SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 1 October 2008, Document no. 80-36-03353
SanDisk uSSD 5000
Product Manual
Revision 1
October 08
SanDisk Corporation
Corporate Headquarters • 601 McCarthy Blvd. • Milpitas, CA 95035
Phone [phone] • Fax [phone]
www.sandisk.com

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation i October 2008, Document no. 80-36-03353
Table of Contents
1. Introduction ........................................................................................ 3
1.1 General Description....................................................................... 3
1.1.1 Applications ............................................................... 3
1.1.2 Rugged and Reliable.................................................... 3
1.1.3 High Performance ....................................................... 3
1.1.4 Cost Effective ............................................................. 3
1.2 Features...................................................................................... 4
1.3 Scope ......................................................................................... 5
1.3.1 Technology Independence ............................................ 5
1.3.2 Defect and Error Management ...................................... 5
1.3.3 Wear-leveling ............................................................. 5
1.3.4 Bad Block Management................................................ 5
2. Product Specifications ......................................................................... 6
2.1 Formatted Capacities..................................................................... 6
2.2 System Environmental Specifications ............................................... 6
2.3 System Power Requirements .......................................................... 7
2.4 Voltage Ramp Down Recommendation ............................................. 7
2.5 System Performance ..................................................................... 8
2.6 System Reliability ......................................................................... 9
2.6.1 MTTF......................................................................... 9
2.7 Endurance ..................................................................................10
2.8 Electrical Interface .......................................................................10
2.8.1 uSSD Connector ....................................................... 10
2.8.2 Electrical Specifications.............................................. 11
2.9 Physical Specifications ..................................................................12
2.9.1 Standard Configuration .............................................. 12
2.9.2 Low Profile Configuration ........................................... 13
2.9.3 uSSD-to-USB Adapter................................................ 13
2.10 Product Markings and Traceability ..................................................14
2.11 OS Support.................................................................................15
2.12 Regulatory Compliance .................................................................15
Ordering Information ............................................................................. 16
Disclaimer of Liability ............................................................................. 17

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation ii October 2008, Document no. 80-36-03353
List of Tables
Table 1: Formatted Capacities ................................................................. 6
Table 2: Environmental Specifications ...................................................... 6
Table 3: Power Requirements.................................................................. 7
Table 4: Performance............................................................................. 8
Table 5: Reliability................................................................................. 9
Table 6: uSSD MTTF .............................................................................. 9
Table 7: Host Interface 2x5 On-Board Header ......................................... 10
Table 8: Absolute Maximum Ratings....................................................... 11
Table 10: DC Characteristics for Full-Speed Operation (TA = 25°C) ............ 11
Table 11: DC Characteristics for High-Speed Operation (TA = 25°C)........... 11
Table 11: Physical Dimensions .............................................................. 12
Table 12: OS Support .......................................................................... 15
Table 13: Ordering Information ............................................................. 16

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 3 October 2008, Document no. 80-36-03353
1. Introduction
1.1 General Description
The SanDisk uSSD takes the benefits of flash storage to new markets with
low-capacity storage requirements, most notably the low-cost PC (LCPC).
Rugged and reliable, it is a fraction of the size and cost of a hard disk drive
(HDD) in the 1 to 16 GB range. SanDisk adds high performance to the uSSD
offering, based on an advanced controller that exemplifies the company’s
years of USB expertise.
1.1.1 Applications
The SanDisk uSSD offers a no-compromise flash-based storage solution for:
LCPCs that need rugged reliability and require up to 4 GB. The uSSD can
meet these requirements more cost-effectively than an HDD
Desktops that support Microsoft® Vista and can benefit from enabling
ReadyBoost® up to 4GB.
Point of sale (POS) stations, where the uSSD replaces the HDD
Blade servers, where the uSSD is ideal to store critical backup files and
provide boot functionality
1.1.2 Rugged and Reliable
Unlike the HDD, the SanDisk uSSD has no moving parts. It keeps working in
challenging environments such as classrooms, kiosks and on space-restricted
server floors. The patented flash management technology brings top data
integrity to the uSSD, even during power losses. Dynamic bad block
management, dynamic and static wear-leveling, and robust error detection
and correction code (EDC/ECC) ensure data reliability.
1.1.3 High Performance
The uSSD achieves a sustained read speed as high as 30 MB/sec and a
sustained write speed of up to 20 MB/sec with single-level cell (SLC)
technology.
1.1.4 Cost Effective
There is no need to pay for more capacity than you require. The uSSD lets you
purchase just the right amount of storage, packed inside a memory device
that’s 25% smaller than a 1.8” HDD. It offers you the choice of single-level
cell (SLC) flash technology or the more cost-effective multi-level cell (MLC)
technology.

