Samsung SHR-6082 User manual

8 Channel/16 Channel DVR
User’s Manual
SHR-6080/6082/6160/6162/6163/6164
imagine the possibilities
Thanks you for purchasing this Samsung product.
To receive a more complete service, please
register your product at
www.samsungsecurity.com

2_ overview
overview
FEATURES
This DVR (Digital Video Recorder) employs MPEG-4 video encoding for 8 or 16 channels of camera input and G.723
audio encoding for 4 channels, and supports simultaneous hard disc recording and playback.
And also it supports network connectivity, providing remote monitoring from a remote PC by transferring video and
audio data.
Provides convenient User Interface
8/16 CH Composite Input Connectors
Supports CIF(S)/Half D1(M)/Full D1(L) recording formats
With the network specific codec, network transfer enabled regardless of the recording conditions
De-interlacing processor for better picture quality
Display of HDD information and status by using HDD SMART
CIF(S) Size (NTSC: 352*240, PAL: 352*288) Recording in 240 (NTSC)/200 (PAL) IPS speed (SHR-6163/6164)
CIF(S) Size (NTSC: 352*240, PAL: 352*288) Recording in 120 (NTSC)/100 (PAL) IPS speed (SHR-6080/6082/
6160/6162)
8/16-channel Loop Through Video port connection
Hard Disk overwrite function
Mass storage hard disk backup through high-speed USB 2.0
Backup function using USB 2.0 flash memory and external CD/DVD writer
(Internal DVD writer is not available for SHR-6080/6160/6163)
Simultaneous Record and Playback of 8/16-channel video data
Various Search Modes (Search By Time, Event, Backup, POS and Motion Detection)
Various Recording Modes (Time Lapse, Event, Scheduled Recording)
Extended Hard Disk Connection (USB 2.0)
Alarm Interface (Input: 8/16, Output: 4, Reset: 1)
Remote Monitoring function by Windows Network Viewer (NET-i Pro/Web viewer)
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

English _3
OVERVIEW
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit.
Follow all the safety instructions listed below.
Keep these operating instructions handy for future reference.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings, Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. if the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.
Unplug this apparatus during lightning storms or when unused for long
periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)

4_ overview
overview
BEFORE START
This user’s manual provides Information for using DVR such as brief introduction, part names, functions, connection
to other equipment, menu setup, and the like.
You have to keep in mind the following notices:
SEC retains the copyright on this manual.
This manual cannot be copied without SEC’s prior written approval.
We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of
instructions mentioned in this manual.
If you want to open the case of your system for checking problems, please consult the expert from the shop
where you bought the product.
You may download open source codes from the following website: www.samsungsecurity.com.
Before installing an additional HDD or connecting an external storage device (USB memory or USB HDD) to this
DVR, check the compatibility. Consult your provider for the compatibility list.
Warning
Battery
Exchanging a wrong battery in your product may cause an explosion. Therefore you must use the same type
of battery as the one being used in the product.
The following are the specifications of the battery you are using now.
Normal voltage: 3V
Normal capacity: 170mAh
Continuous standard load: 0.2mA
Operating temperature: -20°C ~ +85°C (-4°F ~ +185°F)
Connect the power cord into a grounded oulet.
The Mains plug is used as a disconnect device and shall stay readily operable at any time.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
System Shutdown
Turning off the power while the product is in operation, or taking not permitted actions may cause damage to
the hard drive or the product. Also it can cause a dysfunction to the hard disk while using the product.
Please turn off the power using the Power button on the front of your DVR.
After selecting <OK> in the pop-up menu, you can pull off the power cord.
You may want to install a UPS system for safe operation in order to prevent damage caused by an
unexpected power stoppage. (Any questions concerning UPS, consult your UPS retailer.)
Operating Temperature
The guaranteed operating temperature range of this product is 0°C ~ 40°C (32°F ~ 104°F).
This product may not work properly if you run right after a long period of storage at a temperature below the
guaranteed one.
When using the device after a long period of storage at low temperature, place the product at room
temperature for a while and run it.
Especially for the built-in HDD in the product, its guaranteed temperature range is 5°C ~ 55°C (41°F ~ 131°F).
Likewise, the hard drive may not work at a temperature below the guaranteed one.
•
•
•
•
•
•
❖
•
•
•
•
J


