Sanus CFR1615 User manual

Customer Service
Americas: 800-359-5520 • 952-225-6013 • [e-mail]
Europe, Middle East, and Africa: [phone] • [e-mail]
Asia Pacic: 86 755 8996 9226 • [e-mail]
SANUS • 6436 City West Parkway • Eden Prairie, MN 55344 USA
©2013 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Sanus is a division of Milestone.
All other brand names or marks are used for identication purposes and are trademarks of their respective owners.
sanus.com
We are here to help!
Please contact Customer Service with any questions.
CFR1615/ CFR1620
Instruction Manual

2
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
Specifications
Weight capacity free standing or stacked-DO NOT EXCEED: 272 kg (600 lb.) includes any components or accessories
Weight capacity wall mounted-DO NOT EXCEED: 90.7 kg (200 lb.) includes any components or accessories
Do not stack more than 2 rack assemblies
The CFR16 series is designed to support audio/video equipment.
CAUTION: If free standing, to prevent tipping, always load the rack from the bottom up, and load the heaviest item in the rack rst.
If free standing, 50% of the total weight should be mounted in the lower 1/3 of the rack.
If wall mounted, weight can be distributed as required.
CAUTION: Avoid potential personal injuries and property damage!
Do not use this product for any purpose not explicitly specied by manufacturer
The wall must be capable of supporting ve times the weight of the rack and components or accessories combined
If you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this product,
contact Customer Service or call a qualied contractor
Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
English
Required Tools
13mm
(1/2 in.)
5.5mm
(7/32 in.)
10mm
(3/8 in.)

3
Technical Specifications CFR1615
15.12 in.
384.05 mm
18.0 in.
457.25 mm
28.58 in.
725.98 mm
20.24 in.
514.06 mm
20.4 in.
518.41 mm
26.26 in.
667.03 mm
3.49 in.
88.85 mm
19.0 in.
482.60 mm
1.75 in.
44.40 mm

4
Technical Specifications CFR1620
15.12 in.
384.05 mm
18.0 in.
457.25 mm
35.00 in.
889.0 mm
20.24 in.
514.06 mm
20.4 in.
518.41 mm
37.33 in.
948.2 mm
3.49 in.
88.85 mm
19.0 in.
482.60 mm
1.75 in.
44.40 mm

5
[01] x 1 [02] x 1
[03] x 2
[04] x 2
[05] x 1
[06] x 1
Supplied Parts
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your
dealer; contact Customer Service. Never use damaged parts!

6
Supplied Parts
5/16 x 3½ in.
1/4-20 x 3/8 in.
1/4-20
[07] x 4
[08] x 12 [09] x 25 [10] x 4
[11] x 2 [12] x 2
[13] x 4
[14] x 4
[15] x 4
[16] x 2

7
Frame Construction
1
4
2
3
Fit brace [03] over left frame [01]
horizontal screw stud.
Secure brace [03] with nuts [08].
Slide brace [03] back over vertical
screw studs.
Attach right frame [02] to lower brace [03]
with nuts [08].
[01]
[08]
[03]
[01]
[01]
[01]
[02]
[03]
[03]
[03]
[08]
13mm
(1/2 in.)
13mm
(1/2 in.)

8
Frame Construction
5 7
6
Repeat steps 1and 2with upper
brace [03].
Attach alignment panels [04] with
screws [09].
Secure upper brace [03] with nuts
[08].
[03]
[01]
[01]
[02]
[02]
[03]
[04]
[04]
[08]
[09]
[09]
13mm
(1/2 in.)

9
Install Feet (optional) for use on floor
1
4
2
3Tighten nuts (N) until they are ush with the
bottom of the rack.
CAUTION: To avoid potential injury or
property damage, always ensure that your rack is
level.
Adjust the feet [07] to level the rack.
Install feet [07].
Lay assembled frame on its back.
[07]
[07]
(N)

10
Install Casters (optional CA6CK caster kit purchased separately)
1
2Install casters (purchased separately). Make sure
casters are screwed in until the nuts at the top of
the casters are ush against the frame.
Lay assembled frame on its back.

