Samsung SM-R865F User manual

Printed in Korea
GH68-53502B Rev.1.2
English, German, French, Italian,
Spanish, Dutch, Portuguese. 11/2021

SM-R865F
QUICK START GUIDE
KURZANLEITUNG
GUIDE DE PRISE EN MAIN RAPIDE
GUIDA DI RIFERIMENTO RAPIDO
GUÍA DE INICIO RÁPIDO
SNELSTARTGIDS
MANUAL DE CONSULTA RÁPIDA

2
Package contents
•
Galaxy Watch4
•
Wireless charger
•
Quick start guide
The items supplied may vary by region.
Connecting to a mobile device
Download the Galaxy Wearable app and connect the product to a
mobile device by following the on-screen instructions.
Using the Galaxy Wearable app, you can view your product’s
status and customise its settings.
•
Supported mobile devices and features may vary depending
on your region, service provider, or device manufacturer.
Accessing the full user manual and safety information
Visit
www.samsung.com to view the full user manual and the
detailed safety information.
English QUICK START GUIDE

English
3
Device layout
Speaker
Atmospheric
pressure sensor
Home key
(Power key)
Back key
Optical heart
rate sensor
Pressure vent
Microphone
•
Do not insert sharp objects into the product’s external holes.
The inner components may be damaged along with the
water-resistance feature.
•
Do not look directly at the optical heart rate sensor’s lights.
Doing so may impair your vision.
•
If the product becomes hot to the touch, remove it until it
cools. Exposing your skin to the product’s hot surface for a
long time may cause low-temperature burns.
•
If your device is frozen and unresponsive, press and hold the
Home key and the Back key simultaneously for more than
7 seconds to restart it.
QUICK START GUIDE

4
Safety information
Read all safety information before using the device to ensure safe
and proper use.
Follow the warnings below to prevent injuries or damage to
the device.
•
Your device contains magnets. Keep a safe distance between
your device and objects that may be affected by magnets such
as credit cards and implantable medical devices. If you have an
implantable medical device, consult your physician before use.
•
Do not disassemble the device or subject it to physical impacts
or things that could damage it.
•
Use only Samsung-approved chargers and specially designed
cables, and prevent the multipurpose jack from coming into
contact with foreign materials.
•
If any part of the device is broken, smokes, or emits a burning
odor, stop using the device immediately. Use the device again
only after it has been repaired at a Samsung Service Centre.
•
The device can be used in locations with an ambient
temperature of 0 °C to 35 °C.You can store the device at an
ambient temperature of -20 °C to 50 °C. Using or storing the
device outside of the recommended temperature ranges may
damage the device or reduce the battery’s lifespan.
•
For accurate measurement, you have to wear the device so
that it fits your wrist. After measuring, loosen the band to allow
air to reach your skin. It is recommended to wear the device so
that it is not too loose or tight, and that it feels comfortable in
normal circumstances.
•
If you have sensitive skin, you may experience skin irritation
due to certain factors, such as friction, pressure, or moisture,
in the following cases: when the device is too tight or loose,
when the device has sweat or foreign materials on it, or when
the device has been worn too long.

English
5
•
If your skin is irritated where the device is worn, remove
the device immediately and consult your physician to take
proper action.
•
Always keep your device clean and dry.
To prevent possible hearing damage when using
a headset, do not listen to sound at high volume
for long periods.
This marking on the product, accessories or
literature and without the bar on batteries
indicates that the product, battery and its
electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other
household waste.
• For information on Samsung’s environmental commitments
and product regulatory obligations, e.g. REACH, visit our
sustainability page available via
www.samsung.com .
• If there are fixed graphics on part or all of the touchscreen
for extended periods, it may result in afterimages (screen
burn-in) or ghosting.
Your device supports 5ATM, IP68 water- and dust-resistance.
Follow these tips carefully to maintain the water- and
dust-resistance of the device.
•
5ATM water-resistance classification certification means
that the device has been tested by submerging it in 50 m
of fresh water for 10 minutes to meet the requirements of
ISO 22810:2010, and IP68 water-resistance classification
certification means that the device has been tested by
submerging it in 1.5 m of fresh water for 30 minutes to
meet the requirements of IEC 60529. Both cases are tested
by leaving the device still, without any movement, and the
water-resistance is not guaranteed when using the device
under conditions that deviate from the standard.

