Samsung UN JS7000F Series User manual

SUHD TV
SERVICEManual
SUHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**JS7000F
Chassis : UWJ51
Model : UN50JS7000F
UN55JS7000F
UN60JS7000F

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-1-1. Warnings .............................................................................................................. 1-1
1-1-2. Servicing the LED TV........................................................................................... 1-1
1-1-3. Fire and Shock Hazard ........................................................................................ 1-1
1-1-4. Product Safety Notices ........................................................................................ 1-2
1-2. Servicing Precautions..................................................................................................... 1-3
1-2-1. General Servicing Precautions ............................................................................ 1-3
1-3. Static Electricity Precautions .......................................................................................... 1-4
1-4. Installation Precautions .................................................................................................. 1-5
2. Product Specications............................................................................................ 2-1
2-1. Product information ........................................................................................................ 2-1
2-2. Product specication ..................................................................................................... 2-2
2-2-1. Feature & Specications ...................................................................................... 2-2
2-2-2. Detailed Specications......................................................................................... 2-3
2-3. Accessories .................................................................................................................... 2-7
2-4. Viewing the Functions..................................................................................................... 2-8
2-4-1. Learning motion control basics .......................................................................... 2-11
2-4-2. Viewing the Panel .............................................................................................. 2-12
2-4-3. Using the web browser ...................................................................................... 2-17
2-4-4. Playing Multiple Screens.................................................................................... 2-18
2-4-5. Enabling the TV to boot faster............................................................................ 2-19
2-4-6. HDMI UHD Color ............................................................................................... 2-20
2-4-7. Supported Formats ............................................................................................ 2-21
3. Disassembly and Reassembly ............................................................................... 3-1
3-1. Disassembly and Reassembly ....................................................................................... 3-1
3-1-1. TV Disassembly ................................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-1-1. Previous Check.................................................................................................... 4-1
4-2. How to Check Fault Symptom ........................................................................................ 4-3
4-2-1. Video.................................................................................................................... 4-3
4-2-2. Bluetooth / WIFI Module ...................................................................................... 4-5
4-2-3. Jog Function Control............................................................................................ 4-9
4-2-4. T-CON Board ..................................................................................................... 4-10
