/Error and Toner Save LEDs blink, your
system has some problems.
To solve the problem, see “Troubleshooting Error Messages”
on page 5.16
LED Description
Function Description
Printing demo page
In Ready mode, press and hold this button for about 2
seconds until all LEDs blink slowly, and release.
Manual feeding Press this button each time you load a sheet of paper in the
tray, when you select
Manual Feed for Source from your
software application.
For detailed information, see “Using Manual Feed Mode” on
page 3.7.
Canceling print job Press this button during printing. The On Line/Error LED
blinks while the print job is cleared from both the printer
and the computer, and then return to Ready mode. This
may take some time depending on the size of the print job.
In Manual Feed mode, you can’t cancel the print job by
pressing this button.
For detailed information, see “Using Manual Feed Mode” on
page 3.7.
Toner Save mode
on/off
In Ready mode, press this button to turn the Toner Save
mode on or off.
For detailed information, see
Software User’s Guide and
page 4.5.
