SANSTAND SANTOP User manual

PACK CONTENTS
1 x pre-assembled counter unit
1 x dispenser with key to open lid
1 x 500ml sanitiser
4 x AA batteries
4 x rubber feet
Counter Top Units
ASSEMBLY INSTRUCTIONS:
1. Take the 4 rubber feet supplied
and ax one to each corner
2. Insert 4 x AA batteries into
battery compartment on
bottom of dispenser.
3. Take dispenser, remove lid using
white key, remove lid, ll with
sanitiser GEL and attach
to bracket on the stand.
4. Please follow detailed instructions
for the dispenser overleaf.
To order more SanStand products or if you have
any questions, please contact us today:
www.sanstand.co.uk
[email protected]o.uk
0845 519 5442

INSTRUCTIONS
SPECIFICATION
MODEL AUTDISP
OUTER SIZE L110*W100*H165MM
CAPACITY 700ml
DROP VOLUME 0.8-1ml
WEIGHT 480g
MATERIAL ABS, AS
BATTERY 5X1.5V “AA”
TECHNICAL PARAMETERS
ELECTRICAL SOURCE VOLTAGE DC6V
STATIC CURRENT 60UA
WORKING CURRENT 200MA
POWER 4W
EFFECT DISTANCE 0-10CM
Cover Key
Container
LED lamp
Infrared sensor
window
Battery compartment
Pump
Power
on/o
SETUP
FEATURES
The sensor is at the base of the dispenser with eect
range of 0-10cm underneath the sensor.
Continually ashing LED light in standby mode
indicates battery replacment is necessary.
This product is not fully waterproof and should not
be placed in a continually damp environment.
The dispenser works both inside and outside
but should be kept out of direct sunlight as this
can aect the both the sanitiser gel and also the
function of the sensor.
INSTALLATION AND USE
1. Slide the dispenser into the mounting plate (gure 1).
2. Insert batteries into battery compartment with
polarity as indicated (alkaline batteries are
recommended).
3. Open the cover and pour the liquid into the
container (gure 2).
4. Put your hand 0-10cm under the sensor and allow
the dispenser to operate until the sanitiser gel
runs from the nozzle (gure 3). When using the
dispenser for the rst time you may need to
activate the dispenser upto 15 times to enable
the sanitiser gel to work through the pump
before it will dispense.
5. Power On/O button
First press will turn on giving a standard
dispense and LED light ashes once.
Second press will increase to a double
dispense and LED light ashes twice
Third press will turn the dispenser o
and LED light glows for one second
The two dierent settings can be used to give
the right amount of sanitiser gel, ensuring when
itis thicker incolder conditions an eective
doseisdelivered everytime.
IF THE DISPENSER DOESN’T TURN ON
1. Check the batteries are inserted with polarity as
indicated in the battery compartment.
2. Check that the power is on.
IF THE DISPENSER DOESN’T DISPENSE
1. The dispenser needs to be used several times upon
rst use.
2. The sanitiser gel may congeal in cold temperatures.
Use warm water (aproximately 60°c) to disperse the
congealed sanitiser gel.
3. Check that there is gel in the dispenser.
Figure 1 Figure 2 Figure 3
Automatic Soap Dispenser: User manual