4-3. Factory Mode Adjustments ........................................................................................... 4-11
4-3-1. Detail Factory Option ......................................................................................... 4-11
4-3-2. Entering Factory Mode....................................................................................... 4-12
4-3-3. Factory Data ...................................................................................................... 4-13

4-4. White Balance .............................................................................................................. 4-22
4-4-1. Calibration.......................................................................................................... 4-22
4-4-2. Service Adjustment ............................................................................................ 4-22
4-4-3. Adjustment ......................................................................................................... 4-24
4-5. RS-232C....................................................................................................................... 4-25
4-6. AV Control Tabe ............................................................................................................ 4-26
4-7. Updating the TV’s Software .......................................................................................... 4-32
5. Wiring Diagram........................................................................................................ 5-1
5-1. Wiring Diagram............................................................................................................... 5-1
5-2. Connector ....................................................................................................................... 5-2
ANNEX. Exploded View & Part List [UN50JS7000FXZA-IH01] ......................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-2
2-1. Electrical Parts List ...............................................................................................ANNEX-3
ANNEX. Exploded View & Part List [UN55JS7000FXZA-EH01].....................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-2
2-1. Electrical Parts List ...............................................................................................ANNEX-3
ANNEX. Exploded View & Part List [UN60JS7000FXZA-MD01] ....................ANNEX-1
1-1. Exploded View......................................................................................................ANNEX-1
1-1-1. Parts List ....................................................................................................ANNEX-2
2-1. Electrical Parts List ...............................................................................................ANNEX-3

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2015 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

ANNEX. Exploded View & Part List [UN60JS7000FXZA-MD01]
1-1. Exploded View
ANNEX-1
ANNEX. Exploded View & Part List

1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02449A PRODUCT LCD-SHARP; CY-TJ060HGSV1V,JS6900, 1 SA
1-1 BN96-38492B ASSY CHASSIS TOP P; JS6.9K_60,PC+GF,DARK 1 SA
2 BN95-02371C ASSY COVER STAND SMT; J6200,60,DARK TITAN 1 SNA
3 BN96-35006B ASSY SPEAKER P; 6ohm,4pin,10W,JU7000 60" 1 SA
4 BN44-00860A DC VSS-LED TV PD BD; L60SHN_FDY,L60SHN_FD 1 SA
5 BN94-09273A ASSY PCB MISC-MAIN; UN60JS7000FXZA 1 SA
6 BN61-11587A HOLDER-SIDE AV; JU6400,HIPS,BLK,HB, 1 TUN 1 SNA
7 BN59-01194F NETWORK; 11ac Combo,Internal WiFi,USB 2.0 1 SA
8 BN96-35345B ASSY BOARD P-FUNCTION_SW; JU7500,Function 1 SA
9 BN96-35346D ASSY BOARD P-FUNCTION ASSY; JU6400,Functi 1 SA
10 BN96-37201A ASSY BRACKET P-STAND LINK; JU7000 65",HGI 1 SNA
11 BN96-37241R ASSY COVER P-REAR; 60JS6900,USA,MASTER,PC 1 SA
12 BN96-38553A ASSY GUIDE P-STAND; 60JS6900,NORTH AMERIC 1 SA
13 BN96-37971C ASSY STAND P-BASE; J6200 60",BN63-14511A, 1 SA
ANNEX-2
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN60JS7000FXZA (MD01)
1 BN90-06530S ASSY W/I;LED_J6K 1 SNA
0.2 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC 1 SNA
0.2 BN81-12183S A/S PART SET-MECH W/I;UJ6J,U60JJ* 1 SNA
