Samsung SCC-C7437 User manual

Samsung Video Security System | 68 . 69
34x Optical Zoom High Speed Dome Camera
SCC-C7437/C7439
• 1/4" SONY 410K/470K Pixels Super-HAD IT CCD (SCC-C7437)
1/4" SONY 410K/470K Pixels Ex-View HAD PS CCD (SCC-C7439)
• 34x Optical & 16x(0.1step) Digital Zoom
• High Resolution : 600 TV Lines
• Min. illumination 0.0007 Lux (F1.2, 15 IRE, Sens-up 512x, Color)
0.00007 Lux (F1.2, 15 IRE, Sens-up 512x, B/W)
• 0~360º Endless Pan, -6~186º Tilting (D-Flip)
• Pan/Tilt Speed Min. 0.01º/sec, Max. 600º/sec
• Preset 512 ea, Auto Pan 4 ea, Pattern 3 ea
• Wide Dynamic Range (NTSC 128x, PAL 160x) : SCC-C7439 Only
• Virtual Progressive Scan (VPS) : SCC-C7439 Only
• Day Night Function (ICR), Sens-up Function (512x)
• Adaptive Digital Noise Reduction (3D + 2D)
• Back Light Compensation (Area Setting)
• Advanced Motion Detection Function
• eXtended Dynamic Range (XDR)
• Privacy Mask Function (12ea)
• DIS (Digital Image Stabilization) • Time & Day Scheduling
• CCVC (Camera Control Via Coaxial cable, Controller : SCX-RD100)
• RS-485 (Half/Full)/RS-422 Control (Multi-Protocol support)
• Multi-Language OSD (E, F, G, S, I, J, R, P, C, etc) support
• Intelligent Video (Moved/Fixed/Fence/Tracking)
• Alarm Input 8 ea, Output 4 ea
• Operating Temp. : -50 ~ 50˚C
Features
Camera Type Color/BW
Image Device
Pixels Effective
Resolution Horizontal
Min. Scene Color Sens-up Off
Illumination Sens up 512x
B/W Sens-up Off
Sens up 512x
Pan/Tilt Speed Manual Pan
Preset Pan
Manual Tilt
Preset Tilt
Range Panning / Tilting
Number of Auto PAN
Number of Preset
Number of Pattern
Functions Number of Privacy Zone
Day/Night / Motion Detection
Wide Dynamic Range
D-Zoom / High Speed Shutter
Sens Up / BLC
AGC
Auto Focus
Syncronization
Camera ID
VPS (Virtual Progressive Scan)
XDR (eXtended Dynamic Range)
DNR (Digital Noise Reduction)
Schedule
White Balance
Video Output VBS 1.0Vp-p
S/N Ratio
Lens Focal Length / Min. Object Distance
Zoom Ratio / Aperature Ratio
Viewing Angle Tele
Wide
Lens Drive Type / Mount Type
OSD
Alarm Input / Output
Remote Control
Environmental Operating Temperature
Conditions Operating Humidity
Power Power Requirement
Power Consumption
LED Indicator
Physical Dimensions
Specification Weight
Color
Specifications
Color
1/4" Super-HAD IT CCD 1/4" ExView-HAD PS CCD
768 x 494 (NTSC) / 752 x 582 (PAL)
600 TV Lines
0.6Lux(15IRE), 1.2Lux(30IRE), 2Lux(50IRE) 0.3Lux(15IRE), 0.7Lux(30IRE), 1.2Lux(50IRE)
0.001Lux(15IRE) , 0.002Lux(30IRE), 0.004Lux(50IRE) 0.0007Lux(15IRE), 0.001Lux(30IRE), 0.002Lux(50IRE)
0.06Lux(15IRE), 0.12Lux(30IRE), 0.2Lux(50IRE) 0.03Lux(15IRE), 0.07Lux(30IRE), 0.12Lux(50IRE)
0.0001Lux(15IRE), 0.0002Lux(30IRE), 0.0004Lux(50IRE) 0.00007Lux(15IRE), 0.0001Lux(30IRE), 0.0002Lux(50IRE)
0.01˚/sec ~ 180˚/sec
600˚/sec
0.01˚/sec ~ 180˚/sec
600˚/sec
0˚~360˚(Endless) /-6˚~186˚
4 ea
512 ea
3 ea
12 ea
Auto / Day / Night(ICR) /Yes, Sensitivity 1~7 Level
- Yes (NTSC:128x, PAL:160x)
Yes(~16x) /1/100~1/10K sec
Yes(2x ~ 512x) /Off/On
Off/On (Very Low / Low / Mid / High / Very High / User / Fix)
Manual / Auto (pan, tilt, zoom linked) / one AF
Internal / Line lock
Max 54 Character, 2 Line
-Yes
Off/On(Low/Middle/High)
Off/On(Low/Middle/High/User(3D/2D))
Day / Time Schedule
ATW1 / ATW2 / AWC(Manual) / 3200 / 5600
VBS 1.0Vp-p
52 dB
3.4 ~ 115.6mm / 100cm
34x Optical (688x with 16x Digital zoom) /F1.65(W)/F3.7(T)
1.47˚(H) x 1.10˚(V)0
61.22˚(H) x 47.16˚(V)
DC Auto Iris /Board-in type
Yes
8 ea /3 ea (2 Open Collector, 1 relay)
RS485(Half/Full Duplex) / RS422, CCVC
-50˚C ~ +50˚C
Less than 90%
24 VAC
16W / 47W(with fan/Heater)
Yes
228(Ø) x 256(H)mm
3.0kg
Light Gray
Model SCC-C7437 SCC-C7439
Easy Installation
Dimensions (unit:mm)
256
228
240
NEW
