Samsung ML-4600 User manual

This manual is provided for information purposes only. All information included herein is
subject to change without notice. Samsung Electronics is not responsible for any damages, direct
or indirect, arising from or related to use of this manual.
© 2 Samsung Electronics Co., Ltd. All rights reserved.
• ML-46 and Samsung logo are trademarks of Samsung Electronics Co., Ltd.
• IBM and IBM PC are trademarks of International Business Machines Corporation.
• Microsoft, Windows, Windows 9x, Windows 2 and Windows NT are trademarks of
Microsoft Corporation.
• PCL and PCL6 are trademarks of Hewlett-Packard Company.
• Apple, Macintosh, Power Macintosh, iMac and iBook are trademarks of Apple Computer, Inc.
• GNU Ghostscript software, Copyright (C) 1999. Aladdin Enterprise, Menlo Park, California,
and other authors as indicated in its documentation.
• All other brand or product names are trademarks of their respective companies or
organizations.

I
Special Features –––––––––––––––––––––––––––––––––
1.1
Printer Components
–––––––––––––––––––––––––––––– 1.3
Control Panel Buttons –––––––––––––––––––––––––––––– 3.1
Control Panel Lights ––––––––––––––––––––––––––––––– 3.3
Contents
Introduction
STEP 1:Unpack Your Printer –––––––––––––––––––––––––– 2.1
STEP 2:nstall the Toner Cartridge ––––––––––––––––––––– 2.2
STEP 3:Load Paper ––––––––––––––––––––––––––––––––– 2.4
STEP 4:Connect to the Computer with a Parallel Cable ––––– 2.6
STEP 5:Turn on the Printer ––––––––––––––––––––––––––– 2.7
STEP 6:Print a Demo Page! ––––––––––––––––––––––––––– 2.7
STEP 7:nstall the Printer Software ––––––––––––––––––––– 2.8
nstalling Software from Diskette –––––––––––––––––––– 2.13
Choosing Paper and Other Media ––––––––––––––––––––– 4.1
Selecting the Output Location ––––––––––––––––––––––– 4.4
Loading Paper –––––––––––––––––––––––––––––––––––– 4.5
Printing on Envelopes –––––––––––––––––––––––––––––– 4.7
Printing on Heavy Paper –––––––––––––––––––––––––––– 4.9
Printing on Labels –––––––––––––––––––––––––––––––– 4.10
Printing on Transparencies ––––––––––––––––––––––––– 4.11
Printing on Preprinted Paper ––––––––––––––––––––––– 4.12
Printing on Card Stock or Custom-sized Media –––––––––– 4.13
1
2
Setting Up Your Printer
3
Using Control Panel
4
Print Media

II
Maintaining Toner Cartridge ––––––––––––––––––––––––– 6.1
Cleaning the Printer ––––––––––––––––––––––––––––––– 6.4
Maintaining Your Printer
6
Printing a Document ––––––––––––––––––––––––––––––– 5.1
Using Toner Save Mode –––––––––––––––––––––––––––– 5.6
Printing Multiple Pages on One Sheet of Paper –––––––––– 5.7
Fitting Your Document to a Selected Paper Size ––––––––– 5.8
Printing Posters ––––––––––––––––––––––––––––––––––– 5.9
Setting Graphic Properties ––––––––––––––––––––––––– 5.11
Printing Watermarks –––––––––––––––––––––––––––––– 5.14
Using Page Overlay ––––––––––––––––––––––––––––––– 5.17
Reprinting the Last Page –––––––––––––––––––––––––– 5.21
Printing on a Network Environment ––––––––––––––––––– 5.22
Printing Tasks
5
Troubleshooting Checklist ––––––––––––––––––––––––––– 7.1
Solving General Printing Problems –––––––––––––––––––– 7.2
Clearing Paper Jams ––––––––––––––––––––––––––––––– 7.6
Solving Print Quality Problems –––––––––––––––––––––– 7.11
Troubleshooting Error Messages ––––––––––––––––––––– 7.17
Common Windows Problems –––––––––––––––––––––––– 7.19
Problem Solving
7
Printer Specifications ––––––––––––––––––––––––––––––– A.1
Paper Specifications –––––––––––––––––––––––––––––––– A.2
Using Your Printer with a USB Cable ––––––––––––––––– A.10
Using Your Printer with Macintosh ––––––––––––––––––– A.16
Printing from DOS Applications ––––––––––––––––––––– A.23
Linux Driver nstallation ––––––––––––––––––––––––––– A.28
nstalling Optional Memory Card ––––––––––––––––––––– A.30
Appendix
INDEX