1 R001A BN90-07082E ASSY COVER REAR;SUHD 60 1 SNA
0.2 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 18 SA
0.2 R001A BN96-37241R ASSY COVER P-REAR;60JS6900,USA,MASTER,PC 1 SA
..3 R001 BN63-13233X COVER-REAR;JS6900 60",ABS+PC+GF15%,V1,BL 1 SNA
..3 T0071 BN64-02929B INLAY-TERMINAL;JU6400,PC,T0.25,W114.7,L9 1 SNA
..3 BN68-06900B LABEL-TERMINAL SIDE;JU6400,PET,T0.125,15 1 SNA
..3 BN68-07079B LABEL-TERMINAL LICENSE;JU7500,PET,T0.125 1 SNA
1 S001A BN90-07744A ASSY STAND;JS6900 1 SNA
0.2 SB04A BN96-37971C ASSY STAND P-BASE;J6200 60",BN63-14511A, 1 SA
..3 SCREW 6003-001001 SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW 2 SA
..3 SCREW 6003-001119 SCREW-TAPTYPE;FH,+,S,M4,L10,ZPC(BLK),SWR 4 SA
..3 SCREW 6003-001239 SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR 6 SA
..3 BN61-12727A BRACKET-STAND BASE;15Y J6200 60",HGI,T3. 1 SNA
..3 BN61-12728A BRACKET-STAND BAR;15Y J6200 60",HGI,T1.9 1 SNA
..3 CCM1 BN63-05199H SHEET-COVER;AMBER,PE,T0.08,W130mm,200M,C 1 SNA
..3 BN63-14511A COVER-STAND BASE;15Y J6200 60",PC+ABS+GF 1 SNA
..3 BN67-00398P RUBBER-FOOT;RUBBER,SILICONE,15.5*8,2.5,G 5 SNA
..3 BN95-02371C ASSY COVER STAND SMT;J6200,60,DARK TITAN 1 SNA
...4 0204-006861 COATING;SMT-L100,CLEAR,0.928 4 SNA
...4 BN01-00160A TARGET-CHROMIUM-CY;Chromium target,99.95 1 SNA
...4 BN01-00161A TARGET-CHROMIUM-PL;chromium target,over 1 SNA
...4 BN63-14064B SHEET-COVER;PE+PP,0.068,W30,CLEAR,100g/i 1 SNA
...4 BN63-14515A COVER-DECORATION STAND;15Y J6200 60",ABS 1 SNA
...4 BN68-06391B LABEL-STICKER;SMT,ART,10,20,Brown,Dark T 1 SNA
0.2 SG01A BN96-38553A ASSY GUIDE P-STAND;60JS6900,NORTH AMERIC 1 SA
..3 0203-001602 TAPE-OPP MASKING;#232,0.14,15,50000,YEL 0 SNA
..3 6902-002472 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L45 1 SNA
..3 SG03 BN61-12971A GUIDE-STAND;JS6.9K_60,PC+GF20%,BLK 1 SNA
..3 BN68-05381A LABEL-BASE;Art Paper 100G,T0.08,20mmX50m 1 SNA
..3 BN96-32380B ASSY ACCESSORY-SCREW;BN69-10588A,BN61-09 1 SNA
...4 HOLDER-
BOLT BN61-09494D HOLDER-BOLT;BH+,SWRCH18A,L14,M4,B TYPE 4 SA
...4 BN69-10588A BAG SCREW;LDPE,-,0.05,70,90,TRP,-,-,LED 1 SNA
..3 BN96-38693A ASSY ACCESSORY-SCREW;JS7200,HERO 1 SNA
...4 6902-000341 BAG PE;LDPE,T0.05,L90,W70,TRP,,,PE MARK 1 SNA
...4 BN61-09494B HOLDER-EMI BOLT;BH+,SWRCH18A,L14,M4,S TY 4 SA
...4 BN68-07575A LABEL-SCREW 4 X 16;60J6300,ART,15 X 10 m 1 SNA
1 BN91-14300B ASSY SHIELD;UHD 6K 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 10 SA
0.2 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
ANNEX-3
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.2 M-F BN39-01990D LEAD CONNECTOR-FUNCTION;JU7K,FLAT Connec 1 SA
0.2 EC13 BN39-02017B LEAD CONNECTOR;FLAT CONNECTOR
ASS'Y,Lead 1 SA
0.2 BN39-02025A LEAD CONNECTOR-
POWER;UN40JU6400AFXZA,Fla 1 SA
0.2 BN39-02147B LEAD CONNECTOR-JS6900 BLU;BLU,FLAT CONNE 1 SA
0.2 P001A BN44-00860A DC VSS-LED TV PD BD;L60SHN_FDY,L60SHN_FD 1 SA
0.2 NW01 BN59-01194F NETWORK;11ac Combo,Internal WiFi,USB 2.0 1 SA
0.2 SP01A BN96-35006B ASSY SPEAKER P;6ohm,4pin,10W,JU7000 60" 1 SA
0.2 BN96-35345B ASSY BOARD P-FUNCTION_SW;JU7500,Function 1 SA
0.2 FB01A BN96-35346D ASSY BOARD P-FUNCTION ASSY;JU6400,Functi 1 SA
0.2 FL06 BN96-36273H ASSY CABLE P-FFC;UN60JU6400,FFC,NH,350mm 1 SA
0.2 BN96-38579A ASSY INLET P-AC INLET;60JS6900,UL3364/10 1 SNA
1 BN91-15019A ASSY LCM-SHARP;CY-TJ060HGSV1V/H,BN95-024 1 SNA
0.2 PANEL BN95-02449A PRODUCT LCD-SHARP;CY-TJ060HGSV1V,JS6900, 1 SA
..3 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 8 SA
..3 6001-003010 SCREW-MACHINE;CH,+,M3,L6,ZPC(BLK),SWRCH1 7 SNA
..3 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 4 SA
..3 BN02-00114A TAPE ETC-COF;NNB 55",PET,0.07T,20,12,GRE 8 SNA
..3 BN68-05595A LABEL-STICKER;Art Paper 100G,T0.2,80mmX2 1 SNA
..3 BN90-07294A ASSY MISC-BLU;60" JS6.9K,. 1 SNA
...4 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
...4 BN61-11508A SUPPORT-PLATE;Y15 LED,PC,V2,CLEAR,OD-19m 28 SNA
...4 BN61-12966A LGP-DIFFUSER PLATE;60inch Flat, Diffuser 1 SNA
...4 BN63-13509A SHEET-DBEF;DBEF D2 400,PC,0.4,1340.2,761 1 SNA
...4 BN63-14724A SHEET-CGEF;CGEF1-M14-V1,PET,0.26,1340.2, 1 SNA
...4 BN63-14727A SHEET-REFLECTOR;CGEF1-R13-V1,PET,0.20,13 1 SNA
