Samsung OfficeServ 7000 Series User manual

Executive MOBEX
Telephone User Guide
7000 Series
Mobex_Telephone_Guide_Cover_UserGuide55x85 3/15/2011 2:25 PM Page 2

Executive MOBEX
User Guide
March 2011
Samsung Telecommunications America reserves the right without prior notice to revise information in
this guide for any reason. Samsung Telecommunications America also reserves the right without prior
notice to make changes in design or components of equipment as engineering and manufacturing
may warrant. Samsung Telecommunications America disclaims all liabilities for damages arising from
the erroneous interpretation or use of information presented in this guide.
for
OfficeServ™ 7000 Series
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 1

TABLE OF CONTENTS
ABOUT THIS BOOK ................................................................................1
THINGS YOU SHOULD KNOW ................................................2
CONNECTING TO THE SYSTEM ......................................3–4
OUTSIDE CALLS
Making an Outside Call......................................................................................5
INTERCOM CALLS
Calling Other Stations ........................................................................................6
Calling Your System Operator..........................................................................6
CALL PROCESSING
Retrieving Calls on Hold at Another Station..............................................7
Transferring Calls ..................................................................................................7
Transfer with Camp-On......................................................................................7
Setting Up a Conference ..................................................................................8
Forwarding Your Calls....................................................................................8–9
Call Pickup ......................................................................................................9–10
DIALING FEATURES
Speed Dialing......................................................................................................11
Programming Personal Speed Dial Numbers ........................................11
Last Number Redial ..........................................................................................11
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 3

PAGING AND MESSAGING
Making an Internal Page ................................................................................12
Making an External Page ................................................................................12
All Page..................................................................................................................12
Meet Me Page/Answer ....................................................................................12
Call Park and Page ............................................................................................12
Retrieving a Parked Call ..................................................................................13
PERSONAL SPEED DIAL LIST ....................................14–15
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 4

ABOUT THIS BOOK
This booklet provides instructions for call handling and feature interaction on your
Executive MOBEX phone with OfficeServ 7000 Series system.
Please take the time to study this guide and to become familiar with the operation
of your Executive MOBEX phone. Keep it handy. You may need to look up instruc-
tions for infrequently used features.
Learning to use your Executive MOBEX phone correctly will make everyday tele-
phone communications a breeze.
This book is written based on the factory default settings for the feature access
codes. Sometimes, due to programming requirements, these codes may be
changed. If you find that a feature code does not work as described in this book,
please contact your installation and service company to determine the correct
code.
1
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 5

2
THINGS YOU SHOULD KNOW
USER ORIENTATION
Your Executive MOBEX phone interfaces to the OfficeServ 7000 Series system in
two ways:
• By logging in after receiving a MOBEX call, or
• If configured, you may dial in to the system and log in to activate the inter-
face.
Both connection methods will be discussed in this booklet.
To get an outside line from the telephone company once connected,dial an access
code, usually the digit “9.” To call another station in your system, simply dial its
extension number. See your system directory list for other access codes and exten-
sion numbers.
C.O. LINES
Lines from the telephone company are “C.O. lines.”Calls on these lines are referred
to as “outside calls.” These C.O. lines are accessed by dialing an access code. For
example, dial 9to get a local outside line or dial 800–8XX for other line groups.
Each line in the system is numbered beginning with 701, and then 702, 703, etc.To
get a specific line, dial its three digit line number. If Least Cost Routing (LCR) is pro-
grammed into the system, you will only be required to dial 9.
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 6

CONNECTING TO THE SYSTEM
For the remainder of this booklet instructions will assume that you are connect-
ed, logged in, and hearing a system dial tone.There are two ways to connect and
log in:
CONNECTING DURING A MOBEX CALL
When someone calls your office number and rings your Executive MOBEX phone
you can initiate the system connection by dialing the MOBEX feature access code,
typically ✱8.You will hear system dial tone if successful or, if no resources are avail-
able, you will be returned to your caller.
CONNECTING BY CALLING IN TO
THE SYSTEM
If the system administrator has allowed it, you may log in to the Executive MOBEX
interface by dialing in to the system. Your administrator will provide you with
instructions on what number to dial and which login method is used. The two
types of login methods are:
• AUTOMATIC: Meaning the system will automatically log you in based on
the Caller ID of you Executive MOBEX phone, or
• MANUAL: Meaning the system requires you to log in based on your exten-
sion and passcode.
To log in manually:
• call in to the number provided by the administrator
• dial your extension number at the tone (or music)
• you will hear a short confirmation tone
3
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 7