11
Stacking (second rack sold separately)
12
Fit second frame (without feet) onto
rst frame. Secure frames with stacking screws
[10].
[10]

12
Single Wall Mounting (wood stud)
1 2
Locate studs. Verify the center of the stud with an
awl or thin nail or use an edge to edge stud nder.
CAUTION: Avoid potential personal injuries
and property damage!
Any material covering the wall must not
exceed 16 mm (5/8 in.).
Minimum wood stud size: common 2 x 4 in
(nominal 1½ x 3½ in).
Level frame assembly and mark hole locations.
41 cm
(16 in.)

13
3 4
Drill pilot holes as illustrated.
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage: pilot holes MUST
be drilled to a depth of 89 mm (3½ in.), using a
5.5 mm (7/32 in.) diameter drill bit.
89 mm
(3½in.)
Start upper lag bolts [14], hang frame assembly
on bolts [14], then slip "U" washers [11] onto
the upper bolts [14]. Lower bolts [14] use round
washers [12].
Tighten lag bolts [14] only until the washers [11]
and [12] are pulled rmly against the brace [03].
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage DO NOT over-
tighten the lag bolts [14].
[14]
[14]
[11]
[03]
[03]
[12]
5.5 mm
(7/32 in.)
13mm
(1/2 in.)

14
Single Wall Mounting (solid concrete and concrete block)
1 2
Level frame assembly and mark hole locations. Drill pilot holes as illustrated.
CAUTION: To avoid potential injuries or
property damage:
Pilot holes MUST be drilled to adepth of 89 mm
(3½ in.) using a 10 mm (3/8 in.) diameter drill bit.
Never drill into the mortar between blocks.
Minimum solid concrete thickness: 8 in.
Minimum concrete block size: 8 x 8 x 16 in.
10 mm
(3/8 in.)
89 mm
(3½in.)

15
Insert lag bolt anchors [13].
CAUTION: To avoid potential injuries or
property damage be sure the anchors [13] seat
ush with the concrete surface.
34Start upper lag bolts [14], hang frame assembly
on bolts [14], then slip "U" washers [11] onto
the upper bolts [14]. Lower bolts [14] use round
washers [12].
Tighten lag bolts [14] only until the washers [12]
and [12] are pulled rmly against the brace [03].
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage DO NOT over-
tighten the lag bolts [14].
[14]
[14]
[11]
[03]
[03]
[12]
[13]
13mm
(1/2 in.)

16
Wall Mounting - Stacking (wood stud)
1Fit second frame onto rst frame.
Secure frames with stacking screws
[10].2Locate studs. Verify the center of the stud with an
awl or thin nail or use an edge to edge stud nder.
CAUTION: Avoid potential personal injuries
and property damage!
Any material covering the wall must not
exceed 16 mm (5/8 in.).
Minimum wood stud size: common 2 x 4 in
(nominal 1 ½ x 3 ½ in).
[10]
41 cm
(16 in.)

17
3Level frame assembly and mark top hole locations. 4
5
Drill pilot holes as illustrated.
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage: pilot holes MUST
be drilled to a depth of 89 mm (3.5 in.), using a
5.5 mm (7/32 in.) diameter drill bit.
Start top lag bolts [14]. Leave
approximately 13 mm (1/2 in.) of
space from the bolt head to the wall.
13 mm
(1/2 in.)
[14]
5.5 mm
(7/32 in.)
13mm
(1/2 in.)

18
67
Hang frame assembly on bolts [14].Slip "U" washers [11] onto the bolts [14].
Tighten lag bolts [14] only until the washers [11]
are pulled rmly against the brace [03].
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage DO NOT over-
tighten the lag bolts [14].
[14]
[14] [11]
[14]
13mm
(1/2 in.)

19
8Drill remaining pilot holes as illustrated.
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage: pilot holes MUST
be drilled to a depth of 89 mm (3.5 in.), using a
5.5 mm (7/32 in.) diameter drill bit.
9Tighten lag bolts [14] only until the washers [11]
and [12] are pulled rmly against the brace [03].
CAUTION: Improper use could reduce the
holding power of the lag bolt. To avoid potential
injuries or property damage DO NOT over-
tighten the lag bolts [14].
89 mm
(3.5 in.)
[14]
[14]
[14] [11]
[12]
[12]
5.5 mm
(7/32 in.)
13mm
(1/2 in.)

20
Wall Mounting - Stacking (solid concrete or concrete block)
12Level frame assembly and mark hole locations.
Fit second frame onto rst frame.
Secure frames with stacking screws
[10].
[10]