...4 BN63-14771A SHEET-COMPLEX;UTA20,PET,0.33,1340.2,761. 1 SNA
...4 BN96-38483A ASSY LED BAR P;60" Direct Hero Left Modu 10 SNA
...4 BN96-38484A ASSY LED BAR P;60" Direct Hero Right Mod 10 SNA
...4 BN96-38495A ASSY CHASSIS BOTTOM P;JS6.9K_60,EGI-SECC 1 SNA
....5 0203-006897 TAPE-DOUBLE FACE;SI,T1.0,W10,L50,WHT 1 SNA
....5 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 1 SA
....5 M0131 AA63-01112A GASKET;BE46TS,Conductive Fabric,8 mm,15 3 SNA
....5 BN02-00040C TAPE DOUBLE FACE-D-PLATE;F-LED ALL,MKT50 6 SNA
....5 BN02-00173C TAPE OPP;PET,0.05,40,BLK 0 SNA
....5 BN02-00352E TAPE OPP;PET,T0.05,W15,L50M,BLK,ULNO.E16 0 SNA
....5 BN61-11836A HOLDER-SOURCE PCB;Y15 JU7K INX,ABS,WHITE 8 SNA
....5 BN61-11982A HOLDER-WALL RIVET;Y15 F-LED,CR-SPCC,L15. 4 SNA
....5 BN61-12916A HOLDER-MIDDLE U;JS6.9K_60,PC+GF10%,WT012 1 SNA
....5 BN61-12917A HOLDER-MIDDLE D;JS6.9K_60,PC+GF10%,WT012 1 SNA
....5 BN61-12918A HOLDER-MIDDLE LR;JS6.9K_60,PC+GF10%,WT01 2 SNA
....5 BN62-00791A INSULATION-PD BOARD;JS7200,PC,0.43,W320, 1 SNA
....5 M0131 BN63-05878A GASKET;Ecot,Polyurethane+Cu+Ni+Hotmelt 2 SNA
....5 CC02 BN64-03266A CHASSIS-BOTTOM;JS6.9K_60,EGI-SECC,0.8T 1 SNA
....5 FB05A BN96-38487A ASSY BOARD P;60" Direct Hero LED interfa 1 SNA
...4 BN96-38706A ASSY FRAME P-MOLD MIDDLE-U;JS6900 60",PC 1 SNA
....5 BN60-01111K SPACER-MIDDLE UD;Y15 JS6900 60,PET,L83,B 3 SNA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 BN60-01111L SPACER-MIDDLE UD;Y15 JS6900 60,PET,L262, 2 SNA
....5 BN60-01111M SPACER-MIDDLE UD;Y15 JS6900 60,PET,L220, 1 SNA
....5 BN60-01111N SPACER-MIDDLE UD;Y15 JS6900 60,PET,L180, 1 SNA
....5 BN61-11404A FRAME-MOLD MIDDLE U;Y15 JU7K 60",PC+GF10 1 SNA
...4 BN96-38707A ASSY FRAME P-MOLD MIDDLE-D;JS6900 60",PC 1 SNA
....5 BN60-00744A SPACER-RUBBER;Y13 F-LED SLIM,SH-0140U+AT 1 SNA
....5 BN60-01023P SPACER-MIDDLE;Y15 JU7K 60",PET,L15,NTR,T 1 SNA
....5 BN60-01111P SPACER-MIDDLE UD;Y15 JS6900 60,PET,L720, 1 SNA
....5 BN60-01111Q SPACER-MIDDLE UD;Y15 JS6900 60,PET,L570, 1 SNA
....5 BN60-01163M SPACER-PANEL UD;Y15 JU6.4K 60",SI,660,BL 2 SNA
....5 BN61-11405A FRAME-MOLD MIDDLE D;Y15 JU7K 60",PC+GF10 1 SNA
...4 BN96-38708A ASSY FRAME P-MOLD MIDDLE-LR;JS6900 60",P 2 SNA
....5 BN60-01111R SPACER-MIDDLE LR;Y15 JS6900 60,PET,L735, 2 SNA
....5 BN60-01163N SPACER-PANEL LR;Y15 JU6.4K 60",SI,750,BL 2 SNA
....5 BN61-11406A FRAME-MOLD MIDDLE LR;Y15 JU7K 60",PC+GF1 2 SNA
..3 TCON BN95-02488A ASSY T CON;LQ601R3HA6K,Sharp U60Hz 60",H 1 SA
...4 BN62-00705A HEAT SINK-PS;JU 7.5K,A1050,BLACK,135*98. 1 SNA
...4 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK, 1 SNA
...4 BN97-10311A ASSY SMD;BN95-02488A 1 SNA
....5 0202-001899 SOLDER-CREAM;M705-GRN360-K2-VT,20-38um,S 1 SNA
....5 DS01A 0401-001192 DIODE-SWITCHING;MMBD7000LT1,100V,200mA,S 3 SA
....5 0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 SA
....5 0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000mA,SOD- 1 SA
....5 0406-001643 DIODE-TVS;1SMA33AT3G,36.7/38.65/40.6V,40 1 SNA
....5 0406-001689 DIODE-TVS;SMH14A,15.6V,17.9V,1MAV,40A,TP 1 SA
....5 0406-001691 DIODE-TVS;5.5V,7.0V,8.5V,0.5MAV,TP 2 SA
....5 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 1 SA
....5 0502-001345 TR-POWER;FCX491A,NPN,1000mW,SOT89,TR,900 3 SA
....5 0502-001346 TR-POWER;FCX591A,PNP,1000mW,SOT89,TR,30/ 3 SA
....5 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 4 SA
....5 EL02 0601-002037 LED;SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470 2 SA
....5 0801-002345 IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,2 1 SA
....5 0801-003292 IC-CMOS LOGIC;7WB66,Bus Switch,MAB08A,8P 1 SA
....5 1003-002697 IC-LEVEL DRIVER;BD8125MUV,QFN,48P,7x7x0. 1 SNA
....5 1105-002227 IC-DDR3 SDRAM;K4B1G1646G-BCK0,DDR3
SDRAM 2 SA
....5 1203-004363 IC-VOL. DETECTOR;SOT-23,3Z30,2.9x1.6mm,P 1 SA
....5 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 1 SA
....5 1203-008118 IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9 2 SA
....5 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
....5 1203-008424 IC-DC/DC CONVERTER;BM81004MUV,QFN,48P,7x 1 SNA
....5 1204-003617 IC-VIDEO PROCESS;SDP1409.3,FCBGA,1023P,3 1 SA
