S&T Kontron COMe Eval Carrier2 T6 User manual


USER GUIDE
COMe Eval Carrier2 T6 (ADT6)
Doc. Rev 1.2
Doc.-ID: 1065-4472

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
Page left intentionally blank
www.kontron.com //
2

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 3
COMe Eval Carrier2 T6 (ADT6)
Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the user guide or any product characteristics
set out in the user guide. Kontron assumes no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright or mask work rights to these products and makes no
representations or warranties that these products are free from patent, copyright or mask work right infringement
unless otherwise specified. Applications that are described in this user guide are for illustration purposes only.
Kontron makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification. Kontron expressly informs the user that this user guide only contains a general
description of processes and instructions which may not be applicable in every individual case. In cases of doubt,
please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this user guide is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this user guide only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2020 by Kontron S&T AG
Kontron S&T AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 4
Intended Use
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE
FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS FOR
AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING APPLICATIONS,
WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE
PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR
SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless otherwise
stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot
therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as
device in High Risk Applications. All application and safety related information in this document (including application
descriptions, suggested safety measures, suggested Kontron products, and other materials) is provided for reference
only.
Handling and operation of the product is permitted only for trained personnel within a work
place that is access controlled. Please follow the “General Safety Instructions for IT
Equipment” supplied with the system.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author
1.0 Initial issue 2019-Sept-23 hjs
1.1 Introduction modified, corrected signals
5V_MOD and V_WIDE_MOD
2020-Jan-27 hjs
1.2 variant 38116-0000-00-5 removed 2020-July-21 hjs
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into
a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of
mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 6
Symbols
The following symbols may be used in this manual
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE indicates a property damage message.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60 V) when touching
products or parts of them. Failure to observe the precautions indicated and/or prescribed by
the law may endanger your life/health and/or result in damage to your material.
Please refer also to the "High-Voltage Safety Instructions" portion below in this section.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
This symbol indicates general information about the product and the user manual.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 7
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Special Handling and Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not
guaranteed, it is important for the user to be electrically discharged before touching the product with his/her hands
or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not placed
on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the
batteries or conductive circuits on the product.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 8
Lithium Battery Precautions
If your product is equipped with a lithium battery, take the following precautions when replacing the battery.
Danger of explosion if the battery is replaced incorrectly.
Replace only with same or equivalent battery type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or
modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received
from Kontron Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present user guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.
Quality and Environmental Management
Kontron aims to deliver reliable high-end products designed and built for quality, and aims to complying with
environmental laws, regulations, and other environmentally oriented requirements. For more information regarding
Kontron’s quality and environmental responsibilities, visit http://www.kontron.com/about-kontron/corporate-
responsibility/quality-management.
Disposal and Recycling
Kontron’s products are manufactured to satisfy environmental protection requirements where possible. Many of the
components used are capable of being recycled. Final disposal of this product after its service life must be
accomplished in accordance with applicable country, state, or local laws or regulations.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 9
WEEE Compliance
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the product
become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound environmental
disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 10
TABLE OF CONTENTS
Disclaimer .............................................................................................................................................................................................................3
Intended Use....................................................................................................................................................................................................... 4
Revision History..................................................................................................................................................................................................5
Terms and Conditions.......................................................................................................................................................................................5
Customer Support..............................................................................................................................................................................................5
Customer Service ...............................................................................................................................................................................................5
Customer Comments ........................................................................................................................................................................................5
Symbols .................................................................................................................................................................................................................6
For Your Safety....................................................................................................................................................................................................7
High Voltage Safety Instructions ..................................................................................................................................................................7
Special Handling and Unpacking Instruction ............................................................................................................................................7
Lithium Battery Precautions.......................................................................................................................................................................... 8
Quality and Environmental Management ................................................................................................................................................. 8
WEEE Compliance...............................................................................................................................................................................................9
Table of Contents .............................................................................................................................................................................................10
List of Tables.......................................................................................................................................................................................................11
List of Figures ....................................................................................................................................................................................................12
1/ Introduction..........................................................................................................................................................................................13
1.1. Product Description...................................................................................................................................................................................13
1.2. Product Naming Clarification ................................................................................................................................................................14
1.3. Understanding COM Express® Functionality...................................................................................................................................14
1.4. COM Express® Documentation.............................................................................................................................................................15
1.5. COM Express® Benefits...........................................................................................................................................................................15
2/ System specifications.......................................................................................................................................................................16
2.1. Component Main Data.............................................................................................................................................................................16
2.2. Block diagram............................................................................................................................................................................................17
2.3. Product Variants.......................................................................................................................................................................................18
2.4. Environmental Conditions.....................................................................................................................................................................18
3/ Mainboard Views................................................................................................................................................................................19
3.1. Top View.......................................................................................................................................................................................................19
3.2. Front panel ................................................................................................................................................................................................20
4/ Mechanical Specification .................................................................................................................................................................21
4.1. Dimensions..................................................................................................................................................................................................21
5/ Interfaces and Connectors ............................................................................................................................................................. 22
5.1.1. 1000Base-T Connector (J33)..............................................................................................................................................................22
5.1.2. USB Connectors (J64, J65, J33, J63).................................................................................................................................................23
5.1.3. Graphic Interfaces (J32, J39, J2, J14, J17) ........................................................................................................................................ 23
5.1.4. HD Audio (J78)........................................................................................................................................................................................ 25
5.1.5. HD Audio Internal (J48).......................................................................................................................................................................26
5.1.6. COM Ports................................................................................................................................................................................................26
5.1.7. I2C and SMBus (J57 and FPGA U17).................................................................................................................................................. 27
5.1.8. PCIe Slots (J25, J81 – J88) ................................................................................................................................................................... 27
5.1.9. GPIO (General Purpose Input and Output( (J49).........................................................................................................................28
5.1.10. Serial ATA 3.0........................................................................................................................................................................................28
5.1.11. Feature Connector (J57).....................................................................................................................................................................29
5.1.12. External Connector (J21)...................................................................................................................................................................29
5.1.13. Fan 3-Pin/4-Pin Jumper (J93).........................................................................................................................................................30
5.1.14. Fan Connector (J47) ............................................................................................................................................................................31