4
SYSTEM TONES
The system provides several tones to assist you. Some of these tones are already
familiar to you.
Intercom Dial Tone—A steady tone that indicates you can begin dialing.
DIAL TONE
CONTINUOUS
Ringback Tone—Indicates the station you dialed is ringing.
RINGBACK TONE—1000 ms ON/3000 ms OFF
CONTINUOUS
Busy Tone—Indicates the station you dialed is busy.
BUSY TONE—500 ms ON/500 ms OFF
CONTINUOUS
DND/No More Calls Tone—Fast busy tone indicates the station you dialed
is in the Do Not Disturb mode or cannot receive any more calls.
DND/NO MORE CALLS TONE—250 ms ON/250 ms OFF
FOR TEN SECONDS
Transfer/Conference Tone—Indicates your call is being held and you
can dial another party.
TRANSFER/CONF TONE—100 ms ON/100 ms OFF
CONTINUOUS
Confirmation Tone—Very short beeps followed by dial tone indicate you
have correctly set or canceled a system feature.
CONFIRMATION TONE—50 ms ON/50 ms OFF
FOR ONE SECOND
(programmable)
Error Tone—A distinctive two level beeping tone indicates you have done
something incorrectly.Try again.
ERROR TONE—50 ms of tone 1/50 ms of tone 2
FOR THREE SECONDS
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 8

5
OUTSIDE CALLS
MAKING AN OUTSIDE CALL
• Dial a C.O. line or line group access code.
• Receive outside dial tone and then dial the telephone number.
• Finish the call by hanging up.
If your system is programmed to require an authorization code before making a
call:
• Dial ✱and a valid code. You will hear confirmation tone, followed by dial
tone.
• Select a C.O. line.
If your system is programmed to require an account code before making a call:
• Dial 47 and a valid code.
• Dial ✱8and receive transfer tone. Select a C.O. line.
For more information see your system administrator.
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 9

INTERCOM CALLS
CALLING OTHER STATIONS
• Dial the extension number or group number.
• Wait for the party to answer.
• If you hear several brief tone bursts instead of ringback tone, the
station you called is set for Voice Announce or Auto Answer.
• Begin speaking immediately after the tone.
• Finish the call by hanging up.
BUSY STATION CAMP-ON
When you call another station and receive a busy signal but you do not want to
wait for a callback:
• Dial ✱8receive transfer tone and dial 45.
• The called station will receive off-hook ring or camp-on tone.
• You will hear ringback tone.
• Wait for the called party to answer.
The called station must release its first call or put it on hold before answering your
camp-on.
CALLING YOUR SYSTEM OPERATOR
• Dial 0to call your system operator or group of operators.
• If you want to call a specific operator, dial that person’s extension number.
6
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 10

7
CALL PROCESSING
RETRIEVING CALLS ON HOLD AT
ANOTHER STATION
When a line is on hold at any other station:
• Dial 12 plus the extension number of the station that placed the call on
hold—OR—dial 12 plus the line number if you know what it is.
TRANSFERRING CALLS
Transfer is used to send any call to another extension in one of two ways. You can
perform a screened transfer by informing the other extension who is calling or you
can perform a blind transfer without notification.
• While you are speaking on a call, dial ✱8 to receive transfer dial tone and
then dial an extension number. Your call is automatically put on transfer
hold.
• Hang up when you hear ringing—OR—wait for the party to answer and
advise the party of the call and then hang up. If the transfer is refused, you
will be reconnected to the outside line when the station hangs up or you
can ✱8 to return to the outside party.
TRANSFER WITH CAMP-ON
When you are transferring a call to another station and it is busy, you may camp
the call on to this station:
• While you are speaking on a call, ✱8 to receive transfer dial tone and then
dial an extension number. Your call is automatically put on transfer hold.
• Hang up when you hear a busy signal. The called party will be alerted that
a call is waiting.
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 11

