Samsung M3 Station Series User manual

External Hard Drive
M3 Station Series
M3 Station M3 Station 3.0
HX-D101UAB
HX-D101UAE
HX-D101TAB
HX-D101TAE
HX-D151UAB
HX-D151UAE
HX-D151TAB
HX-D151TAE
HX-D201UAB
HX-D201UAE
HX-D201TAB
HX-D201TAE
·
·
·
·
·
·
·
·
·
·
·
·
USER MANUAL

M3 Station Series External Hard Drive 2
Read Me First
About this Manual
User’s Manual
Using this Manual
User Manual
Your product comes with a quick installation guide and a user’s manual.
Following the instructions and precautions of this manual will ensure easier and more enjoyable use of your
M3 Station Series External Hard Drive.
Quick Installation Guide
An installation guide is provided with the purchase of M3 Station Series External Hard Drive.
The Quick Installation Guide explains product components and provides simple instructions on how to install the product.
The User’s Manual contains detailed information about features and instructions on using your
M3 Station Series External Hard Drive.
Carefully read and understand the “Handling Precautions” section before using the product.
Failure to follow all the instructions as outlined in the Handling Precautions section could result in damage to you or to your
M3 Station Series External Hard Drive.
Refer to the Troubleshooting section first if you experience a problem with the product.
Icon Guide
Software and user manuals are available for download at the Samsung External Hard Drive website (www.samsunghdd.com).
The content of this User’s Manual may change without prior notice for product improvement purposes.
Icon Meaning
These must be read thoroughly before using any of the functions.
Precautions
Caution
Note
This contains must-know information about functions. User must be careful.
This contains useful information about the functions.

User Manual
M3 Station Series External Hard Drive 3
Handling Precautions
The following information serves to ensure user’s safety and prevent damage to user’s properties.
Carefully read the information provided and use your product correctly.
Do not unplug the power cord out
by pulling the cable only.
If the power cord is damaged, it may cause
electric shock.
Power Related
Data Cable Usage
Do not unplug the data cable by
severely pulling the cable.
This may damage connector on the product
and may cause a problem with the product.
Use the rated Power adapter
Use only the power adapter supplied with the
product or approved by Samsung Electronics.
Use the product on a flat
surface.
Do not touch the main plug or
power cord with hands.
There is a danger of electric shock.
Do not use a damaged or loose
main plug or power cord or power
outlet.
There is a danger of electric shock or fire hazard.
Do not bend the power cord
excessively or do not place a heavy
object over the power cord.
If the power cord is damaged, it may
cause electric shock or fire and may
increase the wrong operation.
Standardized data cable.
This may increase the wrong operation and
may cause a malfunction.
Do not severely bend the data
cable and do not place a heavy
object over the data cable.
If the data cable is damaged, it may cause a
malfunction.
Installation Related
Do not sit on the product and
do not place a heavy object over
the product.
Product case or connector can be damaged
and may cause a break down.
Avoid blocking the vent at the
bottom or side of the External Hard Drive.
If the vent is blocked, there is a danger of
damaging the External Hard Drive or overheating
the inside of the product.

M3 Station Series External Hard Drive 4
Shock
The External Hard Drive is very portable and you may easily drop it.
Take care not to drop and tip the product while carrying the External Hard Drive.
If you make an impact on the External Hard Drive, it may cause bad sectors on the disk.
Bad sectors can cause various and potentially read/write errors.
Humidity
If you use the product in places exposed to humidity, it may danger of electric shock.
In addition, prolonged exposure to moisture can corrode various parts and components.
Magnets
Magnetic objects can cause various types of damage to the External Hard Drive,
including data damage.
Keep magnets and magnetic objects away from the External Hard Drive.
Disassembly and Label Removal
For repair, please visit the designated (samsung) customer service center.
Unauthorized disassembly, repair, or reform of the product and unauthorized removal
of the labeling will void your warranty.
Safely Remove Hardware
Always use the Safely Remove Hardware feature before shutting down the External Hard Drive or disconnecting the USB cable and power cable.
Regular Virus Scanning
Frequently scan the device for viruses and protect the External Hard Drive from virus infection.
Cleaning the product
Never use cleaning fluid or similar chemicals.
Do not spay cleaner directly on the product.
It may cause discoloration and deformation of the product.
Custody Related
Keep the product and accessories out of the reach of children. It may cause personal injuries and problem.
Always Backup your Important Data
The external drive manufacturer does not guarantee data stored in the external drive
and will not assume responsibility for any mental or material damage incurred during data recovery.
Actual accessible capacity may vary from advertised capacity due to formatting and partitioning of the External Hard Drive, as well as due to your computer's
operating system.
1MB=1,000,000bytes / 1GB=1,000,000,000bytes / 1TB=1,000,000,000,000bytes
User Manual
Backup : Storing the original and a copy on two or more separate and accessible storage media.