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 11
5.1.15. 24-pin ATX Power connector (J5)...................................................................................................................................................31
5.1.16. 8-pin ATX Power connector (J99).................................................................................................................................................. 32
5.1.17. SPI BIOS (J45) ........................................................................................................................................................................................ 33
5.1.18. LPC/eSPI (J29)......................................................................................................................................................................................34
6/ Accessories.......................................................................................................................................................................................... 35
7/ Electrical Specification ....................................................................................................................................................................36
7.1. Supply Voltage ..........................................................................................................................................................................................36
7.2. Power Supply Rise time......................................................................................................................................................................... 36
7.3. Supply Voltage Ripple ............................................................................................................................................................................36
8/ Features................................................................................................................................................................................................ 37
8.1. Rapid Shutdown (J21, Pin17) ................................................................................................................................................................. 37
8.2. Wake Signals............................................................................................................................................................................................. 37
8.3. LEDs and indicators................................................................................................................................................................................38
8.4. Jumper ........................................................................................................................................................................................................39
8.5. Button Switches........................................................................................................................................................................................41
9/ COMe Connector Pin-out (J61).......................................................................................................................................................42
10/ Technical Support ............................................................................................................................................................................. 47
10.1. Warranty ...................................................................................................................................................................................................47
10.2. Returning Defective Merchandise ...................................................................................................................................................47
List of Acronyms..............................................................................................................................................................................................49
About Kontron ..................................................................................................................................................................................................50
LIST OF TABLES
Table 1: Features...............................................................................................................................................................................................14
Table 2: Component Main Data....................................................................................................................................................................16
Table 3: Product Variants ..............................................................................................................................................................................18
Table 4: Environmental Conditions ............................................................................................................................................................18
Table 5: 1000Base-T connector .................................................................................................................................................................22
Table 6: Signals ................................................................................................................................................................................................22
Table 7: USB Double Connector .................................................................................................................................................................23
Table 8: Graphic Interfaces ..........................................................................................................................................................................23
Table 9: Graphic Interfaces DDI ..................................................................................................................................................................24
Table 10: Graphic Interfaces LVDS and eDP............................................................................................................................................24
Table 11: Graphic Interfaces VGA ................................................................................................................................................................24
Table 12: Colorsceme HD Audio .................................................................................................................................................................. 25
Table 13: HD Audio........................................................................................................................................................................................... 25
Table 14: HD Audio internal..........................................................................................................................................................................26
Table 15: COM Ports ........................................................................................................................................................................................26
Table 16: SMBus ............................................................................................................................................................................................... 27
Table 17: PCIe Slots.......................................................................................................................................................................................... 27
Table 18: GPIO with 10 pins...........................................................................................................................................................................28
Table 19: SATA 3.0 ...........................................................................................................................................................................................28
Table 20: Feature Connector with 24 pins .............................................................................................................................................29
Table 21: External Connector with 24 pins .............................................................................................................................................29
Table 22: Fan Connector with 4 pins (J47)...............................................................................................................................................31
Table 23: : ATX Power connector with 24 pins .......................................................................................................................................31
Table 24: ATX Power connector with 8 pins .......................................................................................................................................... 32
Table 25: SPI BIOS............................................................................................................................................................................................ 33
Table 26: Features as SAFS together with eSPI .................................................................................................................................... 33
Table 27: LPC/eSPI (J29)................................................................................................................................................................................34
Table 28: General Accessories List............................................................................................................................................................ 35
Table 29: Wake Signals.................................................................................................................................................................................. 37
Table 30: LEDs ..................................................................................................................................................................................................38