....5 1405-001381 VARISTOR;11V,8VDC,30A,1.6x0.8x0.9mm,TP,2 3 SA
....5 1405-001382 VARISTOR;24.5V,16VDC,120A,2.0x1.25x1.1mm 1 SA
....5 2007-000034 R-CHIP;1ohm,5%,1/4W,TP,3216 2 SNA
....5 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 2 SNA
....5 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 4 SA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 10 SA
....5 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 2 SA
....5 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
....5 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 SA
....5 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 10 SA
....5 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 SA
....5 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 2 SA
....5 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 12 SA
....5 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 SNA
....5 2007-000165 R-CHIP;200Kohm,5%,1/16W,TP,1005 4 SNA
....5 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 29 SA
....5 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 2 SNA
....5 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000336 R-CHIP;120Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000491 R-CHIP;2.2Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000504 R-CHIP;2.2ohm,5%,1/4W,TP,3216 1 SA
....5 2007-000583 R-CHIP;22Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000606 R-CHIP;240ohm,1%,1/10W,TP,1608 1 SA
....5 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000842 R-CHIP;3Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000857 R-CHIP;4.3Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000929 R-CHIP;470ohm,1%,1/10W,TP,1608 3 SNA
....5 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 4 SNA
....5 2007-002437 R-CHIP;2ohm,5%,1/10W,TP,1608 1 SNA
....5 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 2 SNA
....5 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 34 SNA
....5 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,0.35T 3 SA
....5 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 3 SA
....5 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 8 SNA
....5 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,0.35T 3 SA
....5 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 3 SA
....5 2007-007315 R-CHIP;3.9Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 11 SA
....5 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 7 SNA
....5 2007-007590 R-CHIP;82Kohm,1%,1/16W,TP,1005 2 SNA
....5 2007-007627 R-CHIP;16Kohm,1%,1/16W,TP,1005 2 SA
....5 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 6 SA
....5 2007-008035 R-CHIP;160Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-008070 R-CHIP;130ohm,1%,1/10W,TP,1608 1 SNA
....5 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-008167 R-CHIP;120Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-008332 R-CHIP;11.5Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 2 SC
....5 2007-009234 R-CHIP;0.47ohm,1%,1/4W,TP,3216 6 SNA
....5 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-010387 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 SA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 12 SNA
....5 2011-001427 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,2.0 3 SA
....5 AD480 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,TP,1005 1 SA
....5 AD480 2203-000332 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1608 2 SA
....5 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 2 SA
....5 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 3 SA
....5 AD480 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608 1 SA
....5 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
....5 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 5 SA
....5 AD480 2203-002982 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1005 1 SA
....5 AD480 2203-005221 C-CER,CHIP;15nF,10%,50V,X7R,TP,1608 1 SNA
....5 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 4 SA
....5 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 8 SNA
....5 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
....5 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 6 SA
