Samsung SCC-B5398 User manual

ENG
DIGITAL COLOR DOME
CAMERA
user manual
SCC-B5398
SCC-B5396
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsungsecurity.com
ENG FRE
GER
SPA
ITA

2– DIGITAL COLOR DOME CAMERA
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of electric shock is
present within this unit.
This exclamation point symbol is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
WARNING
To prevent damage which may result in fire or electric shock hazard, do not expose this appliance to rain
or moisture.
WARNING
Be sure to use only the standard adapter that is specified in the specification sheet. Using any other adapter
could cause fire, electrical shock, or damage to the product
Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or
damage to the product.
Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat
generation or fire.
Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
When installing the camera, fasten it securely and firmly. A falling camera may cause personal injury.
Do not place conductive objects (e.g. screwdrivers, coins, metal things, etc.) or containers filled with water
on top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.
Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
•
1.
2.
3.
4.
5.
6.
7.
Safety information
CA
8.
9.
10
1.
2.
3.
4.
5.
6.
7.
8.
9.

English – 3
ENG
S
nt
er
Safety information
If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately
disconnect the power source and contact the service center. Continued use in such a condition may cause
fire or electric shock.
If this product fails to operate normally, contact the nearest service center. Never disassemble or modify
this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or
attempted repair.)
When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
CAUTION
Do not drop objects on the product or apply strong shock to it. Keep away from a location subject to
excessive vibrationor magnetic interference.
Do not install in a location subject to high temperature (over 50°C), low temperature (below -10°C), or high
humidity. Doing so may cause fire or electric shock.
If you want to relocate the already installed product, be sure to turn off the power and then move or reinstall
it.
Remove the power plug from the outlet when then there is a lightning. Neglecting to do so may cause fire or
damage to the product.
Keep out of direct sunlight and heat radiation sources. It may cause fire.
Install it in a place with good ventilation.
Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the
CCD image sensor.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
The Mains plug is used as a disconnect device and shall stay readily operable at any time.
8.
9.
10.
1.
2.
3.
4.
5.
6.
7.
8.
9.

4– DIGITAL COLOR DOME CAMERA
Important Safety Instructions
WARNING
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus.
Unplug this apparatus when a card is used. Use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
s

English – 5
ENG
s
e
nd
ve
or
Contents
Introduction
Features 6
Product & Accessories 7
Part Names and Functions 8
Installation
s Installation procedure 11
Adjusting the camera direction 12
How to use OSD Menu
Using Icons in the Menu 14
Main Menu 14
Profile 15
Camera Setup 17
Intelligence 24
Privacy Zone Setup
27
Other Set 28
System Information 29
Language 29
Specifications
Specifications 30

6– DIGITAL COLOR DOME CAMERA
Introduction
FEATURES
High Resolution
This camera has realized high resolution of 600 lines using the top-notch full digital image processing and special
algorithm technologies.
Intelligent Motion Detection & Tracking
This is an intelligent function that automatically detects a motion of an object. You can set a virtual fence so it displays an
alert if an object passes / enters /exits the virtual fence or virtual area.
XDR (eXtended Dynamic Range)
Actively controls the gamma compensation in the way it operates the ambient luminance contrast in a certain pixel
unit to determine the optimal visibility.
High Sensitivity
It implements images of high sensitivity using the up-to-date SONY Super-HAD IT CCD..
Low Illumination
It uses the digital signal technologies such as low illumination and Day/Night functions that make your camera identify
objects even in the worst environment.
Superior Backlight Adjustment
When an object has a bright illumination or sunlight behind it, this camera automatically improves the shaded object
picture quality.
Digital Power Synchronization
The full digital Line Lock function directly adjusts the vertical camera synchronization to enhance the operationability
and reliability of this camera.
Output Signal Setting
You can set the following Video output signals: Image reversion (Horizontal, Vertical, or both), Privacy, Horizontal/
Vertical profiling, and digital zooming.
OSD(On Screen Display) Menu
OSD menu is provided to display the status of camera and to configure the functions interactively.
❖
•
❖
•
❖
•
❖
•
❖
•
❖
•
❖
•
❖
•
❖
•
C
Coaxial Cable Communication
This is a remote control function that overlaps the coaxial cable (for a transfer of the video signal) with the
control signal. In installation or repair, this helps you control the communication controller (optional) without
additional cabling.
❖
•