❖
❖

English _5
OVERVIEW
Package Contents
Please unwrap the product, and place the product on a flat place or in the place to be installed.
Please check the following contents are included in addition to the main unit.
Remote Control Mouse Power Cable
NET-i Pro Software / User’s Manual CD User’s Manual RS-485 connector port
Remote Control Battery (AAA) Bracket Rack SATA Cable

6_ overview
overview
CONTENTS
OVERVIEW
2
2Features
3Important Safety Instructions
4Before Start
6Contents
8Part Names and Functions (Front)
10 Part Names and Functions (Rear)
12 Remote Control
INSTALLATION
14
14 Checking the Installation Environment
15 Rack Installation
15 HDD Addition
CONNECTING WITH OTHER DEVICE
19
19 Connecting the Video, Audio, and Monitor
19 Connecting the Network
20 Connecting the USB
20 Connecting POS Device
21 Connecting the Alarm Input/Output
22 Connecting the RS-485 Device
LIVE
23
23 Getting Started
25 Live Screen Configuration
29 Live Mode
31 Spot Out
32 Zoom
32 Audio On/Off
32 Freeze
33 Event Monitoring
USING THE DVR
34
34 System Setup
42 Setting the Device
50 Setting the Recording
53 Setting the Event
56 Backup
57 Network Configuration
64 Controlling a PTZ Device
SEARCH & PLAY
66
66 Search
69 Playback

English _7
OVERVIEW
WEB VIEWER
70
70 Introducing Web Viewer
71 Connecting Web Viewer
73 Using Live Viewer
79 Using Search Viewer
83 Viewer Setup
93 About
BACKUP VIEWER
94
94 SEC Backup Viewer
APPENDIX
96
96 Product Specification
99 Product Overview
100 Default Setting
103 Troubleshooting
105 Open Source License Report on the Product

8_ overview
overview
PART NAMES AND FUNCTIONS (FRONT)
6080 1 3 4
7 10 6 5
2
8
6160/6163 1 3 4
7 6 5
2
8 10
1 3 4
7 10 6 5
2
9 8
6082
1 3 4
7 6 5
2
9 8 10
6162/6164

English _9
OVERVIEW
Part Names Functions
LED Indicator
ALARM : Lights on when an event occurs.
HDD : Displays the normal access to HDD.
Upon access to HDD, LED repeats on and off.
NETWORK : Displays both network connection and data transfer status.
BACKUP : Displays when Backup is in progress.
REC : Lights on when recording is in progress.
Camera Control
PTZ : Sets PTZ Mode ON/OFF.
ZOOM(TELE) : Sets the screen to the x2 digital zoom.
Runs the TELE function in the PTZ Mode.
FREEZE(WIDE) : Runs the FREEZE function in the Live Mode.
Runs the WIDE function in the PTZ Mode.
BACKUP(VIEW) : Runs the BACKUP function.
Runs the Preset View function in the PTZ Mode.
SEARCH(PRESET) : Goes to the search screen.
Runs the Preset Setup function in the PTZ Mode.
REC Starts or ends the recording.
/
Step Rewind (
) : Used for backward frame-by-frame search while in PAUSE.
Fast Rewind () : Used for quick backward search while in Play.
(-x2,-x4,-x8,-x16,-x32,-x64)
STOP : Used to stop the playback.
►/PLAY/PAUSE : Used to pause or resume the screen.
/Fast Forward () : Used for quick forward playback. (x2, x4, x8, x16, x32, x64)
Step Forward (
) : Used for forward frame-by-frame search while in PAUSE.
Direction &
Select Button
Used to change a value or move the cursor up/down/left/right (▲▼◄ ►).
Selects a menu item or executes the selected menu.
USB Port 1 & 2 Connects the USB devices.
MODE
Each button press in the Live Mode switches the screen to 16-, 9-, 4-, 6-, 8-, 13- split screen,
PIP, and auto sequence mode in order.
In play mode, each press of the button will switch the screen mode to 13-, 1-, 4-, 9-, and 16-
split in order. (1 live channel + (N-1) live channel)
AUDIO Sets Audio ON/OFF.
ALARM Cancels the ALARM LED and the audible alarm when the alarm is going off, and to remove the
icon.
MENU/RETURN Either goes to the system menu screen or moves to the upper menu from the lower menu.
Channel Used to select channel numbers directly in the Live Mode, or numbers in the numeric input
mode.
Jog shuttle
When a scroll bar appears in each menu, acts as a scrolling.
In Play mode, - Jog : Pauses the playback and steps backward or forward.
- Shuttle : Fast playback forward or backward.
OPEN/CLOSE Used to open and close the DVR-RW disc tray. (available for SHR-6082/6162/6164 only)
Power Power LED : Displays the power ON/OFF status.
Power Button : Used to turn the DVR ON/OFF.

