Sanken SAMCO-NS Series User manual

Compact Vector Control Inverter
VVVF Inverter
SAMCO-NS series
Instruction Manual ( Simple Version )
SANKEN ELECTRIC. CO., LTD.

Checking the product and precautions on use
Checking the product
■ Product body：
NS Vector Control Inverter Body (For example: NS-4A017-B):
-1-
LCD Display
Warning Notification
Plastic outlook frame
Terminal block
Rating nameplate
Radiator structure
Grounding terminal

The contents of the model
Rating nameplate
-2-
Series Name
Voltage Class
3Ø-400V
Rated Current
A017: 17A
Capacity: 7.5KW
Load Mode
B: 120% 1 Min.
Internal Code

Draft for the connection with peripheral device
-3-
Power Supply
Input power supply transformer
Wiring circuit breaker
Or
Leakage circuit breaker
Electromagnetic contactor
AC reactor
Zero-phase reactor
Radio noise filter
/noise filter
DC reactor
Zero-phase reactor
Connection with peripheral device

■Installation in the side of left / right ：
Pls. assure the space is above 5cm, whatever is between the inside of cabinet and the
outlook frame of Inverter, or between Inverter’s outlook frame while installed in the side of left/right
Or could be caused of not enough of heat dissipation for Inverter.
-4-

■Installation more layers in the side of up /down：
Pls. assure the distance is above 20cm, whatever is between the inside of cabinent and the outlook frame of Inverter,
or between the Inverter’s outlook frame, and ensure the ventilation and cooling for each Inverter, or will be caused of
being not enough of heat dissipation.
-5-
Cooling Air Cooling Air

■Installment site for ventilation fan in the cabinent:
■ Notification:
◆ When several inverters are set in a control cabinet, be sure to local the ventiliation fans properly
to allow free aire circulation.
◆ Ensure the air in the outside of cabinent flow to the Inverter’s heat dissipation route, take those heat from the
Inverter in operation away in efficient.
◆ If the ventiliation fans are located properly, the ambient termperature will rise and affect the cooling of the Inverter.
(Correct) (Incorrect)
-6-
Cooling Air Cooling Air
Ventilation Fan
V
entilation Fan

Removal and Installation of the front cover
（1）Removal of front cover (Lower)
Unscrew the M4 screws, dismantle as the below Pic.
◆ Pls. carry out this work during the main circuit wiring、control circuit wiring.
-7-

（2）Changed fan
Carry out this work only under changing fan.
（3）Installation
On installation, carrry out this work as the reverse procedures.
-8-

电位器
>5kΩ
JP2
CL E A R
ENT E R
for 10
open
after
while
CL E A R
ENT E R
取付
け
、運転
の
前
に
必
ず
取扱説明書
を
読
み
、
そ
の指示に従うこ と。
通電中及
び
電源遮断後
10
分以内
はカバーを
開
け
ないこと。
for 10
open
after
while
CL E A R
ENT E R
取付
け
、運転
の
前
に
必
ず
取扱説明書
を
読
み
、
そ
の指示に従うこ と。
通電中及
び
電源遮断後
10
分以内
はカバーを
開
け
ないこと。
for 10
open
after
while
Terminal Connection Draft
TerminalinMaincircuit
Input terminal
Output terminal
Communicationterminal
Isolationcable
DCreactor (optional selection)
Brake Unit
（Optional）
Braking Resistor(Optional Selection)
P1 P PR X
Input Power
3Ø 380~460V
50/60Hz
M CC B
MC
R
S
T
Main Circuit
U
V
W
IM 3 phase inductive motor
User load
Load Current<150mA
24V
DCM
Digital Power 24V FA
FB
FC
Relay contact output
Contact capacity：250V,0.3A
Factory preset：Breakdow display
Code No.：F1513
FR
RR
2DF
3DF
MBS
DI1
DI2
DI3
DI4
DI5
DCM
Control Circuit
DO1
DOE
Vout V
Iout
Open collector output
Allowed loading：48V,50mA
Factory preset：Display in operation
Code No.：F1509
0 ~ 10V Voltage output
4 ~ 20mA Current output
Digital signal on ground
Frequency setting power 12V
ACM
Analog signal
5V
Only for potentiometer V+
0~5V,0~10Vvoltage
0.3W
0~10Vvoltage or 4~20mAcurrent
VRF
V/ I
ACM
F1002=9 Current Mode
Analog signal on ground
Terminalresistor
5G
TRA
TRB
SG
ON
OFF
TerminalResistor
Switching
RS485 communication port
Outlookdimensions
Mode No. Outlook Frame Dimension
H H1 W W1 D d t
NS-4A003-B
Ød
Ea s y k W ° C Mp a % r p m sk V A H z
NS-4A004-B
DR I V E
ST O P
PR O G
WARNING
■ Riskofelectricshock.
●Readthemanualbeforeinstallationandoperation.
●Do not
minu tes
this co er
isolating po wer.
isappliedor
●Ensure properearthconnection.
H1H
130 121 115 106 166 4.5 5
危险
NS-4A006-B
■有可能引起受伤，触电。
●安装运行前请务必阅读操 作说明 书并遵 照其指 示。
●通电时及切断电源 10 分钟内 请不要 打开前 面盖板 。
●请正确接地。
W1
W
t
D
Ød
NS-4A009-B
Ea s y k W ° C Mp a % r p m sk V A H z
DR I V E ST O P
PR O G
NS-4A013-B
WARNING
■ Riskofelectricshock.
●Readthemanual bef o r ei n s t all at i o n and operation.
●Do not
minu tes
this co er
isolating po wer.
isappliedor
●Ensure properearthconnection.
危険
■けが、感電のおそれあ り。
●
●
●確実に接地を行うこと。
H1H
225 214 140 129 150 5.5 6
危险
■有可能引起受伤，触电。
●安装运行前请务必阅读操 作说明 书并遵 照其指 示。
●通电时及切断电源 1 0 分钟内请不 要打开 前面盖 板。
●请正确接地。
NS-4A017-B
W1
W
t
D
Ød
NS-4A024-B
Ea s y k W ° C Mp a % r p m sk V A H z
DR I V E ST O P
PR O G
NS-4A032-B
WARNING
■ Riskofelectricshock.
●Readthemanualbeforeinstallationandoperation.
●Do not
minu tes
this co er
isolating po wer.
isappliedor
●Ensure properearthconnection.
危険
■けが、感電のおそれあ り。
●
●
●確実に接地を行うこと。
危险
■有可能引起受伤，触电。
●安装运行前请务必阅读操 作说明 书并遵 照其指 示。
●通电时及切断电源 1 0 分钟内请不 要打开 前面盖 板。
●请正确接地。
H1H
300 285 200 185 175 6.5 6
NS-4A038-B
-9-
Multi
-
functions terminal
Frequency setting terminal
Relay
-
9
-