....5 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,0.5 119 SA
....5 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 1 SA
....5 AD480 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 7 SC
....5 AD480 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012 8 SA
....5 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 5 SA
....5 AD480 2203-006741 C-CER,CHIP;470nF,10%,25V,X5R,TP,1608,0.8 1 SNA
....5 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 1 SNA
....5 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 3 SNA
....5 AD480 2203-006960 C-CER,CHIP;1000nF,10%,50V,X7R,TP,2012 1 SNA
....5 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 51 SNA
....5 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 4 SA
....5 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 6 SA
....5 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 6 SNA
....5 AD480 2203-007370 C-CER,CHIP;10000nF,10%,10V,X7R,TP,2012 8 SA
....5 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 53 SA
....5 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 10 SA
....5 AD480 2203-008315 C-CER,CHIP;22000nF,20%,25V,X5R,TP,2012,1 2 SA
....5 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 3 SA
....5 2703-003937 INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00 1 SA
....5 2703-004199 INDUCTOR-SMD;10uH,20%,6.6x7.0mm,2.2mm,0. 1 SNA
....5 2703-004589 INDUCTOR-SMD;2.2uH,20%,5050,2T,0.048Ohm, 2 SA
....5 2801-005324 CRYSTAL-SMD;27MHz,30ppm,Ceramic SMD(4pin 1 SA
....5 3301-002039 BEAD-SMD;26ohm,1608,TP 13 SA
....5 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 1 SNA
....5 3601-001402 FUSE-SURFACE MOUNT;125V,7A,FAST ACTING,C 1 SNA
....5 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
....5 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
....5 3711-007839 CONNECTOR-HEADER;BOX,15P,1R,1.25mm,SMD-A 1 SA
....5 6302-001290 GASKET;SMR-TS-4-4.5-3,4.0mm,Ni+Au+SUS+Mg 6 SNA
....5 BN41-02291A PCB MAIN;2015 Sharp U120Hz,FR-4,4,1.6,16 1 SNA
....5 BN68-04746A LABEL-SMD;all model,POLY*,25.4mm x 9.53m 1 SNA
....5 BN97-10312A ASSY MICOM;1107-002265,BN95-02488A,Sharp 1 SNA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
.....6 IC 1107-002265 IC-NOR FLASH;W25Q32FVSSIG,32Mbit,SOP,8P, 1 SA
..3 FL06 BN96-34970A ASSY CABLE P-FFC;UHD,FFC,NH,57mm,1.0,96 2 SNA
..3 BN96-35019A ASSY COVER P-SOURCE PCB;Y15 FLAT, 60,BN6 1 SNA
...4 BN62-00537R INSULATION-S-COVER-L;Y15 JU7K 60" SHP,PE 1 SNA
...4 BN63-13206A COVER-SOURCE PCB L;Y15 JU7K 60",EGI-SECC 1 SNA
..3 BN96-35300A ASSY OPEN CELL;LQ601R3HA6K,SHARP 60inch 1 SNA
...4 BN81-11327A A/S-IC DRIVER SOURCE;SHARP 60inch UD 120 24 SNA
...4 BN81-11328A A/S-SS-FPC;SHARP 60inch UD 60/120Hz,QPWB 2 SNA
...4 BN81-11329A A/S-POLARIZER-TFT;SHARP 60inch UD 60/120 1 SNA
...4 BN81-11330A A/S-IC DRIVER GATE;SHARP 60inch UD 120Hz 16 SNA
...4 BN81-11331A A/S-ASSY PCB-SOURCE LEFT-LEFT;SHARP 60in 1 SNA
...4 BN81-11332A A/S-ASSY PCB-SOURCE LEFT-RIGHT;SHARP 60i 1 SNA
...4 BN81-11333A A/S-ASSY PCB-SOURCE RIGHT-LEFT;SHARP 60i 1 SNA
...4 BN81-11334A A/S-ASSY PCB-SOURCE RIGHT-RIGHT;SHARP 60 1 SNA
...4 BN81-11340A A/S-POLARIZER-C/F;SHARP 60inch UD 60Hz,P 1 SNA
..3 BN96-36283A ASSY COVER P-SOURCE PCB;Y15 JU7K 60",BN6 1 SNA
...4 BN62-00537Q INSULATION-S-COVER-R;Y15 JU7K 60" SHP,PE 1 SNA
...4 BN63-13207A COVER-SOURCE PCB R;Y15 JU7K 60",EGI-SECC 1 SNA
..3 SB05A BN96-37201A ASSY BRACKET P-STAND LINK;JU7000 65",HGI 1 SNA
...4 BN02-00074A TAPE PET;CCFL 32"/40",3M1360NH(B),T0.05, 2 SNA
...4 BN60-00162A SPACER-FOAM;FOAM,50000L,BLK,0.35T,20W 0 SNA
...4 CB18 BN61-11517A BRACKET-STAND LINK;JU7000 65",HGI-SGHC,2 1 SNA
....5 BN61-09605A BRACKET-STOPPER NUT;LED TV F6100,Others 4 SNA
...4 BN62-00741A INSULATOR-TCON BOARD;JU7000,PC,BLK,68,14 1 SNA
...4 BN63-08816A GASKET;FABRIC GASKET,PUR FOAM,14mm 짹0.5 5 SNA
..3 TC01A BN96-38492B ASSY CHASSIS TOP P;JS6.9K_60,PC+GF,DARK 1 SA
...4 BN02-00381S TAPE CONDUCTIVE-PTC(UD);Y15 UHD Flat 60" 2 SNA
...4 BN02-00381T TAPE CONDUCTIVE-PTC(LR);Y15 UHD Flat 60" 2 SNA
...4 BN60-00715A SPACER-TOP,CORNER;Y13 Slim F-LED,GASKET* 2 SNA
...4 BN60-01115A SPACER-TOP LINK;Y15 JU7K,CONDUCTIVE FABR 3 SNA