6
•
Failure to follow the tips below may result in damage to your
device and will not guarantee its performance, including its
water-resistance.
- Do not expose your device to liquids other than fresh
water or chemical products, such as sunscreen, hand
sanitizer, cosmetics, soapy water, detergent, oil, perfume,
coffee, or beverages.
- It is recommended to swim in a swimming pool or where
its water level is not deep (approximately within 1.5 m).
- Do not stay underwater, dive, or play water sports,
such as water-skiing, surfing, jumping into water, and
do not swim or use the device in fast-moving water,
such as a river.
Removing the battery
•
To remove the battery, contact an authorised service
centre.To obtain battery removal instructions, please visit
www.samsung.com/global/ecodesign_energy .
•
For your safety, you must not attempt to remove the battery. If
the battery is not properly removed, it may lead to damage to
the battery and device, cause personal injury, and/or result in
the device being unsafe.
•
Samsung does not accept liability for any damage or loss
(whether in contract or tort, including negligence) which
may arise from failure to precisely follow these warnings and
instructions, other than death or personal injury caused by
Samsung’s negligence.
Specific Absorption Rate (SAR) certification information
For SAR values specific to your model, visit
www.samsung.com/sar
and search for your region and device with the model number.

English
7
Band and mode Output power
WCDMA 900/2100 24 dBm
LTE 1/3/7/8/20/28 23 dBm
Wi-Fi 2.4 GHz 20 dBm
Bluetooth 2.4 GHz 20 dBm
Wi-Fi 5.1–5.7 GHz 23 dBm
Wi-Fi 5.8 GHz 25 mW
NFC 13.56 MHz 42 dBµA/m at 10 m
Wireless Charging
110.01 kHz–148 kHz 37.7 dBµA/m at 10 m
The use of the WLAN band is restricted to indoor use only.
This restriction is applicable in: AT, BE, BG, CH, CY, CZ, DE, DK, EE,
ES, EL, FI, FR, HR, HU, IE, IS, IT, LI, LT, LU, LV, MT, NL, NO, PL, PT, RO,
SE, SI, SK, TR, UK(NI), GB.
Declaration of Conformity
Samsung declares that this device is in compliance with Directive
2014/53/EU and with the relevant UK statutory requirements.
Go to
www.samsung.com/mobile_doc to view the Declaration
of Conformity.
Samsung
PO Box 12987, Dublin. IE / Yateley, GU46 6GG. UK
Copyright © 2021 Samsung Electronics Co., Ltd.

8
Lieferumfang
•
Galaxy Watch4
•
Induktive Ladestation
•
Kurzanleitung
Laden Sie das Gerät nicht länger als eine Woche auf, da eine
Überladung die Akkulebensdauer beeinträchtigen kann.
Die bereitgestellten Artikel variieren möglicherweise je
nach Region.
Verbindung mit einem Mobilgerät herstellen
Laden Sie die Anwendung„Galaxy Wearable“ herunter und verbinden Sie
das Produkt mit einem Mobilgerät. Befolgen Sie dazu die Anweisungen
auf dem Bildschirm.
In der Anwendung„Galaxy Wearable“ können Sie den Status des Produkts
aufrufen und seine Einstellungen anpassen.
•
Die unterstützten Mobilgeräte und Funktionen variieren
möglicherweise je nach Region, Dienstanbieter oder Gerätehersteller.
Vollständiges Benutzerhandbuch und Sicherheitshinweise aufrufen
Unter
www.samsung.com finden Sie das vollständige Benutzerhandbuch
sowie detaillierte Sicherheitshinweise.
Deutsch KURZANLEITUNG

Deutsch
9
Geräteaufbau
Lautsprecher
Luftdrucksensor
Zurück-Taste
Home-Taste (Ein-/
Aus-Taste)
Optischer
Pulssensor
Druckventil
Mikrofon
•
Stecken Sie keine scharfen Gegenstände in die Löcher des Produkts.
Dadurch können die Innenteile beschädigt und der Schutz gegen
Wasser beeinträchtigt werden.
•
Sehen Sie auf keinen Fall direkt in das Licht des optischen Pulssensors.
Dies kann zu Sehschäden führen.
•
Sollte sich das Produkt erhitzen, nehmen Sie es ab und lassen Sie
es abkühlen. Ein längerer Kontakt mit der heißen Oberfläche des
Produkts kann zu Niedertemperaturverbrennungen führen.
•
Wenn das Gerät nicht reagiert, halten Sie die Home-Taste und die
Zurück-Taste gleichzeitig mehr als 7 Sekunden lang gedrückt, um
es neu zu starten.
KURZANLEITUNG