10_ overview
overview
PART NAMES AND FUNCTIONS (REAR)
6080/6082
6160/6162/6163/6164
1 2 3 4 5 7 8 9 10 12116
13 24 5 7 8 9 10 12116

English _11
OVERVIEW
Part Names Functions
VIDEO OUT Composite Video Signal Output Port (BNC type connector).
AUDIO OUT Audio Signal Output Port (RCA jack).
VGA VGA Video Signal Output Port.
AUDIO IN Audio input signal port (RCA Jack).
USB USB connector port.
SPOT A live screen output port, separate from the VIDEO OUT.
Supports Single, 4-, 9-, 16-split, and Auto Sequence modes
NETWORK NETWORK connector port.
RS-485 Used for RS-485 communication. (TX+, TX-, RX+, RX-)
ALARM
- ALARM IN 1~16(SHR-6160/6162/6163/6164): Alarm Input port.
- ALARM IN 1~8(SHR-6080/6082): Alarm Input port.
- ALARM RESET IN: Alarm Reset port.
- ALARM OUT 1–4: Alarm Output port.
LOOP OUT Used to transfer a video signal to other video devices.
VIDEO IN Composite Video Signal Input Port (BNC type connector).
AC 100-240V~ IN AC 100 ~ 230V (PAL)
AC 110 ~ 220V (NTSC)

12_ overview
overview
REMOTE CONTROL
DVR
Available after switching to DVR mode by pressing the [DVR] button on the remote control.
Using the numeric buttons
CHANNEL 1–9 Press each button between 1 to 9.
CHANNEL 10 Press the [+10] button first, then press the 0 button again within 3 seconds.
CHANNEL 11–16 Press the [+10] button first, then press any number between 1 to 6 within 3 seconds.
SEARCH
Displays the search menu．
POWER
Displays the Exit pop up screen．
NUMBER [0~+10]
Used as the numeric input keys, or displays a single
channel．
T/W
Zooms in or out．
BACKUP
Displays the Backup Menu.
MODE
Changes the screen mode．
MENU
Goes to the system menu screen.
Up/Down/Left/Right(▲▼◄ ►)/ENTER
Moves the cursor up/down/left/right, and runs the
Select Menu．
FREEZE
Freezes the screen temporarily．
ZOOM
Runs the digital zoom (x2) function.
VIEW
Runs the View function in the PTZ mode．
OPEN/CLOSE
Opens or closes the CD tray.
DVR
Activates the DVR function.
ID
Sets the ID of the system.
Select 2 digits from 0 ~ 9 while pressing the ID Key.
PTZ
Displays or ends PTZ.
SCROLL ,.
Moves the menu scroll.
RETURN
Returns to the previous screen.
AUDIO
Turns Audio on/off.
ALARM
Cancels the Alarm.
REC LOCK
Selects the recording lock function.
PRESET
Displays the Preset Setup.
REC
Starts or ends the live recording．
Skip Backward (by unit time),
Slow Rewind, Slow Forward,
Skip Forward (by unit time) Move Frame
While paused, moves to the previous/next frame.
FR, STOP, PLAY/PAUSE, FF

English _13
OVERVIEW
MONITOR
Available after switching to Monitor mode by pressing the [MONITOR] button on the remote control.
Using the Numeric buttons
CHANNEL 1–9 Press any button among 1 to 9.
Changing the Remote Control ID
Press the ID button of the remote control and check the ID displayed on the DVR screen.
The factory default ID of the remote control is 00.
Enter 2 digits of your selection in order, while pressing the system [ID] button.
When ID input is done, press the system [ID] button again to check the setting.
If you want to change the remote control ID to 08: Press 0 and 8 in order while the system [ID] button is pressed.
Remote control's ID and DVR’s ID should be matched for proper operation. Refer to “Remote Devices”. (Page 46)
1.
2.
3.
M
AUTO
Selects the screen status automatically．
POWER
Turns the monitor power on/off．
NUMBER [0~9]
Changes the system ID.
+/-
Adjusts the audio volume．
ID RESET
Initializes the ID value to 01.
P.MODE
Selects the screen mode．
MENU
Displays the Setup Menu．
Up/Down/Left/Right(▲▼◄ ►)/ENTER
Moves the cursor up/down/left/right, and runs the
Select Menu.
FREEZE
Screen Freeze．
UNDER SCAN
Displays the video screen within a screen．
MONITOR
Activates the monitor function.
ID
Sets the ID.
Select 2 digits from 0 ~ 9 while pressing the ID Key.
MUTE
Mutes the audio out.
SOURCE
Selects the input signal source.
PIP
Selects or deselects the PIP function.