Table of Contents
User Manual
M3 Station Series External Hard Drive 5
Connecting your M3 Station Series
13 For Windows
14 For Macintosh
Safely Removing your M3 Station Series
Read Me First
2 About this Manual
2 Quick Installation Guide
2 User’s Manual
2 Using this Manual
2 Icon Guide
Handling Precautionst
3 Use the reted Power adapter
3 Installation Related
3 Power Related
3 Data Cable Usage
4 Shock
4 Humidity
4 Magnets
4 Disassembly and Label Removal
4 Always Backup your Important Data
4 Regular Virus Scanning
4 Cleaning the product
4 Custody Related
4 Safely Remove Hardware
Specifications
6 System Requirements
7 Components
7 Overview
8 Installation
11 Copying / Moving Files
11 Removable Disk Method
15 FAQ
Troubleshooting
Appendix
16 Partitioning and Changing File System Type
16 Reformat to FAT32
16 Reformat to NTFS
16 Format in Macintosh
17 Product Certifications
17 FCC
18 Warranty Information
10 Macintosh
9 Windows
Using your M3 Station Series

Introduction
User Manual
M3 Station Series External Hard Drive 6
The M3 Station Series External Hard Drive is a high-performance External Hard Drive that supports USB *
Unlike conventional desktop disk drives, the M3 Station Series External Hard Drive makes it possible for you to
instantaneously add greater storage capacity to your system without having to take the computer apart.
This means that your M3 Station Series External Hard Drive comes fully partitioned and formatted for your use
and you can instantly access to the drive by simply plugging it into your computer through a USB port.
Additional setting are not necessary.
Specifications
PC : Windows XP / Vista / 7
Macintosh : Mac OS X 10.4.8 or Later
Upgrade your operating system to the latest version to enjoy better performance and reliability.
System Requirements
Category
47mm X 130mm X 180.6mm
Noble Begie / Brown Black
USB 2.0 USB 3.0
480 Mbps Max. 5 Gbps Max.
DC +12V, 2.0A
Windows XP / Vista / 7
Mac OS X 10.4.8 or Later
1TB , 1.5TB , 2TB
NTFS
M3 Station Series USB 2.0 M3 Station Series USB 3.0
Interface
Transfer Rate
Power
Operating System
Hard Disk Capacity
Dimensions (W x H x L)
Color
Format System
* M3 Station : USB 2.0
M3 Station 3.0 : USB 3.0

User Manual
M3 Station Series External Hard Drive 7
Components
When you purchase a M3 Station Series External Hard Drive, make sure that all components have been included
in your product package.
There are ports to connect various cables including
USB on the backside of M3 Station Series
USB Cable Power Adapter
Quick Start Guide
Samsung M3 Station Series External Hard Drive
Overview
Power
USB 3.0
LED Description
1) Standby Status : Steadily lit LED
2) Read/Write in Progress : Blinking LED
M3 Station Series

User Manual
M3 Station Series External Hard Drive 8
Installation
Connecting a M3 Station Series
Power on a M3 Station Series
Connecting your M3 Station Series
Verify that the computer meets the minimum system requirements as outlined in #System Requirements.
Connect the Data cable to your desktop/laptop computer as shown in the figure below.
To use the M3 Station 3.0 model at its Maximum speed, you need a PC or a Host Card that supports USB 3.0 interface.
Plug in the power adapter and connect the USB cable to the corresponding port on your desktop PC or notebook PC.
Turn the power on your drive with power dial.
Now you can enjoy your drive.
M3 Station Series will not power on
when the USB Cable disconnected.
4
3
1
2

M3 Station Series External Hard Drive 9
Windows
The operating system will recognize and display “Samsung” drive under “My Computer.”
System Tray indicating an external device
In the Windows Explorer, you will see a new Samsung drive
User Manual
When you connect the M3 Station Series External Hard Drive to the computer a device icon will appear
in the system tray at the lower right corner of the screen.
You are now ready to use the Samsung M3 Station Series External Hard Drive.