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 4 October 2008, Document no. 80-36-03353
1.2 Features
The SanDisk uSSD 5000 provides the following system features:
Non-volatile storage (no battery required)
USB 2.0 interface, certified by the USB organization
(http://www.usb.org/home)
Complies with Microsoft Vista ReadyBoost® requirements
Up to 16 GB of mass storage based on SanDisk’s reliable flash technology
SLC flash and MLC flash-based configurations
Fixed configuration (not removable)
Low power consumption
High performance:
Sustained Read and write speed of up to 30 MB/sec for reading, 20 MB/sec
for writing (SLC configuration)
Rugged
Lightweight
Silent
Standard and low profile
Advanced error detection and error correction algorithms
Advanced wear-leveling algorithms
Guaranteed data integrity even after power loss
MTTF > 8,000,000 hours
Multiple OS support
Warranty: 3 years

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 5 October 2008, Document no. 80-36-03353
1.3 Scope
This document describes the key features and specifications of the uSSD 5000,
as well as the information required to interface this product to a host system.
1.3.1 Technology Independence
To write or read a sector (or multiple sectors), the host computer software
simply issues a Read or Write command to the module.
This command contains the address and the number of sectors to write/read.
The host software then waits for the command to be completed.
The host software does not participate in the details of how the flash memory
is erased, programmed or read. This is extremely important as flash devices
are expected to increase in complexity in the future. Because the uSSD 5000
uses an intelligent on-board controller, the host system software will not need
to be changed as new flash memory evolves. As such, systems that support
uSSD 5000 now will be able to access future SanDisk Modules built with new
flash technology without any need to update or change the host software.
1.3.2 Defect and Error Management
The uSSD 5000 contains a sophisticated defect and error management
system.
If necessary, the Module will rewrite data from a defective sector to a good
sector. This is completely transparent to the host and does not consume any
user data space.
The uSSD 5000 soft error rate specification is much better than the magnetic
disk drive specification.
In the extremely rare case that a read error does occur, the uSSD 5000 has
innovative algorithms to recover the data by using hardware on-the-fly Error
Detection Code/Error Correction Code (EDC/ECC), based on a BCH algorithm.
These defect and error management systems, coupled with solid state
construction, give the SanDisk uSSD 5000 unparalleled reliability.
1.3.3 Wear-leveling
Wear-leveling is an inherent part of the erase-pooling functionality of the
SanDisk uSSD 5000, using NAND memory.
Advanced features of dynamic and static wear-leveling and automatic block
management are used to ensure high data reliability and maximize flash life
expectancy.
1.3.4 Bad Block Management
Bad blocks are occasionally created during the lifecycle of a flash component,
in a phenomenon called dynamic bad block accumulation. These bad blocks
must be dynamically marked and replaced to prevent read/write failures.
When a bad block is detected, the embedded bad block mapping algorithm
maps out the block, which is then no longer used for storage.

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 6 October 2008, Document no. 80-36-03353
2. Product Specifications
For all the following specifications, unless otherwise stated, values are defined
at ambient temperature and nominal supply voltage.
2.1 Formatted Capacities
Table 1 shows the formatted capacities for the uSSD 5000:
Table 1: Formatted Capacities
Capacity
[GB]
Capacity (formatted
in bytes)
Sectors/Module
(Max. LBA+1)
No. of
Heads
No. of Sectors/
Track
No. of
Cylinders
SLC Configurations
1
1,002,438,656
1,957,537
16
63
1,942
2
2,048,900,608
4,001,760
16
63
3,969
4
4,110,188,032
8,027,712
16
63
7,963
8
8,220,645,376
16,055,949
16
63
15,928
MLC Configurations
2
2,048,900,608
4,001,760
16
63
3,969
4
4,110,188,032
8,027,712
16
63
7,963
8
8,220,645,376
16,055,949
16
63
15,928
16
16,441,481,216
32,112,269
16
63
31,857
2.2 System Environmental Specifications
Table 2 lists the environmental specifications, including temperature, noise
level, vibration, shock and altitude.
Table 2: Environmental Specifications
Specification
Parameters
Temperature
Operating (Commercial): 0° C to 70° C
Storage temp without user data retention: -40° C to 85° C
Storage temp with user data retention: 0° C to 70° C
Noise Level
0 dB
Vibration
Operating: 2.17gRMS (20Hz to 2000Hz, 3 vibration axes, 60 min)
Non operating: 3.08 gRMS (20 Hz to 2000 Hz)
Shock
Operating: 50 g, 11 msec duration, half sine
Non operating: 1,500 g, 0.5 msec duration, half sine
Altitude (relative to sea
level)
80,000 ft. maximum
ESD
Contact discharge: Up to 4 KV (enclosed in a host)
Air discharge: Up to 8 KV (enclosed in a host)
Flammability ratings for
major components
PCB: 888-1 94V0 HK
ASIC Packaging materials: 94V0
Flash packaging materials: 94V0
Labels: CM-100-SM, CM-200-WS