SETTING UP A CONFERENCE
You may conference five parties (you and four other parties) in any combination of
outside lines and internal stations in any order.
• While you are engaged in a conversation, dial ✱8, receive transfer tone and
dial 46.You will receive conference tone.
• Make another call, either intercom or outside.
• After the called party answers, dial ✱8 and receive conference tone.
• Make another call—OR—dial ✱8 to join all parties.
• Repeat as necessary.
To drop a party from your conference call:
• Dial ✱8, receive confirmation tone and dial the extension or line number
that is to be dropped.
• Receive conference tone and dial 46 to rejoin the other parties.
NOTE: To leave the conference, hang up. Control will be passed to the first internal
station that was added. If there are no internal stations and you wish to leave out-
side lines connected together in a trunk to trunk conference, follow the instruc-
tions to drop a party and use your extension number.When the parties on the out-
side lines hang up, the lines will release automatically, proceeding disconnect
supervision is supplied by the telephone company.
FORWARDING YOUR CALLS
You may forward your calls to other stations or groups of stations. When they are
programmed, Forward All Calls will have priority over Forward Busy and Forward
No Answer conditions.
To clear all call forward conditions set at your station dial 600.
NOTE: It is not necessary to clear call forwarding to change your selection; simply
enter a new forward command.
FORWARD ALL CALLS
To forward all of your calls to another station:
• Dial 601 followed by the destination you want your calls to forward to.This
can be an internal (within your system) or external (outside your system
such as a cell phone) number.
• Receive confirmation tone and hang up.
To cancel Forward All Calls dial 600—OR—dial another forward code, e.g., 604.
8
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 12

9
FORWARD BUSY
To forward calls to another station when you are on the phone:
• Dial 602 followed by the destination you want your calls to forward to.This
can be an internal (within your system) or external (outside your system
such as a cell phone) number.
• Receive confirmation tone and hang up.
To cancel Forward Busy dial 600—OR—dial another forward code, e.g., 604.
FORWARD NO ANSWER
To forward calls to another station when you do not answer:
• Dial 603 followed by the destination you want your call to forward to. This
can be an internal (within your system) or external (outside your system
such as a cell phone) number.
• Receive confirmation tone and hang up.
To cancel Forward No Answer dial 600—OR—dial another forward code, e.g., 604.
FORWARD NO ANSWER/BUSY
To forward calls to another station when you do not answer or when you are on
the phone:
• Dial 604.
• Receive confirmation tone and hang up.
NOTE: This option will only work if Forward No Answer and Forward Busy destina-
tions are already programmed.
To cancel Forward No Answer/Busy dial 600—OR—dial another forward code,
e.g., 601.
STATION CALL PICKUP
To pick up (answer) a call ringing at another station:
• Dial 65 plus the extension number of the ringing phone.
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 13

GROUP CALL PICKUP
To pick up (answer) a call ringing in any pickup group:
• Dial 66 plus the desired group number.
GROUP NUMBERS
01-10 OfficeServ 7030
01-20 OfficeServ 7100 and OfficeServ 7200-S
01-99 OfficeServ 7200 and OfficeServ 7400
NOTE: Station and group pickup features cannot be used to answer recalls to a sta-
tion, only new ringing calls and operator recalls.
10
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 14

11
DIALING FEATURES
SPEED DIALING
You can dial a preprogrammed telephone number stored in the system-wide
speed dial list of numbers 500–999 or from your personal list of numbers 00–49.
• Dial 16.
• Dial the desired speed dial number.
• The telephone number is automatically dialed for you.
NOTE:Your system may be set for 950 system wide numbers.If so the system speed
dial access codes are 050~999 and the station speed dial codes are 000~049.
PROGRAMMING PERSONAL
SPEED DIAL NUMBERS
To program personal speed dial numbers:
• Dial 15105 the next available speed dial bin number (e.g. 01), a trunk or
trunk group number and your speed dial digits.
• Hang up.
NOTE: It is much easier to have your System Administrator program these for you.
LAST NUMBER REDIAL
To redial the last telephone number you have dialed:
• Dial 19.
NOTE: Redial does not apply to intercom calls.
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 15

12
PAGING AND MESSAGING
MAKING AN INTERNAL PAGE
To make an announcement through the keyset speakers in the idle condition:
• Dial 55 plus zone number 0, 1, 2, 3 or 4.
• After the brief attention tone, make the announcement.
MAKING AN EXTERNAL PAGE
To make an announcement through the external paging speakers:
• Dial 55 plus zone number 5, 6, 7 or 8—OR—dial 55 plus 9to page all exter-
nal zones.
• After the brief attention tone, make the announcement.
ALL PAGE
To page all designated keysets in internal zone 0 and all external zones at the same
time:
• Dial 55 plus ✱.
• After the brief attention tone, make the announcement.
MEET ME PAGE/ANSWER
• Make a page by dialing 54 plus any zone and instruct the paged person to
dial 56.
• After completing the page, dial ✱8 and remain off-hook until the paged
person dials 56 from any phone. The paged person will be automatically
connected with you.
CALL PARK AND PAGE
When you have an outside call for someone who is not at his/her desk, you can
park the call and page the requested party:
• While in conversation, dial ✱8 and dial 55. The call is automatically parked
at your station.
• Dial the desired page zone and make the announcement. Be sure to
include your station number, for example,“Mr. Smith, park 201.”
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 16