III
Environmental and Safety Consideration
The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR, chapter 1
Subchapter J for Class (1) laser products, and elsewhere is certified as a Class laser product
conforming to the requirements of EC 825.
Class laser products are not considered to be hazardous. The laser system and printer are
designed so there is never any human access to laser radiation above a Class level during
normal operation, user maintenance, or prescribed service condition.
WARNING
Never operate or service the printer with the protective cover removed from Laser/Scanner
assembly. The reflected beam, although invisible, can damage your eyes.
CAUT ON - NV S BLE LASER RAD AT ON WHEN TH S COVER OPEN. DO
NOT OPEN TH S COVER.
VORS CHT - UNS CHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET. N CHT
DEM STRAHL AUSSETZEN.
ATTENT ON - RAYONNEMENT LASER NV S BLE EN CAS D’OUVERTURE.EXPOS T ON DAN
GEREUSE AU FA SCEAU.
ATTENZ ONE -RAD AZ ONE LASER NV S B LE N CASO D APERTURA.
EV TARE L’ESPOS Z ONE AL FASC O.
PRECAUC ON -RAD AC ON LASER V S BLE CUANDO SE ABRE. EV TAR EXPONERSE AL
RAYO.
ADVARSEL. - USYNL G LASERSTRÅLN NG VED ÅBN NG NÅR S KKERHEDSBRYDERE ER
UDE AF FUNKT ON. UNDGÅ UDSAETTELSE FOR STRÅLN NG.
ADVARSEL. - USYNL G LASERSTRÅLN NG NÅR DEKSEL ÅPNES. ST RR KKE NN
STRÅLEN. UNNGÅ EKSPONER NG FOR STRÅLEN.
VARN NG - OSYNL G LASERSTRÅLN NG NÄR DENNA DEL ÄR ÖPPAND OCH SPÄRREN ÄR
URKOPPLAD. BETRAKTA EJ STRÅLEN. STRÅLEN ÄR FARL G.
VARO! - AVATTAESSA JA SUOJALUK TUS OH TETTAESSA OLET ALTT NA
NÄKYMÄTTÖMÄLLE LASERSÄTE LYLLE ÄLÄ KATSO SÄTEESEEN.
Laser Safety Statement

IV
Ozone Safety
Power Saver
During normal operation, the Samsung ML-4600 printer produces
ozone. The ozone produced does not present a hazard to the
operator. However, it is advisable that the machine be operated in
a well ventilated area.
f you need additional information about ozone, please contact
your nearest Samsung dealer.
This printer contains advanced energy conservation technology
that reduces power consumption when it is not in active use.
When the printer does not receive data for an extended period of
time, power consumption is automatically lowered.
The energy star emblem does not represent EPA endorsement of
any product or service.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
f this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• ncrease the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Regulations
Radio Frequency Emissions
Environmental and Safety Consideration

V
Do not make any changes or modifications to the equipment unless otherwise specified in the
manual. f such changes or modifications should be made, you must first stop operation of the
equipment.
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of FCC
Rules.
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the interference-causing equipment standard entitled “Digital
Apparatus”, CES-003 of the ndustry and Science Canada.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils
numériques de Classe B prescrites dans la norme sur le matériel brouilleur: “Appareils
Numériques”, CES-003 édictée par l’ ndustrie et Sciences Canada.
Canadian Radio Interference Regulations
We,
SAMSUNG ELECTRON CS CO., LTD.
#259, Gong Dan-Dong, Gumi-City, Kyung Buk, Korea
declares sole responsibility that the
Samsung ML-4600 Laser printer
meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility and Low Voltage
Directive 73/23/EEC.
Compliance was demonstrated to the following specifications as listed in the official journal of
the European Communities:
EN 50081-Emissions:
EN 55022 Radiated, Class B
EN 55022 Conducted, Class B
EN 61000-3-2 Power Harmonics
EN 61000-3-3 Voltage Fluctuations and Flicker
EN 50082- mmunity:
EC 801-2 Electrostatic Discharge
EC 801-3 RF Radiated
EC 801-4 Fast Transient/Burst
EN 60950-Safety
EC Declaration of Conformity
Environmental and Safety Consideration

Congratulations on your purchase of a Samsung ML-4600
printer! This chapter provides information on the
following topics
◆ Special Features
◆ Printer Components
1
1

Special Features
INTRODUCTION
1.1
Samsung ML-4600 is a versatile, productive printer equipped
with special features that will improve print quality, giving you
a competitive edge. You can
• You can print at 1200 dpi class. See page 5.12.
• Your printer prints 8 pages-per-minute.
• The PCL 6 printer language enables fast printing
performance.
Print with excellent quality and high speed
• Standard 150-sheet automatic feeder and a 1-sheet
manual feeder supports various sizes and types of paper.
• Two output locations Select either the face-down output
tray or the face-up output slot for the most convenient
access.
Flexible paper handling
• If you select Toner ave mode, your printer will use less
toner. See page 5.6.
• Print multiple pages on a single sheet of paper to save paper
(N-up printing). See page 5.7.
• One-touch last page printing is available in the Ready
mode. See page 5.21.
• The printer conserves electricity by automatically reducing
power consumption when it is not active.
• This product meets Energy tar guidelines for energy
efficiency.
Save your time and money

INTRODUCTION
1.2
• You can customize your documents by using Watermarks
such as “Confidential.” See page 5.14.
• Preprinted forms and letterheads can be printed on plain
paper. See page 5.17.
• Print Posters. The text and pictures of each page of your
document are magnified and printed across the selected
sheet of paper. After the document has printed, trim off the
white edges of each sheet. Tape the sheets together to form
a poster. See page 5.9.
Create professional documents
WORLD BEST
Dear ABC
Regards
• You can print in Windows 95/98/NT4.0/2000.
• Your printer is compatible with Linux, DO , and Macintosh.
• The ML-4600 printer comes with both Parallel and U B
interfaces.
Print in various environments
The ML-4600 is shipped with 4 MB of memory included. You
can expand the memory capacity of your printer (up to 68 MB
maximum) by installing optional memory modules. See page
A.30.
Expand the printer capacity
Special Features