14_ installation
installation
Please be noticed with the followings before you use the product.
Do not use the product outdoor.
Do not spill water or liquid in the connection part of the product.
Do not impose the system to excessive shock or force.
Do not pull out the power plug forcefully.
Do not disassemble the product on your own.
Do not exceed the rated input/output range.
Use a certified power cord only.
For the product with an input ground, use a grounded power plug.
CHECKING THE INSTALLATION ENVIRONMENT
Samsung Digital Video Recorder (“DVR” hereinafter) is a
state-of-art security device, and contains mass storage
hard disk(s) and critical circuits inside.
When the temperature rises inside the product, the product
may breakdown and the product life be shortened. Please
pay attention to the following recommendations before
installation.
The followings are the recommendations when Samsung DVR is installed on a rack.
Please ensure that the rack inside is not sealed.
Please ensure the air is circulated through the inlet/outlet as shown in the picture.
If the DVR or other devices on a rack is to be stacked as in the picture, provide a
suitable space or install a ventilating opening for air circulation.
For natural air convection, place the inlet at the bottom of the rack and the outlet on
top.
It is strongly recommended that a fan motor is installed at the inlet and the outlet for
air circulation. (Please fit a filter at the inlet to screen dust or foreign substances.)
Please maintain the temperature inside the rack or surrounding areas between 0°C
~ 40°C (32°F ~ 104°F) as shown in the figure 1.
•
•
•
•
•
•
•
•
•
•
1.
2.
3.
4.
5.
6.
One Year: 24HR X 365 DAY =8,760 HR
Temperature
Unit: ºC
Life (Unit: HOURS)
[Figure 1]
[Figure 2]

English _15
INSTALLATION
RACK INSTALLATION
Loosen the screws on both sides (4 screws on each side) and install
the Bracket-Rack as shown in the figure, and then fasten the screws
on both sides (4 screws on each side).
Fix the screws not to be loosened by vibrations.
HDD ADDITION
You can install additional HDDs.
Make sure to unplug the power cord from the wall outlet to prevent possible electric shock, injury or product
damage.
Please consult your provider for further information on HDD installation since improper installation or settings may
damage the product.
Number of HDDs supported : SHR-6082/6162/6164: Default 1 HDD + Up to 4 HDDs added
SHR-6080/6160/6163: Default 1 HDD + Up to 5 HDDs added
Cautions for data loss (HDD care)
Please pay attention so that the data inside the HDD is not damaged.
Before adding a HDD, please check the compatibility with this DVR product.
HDD is vulnerable to malfunction due to its sensitive nature against externalities or shocks during operation. Please
ensure that the HDD is free from such shock or externalities.
We are not liable for any damage to the HDD incurred by user’s carelessness or externalities.
Cases might cause damage to HDD or recorded data
To minimize the risk of data loss from a damaged HDD, please backup data as often as possible.
Data may be lost due to external impacts during disassembly or installation of the DVR.
HDD may be damaged if the DVR is suddenly stopped by a power cut or power off during operation.
HDD or files stored inside may be damaged if the main body is moved or impacted during the HDD operation.
Cautions when adding a HDD
When adding a HDD, pay attention so that the cable does not get caught between unsuitable spaces or
the cable’s insulation does not come off.
Pay attention so as not to lose the disassembly screws or accessories.
If the screws or accessories are not put together, the product may breakdown or not operate properly.
Please check the HDD compatibility before adding a HDD.
Please contact your nearest dealer to obtain the list of compatible devices.


J

1.
2.

3.