Macintosh
After clicking the SAMSUNG icon, the following folder will appear.
M3 Station Series External Hard Drive 10
User Manual
Connect your M3 Station Series External Hard Drive to the computer.
Your Macintosh operating system will then generate a SAMSUNG.
Macintosh External Hard Drive connection icon
Macintosh Folders
You are now ready to use the Samsung M3 Station Series External Hard Drive.
Samsung provides Samsung NTFS 3G driver which can be used to write data on NTFS-format External Hard
Drives on Mac OS. Samsung NTFS 3G driver can be downloaded from the Samsung website.
(http://www.samsunghdd.com Support Download External HDD)

User Manual
M3 Station Series External Hard Drive 11
Removable Disk Method
From the Windows Desktop click:
Copying / Moving Files
It is important to understand the difference between Copy and Move.
Copy : is to make a duplicate folder or file and store it so that you have two copies.
Move : is to take a folder or file from one location and put it into another.
WHEN YOU MOVE A FOLDER OR FILE, YOU NO LONGER HAVE A BACKUP COPY.
Copy and paste files from the computer to the M3 Station Series External Hard Drive (Removable Disk Method).
Start Programs Accessories Windows Explorer
Getting to the Windows Explorer
Using your M3 Station Series
Now that you have successfully installed your new M3 Station Series External Hard Drive,
you copy or move files or whole folders from your new M3 Station Series to your computer and vice-versa.
For the purposes of this manual, we will make a copy of the Temp folder on the C drive of your computer and
copy it to the M3 Station Series External Hard Drive.
From the Windows Explorer, you will see various drive letters; A, C, your C drive is your local Hard Drive.
The M3 Station Series Drive will most likely be the E drive however, it could be any drive letter.
For the purposes of this manual, we will assume that the M3 Station Series drive is the E drive.
As well, for practice copying folders and files, we will copy the Temp folder onto the M3 Station Series drive.

User Manual
From the Windows Explorer screen:
Click Local Disk C
From the right-hand pane:
Right-click the Temp folder Click Copy
M3 Station Series External Hard Drive 12
1) From this side, click the
Local C drive.
2) From this side, right click on the
Temp folder and choose Copy.
Now, we will copy the Temp folder from the Local C drive, to the Samsung E drive.
From the left pane in the Windows Explorer : Right Click Samsung E Click Paste
When you Right-Click on a file or folder, you get another menu.
Using a Right-Click again, we can paste the Temp file onto the M3 Station Series drive.
Right click on the Samsung E drive and choose Paste.
Do not disconnect the data cable between the PC and the M3 Station Series during file transfer.
This could cause data loss and damage to the M3 Station Series.

M3 Station Series External Hard Drive 13
Click “Safely Remove Hardware.”
User Manual
When you see the “Safely Remove Hardware” message, you may safely remove the device from the system.
For Windows
Safely Removing your M3 Station Series
The taskbar is located at the bottom-right of the screen.
The 'Safely Remove Hardware' prompt will list every device that is attached to your system.
Click ‘Samsung M3 Station Series USB Device’
This prompt will list all of the Mass Storage Devices like your Local Hard drive and
your M3 Station Series Hard drive
Right-click the device icon from the system tray at the lower right corner of your screen.

For Macintosh
This safely disconnects the drive. It is now safe to detach the drive from the computer.
M3 Station Series External Hard Drive 14
User Manual
For the Macintosh click the USB icon and choose Eject “SAMSUNG”
Do not disconnect the data cable between the PC and the M3 Station Series during file transfer.
This could cause data loss and damage to the M3 Station Series.
Click the External Hard Drive icon and select [Eject “SAMSUNG.”]