RETRIEVING A PARKED CALL
To retrieve a call that has been parked for you:
• Dial 10 plus the station number that was announced.You will be connect-
ed to the parked call.
13
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 17

14
PERSONAL SPEED DIAL NUMBERS
CODE NAME TELEPHONE NUMBER
00 _________________________ _________________________
01 _________________________ _________________________
02 _________________________ _________________________
03 _________________________ _________________________
04 _________________________ _________________________
05 _________________________ _________________________
06 _________________________ _________________________
07 _________________________ _________________________
08 _________________________ _________________________
09 _________________________ _________________________
10 _________________________ _________________________
11 _________________________ _________________________
12 _________________________ _________________________
13 _________________________ _________________________
14 _________________________ _________________________
15 _________________________ _________________________
16 _________________________ _________________________
17 _________________________ _________________________
18 _________________________ _________________________
19 _________________________ _________________________
20 _________________________ _________________________
21 _________________________ _________________________
22 _________________________ _________________________
23 _________________________ _________________________
24 _________________________ _________________________
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 18

15
PERSONAL SPEED DIAL NUMBERS
CODE NAME TELEPHONE NUMBER
25 _________________________ _________________________
26 _________________________ _________________________
27 _________________________ _________________________
28 _________________________ _________________________
29 _________________________ _________________________
30 _________________________ _________________________
31 _________________________ _________________________
32 _________________________ _________________________
33 _________________________ _________________________
34 _________________________ _________________________
35 _________________________ _________________________
36 _________________________ _________________________
37 _________________________ _________________________
38 _________________________ _________________________
39 _________________________ _________________________
40 _________________________ _________________________
41 _________________________ _________________________
42 _________________________ _________________________
43 _________________________ _________________________
44 _________________________ _________________________
45 _________________________ _________________________
46 _________________________ _________________________
47 _________________________ _________________________
48 _________________________ _________________________
49 _________________________ _________________________
Mobex_User_Guide_SLT_screen.qxd 3/16/2011 3:46 PM Page 19

www.samsung.com/bcs
FEATURES AND SPECIFICATIONS
03/2011
LINE GROUPS
9 Local/LCR
800 ____________________________
801 ____________________________
802 ____________________________
STATION GROUPS
501 _____________________________
502 _____________________________
503 _____________________________
504 _____________________________
PAGING ZONES - DIAL 55 PLUS
0 All Internal Zones
1 _____________________________
2 _____________________________
3 _____________________________
4 _____________________________
5 _____________________________
6 _____________________________
7 _____________________________
8 _____________________________
9 All External Zones
✱All External Zones and Internal Zone 0
FEATURE ACCESS CODES
10 + xxx Pick Up A Parked Call
12 + xxx Pick Up A Held Call
HF-13 Door Lock Release
16 + xxx Speed Dialing
17 Save And Redial Number
18 New Call (Recall)
19 Last Number Redial
400 Cancel Do Not Disturb
401 Set Do Not Disturb
42 + xxx Cancel Message You Left
43 Return Message
HF-44 Callback
HF-45 Busy Station Camp-On
HF-46 Conference
HF-47 Account Code
48 + xx Cancel Programmed MSG
HF-49 Send Flash To C.O. or PBX
56 Meet Me Answer
600 Cancel All Call Forward
601 + xxx Set Forward All Calls
602 + xxx Set Forward Busy
603 + xxx Set Forward No Answer
604 + xxx Set Fwd Busy/No Answer
605 + xxx Set Forward on DND
606 + xxx Set Forward Follow Me
65 + xxx Pick Up Ringing Extension
66 + xx Pick Up Group
67 Universal Answer
✱Authorization Code
✱8 Mobex
Note: HF Indicates Hookflash.
Mobex_Telephone_Guide_Cover_UserGuide55x85 3/15/2011 2:25 PM Page 1