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 12
Table 31: Jumper ..............................................................................................................................................................................................39
Table 32: Buttons .............................................................................................................................................................................................41
Table 33: Pin-out List .....................................................................................................................................................................................42
LIST OF FIGURES
Figure 1: COMe Eval Carrier2 T6...................................................................................................................................................................13
Figure 2: Block Diagram COMe-Type6 Eval Carrier............................................................................................................................... 17
Figure 3: Top View of COMe Eval Carrier2 T6..........................................................................................................................................19
Figure 4: Front Panel......................................................................................................................................................................................20
Figure 5: Board Dimensions ..........................................................................................................................................................................21
Figure 6: 1000Base-T connector ................................................................................................................................................................22
Figure 7: USB Double Connector................................................................................................................................................................. 23
Figure 8: HD Audio........................................................................................................................................................................................... 25
Figure 9: HD Audio 10-pin..............................................................................................................................................................................26
Figure 10: GPIO..................................................................................................................................................................................................28
Figure 11: Configuring GPIO Pins using JIDA32/K-Station...................................................................................................................28
Figure 12: Feature Connector with 24 pins .............................................................................................................................................29
Figure 13: External Connector with 24 pins............................................................................................................................................29
Figure 14: Fan 3-Pin/4-Pin Jumper with 3 pins .....................................................................................................................................30
Figure 15: Fan Connector with 4 pins .........................................................................................................................................................31
Figure 16: ATX Power connector with 24 pins ........................................................................................................................................31
Figure 17: ATX Power connector with 8 pins .......................................................................................................................................... 32
Figure 18: LPC/eSPI (J29)...............................................................................................................................................................................34
Figure 19: Jumpers 5V_MOD and V_WIDE_MOD...................................................................................................................................40
Figure 19: Button Switches............................................................................................................................................................................41
Figure 20: COMe Connector with 220 pins..............................................................................................................................................42
Figure 21: COMe Connector Pinout.............................................................................................................................................................42