Troubleshooting
User Manual
M3 Station Series External Hard Drive 15
Check the Data cable connection.
Check the LED light on the External Hard Drive.
Check the power supply to M3 Station Series External Hard Drive.
Ticking noise is an indication of insufficient power.
If the drive is not being recognized, try plugging it into a different USB port.
Q2. The actual storage capacity of M3 Station Series External Hard Drive is different than the capacity
shown on the packaging.
A2. Type of file system used for the drive, partitioning arrangement, type of operating system, and various other factors can
affect the actual storage capacity displayed by your computer.
(1MB=1,000,000bytes and 1GB=1,000,000,000bytes. 1TB=1,000,000,000,000bytes)
Q3. I connected my M3 Station Series External Hard Drive, and the computer seems to recognize it,
but the drive won’t show up under Windows Explorer.
A3. M3 Station Series External Hard Drive is by default formatted to NTFS and will work normally when you connect it to
your computer. However, if the partition has been erased or the file system has been changed to a one that’s not
recognized by Windows, the drive will not appear under Windows Explorer. Try formatting the drive to FAT32 or NTFS.
(Caution : Formatting will erase all data stored in the drive.)
Q4. I am using Windows XP and cannot format the drive to FAT32.
A4. Windows operating systems that followed Windows NT have limited FAT32 formatting to 32GB. Therefore, if you wish to
format your M3 Station Series External Hard Drive to FAT32, you will need to download a format utility from our website.
(Caution : Formatting will erase all data stored in the drive. We recommend that you back up your data before proceeding.)
Q5. My computer will not boot up properly.
A5. If you boot up your system with M3 Station Series External Hard Drive connected to the computer,
it’s possible that your system’s BIOS is attempting to boot from the External Hard Drive.
Change the BIOS booting sequence or disconnect the External Hard Drive from the system and then try booting again.
Q6. I am using a Mac, and I can’t copy files.
A6. If the drive has been formatted to NTFS, data stored in the drive can only be read by Mac systems.
To use the drive on Mac OS X operating systems, use Samsung NTFS 3G Driver or reformat your drive.
Samsung NTFS 3G driver : (Refer to the 10 page)
Reformat : (Refer to the 16 page)
FAQ
- USB 3.0
Q1. File transfer takes too long.
A1. - USB 2.0
You will experience slow file transfer speeds if your computer does not support USB 2.0 or if you do not connect
M3 Station Series External Hard Drive to a USB 2.0 port. Try connecting M3 Station Series External Hard Drive to
a different port or, if your computer does not support USB 2.0, purchase a separate USB 2.0 port.
To use the M3 Station 3.0 model at its Maximum speed, you need a PC or a Host Card that supports USB 3.0
interface and USB 3.0 Cable.

User Manual
M3 Station Series External Hard Drive 16
Reformat to FAT32
Reformat to NTFS
Reformat in Macintosh
Partitioning and Changing File System Type
It’s possible to partition your M3 Station Series External Hard Drive and change the file system type.
Reformat to FAT32
- Use Samsung Format Utility to format your M3 Station Series External Hard Drive to FAT32.
(Samsung Format Utility is a Windows application and is available for downloaded from Samsung’s online Customer Support page.)
Appendix
WARNING – PARTITIONING AND FORMATTING YOUR DRIVE WILL PERMANENTLY ERASE ALL THE FILES ON THE
DRIVE. DO NOT ATTEMPT TO DO THIS UNLESS ALL OF YOUR FILES HAVE BEEN BACKED UP AND
CHECKED FOR RELIABILITY AND READABILITY.
Reformat to NTFS
Format in Macintosh
Following describes formatting to NTFS in Windows XP:
- Connect M3 Station Series External Hard Drive to the computer.
- Click “Start” from the lower left corner of your screen.
- Right-click “My Computer” and then select “Manage.”
- From the “Computer Management” tool, select “Disk Management.”
- Right-click the drive you wish to format and then select “Delete Partition.”
- Once drive partition has been deleted, right-click the drive you wish to format and then select “New Partition” as shown
in the diagram below.
- From Create Partition Wizard, select “Primary Partition” and then enter the desired size of the partition.
- From the “File System” menu, select “NTFS” and format.
Following describes formatting in Mac OS X:
- Launch Mac OS X’s “Disk Utility” tool.
- Open the main drive folder from the desktop. Open the “Applications” folder and then the “Utilities” folder.
- Select the “Disk Utility” file.
- Select the drive you wish to reformat.
- Select the “Erase” menu.
- Select “Mac OS Extended (Journaled)” from “Volume Format” menu and then Click “Erase” button
- Once formatting is complete, the drive will appear on your desktop.