16_ installation
installation
Adding a HDD
Make sure to unplug the power cord from the wall outlet before proceeding with the installation.
Number of HDDs to install : SHR-6082/6162/6164 : Default 1 HDD + Up to 4 HDDs added
SHR-6080/6160/6163 : Default 1 HDD + Up to 5 HDDs added
By factory default, the unit is equipped with one HDD.
The following instructions are when you have installed the maximum number of HDDs on the master unit.
First, loosen the screws in the left and right sides
and remove the cover.
1) If adding HDDs to SHR-6080, 6160&6163
For SHR-6082/6162/6164 models, see the following page.
Loosen the screws (x4) in the left/right and upper
sides and remove the upper and lower brackets.
Install HDDs (x3) on the lower bracket and fix them
with screws.
The screw (UNC 6-32) to use in the installation comes with
the HDD.
Firmly secure the screw so that it can not get loose from
such as vibration.
Install HDDs (x2) on the upper bracket and fix them
with screws.
M


1.
M
2.
3.


4.
Cover
Upper Bracket
Lower
Bracket
Lower Bracket
Upper Bracket
Add
Installed by
default
Add
Add
Add
Add

English _17
INSTALLATION
When the installation of additional HDDs is done,
insert the lower and upper brackets into the DVR
and fix them with the provided screws.
When the installation of additional HDDs is done,
connect the power cable and connect the HDD
signal cables (SATA Cable) to connectors ~ on
the main board.
You can check the HDD map directly on the DVR.
Refer to “Storage Device > HDD Map”. (Page 44)
Note that the order of the HDD data cable is nothing to do
with the operation. Just make arrangements of the
connectors considering the length of each connector.
SHR-6080, 6160 & 6163 do not support DVD media.
2) If adding HDDs to SHR-6082, 6162 & 6164
Loosen the screws (x4) in the left/right and upper
sides to remove the upper bracket and loosen the
lower screws (x2) to remove the lower bracket.
5.
6.



2.
Upper Bracket
Lower
Bracket
Upper Bracket
Lower Bracket

18_ installation
installation
Install a HDD (x1) on the lower bracket and fix it with
screws.
Install HDDs (x3) on the upper bracket and fix them
with screws.
When the installation of additional HDDs is done,
insert the lower and upper brackets into the DVR
and fix them with the provided screws.
When the installation of additional HDDs is done,
connect the power cable and connect the HDD
data cables (SATA Cable) to connectors ~ on
the main board.
Note that the number of a HDD data calbe is nothing to do
with operation of the HDD. Just make arrangements of the
connectors considering the length of each connector.
Check if the connectors are properly connected and
there is no problem with wiring, and close the cover
and fix it with screws.
3.
4.
5.
6.

7.
Cover
Upper Bracket
Lower
Bracket
Lower Bracket
Upper Bracket
Add
Installed by default
Add
Add
Add

English _19
CONNECTING WITH OTHER DEVICE
connecting with other device
The following figures are based on Model SHR-6164.
CONNECTING THE VIDEO, AUDIO, AND MONITOR
CONNECTING THE NETWORK
Connecting to Internet through Ethernet (10/100/1000BaseT)
M
VIDEO IN AUDIO IN SPOT
AC 100-240V~IN
RS-485 / ALARM
USB 2.0
VIDEO OUT
(VGA)
VIDEO OUT
(composite)
AUDIO OUT
NETWORK
RS-232CONSOLE
LOOP OUT
Windows
NET-i Pro
Back Bone
Hub/Switcher
Hub/Switcher
RJ-45 Ethernet Cable
(Direct Cable)

20_ connecting with other device
connecting with other device
Connecting to Internet through ADSL
CONNECTING THE USB
There are two USB ports at the front and one at the back of the product.
You can connect a USB HDD, USB CD/DVD player, USB memory or mouse to the USB port.
If a USB HDD is connected to the system, recognition and settings are available in “Menu > Setting the Device >
Storage Device”. (Page 44)
This product supports hot-plugging, which connects/removes the USB device during the system operation.
The USB type HDD must be set as Master.
If you use the USB device for Backup purposes, format it with FAT32 on PC if it is not formatted on the DVR.
CONNECTING POS DEVICE
You can connect a POS device to the RS-232C port on the product’s rear side when you connect it directly with
a RS-232C cable.
Connection setup for the RS-232C port is available in “Menu > Device > POS Devices”, press the
<POS Device Setup> button and set <Baud rate, Parity, Data, Stop bit and Transfer Type>. (Page 46)
1.
2.
3.
4.
J

1.
2.
Hub/Switcher
Phone(ADSL) Line ADSL MODEM
RJ-45 Ethernet Cable
(Direct Cable)
Windows
NET-i Pro