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 7 October 2008, Document no. 80-36-03353
2.3 System Power Requirements
All values quoted in Table 3: Power Requirements
are typical at 25° C and nominal supply voltage unless otherwise stated.
Table 3: Power Requirements
Power Mode
5V +/- 10% IDD
5V +/- 10% IDD
Products
SLC 1GB, 2GB, 4GB,
8GB
MLC 2GB
MLC 4GB, 8GB, 16GB
Standby
2.5 mA
2.5 mA
Operating HS Read
150 mA
200 mA
Operating HS Write
150 mA
200 mA
Idle HS
100 mA
100 mA
2.4 Voltage Ramp Down Recommendation
Memory
Min
Typ
Max
Unit
Tpoff
Binary
1
-
-
ms
MLC
3
-
-
ms
Vflash_protect
Any
4.27
4.38
4.49
V
Vflash_min
Any
-
-
2.7
V
Vflash_min
Vflash_protect
Tpoff

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 8 October 2008, Document no. 80-36-03353
2.5 System Performance
Table 4 lists the performance parameters of the SLC and MLC flash-based
configurations:
Table 4: Performance
Specification
Parameters
Maximum performance for 1 GB, 2 GB, 4GB and 8GB (SLC flash
configurations)
Sequential Read
30 MB/sec
Sequential Write
20 MB/sec
Random Read
30 MB/sec
Random Write
6 MB/sec
Maximum performance for 2 GB (MLC configuration)
Sequential Read
27 MB/sec
Sequential Write
6 MB/sec
Random Read
25 MB/sec
Random Write
2.2 MB/sec
Maximum performance for 4 GB, 8 GB and 16GB (MLC configuration)
Sequential Read
27 MB/sec
Sequential Write
12 MB/sec
Random Read
25 MB/sec
Random Write
3.5 MB/sec
Host compatibility
USB 2.0
Up to 60 MB/sec
Note: Random read and write were measured on Windows 2000 with HDBench on a 100MB file transfer

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 9 October 2008, Document no. 80-36-03353
2.6 System Reliability
Table 5: Reliability
Specification
Parameters
Data Reliability
Error detection / error correction based on
BCH algorithm
Data integrity after power loss
Data is guaranteed after power loss
Bad blocks
Transparent bad block management
Wear-leveling
Dynamic and Static Wear-leveling
2.6.1 MTTF
The reliability figure of merit most often used for electronic equipment is Mean
Time To Failure (MTTF). SanDisk estimates MTTF using a prediction
methodology based on reliability data for the individual components in
SanDisk products.
Component data comes from several sources: device life tests, failure analysis
of earlier equipment, device physics, and field returns.
SanDisk uses following methods to predict reliability:
Telcordia Special Report SR-332, Reliability Prediction Procedure for
Electronic Equipment (RPP).
British Telecom Industry HRD5, Handbook of Reliability Data for Electronic
Components used in Telecommunication System.
Table 6 summarizes the MTTF prediction results for various uSSD
configurations. The analysis was performed using a RAM Commander™ failure
rate prediction.
Failure Rate: The total number of failures within an item population,
divided by the total number of life units expended by that population,
during a particular measurement interval under stated condition.
Mean Time To Failures (MTTF): A basic measure of reliability for
repairable items: The mean number of life units during which all parts of
the item perform within their specified limits, during a particular
measurement interval under stated conditions.
Table 6: uSSD MTTF
Product
Condition
MTTF (Hours)
1GB, 2GB, 4GB
Telcordia SR-332, GB, 25°C
10M
8GB, 16GB
Telcordia SR-332, GB, 25°C
8M