English – 7
ENG
Introduction
Components
Checking components in the package
Camera
Test Monitor Cable User’s Guide
Image Part name Standard Quantity Usage
Plastic anchor HUD 5 4 (EA)
Attach each piece to screw connection holes for
strengthening connection
ASSY screw
machine
BH M5 X L6.
(White+o-ring)
8Used for filling in the holes when installing
pipe and wall mount
ASSY screw
tapping
TH M4xL30 (Black+
o-ring)
4Used when installing your camera on the
ceiling or wall。
L-Wrench TROX T-20 1 Used for assembling/disassembling the
Dome cover
Template 1 Used for guiding the installation
Gasket-pipe hole T2.5 W56 1 Used to make a wiring hole when installing
the camera on the ceiling or wall
NOTE
The test monitor cable is used to test the camera by connecting to a portable display. If you
really want to connect the camera to a monitoring display, use the BNC cable. 。
–
–
–

8– DIGITAL COLOR DOME CAMERA
Introduction
1
24
Lens
910
11
3
8
12
Video connector
Power connector
5
66
7
7
1.Dome cover: Covers the inner cover, lens, and
main body to protect them.
2.Cover screw: Use it to assemble or
disassemble both dome cover and case.
3.Inner cover: Covers the main body to protect it.
4.Wing locker: Push a long thin screwdriver into
its narrow spot and press it outward when you want
to remove the inner cover.
5.Main body: Includes a lens, a switch board, a
PCB board, screws, and such.
6.Screws for assembly and disassembly: Using
these 2 screws, the Main
body is closely connected to the Case.
7.Hooker: By pulling the left/right levers in the
arrow direction, the Main body can be detached
from the Case.
8.Case: Used as a ceiling or wall fixture. It is
fixed using four screws provided in the package.
9.Zoom lever: Using this lever, the lens zoom can
be adjusted and fixed.
10.Focus lever: Using this lever, the lens focus can
be adjusted and fixed.
11.Tilt fixing screw: Using this screw, the slope of
the lens can be adjusted and fixed.
12.Cable: Connect the Video connector to BNC
cable and Power connector to power adapter.
Components of your camera
Your camera has the following components:
❖
•

English – 9
ENG
Introduction
Setting switches❖
SETUP Switch
This switch is used to set the function or property. When this switch is pressed for at least 2 seconds, the
MAIN MENU appears.
ef (Left/Right) : By pressing this switch left or right, you can move left or right on the menu or change the
displayed value.
cd (Up/Down) : By pressing this switch up or down, you can move up or down on the menu.
: When you press this switch in the menu, the selected function is confirmed. To enter a submenu, press
this button..
•

10 – DIGITAL COLOR DOME CAMERA
Installation
C
B
A
Bottom of camera
Installing camera
Before installation
Before installing your camera, you have to read the following cautions:

You have to check whether the location (ceiling or wall) can bear five times the weight of your camera.

Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may
cause a breakdown or fire. You can use wall mount adaptor (SADT-102WM), and pole mount adaptor (SADT-
100PM) for installing the camera on the wall or pipeline.

When installing your camera, don’t allow any person to approach the installation site. If you have any valuable
things under the place, move th
em away.
About the installation holes
A:Use these holes when directly installing your camera on the ceiling or
wall.
While those are not used, fill in the holes using the screw machine (M5
X L6.) for waterproofing.
B: Use four holes when directly installing your camera on the junction box
You can use the 4 1/8 diameter round type junction box for assembly.
(The junction box, gasket, and cover are separately purchased items.)
C: Use these holes when installing the wall mount adapter (SADT-
102WM)
While those are not used, fill in the holes using the screw machine (M5
X L6.)
for waterproofing.
The holes that are not used should be tightly
sealed up using the screws provided for
waterproofing. When the screws don’t have rubber
rings inside or are not closely attached, note that it
can cause waterproofing problem.
For attaching screws, see page 16
“Disassembling/assembling the Main body from
the Case.”
B
a
To
1.
2