...4 BN60-01254E SPACER-TOP (D);JU6.4K 60",PUR FOAM,L1300 1 SNA
...4 FD01 BN63-13308D COVER-DECORATION;JS6.9K_60,ABS+PC+MF17%, 1 SNA
....5 BN63-12938A FILM HOT STAMPING;UH69,PET,25um,30mm,DGE 1 SNA
...4 BN63-14373E SHEET-COVER;PE+PP,0.068,33mm,ST-671HP,CL 5 SNA
...4 AC157 BN64-02897C CHASSIS-TOP;JS6.9K_60,ABS+PC+MF15%,DARK 1 SNA
..3 M0131 BP63-00321A GASKET;HLP5063,Conductive Fabric,0.12mm, 1 SNA
1 M0017 BN91-16264A ASSY CHASSIS;UN60JS7000FXZA 1 SNA
0.2 M0014 BN94-09273A ASSY PCB MISC-MAIN;UN60JS7000FXZA 1 SA
..3 BN61-11587A HOLDER-SIDE AV;JU6400,HIPS,BLK,HB, 1 TUN 1 SNA
..3 AH020 BN62-00726A HEAT SINK;Y15 UHD 6K (Main),A1050,BLACK 1 SNA
..3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK, 1 SNA
..3 BN97-09484A ASSY DRM-KEY;JU7000,7500,HDCP, MAC 1 SNA
...4 BN46-00109H KEY CODE-CERTIFI;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFI;MIRACAST(HDCP2.2), TV 1 SNA
..3 BN97-10061A ASSY SMD;UHD 6K,BN41 1 SNA
...4 0202-001899 SOLDER-CREAM;M705-GRN360-K2-VT,20-38um,S 5 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 4 SNA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 SA
...4 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
...4 0406-001573 DIODE-TVS;AOZ8806DI-05,6V,1uA/V,0.85V/A 1 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6/-/-V,150W,SLP2510 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM 6 SA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 3 SC
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7Koh 1 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,-30V,-11. 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,-20V,-4.2A,0.052o 1 SA
...4 0505-002893 FET-SILICON;AO4801AS,P,-30V,-5A,2W,SOIC- 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,380mA,1.19ohm, 2 SA
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 4 SA
...4 1001-001860 IC-ANALOG SWITCH;NX5L2750CGU,QFN,10P,1.4 1 SNA
...4 1001-001934 IC-VIDEO SWITCH;SiI9777,LQFP,208P,28X28m 1 SA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002528 IC-DDR3 SDRAM;K4B4G1646D-BCMA,DDR3 1866, 4 SA
...4 1105-002534 IC-DDR3 SDRAM;K4B2G1646Q-BCMA,DDR3
SDRAM 2 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-003891 IC-AUDIO AMP;NTP7415,MLF,48P,7x7mm,DUAL, 1 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-006330 IC-POWER SUPERVISOR;TPS2065DBV,SOT-23,5P 2 SA
...4 1203-007018 IC-DC/DC CONVERTER;TPS54821RHL,QFN,14P,3 1 SA
...4 1203-007238 IC-PWM CONTROLLER;TPS54427,DDA,8P,4.8x3. 2 SNA
...4 1203-007694 IC-DC/DC CONVERTER;SN1106041DDAR,DDA,8Z3 1 SA
...4 1203-008023 IC-POSI.ADJUST REG.;AOZ2003PI,SO-8,8P,4. 1 SA
...4 1203-008082 IC-DC/DC CONVERTER;TPS54627DDAR,SOP 8P,8 1 SA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 2 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008112 IC-POSI.ADJUST REG.;AOZ2002PI,SO-8,8P,4. 1 SA
...4 1203-008183 IC-DC/DC CONVERTER;AOZ3015PI-1,EPAD SO-8 1 SA
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008393 IC-DDR TERMINATION REG.;AP2303MTR-G1-89, 1 SA
...4 1203-008454 IC-DC/DC CONVERTER;TPS56528,HSOP8,8P,4,8 1 SA
...4 1204-003587 IC-DECODER;SDP1406,PBGA,1053P,31x31mm,PL 1 SA
...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4. 3 SA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5x0.6mm,TP,1 14 SA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 42 SA
...4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000166 R-CHIP;300Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 63 SA
...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 4 SNA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 11 SA
...4 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 50 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 5 SA
ANNEX-9
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 1 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 4 SA
...4 2007-001284 R-CHIP;4.7ohm,5%,1/16W,TP,1005 16 SNA
...4 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 16 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 11 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 10 SNA
...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,0.35T 20 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 24 SA