User Manual
M3 Station Series External Hard Drive 17
Product Certifications
FCC
CAUTION : Changes or modifications not expressly approved by the part responsible for
compliance could void the user’s authority to operate the equipment.
Note : This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications, However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
Class B
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CE (European Union/Community)
VCCI (Voluntary Control Council for Interference by Information)
FCC (Federal Communications Commission)
C-TICK
KCC
(Korea Communications Commission)
BSMI (Bureau of Standards, Metrology and Inspection)
cUL (C- Underwriter’s Laboratories, Inc)
TUV (Technischer Uberwachungs Verein)
CB
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household
waste at the end of their working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items from other types of waste and recycle
them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office,
for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other commercial wastes for disposal.

User Manual
M3 Station Series External Hard Drive 18
Warranty Information
Limited Warranty
Warranty Period
The warranty period for product is three (3) years from the documented date of purchase from
Samsung or a Samsung’ authorized reseller.
Customer Service
To request warranty service, please contact the place of purchase, or visit our web site (www.samsunghdd.com)
for information on obtaining service or an RMA (Return Material Authorization) number. Submit your phone number, e-mail,
address, name, product model, and serial number(s) and an RMA number with all pertinent information will be provided to
you for returning product to Samsung. When you return the product to Samsung, the product must be properly packaged in
original packing with a traceable forwarder and freight prepaid to the return address listed on the RMA. Remember to write
the RMA number on the out side of box, or the shipment will be refused and returned to you at freight collect.
Samsung, or an authorized Samsung service center, will replace your product with a functionally equivalent product.
Samsung will not return your original drive and data recovery is not included.
It is highly recommended that you backup your data. Once your drive is received at Samsung, the ownership of the
product and all content therein will be transferred to Samsung.
Please contact Samsung with any comments or inquiries at www.samsunghdd.com
Samsung makes the following limited warranties during the warranty period: (a) the Products will function properly under
normal use; (b) the Products will be free from defects in materials or workmanship; (c) the Products will conform to the
published specifications; and (d) the Products will conform to any additional specifications agreed to in writing by the parties.
Samsung warranties do not cover any problem that is caused by (a) commercial use; accident; abuse; neglect; shock;
electrostatic discharge; heat or humidity beyond product specifications; improper installation; operation; maintenance or
modification; or (b) any misuse contrary to the instructions in the user’s manual; or (c) lost passwords; or (d) malfunctions
caused by other equipment.
Our limited warranties are void if a product is returned with removed, damaged, or tampered labels or any alterations
(including removal of any component or external cover). Our warranties do not cover data loss – back up the contents
of your drive to a separate storage medium on a regular basis. Also, consequential damages; incidental damages; and
costs related to data recovery, removal and installation are not recoverable under our warranties.
The following limited warranty applies to the Samsung External Hard Drive but does not supersede
regional and national laws and regulations.

M3 Station Series External Hard Drive User Manual EN (Rev. 00)
Samsung Electronics Co., Ltd.
STORAGE SYSTEM DIVISION
HEAD OFFICE: 416, MAETAN-3 DONG, YEONGTONG-GU, SUWON SI, GYEONGGI-DO, KOREA, 443-742
FAX : [phone]
Copyright
Samsung Electronics reserves all copyrights to the content of this manual. Copyright laws prohibit reproduction
of this manual in part or whole by any third party without the explicit consent of Samsung Electronics.
Sa msung Electronics does not assume any patent responsibility for the use of information contained in this manual.
Disclaimer
This user’s manual has been subjected to thorough reviews and verifications to ensure accuracy of its content
and contains information that’s pertinent to the model and series it describes at the time of publication. However,
content of this manual and/or product specifications are subject to change without prior notice and with no direct
or indirect liability on Samsung Electronics’ part concerning such change.