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 10 October 2008, Document no. 80-36-03353
2.7 Endurance
The uSSD5000 SLC flash-based configurations have guaranteed endurance of
3 years for all capacities (1, 2, 4 and 8GB).
The uSSD5000 MLC flash-based configurations have guaranteed endurance of
3 years as follows:
BAPCO Student profile –uSSD MLC 8GB and up.
BAPCO Personal profile –uSSD MLC 4GB and up.
2.8 Electrical Interface
Table 7 lists the host interface on-board header pins and signals.
Table 7: Host Interface 2x5 On-Board Header
Pin
Signal
Pin
Signal
1
+5VDC
2
+5VDC
3
USB1 Data(-)
4
USB2 Data(-)
5
USB1 Data(+)
6
USB2 Data(+)
7
GND
8
GND
9
Key (no pin)
10
NC
2.8.1 uSSD Connector
Figure 1 illustrates the uSSD 2x5 device interface connector:
Figure 1: uSSD 2x5 Connector Pinout

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 11 October 2008, Document no. 80-36-03353
2.8.2 Electrical Specifications
2.8.2.1 Absolute Maximum Ratings
Table 8: Absolute Maximum Ratings
Parameter
Symbol
Min
Max
Unit
Ambient Operating Temperature Range (Commercial)
TA
0
70
°C
Power Supply Voltage Relative to Ground
Vbus
0
5.5
V
Voltage level on D+ / D- Relative to Ground 3
Vdata
-0.3
5.8
V
2.8.2.2 DC Characteristics
Table 9: DC Characteristics for Full-Speed Operation (TA = 25°C)
Parameter - USB Signals
Symbol
Min
Typ
Max
Unit
Supply Voltage:
VBUS
4.5
5.0
5.5
V
Supply Current (RMS):
Operating
Suspend
Icc
Iccs
-
-
120
1.6
150
2.5
mA
mA
Max Current Consumption (Peak Value)
-
-
150
mA
Input Levels USB Signals (D+, D-):
Low
High
VIL
VIH
-
2.0
-
-
0.8
-
V
V
Output Voltage USB Signals (D+, D-):
Low
High
VOL
VOH
0.0
2.8
-
-
0.3
3.6
V
V
Output Signal Crossover Voltage USB
Signals (D+, D-)
VCRS
1.3
-
-
2.0
V
Table 10: DC Characteristics for High-Speed Operation (TA = 25°C)
Parameter - USB Signals
Symbol
Min
Typ
Max
Unit
Supply Voltage:
VBUS
4.5
5.0
5.5
V
Supply Current (RMS)
Operating
Suspend
Icc
Iccs
-
-
120
1.6
150
2.5
mA
mA
Max Current Consumption (Peak Value)
-
-
150
mA
Input Levels USB Signals (D+):
Low
High
VIL
VIH
-10
360
-
-
10
440
mV
mV
Input Levels USB Signals ( D-):
Low
High
VIL
VIH
360
-10
-
-
440
10
mV
mV
Output Voltage USB Signals (D+, D-):
Low
High
VOL
VOH
-10
360
10
440
mV
mV

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 12 October 2008, Document no. 80-36-03353
2.9 Physical Specifications
SanDisk offers the uSSD 5000 in 2 form factors:
Standard profile
Low profile
Table 11 and Figure 2, Figure 3 and Figure 5 list the physical specifications
and dimensions of the uSSD 5000.
Table 11: Physical Dimensions
Dimension
Parameters
Weight
4.9g
Length
Standard and Low Profile: 37.80 ± 0.25 mm
Width
Standard and Low Profile:26.65 ± 0.25 mm
Thickness
Standard profile: 10.60 ± 0.25 mm
Low Profile: 6.58 ± 0.25 mm
2.9.1 Standard Configuration
Figure 2: uSSD Standard Version, Side View

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 13 October 2008, Document no. 80-36-03353
Figure 3: uSSD Standard Version, Bottom View
2.9.2 Low Profile Configuration
Figure 4: uSSD 2x5 Low Profile Version, Side View
Figure 5: uSSD 2x5 Low Profile Version, Bottom View
2.9.3 uSSD-to-USB Adapter
An adapter is available to assist customers in evaluating the uSSD 5000. The
adapter enables inserting the uSSD 5000 in an external desktop or laptop USB
port.
The adaptor is available at its leaded format for purchasing and its SKU is
SDADP-UC-001
Figure 6: uSSD External USB Adapter

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 14 October 2008, Document no. 80-36-03353
2.10 Product Markings and Traceability
SKU# Ordering Info See Appendix A for further options
SDUS5AB-001G - SD SanDisk
US5 uSSD 5000
A standard profile with LED /E low Profile with LED/
/F low Profile with external LED
B Binary (SLC)/J MLC
YYWWDMNNNNN –YY year
WW week
D Month day
M Subcontractor code
NNNNN Running serial number
Firmware# - according to Bill of Material
54-90-XXXXX-CCCC Internal SanDisk subunit Number