Description of Main Circuit Terminals
*1
When connecting the reactor, pls. remove the jumper
P1 and P
Composition of Main Circuit Terminals
-1 -
Terminal Symbol Name Description
R,S,T Input Power Terminals Terminals connected to 3 phase commercial power supply
U,V,W Inverter output terminals Terminals connected to 3 phase induction motor
P,P1 DC reactor connection
Terminals
Terminals connected to DC reactor *1
P,PR Brak Resistor connection
termials Terminals connected to brake resistor between P-PR
P,X DC side voltage terminals
Terminals connected to brake unit
P is DC positive，X is DC negatitive
Ground Terminal Terminal for grounding of inverter casing

Distribution Terminal For Main Circuit
1．NS-4A003-B、NS-4A004-B、NS-4A006-B
-11-

2．NS-4A009-B、NS-4A013-B、NS-4A017-B
-12-

3．NS-4A024-B、NS-4A032-B、NS-4A038-B
-13-

Main circuit terminal connection draft
◎Capacities of MCCB and MC and wire size
-14-
Model No.
MCCB
(Leakage circuit brakerer)
[A]
MC（Electromagnetic contactor）
Rated Current
[A]
Rated making current
[A]
NS-4A003-B 5 7 20
NS-4A004-B 5 7 20
NS-4A006-B 15 7 20
NS-4A009-B 20 7 20
NS-4A013-B 30 7 20
NS-4A017-B 30 17 32
NS-4A024-B 50 25 50
NS-4A032-B 60 25 50
NS-4A038-B 70 32 60
Shorten Plate
DC
Reactor
Optional Accessory
Braking Resistor
Power Supply
Motor

Recommend Wire Size
Note 1: The value for wires in the main circuit are for
600V
IV
PVC
-
insulated wires (
60 ) When the℃
inverter ambient temperature is 40℃
The value in（ ）are for 600V bridged-polyethylened insulated wires（90℃）
Note 2: The maximum wire size indicates the maximum wire cross-sectional are that can be used with
the terminal block
-15-
Main Circuit
2
Recommended wire size[mm ] Screw
diameter
Tightening
Torque
N·m
Max.
Wire size
2
mm
Input Wire R、S、T P、P1
PR、X U、V、W
Grounding wire
NS-4A003-B 2.0 (2.0) 2.0 (2.0) 2.0 (2.0) 5.5
M4 1.2 5.5
NS-4A004-B
2.0 (2.0) 2.0 (2.0) 2.0 (2.0) 5.5
NS-4A006-B
2.0 (2.0) 2.0 (2.0) 2.0 (2.0) 5.5
NS-4A009-B
2.0 (2.0) 2.0 (2.0) 2.0 (2.0) 5.5
NS-4A013-B
3.5 (2.0) 3.5 (2.0) 2.0 (2.0) 5.5
NS-4A017-B
5.5 (2.0) 5.5 (2.0) 3.5 (2.0) 5.5
NS-4A024-B
5.5 (2.0) 5.5 (2.0) 5.5 (2.0) 5.5
M5 2.0 14
NS-4A032-B
8.0 (3.5) 8.0 (3.5) 8.0 (3.5) 14
NS-4A038-B
14 (5.5) 14 (5.5) 8.0 (3.5) 14

