Sananbio RADIX S-Kit User manual

www.sananbious.com
R ead t h e Q u i c k S t a r t a n d U s e r M a n u a l c a r e f u l l y .
D e v i a t i o n f r o m t h e u s e r m a n u a l m a y r e s u l t i n r i s k o f
f l o o d , f i r e , o r e l e c t r i c s h o c k
D o n o t u s e h a m m e r s o r c l a m p s o n t h e S - K i t . U s e a
r u b b e r m a l l e t
W A R N I N G : R i s k o f e l e c t r i c s h o c k : D o n o t c o n n e c t
p o w e r d u r i n g t h e a s s e m b l y p r o c e s s
W A R N I N G : R i s k o f e l e c t r i c s h o c k : M a k e s u r e a l l
c o n n e c t o r a r e s e c u r e l y f a s t e n e d b e f o r e u s e .
W A R N I N G : R i s k o f e l e c t r i c s h o c k o r f i r e : P r o p e r
c i r c u i t p r o t e c t i o n , e . g . A F C I , G F C I , e t c . m u s t b e
i n s t a l l e d .
A T T E N T I O N : R i s k o f f l o o d : D o n o t o v e r f i l l t h e
r e s e r v o i r
A T T E N T I O N : R i s k o f f l o o d : P r o p e r d r a i n a g e m u s t b e
i n s t a l l e d a n d i n s p e c t e d
W A R N I N G : R i s k o f e l e c t r i c s h o c k : T u r n o f f p o w e r
w h e n c l e a n i n g o r m a i n t e n a n c e i s i n p r o g r e s s
W A R N I N G : T i p - o v e r h a z a r d : D o n o t c l i m b o r s t a n d o n
t h e S - K i t
Quick
Start
Safety Warnings
What's in the box
Before you start
S-Kit
Please read the user manual carefully before use.
It's highly recommended to assemble the Product close to
the desired installation site.
It's recommended to have an open space with an area
greater than 40 sf ft with flat surface.
Installing this module will require 2 to 3 adults.
Tools required: a rubber mallet.
If you have any questions or uncertainties, please contact
your local sales representative for assistance.
Each S-Kit consists of two main components:
3 layers stacked (2 grow beds and 1 light canopy ), all grow
lights are pre-assembled.
Grow Rafts and Light Barriers
The water reservoir; Inside the reservoir, you will find:
1.
2.
3.
RADIX Vertical Hydroponic System
Bottom Layer (Grow Bed without Lights
Top Layer (Light Canopy)
Middle Layer (Grow Bed with Lights)
Reservoir
(Additional Parts Inside)
Rafts (Light Barriers Underneath)
All specifications and instructions are subject to change
© Sananbio 2019 Version 1.0
a. Modules legs and spacers: legs with outlets (3), leg
without outlet (1) , and spacers (8).
b. Electrical connection parts: Power cord_main supply
outfitted with a wall plug (1) and power cord_interconnection
(1).
c. Plumbing parts: supply tubing (1), Submersible pump (1)
and drain hose (1) . The drain hose is pre-assembled with
Plumb-Quick fitting.
d. Raft caps, Dams and filter: raft caps (112), Retaining
Dams 12mm (4), Retaining Dams 25mm (4), Filter (1)
The Quick Start is developed to be used with the
latest Radix User Manual. Please read all
instructions carefully before use and keep them
for future reference
Before First Use
Make sure all mechanical/electrical connections are
securely fastened
Refer to the RADIX User Manual for operation and
maintenance instructions. Only use Shallow Flow Mode
per Section 4-2-2. Wipe the S-Kit with a soft cloth or
sponge to remove any excess dust. Use only designated
sanitizing solutions.

2
Bottom Layer
Top Layer
4
4.1 Stage the top layer on top of spacers. Pull out the
supply tubing to reach the water inlet on the front right
corner and connect the grow light connectors
4.2 Push the top layer onto the spacers. Make sure the
supply tubing is fully inserted into the top front right spacer.
Accessories assembly
5
3
Middle Layer
2.1 Retrieve the layer. Flip over and lay it on a flat surface.
2.2 Install the bottom legs. The bottom leg without outlet goes
to the back left corner. All the legs with outlets should have
the outlets facing inward towards the center of the long front
side.
2.3 Flip the bottom layer and lock the casters. The bottom
layer should look like the picture below.
3.5 Insert four additional grey spacers onto the top of the
Middle Layer. Make sure the Tee Cable goes through the
spacer and is ready to connected to the Top Layer
3.6 Insert the supply tubing into the Bottom Leg with Outlet
iin the front left corner. Make sure it’s not pinched as
shown below
3.1 Retrieve the grow bed. Flip
over and lay it on a flat surface.
3.2 Secure the four grey spacer into
the middle layer's corners. Make
sure the side of the Tee Cable,
connected with the bottom cable,
goes through the spacer and the
unconnected side points up.
3.3 Flip the whole layer and stage it
on top of the Bottom Layer.
4.3 Use a rubber mallet to ensure all legs are fully secured.
Start from the bottom layer and move upwards.
5.1 Place the reservoir under the Bottom Layer in between
the bottom legs. Place the lid with the opening towards the
front. Connect the drain hose to the water outlet then tighten
the clamps. Do NOT over tighten. Place the loose end of
drain hose inside the reservoir through the lid opening.
5.2 Follow the instructions from the pump manufacturer to
connect the pump.Connect the supply tubing to the pump and
place the pump inside the reservoir through the lid opening.
Make sure leave the power cord of the pump outside the
reservoir.
5.3 Set the flow rate dial of the pump at maximum.
3.4 Connect the Bottom cable with Power
Cord_Interconnection before securing the spacers into the
bottom layer. Make sure the cables are not being pinched.
www.sananbious.com
1
Identify the Front/Back
RADIX S-Kit Quick Start v1.0
1.1 When stacked, all layers have been aligned to have the
same orientation. The side with the SANANBIO logo is the
FRONT.
1.2 During installation keep the orientation consistent to make
sure the corners are aligned properly for electrical, supply
tubing and water circulation. The picture below demonstrates
how the water cascades following the numerical order
Let's Grow, Together!