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 13
1/ Introduction
1.1. Product Description
The COMe Eval Carrier2 T6 is being developed as an evaluation, testing and validation carrier board (baseboard) in
ATX form factor for COM Express® Type 6 modules. It offers a testing platform for a huge variety of interfaces. Main
purpose of this carrier board is to bring out all the signals from COM Express® connector of COMe Type6 modules to
industry standard interfaces. The key features are:
1x 1000Base-T interface
4x USB 3.1 Interface, up to 8x USB 2.0
9x PCIe slot (1x x16 + 8x x1)
4x SATA standard interface,
External fan connector
Pin headers for COM Express® specific signals enabling measurement like GPIOs, I2C, SMBus and Feature
connector
External BIOS flash socket
Figure 1: COMe Eval Carrier2 T6

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 14
1.2. Product Naming Clarification
The product names for Kontron COM Express® Computer-on-Modules consist of a short form of the industry
standard (COMe-), the form factor (b=basic, c=compact, m=mini), the capital letters for the CPU and Chipset
Codenames (XX) and the pin-out type (#) followed by the CPU Name.
COM Express® defines a Computer-On-Module, or COM, with all components necessary for a bootable host computer,
packaged as a super component.
COMe-bXX# modules are Kontron's COM Express® modules in basic form factor (125 mm x 95 mm)
COMe-cXX# modules are Kontron's COM Express® modules in compact form factor (95 mm x 95 mm)
COMe-eXX# modules are Kontron's COM Express® modules in extended form factor (155 mm x 110 mm)
The COMe Eval Carrier2 T6 fits all three types of modules.
1.3. Understanding COM Express® Functionality
All Kontron COM Express® extended, basic and compact modules contain two 220pin connectors; each of it has two
rows called Row A & B on primary connector and Row C & D on secondary connector. The COM Express® Computer-
On-Module (COM) features the following maximum amount of interfaces according to the PCI Industrial Computer
Manufacturers Group (PICMG) module Pin-out type.
Table 1: Features
Feature COMe Eval Carrier2 T6
Serial ATA 4x
PCI Express x16 1x
PCI Express x1 8x
USB 3.1 4x
GPIO 10x
FAN PWM out 1x
Ethernet 1x

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 15
1.4. COM Express® Documentation
The COM Express® Specification defines the COM Express® module form factor, pin-out, and signals. This document is
available at the PICMG® website by filling out the order form.
1.5. COM Express® Benefits
COM Express® modules are compact and highly integrated computers. All modules feature a standardized form
factor and connector layout which carry a specified set of signals. Each COM is based on the COM Express®
specification. This standardization allows designers to create a single-system baseboard that can accept present and
future COM Express® modules.
The baseboard designer can optimize exactly how each of these functions implements physically. Designers can
place connectors precisely where needed for the application on a baseboard designed to optimally fit a system’s
packaging.
A single baseboard design can use a range of COM Express® modules with different sizes and pin-outs. This flexibility
can differentiate products at various price/performance points. The modularity of a COM Express® solution also
ensures against obsolescence when computer technology evolves. A properly designed COM Express® baseboard can
work with several successive generations of COM Express® modules.
A COM Express® baseboard design has many advantages of a customized computer-board design and, additionally,
delivers better obsolescence protection, heavily reduced engineering effort, and faster time to market.