※
1
The above brake resistor is selected by the max. use rate
10%ED.
-16-
Model No. External brake resistor(Recommend）
External brake resistor (limit value)
Resistor value Capacity ※1 Resistor value Capacity ※1
NS-4A003-B 700Ω or above 100W 420Ω or above 300W
NS-4A004-B 700Ω or above 100W 420Ω or above 300W
NS-4A006-B 320Ω or above 200W 190Ω or above 300W
NS-4A009-B 160Ω or above 400W 130Ω or above 500W
NS-4A013-B 120Ω or above 600W 80Ω or above 800W
NS-4A017-B 80Ω or above 800W 52Ω or above 1100W
NS-4A024-B 60Ω or above 1000W 38Ω or above 1500W
NS-4A032-B 40Ω or above 1500W 32Ω or above 1800W
NS-4A038-B 40Ω or above 1500W 32Ω or above 1800W

Recommend wire size
：
0.75[
mm
2
]
Composition of Control Circuit Terminals
Wire size
Terminal screw diameter：M3
Tightening torque：0.5[N•m]
The arrangement of control circuit terminals is as shown in the following
■ Most Attention：
▲ Don’t input stronger voltage to the control terminal! Or control board burnt
▲ Pls. move the control calbe far away to power cable in avoid of intevenue or noise.
-17-

Function of control circuit terminals
-18-
Type Terminal
Symbol
Terminal Name Function Description Rated Specification
Multi function input
DCM
Digital signal common
terminals
Common terminals for digital i
nput and
output signals and 24V
power supply
Total current consumed:
100mA or less
DI1
～
DI5
Multi-Functional input
terminals
Signals valid while the short
-circuited between DIX and
DCM
Input resistor：about 6.6kΩ
When short-circuited：about 3～
5mA
Analog value input
ACM
Analog signal common
terminals
Common terminals for analog
Input and output Total current consumed:100mA or less
+V Frequency setting power
supply Connected to a potentiometer
of 5kΩ，0.3W or above
DC 10～12V
※it can not be connnected to any
Element other than the potentiometer
VRF
Analog voltage input
terminal
Setting frequency through input
voltage
Input resistor：about 34kΩ
Max. alllowed voltage：DC12V
V/I
Analog voltage or input
Current terminal
This way of current/voltage
switching independely
Voltage input is the same spec. as
VRF current input resisto: about
250Ω, Max.allowed current:30mA
Power
Supply
24V 24V client’s power supply DC24V
Power supply for customer
Max. allowable output current
for DC 24V 150mA
Multifunctional output
DO1
DOE
Multifunctional collector
output terminals
Sending signals for func
tion through
selected fuction code.
Open collector output
Allowable loading: DC48V
、50mA
Analog value output
Vout
0～10V voltage output
terminal
voltage output for setting
internal signal 0～10V
Iout 4～20mA current output
terminal Current output for setting
Internal signal 4～20mA
Communication terminals
TRA RS485 communication sending/receiving (+) RS485“+” signal
Communication speed:1200-57600bps
Total Length：500m
TRB RS485 communication sending/receiving (-) RS485“-” signal
SG
RS485 common
communication terminals
SG terminal for connected
communicated equipment while
RS485 on communication
※
selected on site for Inverter side
Communication equipment side
Single-end earthed
JP2 Terminal resistor switching
selected
The selection of
whethe connected
100Ωterminal resistor
OFF Resistor Open
ON Resistor Connection
Contact output
FA
FB
FC
Abnormal alarm signal
Output and multifunctional
Contact output
The default of that terminal is
Inverter warning and stop contact
output signal, which is selected the
others function through setting
function code of F1513、F1504
Contact capacity: AC250V/0.3A
The selection of warning contact
Normal：FA-FC opened
Abnormal：FA-FC closed

LCD Operation Panel
Name and Function for each part of panel
Description：
Primary Screen 5 digit 7 segment LCD : Shown the following data through changing Left/Right direction key or
parameters setting, “Current operation frequency、Output current、RPM、Load factor、Output voltage、Voltage value、
Set value and warning content”.
Secondary Screen 5 digit 7 segment LCD: Shown the data of “Current output voltage、DC Voltage、Active power、Apparent
power、Radiator temperature and the others content” by setting parameters.
“Units” is only for primary screen, mainly display “Frequency(Hz)、Output current(A)、Speed roation(Rpm)、Load factor(%)、
Output voltage(V)、Pressure value(MPa)”.
-19-
Status Display Inverter status during operation /stop
<Frequency> <Output Current> <Roatation Speed> <load factor>
<Output Voltage> <Pressure Value>
Seconda r y scree n
Primary screen
Inverter Condition
Information
Units
Direction Key