...4 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 4 SNA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 16 SNA
...4 2007-007308 R-CHIP;33Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007310 R-CHIP;8.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005 5 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007314 R-CHIP;5.6Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 24 SA
...4 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 9 SNA
...4 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 24 SA
...4 2007-007767 R-CHIP;200ohm,1%,1/16W,TP,1005 6 SA
...4 2007-007861 R-CHIP;62Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 2 SNA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 11 SA
...4 2007-008137 R-CHIP;24Kohm,1%,1/16W,TP,1005 3 SNA
...4 2007-008213 R-CHIP;4.3Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 4 SA
...4 2007-009117 R-CHIP;49.9Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 3 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 5 SA
...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 4 SA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 6 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 3 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 19 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 3 SA
ANNEX-10
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 5 SNA
...4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 6 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 5 SA
...4 AD480 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 10 SNA
...4 AD480 2203-003019 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1005 3 SNA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 1 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 331 SA
...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 2 SNA
...4 AD480 2203-006257 C-CER,CHIP;470nF,10%,6.3V,X5R,TP,1005,0. 2 SNA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 8 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 53 SNA
...4 AD480 2203-006636 C-CER,CHIP;220nF,10%,25V,X7R,TP,1608 2 SA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 6 SNA
...4 AD480 2203-006838 C-CER,CHIP;2200nF,10%,6.3V,X5R,TP,1005 13 SA
...4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 1 SNA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 4 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 37 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 15 SA
...4 AD480 2203-007486 C-CER,CHIP;1000nF,10%,50V,X5R,TP,1608 2 SA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 107 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 21 SA
...4 2409-001338 C-POLYMER ,CHIP;47uF,20%,6.3V,TP,3.2x1.6 1 SA
...4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 1 SA
...4 2703-000158 INDUCTOR-SMD;1uH,10%,2012,.4Ohm,50mA,45, 1 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1608,1.35Ohm,35mA 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-003135 INDUCTOR-SMD;4.7uH,20%,6965,0.04Ohm,7000 1 SNA
...4 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366,0.015ohm,700 4 SA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,5050,4mm,0.072Ohm 4 SA
...4 2703-005193 INDUCTOR-SMD;2.2uH,20%,6060,4.5,0.024ohm 1 SA
...4 2703-005194 INDUCTOR-SMD;3.3uH,20%,6060,4.5,0.03ohm, 1 SA
...4 2801-003954 CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh 1 SA
...4 2801-004477 CRYSTAL-SMD;24.576MHz,20ppm,SMD,18pF,20o 1 SA
...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz 6 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 53 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 2 SA
...4 3701-001861 CONNECTOR-HDMI;19P,FEMALE,AU,0.5mm,BLK,S 4 SA
...4 3707-001106 CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF 1 SA
...4 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
...4 EH01 3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 SA
...4 EH01 3711-008422 HEADER-BOARD TO CABLE;BOX,9P,1R,1.25mm,S 1 SA
...4 EH01 3711-008659 HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,ANG 1 SA
...4 EH01 3711-008859 HEADER-BOARD TO CABLE;BOX,12P,2R,2.0mm,A 1 SA
ANNEX-11
ANNEX. Exploded View & Part List