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 16
2/ System specifications
2.1. Component Main Data
The table below summarizes the features of the motherboard.
Table 2: Component Main Data
COMe Eval Carrier2 T6
Form factor Testing Hardware with 244.0 mm x 305.0 mm (ATX)
Memory
EEPROM System
(U13)
JILI EEPROM
External I/O
LAN 1x Gbit-Ethernet port
USB 4x USB 3.1 + 4x USB 2.0 double stack
Internal I/O
SATA 4x Gen3 slots
Feature Connector 1x connector with 2x12 pins
PCIe 1x x16, 8x x1
LEDs SMD LEDs e.g. for
VCC/Type/Ethernet/HDD/USB_OC/CPLD0,1/THRMTRIP/SUS_STAT,S3,S4,S5
GPIO GPIO Header with 10 pins
I2C Feature Connector (J57)
Battery CR2032 battery holder
Fan 4-pin fan connector, Voltage can be 5
V or 12 V (default 4-pole)
Carrier Board Power
Power input Carrier is powered from standard ATX power supply with ATX 24-pin and8-pin connectors.
Single Supply
Support
carrier requires ATX power
S-States S3, S4, S5
S5 Eco Mode yes
Kontron Features
M.A.R.S. support no
Watchdog support Triple Staged
Miscellaneous
Miscellaneous 2x UART, 7-Segment Postcode Display
Graphics
DisplayPort DP 3x DP
VGA 1x VGA
LVDS 1x LVDS, 1x eDP
Danger of explosion if the lithium battery is incorrectly replaced.
•Replace only with the same or equivalent type recommended by the manufacturer
•Dispose of used batteries according to the manufacturer’s instructions

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 17
2.2. Block diagram
Figure 2: Block Diagram COMe-Type6 Eval Carrier

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 18
2.3. Product Variants
Table 3: Product Variants
Product Number Description
38116-0000-00-5 COMe height: 5mm
2.4. Environmental Conditions
Table 4: Environmental Conditions
Operating -40°C to +85°C
Some connectors and Codecs has operating temperature only 0°C to +70°C, relative
humidity (non-condensing) 10 % to 93 % at 40°C
Storage -40°C to +85°C
relative humidity (non-condensing) 10 % to 93 % at 40°C
Waste Electrical
and Electronic
Equipment (WEEE)
Components and materials of the product must not contain lead, mercury, cadmium,
hexavalent, chromium, polybrominated biphenyls (PBB) or polybrominated diphenyl ethers
(PBDE). (Directive 2002/95/EC)
RoHS II Compliance The product will comply with the European Council Directive on the approximation of the
laws of the member states relating to Directive 2011/65/EU or the last status thereof.
Theoretical MTBF not applicable
Compliance
CE marked according to low voltage directive 2006/95/EC EN60950
Customer specific requirements based on EN 62368-1:2014 (Second Edition)
EMC according to IEC 61000-6-2:2005 (Second Edition) and IEC 61000-6-3:2006
(Second Edition) + A1:2010 in reference system
Reach compliance

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 19
3/ Mainboard Views
3.1. Top View
Figure 3: Top View of COMe Eval Carrier2 T6
1. 4x PCI x1 (J85/J86/J87/J88)
2. Power Connector (J99)
3. eDP (J14)
4. ATX Power Connector (J5)
5. LVDS (J2)
6. Button Switches
7. 4x PCI x1 (J81/J82/J83/J84))
8. POST Code Display
9. PCIe x16
10. 4x SATA
11. 2x COMe (J61)
12. HDA (J48)
13. GPIO (J49)
14. SPI (J45)
15. Fan (J93)
16. CPLD/JTAG (J15)
17. CPLD/UART (J62)
18. Jumper
19. Battery (J20)
20. COM Port (J1)
21. VGA (J17)
22. LPC/eSPI (J29)
10
9
8
7
6
4
2
1
19
18
17
13
12
15
16
20
11
5
3
14
21
22

COMe Eval Carrier2 T6 (ADT6) User Guide Rev 1.2
www.kontron.com // 20
3.2. Front panel
Figure 4: Front Panel
23. 5x Audio Connectors (J78)
24. 2x DP (J32)
25. 1x DP (J39)
26. 2x USB (J63)
27. 4x USB 3.0
28. 1x GE Connector (J33)
29. 2x USB
24
23
28
25
29
27
26