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 15 October 2008, Document no. 80-36-03353
2.11 OS Support
The uSSD 5000 is supported under the operating systems listed in Table 12.
In the standard boot and storage modes, the uSSD 5000 is recognized as a
fixed disk in the system. The system can also boot from the uSSD 5000,
eliminating the need for additional components.
Software packages for the supported operating systems can be downloaded
from the SanDisk website, along with the relevant documentation.
Table 12: OS Support
Operating System
Version
Support
Windows XP Pro
Service Pack 2
SanDisk driver
Windows XP Embedded
SP2 FP 2008
Native in the OS
Windows Vista (Storage and ReadyBoost support)
32 bit + 64 bit
Native in the OS
Windows Embedded for Point of Service (WEPOS)
Service Pack 2
SanDisk driver
Windows Server 2003
SanDisk driver
Windows CE
5.0 and 6.0
Native in the OS
Linux
Kernel 2.6.XX
Native in the OS
DOS
Native in the OS
2.12 Regulatory Compliance
The uSSD 5000 complies with the following:
USB Organization certification
RoHS (6 Materials)
Chinese RoHS
FCC Class B for Information Technology [MIC, BMSI, VCCI]
CE EN 55022/55024
UL 60-950-1 CSA C22.2 No. 60950-1-03
WHQL for Windows Xp, Windows Vista and Windows server 2003
Windows Vista ReadyBoost®compliance

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 16 October 2008, Document no. 80-36-03353
Ordering Information
Table 13: Ordering Information
SKU
Capacity
Standard
Profile
Low
Profile
Internal
Led
External
Led
MLC
Binary
SDUS5AB-001G
1GB
X
X
X
SDUS5EB-001G
1GB
X
X
X
SDUS5EB-001G-1190
1GB
X
X
X
SDUS5FB-001G-1036
1GB
X
X
X
SDUS5AB-002G
2GB
X
X
X
SDUS5AJ-002G
2GB
X
X
X
SDUS5EB-002G
2GB
X
X
X
SDUS5EJ-002G
2GB
X
X
X
SDUS5FB-002G
2GB
X
X
X
SDUS5FB-002G-1036
2GB
X
X
X
SDUS5FJ-002G
2GB
X
X
X
SDUS5AB-004G-1036
4GB
X
X
X
SDUS5FB-004G
4GB
X
X
X
SDUS5FJ-004G
4GB
X
X
X
SDUS5AB-004G
4GB
X
X
X
SDUS5AB-004G-1035
4GB
X
X
X
SDUS5AJ-004G
4GB
X
X
X
SDUS5EB-004G
4GB
X
X
X
SDUS5EJ-004G
4GB
X
X
X
SDUS5AB-008G
8GB
X
X
X
SDUS5FB-008G
8GB
X
X
X
SDUS5FJ-008G
8GB
X
X
X
SDUS5AB-008G-1035
8GB
X
X
X
SDUS5AJ-008G
8GB
X
X
X
SDUS5EB-008G
8GB
X
X
X
SDUS5EJ-008G
8GB
X
X
X
SDUS5AJ-016G
16GB
X
X
X
SDUS5EJ-016G
16GB
X
X
X
SDUS5FJ-016G
16GB
X
X
X
1 megabyte (MB) = 1 million bytes; 1 gigabyte (GB) = 1 billion bytes. Some of the listed
capacity is used for formatting and other functions, and thus is not available for data storage.

SanDisk uSSD 5000 Product Manual
© 2008 SanDisk® Corporation 17 October 2008, Document no. 80-36-03353
Disclaimer of Liability
SanDisk Corporation Policy
SanDisk Corporation general policy does not recommend the use of its products in life
support applications wherein a failure or malfunction of the product may directly
threaten life or injury.
Accordingly, in any use of products in life support systems or other applications where
failure could cause damage, injury or loss of life, the products should only be
incorporated in systems designed with appropriate redundancy, fault tolerant or back-
up features.
SanDisk shall not be liable for any loss, injury or damage caused by use of the
Products in any of the following applications:
Special applications such as military related equipment, nuclear reactor control,
and aerospace
Control devices for automotive vehicles, train, ship and traffic equipment
Safety system for disaster prevention and crime prevention
Medical-related equipment including medical measurement device
